ACCESSORY SOCKET

CHASSIS ELECTRICAL

54A-219

INSPECTION

ACCESSORY SOCKET RELAY CHECK

M1542300300098

AC510090

AI

4

1

2

3

Junction
block

<LHD>

Accessory
socket relay

4

2

3

1

AC510088

AF

4

1

2

3

Junction
block

<RHD>

Accessory
socket relay

4

1

3

2

Battery voltage

Tester
connection

Specified
condition

Not supplied

3

− 4

Open
circuit

• Connect terminal 2

to the positive
battery terminal

• Connect terminal 1

to the negative
battery terminal

3

− 4

Continuity
(2

Ω or

less)

CIGARETTE LIGHTER

CHASSIS ELECTRICAL

54A-220

CIGARETTE LIGHTER

INSPECTION

CIGARETTE LIGHTER CHECK

M1542200300068

1. Remove the plug and check the spot for wear.
2. Check that there are no tobacco stains or foreign

particles on the element.

3.

Using an ohmmeter, check that the element resist-

ance value is 1.7

Ω

AC102585AB

Element

Spot

COLUMN SWITCH

CHASSIS ELECTRICAL

54A-221

COLUMN SWITCH

SPECIAL TOOLS

M1543100200045

COLUMN SWITCH

CHASSIS ELECTRICAL

54A-222

Tool

Number

Name

Use

MB990784

Ornament
remover

Removal of column cover

MB990784
