TROUBLESHOOTING SUPPLEMENTAL RESTRAINT SYSTEM (SRS) 52B-27 STEP 3. Resistance measurement between the AC501670 AB C-131 (Y) Connector: C-131 Harness side (2) Disconnect SRS-ECU connector C-131. AC903858AD Connector: C-305 <LHD> Harness side C-305 (Y) AC903869AD Connector: C-305 <RHD> Harness side C-305 (Y) C-305 DANGER To prevents the air bag from deploying unin- (3) Disconnect the clock spring connector C-305. AC100391 Section C-131 Harness side connectors Cable tie Short spring 4 mm or more Terminal A BE A CAUTION Insert an insulator such as a cable tie to a depth between terminals 11, 12 and the short spring to AC501384 AC501384 C-131 C-305 AB CAUTION Do not insert a test probe into the terminal from terminals. • SRS-ECU connector C-131 terminal No.11 and the clock spring connector C-305 terminal • SRS-ECU connector C-131 terminal No.12 and the clock spring connector C-305 terminal OK: Continuity (Less than 2 Ω) Q: Are the check results normal? YES : Go to Step 4. NO : Repair the harness wires between SRS- STEP 4. Check whether the diagnosis code is Q: Is diagnosis code B1401 set? |
