SPECIAL TOOL

INTERIOR

52A-2

SPECIAL TOOL

M1521000600479

Tool

Tool number

Name

Use

MB990784

MB990784

Ornament remover

Removal of switch, trim, etc.

INSTRUMENT PANEL ASSEMBLY

REMOVAL AND INSTALLATION

M1521001702691

WARNING

For removal and installation of the passenger's (front) air bag module, always observe the
service procedures described in GROUP 52B, Driver’s, Front Passenger’s Air Bag Module(s)
and Clock Spring (Refer to ).

The following bolts and screws are used for installing the instrument panel. Bolts and screws are indicated as
marks shown in the illustration in the sections of "Removal and Installation" and "Disassembly and Reassem-
bly."

Name

Symbol

Size (D

× L) mm

Colour

Shape

Tapping screw

a

4

× 12

−

AC104436

b

5

× 12

−

c

5

× 16

−

d

5

× 10

−

AC104450

e

5

× 12

−

f

5

× 16

−

g

Green

Machine flange screw

h

5

× 8

−

AC104322

Washer assembly screw i

4

× 12

−

AC104422

j

5

× 12

−

Washer assembly bolt

k

6

× 16

−

AC104417

INSTRUMENT PANEL ASSEMBLY

INTERIOR

52A-3

CAUTION

• Refer to GROUP 52B, Service Precautions (Refer to ) and Driver’s, Front Passenger’s Air bag Mod-

ule(s) and Clock Spring (Refer to ) before removing the passenger’s (front) air bag module.

•

Pre-removal and Post-installation Operation
• Removal and Installation of Front Pillar Trim (Refer to

P.52A-11

<Single Cab>,

P.52A-13

<Club Cab > or

P.52A-

15

<Double Cab>).

• Removal and Installation of Hood Lock Release Handle

(Refer to GROUP 42, Hood ).

• Removal and Installation of Fuel filler lid lock release han-

dle (Refer to GROUP 42, Fuel filler lid <Single Cab>,

<Club Cab > or <Double Cab>).

ACA00252

1

f

2

i

3

4

5

g

f

6

k

7

8

f

10

11

12

13

16

16

b

b

h

h

f

a

<GLS>

18

18

19

f

20

b

21

22

23

c

24

25

26

k

f

f

15

14

b

AB

17

<With lid-GLX,
without lid-GL>

9

8

<GLS,GLX>

<GL>

Do not subject the SRS-ECU to any shocks when removing or installing the instrument panel.

Removal steps

1.

Passenger’s side under cover
<Except vehicles Single cab>

2.

Glove box

3.

Glove box lock assembly

4.

Instrument panel side cover

•

Passenger’s (front) air bag module
(squib) connector

5.

Glove box cover

6.

Passenger’s (front) air bag module
assembly <GLS-Limited> (Refer to
GROUP 52B, Driver’s, Front
Passenger’s Air bag Module(s) and
Clock Spring ).

•

Cigarette lighter connector

•

Cigarette lighter illumination lamp
connector

7.

Lower panel assembly

8.

Centre lower panel assembly

9.

Down light garnish<GLS,GLX>

10 Spacer
11. Accessory box <Vehicles without

audio>

12. Centre upper box hood <GL, GLX>

or RV meter hood <GLS-Limited>
or MDS <GLS-Limited>

13. Centre upper panel assembly
14. Heater control panel assembly

(Refer to GROUP 55A, Heater
Control Assembly and A/C switch
<Single Cab>, <Club Cab , Double
Cab>).

15. Hazard warning lamp switch (Refer

to GROUP 54A, Hazard Warning
Lamp Switch ).

16. Centre air outlet
17 Passenger’s air bag cut off switch
18. Centre upper box <GL, GLX> or RV

meter <GLS-Limited> or MDS
<GLS-Limited (option)>

19. Driver’s side under cover <Except

vehicles Single cab>

21. Driver’s side under cover bracket

<Except vehicles Single cab>

22. Fuse lid
•

Key reminder switch connector

•

Column-ECU connector

•

Clock spring connector

•

Ignition switch connector

23. Steering column upper cover
23. Steering column lower cover
24. Meter bezel assembly
25. Combination meter assembly
•

Glove box lamp connector

•

Front pillar trim (Refer to

P.52A-

11

<Single Cab>,

P.52A-13

<Club

Cab > or

P.52A-15

<Double Cab>.

•

Steering column shaft (Refer to
GROUP 37, Steering Column Shaft
assembly ).

26. Instrument panel assembly

INSTRUMENT PANEL ASSEMBLY

INTERIOR

52A-4

Removal steps (Continued)

INSTRUMENT PANEL ASSEMBLY

INTERIOR

52A-5

CLIP AND CLAW POSITIONS

AC809365

Section C – C

Section D – D

Section F – F

Section G – G

Section J – J

Section L – L

Section A – A

Section B – B

Section E – E

Section H – H

Section I – I

Section M – M

Section N – N

Section O – O

Section P – P

Section Q – Q

Section R – R

AD

Clip

Claw

Claw

Clip

Clip

Clip

Claw

Claw

Clip

Claw

Clip

Clip

Claw

Claw

Section K – K

Claw

Claw

Clip

Clip

A A

B

B

C

C

E

D

D

F

G

G

G

G

H

H

I

I

K

J

J

L

L

M

M

N

N

O

P

P

Q

Q

R

R

Section S – S

Claw

S

S

NOTE
(1)         : Clip positions
(2)         : Claw positions

F

O

K

5

23

4

23

8

23

8

13

8

13

13

23

23

13

13

11

12

23

19

20

20

19

18

7

23

7

7

23

21

23

21

23

21

23

21

23

6

23

E

C

C

E

E

D

D

NOTE: Each number in the illustration indicates a
part number.
