REAR GATE

BODY

42-240

REAR GATE LATCH ASSEMBLY

REMOVAL AND INSTALLATION

M1425003400059

Post-installation Operation
• Rear Gate Fit Adjustment (Refer to

P.42-238

).

• Rear Gate Outside Handle Adjustment (Refer to

P.42-

238

).

AC805340

1

2

2

3

3

4

AB

<Vehicles with high-
mounted stop lamp>

<Vehicles without
high-mounted stop lamp>

AC502693

AC502694

AC502686

AC503697AB

2

3

2

Rear gate outside handle removal
steps

1. Rear gate cover
2. Rear gate outside handle

Rear gate latch removal steps

1. Rear gate cover
3. Rear gate latch
4. Rear gate handle controller

REAR BODY ROPE HOOK

BODY

42-241

REAR BODY ROPE HOOK

REMOVAL AND INSTALLATION

M1425004000087

AC509878

2

1

6

6

7

5

3

4

3

<Single cab>

AD

AC903759

2

1

6

6

7

5

3

4

3

AB

<Double cab>

Rear body rope hook removal
steps

1.

Rear body plug

2.

Rear body rope hook

>>A<<

3.

Rear body grommet A

>>A<<

4.

Rear body grommet B
Rear gate rope hook removal
steps

•

Rear gate cover (Refer to

P.42-

240

.)

5.

Rear gate rope hook

>>B<<

6.

Rear body grommet C

>>B<<

7.

Rear body grommet D

REAR BODY ROPE HOOK

BODY

42-242

INSTALLATION SERVICE POINTS

>>A<< REAR BODY GROMMET A AND B INSTAL-
LATION

AC509880AB

Rear body grommet A,B

a

CAUTION

Install the grommets at correct locations in order
not to damage them.

Standard value (a): 40 mm <Rear body grom-
met A>,

                                 33mm <Rear body grom-
met B>

>>B<< REAR BODY GROMMET C AND D
INSTALLATION

AC509879AB

Rear body grommet C, D

a

Mark

CAUTION

Install the grommets at correct locations in order
not to damage them.
Install the grommets so that the mating marks face
upward.

Standard value (a): 46.5 mm <Rear body
grommet C>,
                                 38.5mm <Rear body grom-
met D>

REAR SIDE PANEL

BODY

42-243

REAR SIDE PANEL

REMOVAL AND INSTALLATION

M1425003700094

AC503698

AC502700

AC502702

Section A – A

A

A

AD

Clip

<Club cab>

1

Note
         : Clip positions

1

AC503699

AC502702

AC502701

Note
         : Clip positions

Section A – A

A

A

AE

Clip

1

1

2

<4WD>

<2WD>

<Double cab>

Removal steps

1. Rear side panel
2. Rear wheelhouse stay
