REAR PANEL POWER WINDOW <Vehicles with rear panel power window>

BODY

42-56

REAR PANEL WINDOW REGULATOR

REMOVAL AND INSTALLATION

M1429005800099

Post-installation Operation
• Rear Panel Power Window Glass Adjustment (Refer to

P.42-53

).

• Rear Panel Power Window Initial Set (Refer to

P.42-55

).

AC502512

AC505125AB

2

3

4

5

6

8

8

9

9

10

11

7

7

5.0 ± 1.0 N·m

12

13

14

15

16

18

17

A

A

A

A

N

N

N

N

N

N

N

AC505196

AC502679

AC502500

Sealant: 3M ATD Part No. 8625 or equivalent

Sealant: 3M ATD Part No. 3509 or equivalent

2

AC

Section A – A

8

AC901903

1

5

AB

REAR PANEL POWER WINDOW <Vehicles with rear panel power window>

BODY

42-57

Rear panel power window switch
removal

1.

Rear panel power window switch
(Refer to GROUP 52A, Centre
lower panel assembly, Instrument
Panel Assembly .)
Rear panel power window
regulator assembly removal
steps

•

Cab rear end lower trim (Refer to
GROUP 52A, Interior Trim .)

>>

B

<<

2.

Waterproof film

<<

A

>>

3.

Rear window panel assembly

4.

Rear window panel

5.

Rear panel power window regulator

6.

Rear panel power window motor
Rear slide window glass and rear
side window glass removal
steps

•

Headlining (Refer to GROUP 52A,
Headlining .)

•

Cab rear end lower trim (Refer to
GROUP 52A, Interior Trim .)

>>

B

<<

2.

Waterproof film

7.

Rear window side moulding

8.

Rear side window glass assembly

9.

Rear body cushion

10. Cab rear window weatherstrip
11. Rear window moulding lower
12. Rear slide window sash side (RH

side)

13. Rear slide window glass

runchannel

14. Rear slide window glass
15. Rear slide window sash side (LH

side)

16. Rear slide window sash upper

>>

A

<<

17. Clip
18. Rear window moulding upper

Post-installation Operation
• Rear Panel Power Window Initial Set (Refer to

P.42-55

).

REAR PANEL POWER WINDOW <Vehicles with rear panel power window>

BODY

42-58

AC502521

19

5.0 ± 1.0 N·m

AB

Rear panel power window-ECU
removal steps

•

Rear pillar trim (Refer to GROUP
52A, Interior Trim .)

19. Rear panel power window-ECU

REAR PANEL POWER WINDOW <Vehicles with rear panel power window>

BODY

42-59

REMOVAL SERVICE POINT

<<A>> REAR WINDOW PANEL ASSEMBLY
REMOVAL
1. Activate the anti-trap function successively 3

times to deactivate the anti-trapping function.

AC502522AB

Rear slide window glass mounting bolts

2. Lower the rear slide window glass until the rear

slide window glass mounting bolts are seen.

3. Remove the rear slide window glass mounting

bolts.

CAUTION

If tinting film is adhered to the rear slide window
glass, attach the special tool, window glass
holder (MB990480) to the outside of the glass to
prevent the film from peeling off.

AC502524AB

MB990480

4. Lift the rear slide window glass, and attach the

special tool, window glass holder (MB990480) to
the glass as shown to prevent the glass from
falling.

5. Remove the rear window panel assembly.

INSTALLATION SERVICE POINTS

>>A<< CLIP INSTALLATION
Since the clip is damaged when the rear slide win-
dow sash upper is removed, replace the clip
(6137A009) and install it to the body.

>>B<< WATERPROOF FILM INSTALLATION
