Interior Features

Interior Equipment

Assist Grips

Rear Coat Hooks

▼ Assist Grips

▼ Rear Coat Hooks

WARNING

Never hang heavy or sharp objects on

the assist grips and coat hooks:

Hanging heavy or sharp-ended objects

such as a coat hanger from the assist

grips or coat hooks is dangerous as

they can fly off and hit an occupant in

the cabin if a curtain air bag was to

deploy, which could result in serious

injury or death.

Always hang clothes on the coat hooks

Do not use the assist grips when

and the assist grips without hangers.

getting in and out of the vehicle or

getting out of a seat:

An assist grip could break under a

heavy load resulting in injury.

Use the assist grips to support your

body while seated in the vehicle and

while the vehicle is moving.

5-45

Interior Features

Interior Equipment

▼ Overhead Console*

Storage Compartments

This console box is designed to store

▼ Storage Compartments

eyeglasses or other accessories.

Push and release to open.

WARNING

Keep storage boxes closed when

driving:

Driving with the storage boxes open is

dangerous. To reduce the possibility of

injury in an accident or a sudden stop,

keep the storage boxes closed when

driving.

▼ Storage Pocket

When loading cargo, make sure that it

is completely secured:

To use, open the lid.

If the cargo is not completely secured,

it may move or collapse while driving

or during sudden braking, resulting in

injury or an accident.

Do not put articles in storage spaces

with no lid:

Putting articles in storage spaces with

no lid is dangerous as they could be

thrown around the cabin during

sudden braking, maneuvering, or

▼ Glove Compartment

acceleration and cause an accident

depending on how the article is stored.

To open the glove compartment, pull

the knob toward you.

CAUTION

Do not leave lighters or eyeglasses in

the storage boxes while parked under

the sun. A lighter could explode or the

plastic material in eyeglasses could

deform and crack from high

temperature.

To close the glove compartment, firmly

press in the center of the glove

compartment lid.

5-46

*Some models.

Interior Features

Interior Equipment

▼ Center Console

NOTE

If a rear seatback is folded, open/close

Sliding

the console lid while it is slid to the 1st

The console lid can be slid rearward in

step. The console lid and the rear seat

2 steps.

(head restraint) will contact each other

Slide the console lid rearward while

and the console lid cannot be

pulling the knob.

opened/closed while it is slid to the

2nd step.

Center console divider

Opening/closing

The console lid can be opened at the

1st or 2nd step of the slide positions.

Small items can be placed using the

Pull the console lid up while pulling

center console divider.

the knob.

▼ Luggage Compartment

Cargo Securing Loops

Use the loops in the luggage

compartment to secure cargo with a

rope or net. The tensile strength of the

loops is 196 N (20 kgf, 44 lbf). Do not

apply excessive force to the loops as it

will damage them.

CAUTION

Do not put your hands or fingers

around the moving part of the console

lid when operating it. Otherwise, your

hands or fingers could be injured.

5-47

Maintenance and Care

How to keep your Mazda in top condition.

Essential Information

6-2

Brake Fluid

6-20

Introduction

6-2

Washer Fluid

6-20

Body Lubrication

6-21

Wiper Blades

6-22

Scheduled Maintenance

6-4

Battery

6-27

Scheduled Maintenance

6-4

Key Battery Replacement

6-29

Tires

6-31

Owner Maintenance

6-11

Light Bulbs

6-34

Owner Maintenance

Fuses

6-35

Precautions

6-11

Hood

6-12

Appearance Care

6-43

Engine Compartment

Exterior Care

6-43

Overview

6-14

Interior Care

6-49

Engine Oil

6-16

Engine Coolant

6-18

6-1

Maintenance and Care

Essential Information

To continue warranty eligibility and to

Introduction

protect your investment, it is your

responsibility to properly maintain your

▼ Introduction

vehicle according to factory

Be careful not to hurt yourself when

recommended schedules outlined in

inspecting your vehicle, replacing a

this manual. As part of this you must

tire, or doing some kind of

keep your maintenance records,

maintenance such as changing the oil

receipts, repair orders and any other

and filter. In particular, wear thick work

documents as evidence this

gloves such as cotton gloves when

maintenance was performed. You must

touching areas that are difficult to see

present these documents, should any

while inspecting or working on your

warranty coverage disagreement occur.

vehicle. Doing inspections or

Failure to do so can result in your

procedures with your bare hands could

warranty being voided either in whole

cause injury.

or in part.

If you are unsure about any procedure

This evidence may consist of the

this manual describes, we strongly urge

following:

you to have a reliable and qualified

^ The Mazda Scheduled Maintenance

service shop perform the work,

Record, refer to the Warranty

preferably an Authorized Mazda

Booklet, must be completely filled

Dealer.

out showing mileage, repair order

number, date for each service, and

Factory-trained Mazda technicians and

signed by a qualified automotive

genuine Mazda parts are best for your

service technician who service

vehicle. Without this expertise and the

vehicles.

parts that have been designed and

^ Original copies of repair orders or

made especially for your Mazda,

other receipts that include the

inadequate, incomplete, and

mileage and date the vehicle was

insufficient servicing may result in

serviced. Each receipt should be

problems. This could lead to vehicle

signed by a qualified automotive

damage or an accident and injuries.

service technician.

^ For self maintenance, a statement

For expert advice and quality service,

that you completed the maintenance

consult an Authorized Mazda Dealer.

yourself, displaying mileage and the

date the work was performed. Also,

receipts for the replacement parts

(fluid, filters, etc.) indicating the date

and mileage must accompany this

statement.

6-2

Maintenance and Care

Essential Information

NOTE

The malfunction diagnosis connector is

If you elect to perform maintenance

designed exclusively for connecting the

yourself or have your vehicle serviced

specially designed device to perform

at a location other than an Authorized

on-board diagnosis.

Mazda Dealer, Mazda requires that all

Do not connect any devices other than

fluids, parts and materials must meet

the specially designed malfunction

Mazda standards for durability and

diagnosis devices for servicing. If any

performance as described in this

device other than the malfunction

manual.

diagnosis device is connected, it may

affect the vehicle's electrical devices or

lead to damage such as battery

Claims against the warranty resulting

depletion.

from lack of maintenance, as opposed

to defective materials or authorized

Mazda workmanship, will not be

honored.

Any auto repair shop using parts

equivalent to your Mazda's original

equipment may perform maintenance.

But we recommend that it always be

done by an Authorized Mazda Dealer

using genuine Mazda parts.

Selecting “Vehicle Status Monitor”

enables the system to notify you of

1. Malfunction diagnosis connector

your vehicle's approaching inspection/

servicing period. Refer to the

Information section in the Mazda

Connect Owner's Manual.

6-3

Maintenance and Care

Scheduled Maintenance

▼ Scheduled Maintenance (U.S.A. and Puerto Rico)

Vehicles utilizing the vehicle status monitor feature:

The vehicle status monitor feature alerts you of maintenance needs by turning on the

wrench indicator light or displaying a message in the instrument panel, or both.

Every maintenance must be done when the display/wrench indication comes on.

The display/wrench indication will come on before reaching the maximum interval

of 16,000 km (10,000 miles), or 12 months (after the previous maintenance).

If you drive your vehicle under any of the following conditions, follow the Severe

Driving Scheduled Maintenance and replace the engine oil and filter every 8,000 km

(5,000 miles) or 6 months, whichever comes first.

Otherwise, follow the Normal Driving Scheduled Maintenance intervals.

1. The vehicle is idled for long periods or driven at low speeds, such as with police

cars, taxis, or driver's education school car.

2. Driving under dusty conditions.

3. Driving for long periods in cold temperatures or driving regularly for short distan-

ces only.

4. Driving under extremely high temperature conditions.

5. Driving continuously in mountainous regions.

If you are following the Severe Driving Scheduled Maintenance (8,000 km (5,000

miles) or 6 months oil replacement interval), set the vehicle status monitor manually.

Refer to the Information section in the Mazda Connect Owner's Manual. Please

contact an Authorized Mazda Dealer if necessary.

USA and Puerto Rico Residents (Normal Driving Scheduled Maintenance):

Number of times, maintenance was performed.

Maintenance Item

Engine oil & filter ^*1

SKYACTIV-G

Replace every 64,000 km (40,000 miles).

2.5T

Spark plugs

Except SKY-

ACTIV-G

Replace every 120,000 km (75,000 miles).

2.5T

Air filter

Fuel lines & hoses^*2

Hoses and tubes for emission^*2

Drive belts

Engine coolant level

Replace at first 192,000 km (120,000 miles) or 120

Engine coolant^*3

months; after that, every 96,000 km (60,000 miles) or

60 months.

6-4

Maintenance and Care

Scheduled Maintenance

Number of times, maintenance was performed.

Maintenance Item

Vacuum brake booster and hose

Exhaust system and heat shields

Brake lines, hoses and connections

Brake and clutch fluid level

Disc brakes

Steering operation and linkages

Front and rear suspension, ball joints and

wheel bearing axial play

Driveshaft dust boot

Bolts and nuts on chassis and body

Cabin air filter

Replace every 48,000 km (30,000 miles) or 24 months.

Tire rotation

Rotate every 16,000 km (10,000 miles).

Tire inflation pressure and tire wear^*4

Function of all lights

Chart symbols:

I: Inspect: Inspect and clean, repair, adjust, fill up, or replace if necessary.

R: Replace

T: Tighten

Remarks:

^*1

Reset the engine oil data whenever replacing the engine oil regardless of the message/wrench

indicator light display.

^*2

According to state/provincial and federal regulations, failure to perform maintenance on these items

will not void your emissions warranties. However, Mazda recommends that all maintenance services

be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.

^*3

Use of FL-22 is recommended when replacing coolant. Using coolant other than FL-22 may cause

serious damage to the engine and cooling system.

^*4

Inspect a spare tire if equipped.

6-5

Maintenance and Care

Scheduled Maintenance

USA and Puerto Rico Residents (Severe Driving Scheduled Maintenance):

Number of months or kilometers (miles), whichever comes first.

Months

× 1000 km

× 1000 miles

Engine oil & filter^*1

Maintenance Interval (other than engine oil

1st

2nd

3rd

4th

& filter replacement)^*2

Chart symbols:

R: Replace

Remarks:

^*1

Reset the engine oil data whenever replacing the engine oil regardless of the message/wrench

indicator light display.

^*2

Follow Maintenance Interval listed in Normal Driving Scheduled Maintenance.

▼ Scheduled Maintenance (Canada)

Vehicles utilizing the vehicle status monitor feature:

The vehicle status monitor feature alerts you of engine oil replacement by turning on

the wrench indicator light or displaying a message in the instrument panel, or both.

Every engine oil replacement must be done when the display/wrench indication

comes on. The display/wrench indication will come on before reaching the maxi-

mum interval of 16,000 km (10,000 miles), or 12 months (after the previous main-

tenance).

If you are following 8,000 km (5,000 miles) or 6 months maintenance interval, set

the vehicle status monitor manually.

Refer to the owner's manual section of mazda.ca for the Mazda Connect owner's

manual or contact an Authorized Mazda Dealer if necessary.

6-6

Maintenance and Care

Scheduled Maintenance

Canada residents

Number of months or kilometers (miles), whichever comes first.

Months

Maintenance Interval

×1000 km

×1000 miles

Replace when the wrench indicator light is ON.

Engine oil & filter^*1*2

(Upper limit interval is 16,000 km (10,000 miles) or 12

months.)

SKYACTIV-G

Replace every 64,000 km (40,000 miles).

2.5T

Spark plugs

Except SKY-

ACTIV-G

Replace every 120,000 km (75,000 miles).

2.5T

Air filter

Replace every 56,000 km (35,000 miles) or 36 months.

Drive belts^*3

Engine coolant level

Replace at first 192,000 km (120,000 miles) or 120

Engine coolant^*4

months; after that, every 96,000 km (60,000 miles) or

60 months.

Fuel lines & hoses^*5

Hoses and tubes for emission

Brake lines, hoses and connections

Vacuum brake booster and hose

Disc brakes

Tire rotation

Rotate every 8,000 km (5,000 miles).

Tire inflation pressure and tire wear^*6

Steering operation and linkages

Front and rear suspension, ball joints and

wheel bearing axial play

Body condition inspection for rust, corro-

sion and perforation

Driveshaft dust boot

Bolts and nuts on chassis and body

Exhaust system and heat shields

Cabin air filter

Chart symbols:

I: Inspect: Inspect and clean, repair, adjust, fill up, or replace if necessary.

6-7

Maintenance and Care

Scheduled Maintenance

R: Replace

C: Clean

L: Lubricate

T: Tighten

Remarks:

^*1

Reset the engine oil data whenever replacing the engine oil regardless of the message/wrench

indicator light display.

^*2

If you drive your vehicle under any of the following conditions, replace the engine oil & filter every

8,000 km (5,000 miles) or 6 months, whichever comes first.

1. The vehicle is idled for long periods or driven at low speeds, such as with police cars, taxis, or

driver's education school vehicles.

2. Driving under dusty conditions.

3. Driving for long periods in cold temperatures or driving regularly for short distances only.

4. Driving under extremely high temperature conditions.

5. Driving continuously in mountainous regions.

^*3

Also inspect the air conditioner drive belts, if equipped.

If the vehicle is operated primarily under any of the following conditions, inspect the drive belts more

often than the recommended intervals.

a) Driving under dusty conditions.

b) The vehicle is idled for long periods or driven at low speeds.

c) Driving for long periods in cold temperatures or driving regularly for short distances only.

d) Driving under extremely high temperature conditions.

e) Driving continuously in mountainous regions.

f) Driving for long period in extremely wet or heavy rain condition.

^*4

Use of FL-22 is recommended when replacing engine coolant. Using engine coolant other than FL-22

may cause serious damage to the engine and cooling system.

^*5

According to state/provincial and federal regulations, failure to perform maintenance on these items

will not void your emissions warranties. However, Mazda recommends that all maintenance services

be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.

^*6

Inspect a spare tire if equipped.

▼ Scheduled Maintenance (Mexico)

Vehicles utilizing the vehicle status monitor feature:

The vehicle status monitor feature alerts you of maintenance needs by turning on the

wrench indicator light or displaying a message in the instrument panel, or both.

Every maintenance must be done when the display/wrench indication comes on.

The display/wrench indication will come on before reaching the maximum interval

of 10,000 km, or 6 months (after the previous maintenance).

If you drive your vehicle under any of the following conditions, follow the Severe

Driving Scheduled Maintenance and replace the engine oil and filter every 5,000 km

or 3 months, whichever comes first.

Otherwise, follow the Normal Driving Scheduled Maintenance intervals.

1. The vehicle is idled for long periods or driven at low speeds, such as with police

cars, taxis, or driver's education school car.

6-8

Maintenance and Care

Scheduled Maintenance

2. Driving under dusty conditions.

3. Driving for long periods in cold temperatures or driving regularly for short distan-

ces only.

4. Driving under extremely high temperature conditions.

5. Driving continuously in mountainous regions.

If you are following the Severe Driving Scheduled Maintenance (5,000 km or 3

months oil replacement interval), set the vehicle status monitor manually.

Refer to the Information section in the Mazda Connect Owner's Manual. Please

contact an Authorized Mazda Dealer if necessary.

Mexico Residents (Normal Driving Scheduled Maintenance):

Number of times, maintenance was performed.

Maintenance Item

Engine oil & filter^*1

SKYACTIV-G

2.5T

Replace every 64,000 km

Spark plugs

Except SKY-

ACTIV-G

Replace every 120,000 km.

2.5T

Air filter

Drive belts

Engine coolant level

Replace at first 192,000 km or 120 months; after that,

Engine coolant^*2

every 96,000 km or 60 months.

Fuel lines & hoses^*3

Hoses and tubes for emission^*3

Fuel filter

Replace every 60,000 km.

Brake lines, hoses and connections

Vacuum brake booster and

With vacuum

hose

booster

Brake and clutch fluid level

Brake fluid

Disc brakes

Tire rotation

Rotate every 10,000 km.

Tire inflation pressure and tire wear^*4

Steering operation and linkages

Front and rear suspension, ball joints and

wheel bearing axial play

6-9

Maintenance and Care

Scheduled Maintenance

Number of times, maintenance was performed.

Maintenance Item

Driveshaft dust boot

Bolts and nuts on chassis and body

Exhaust system and heat shields

Cabin air filter

Replace every 40,000 km or 24 months.

Function of all lights

Chart symbols:

I: Inspect: Inspect and clean, repair, adjust, fill up, or replace if necessary.

R: Replace

T: Tighten

Remarks:

^*1

Reset the engine oil data whenever replacing the engine oil regardless of the message/wrench

indicator light display.

^*2

Use of FL-22 is recommended when replacing engine coolant. Using engine coolant other than FL-22

may cause serious damage to the engine and cooling system.

^*3

According to state/provincial and federal regulations, failure to perform maintenance on these items

will not void your emissions warranties. However, Mazda recommends that all maintenance services

be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.

^*4

Inspect a spare tire if equipped.

Mexico Residents (Severe Driving Scheduled Maintenance):

Number of months or kilometers , whichever comes first.

Months

× 1000 km

Engine oil & filter^*1

Maintenance Interval (other than engine oil

1st

2nd

3rd

4th

& filter replacement)^*2

Chart symbols:

R: Replace

Remarks:

^*1

Reset the engine oil data whenever replacing the engine oil regardless of the message/wrench

indicator light display.

^*2

Follow Maintenance Interval listed in Normal Driving Scheduled Maintenance.

6-10

Maintenance and Care

Owner Maintenance

As explained in the Introduction (page

Owner Maintenance

6-2), several procedures can be done

Precautions

only by a qualified service technician

with special tools.

▼ Owner Maintenance Precautions

Improper owner maintenance during

The owner or a qualified service

the warranty period may affect

technician should make these vehicle

warranty coverage. Refer to

inspections at the indicated intervals to

Introduction (page 6-2) for owner's

ensure safe and dependable

responsibility in protecting your

operation.

investment. For details, read the

separate Mazda Warranty statement

Bring any problem to the attention of

provided with the vehicle. If you are

an Authorized Mazda Dealer or

unsure about any servicing or

qualified service technician as soon as

maintenance procedure, have it done

possible.

by an Authorized Mazda Dealer.

When Refueling

There are strict environmental laws

^ Brake fluid level (page 6-20)

regarding the disposal of waste oil and

^ Engine coolant level (page 6-18)

fluids. Please dispose of your waste

^ Engine oil level (page 6-17)

properly and with due regard to the

^ Washer fluid level (page 6-20)

environment.

At Least Monthly

We recommend that you entrust the oil

^ Tire inflation pressures (page 6-31)

and fluid changes of your vehicle to an

At Least Twice a Year (For Example,

Authorized Mazda Dealer.

Every Spring and Fall)

WARNING

You can do the following scheduled

maintenance items if you have some

Do not perform maintenance work if

mechanical ability and a few basic

you lack sufficient knowledge and

tools and if you closely follow the

experience or the proper tools and

directions in this manual.

equipment to do the work. Have

^ Engine coolant (page 6-18)

maintenance work done by a

^ Engine oil (page 6-17)

qualified technician:

Performing maintenance work on a

vehicle is dangerous if not done

Improper or incomplete service may

properly. You can be seriously injured

result in problems. This section gives

while performing some maintenance

instructions only for items that are easy

procedures.

to perform.

6-11

Maintenance and Care

Owner Maintenance

If you must run the engine while

Hood

working under the hood, make

certain that you remove all jewelry

▼ Hood

(especially rings, bracelets, watches,

and necklaces) and all neckties,

scarves, and similar loose clothing

WARNING

before getting near the engine or

cooling fan which may turn on

Always check that the hood is closed

unexpectedly:

and securely locked:

Working under the hood with the

A hood that is not closed and securely

engine running is dangerous. It

locked is dangerous as it could fly open

becomes even more dangerous when

while the vehicle is moving and block

you wear jewelry, loose clothing or

the driver's vision which could result in

have long hair or a long beard.

a serious accident.

Either can become entangled in

▼ Opening the Hood

moving parts and result in injury.

With the vehicle parked, pull the

release handle to unlock the hood.

Pull over to a safe location, then

switch the ignition off and make sure

the fan is not running before

attempting to work near the cooling

fan:

Working near the cooling fan when it is

running is dangerous. The fan could

continue running indefinitely even if

the engine has stopped and the engine

compartment temperature is high. You

Insert your hand into the hood

could be hit by the fan and seriously

opening, slide the latch lever in the

injured.

direction of the arrow as shown in

the illustration, and lift up the

Do not leave items in the engine

hood.

compartment:

After you have finished checking or

doing servicing in the engine

compartment, do not forget and leave

items such as tools or rags in the

engine compartment.

Tools or other items left in the engine

compartment could cause engine

damage or a fire leading to an

unexpected accident.

6-12

Maintenance and Care

Owner Maintenance

3. Grasp the support rod in the

3. Lower the hood slowly to a height

padded area and secure it in the

of about 20 cm (7.9 in) above its

support rod hole indicated by the

closed position and then let it drop.

arrow to hold the hood open.

CAUTION

When closing the hood, do not push it

excessively such as by applying your

weight. Otherwise, the hood could be

deformed.

1. Pad

2. Support rod

▼ Closing the Hood

1. Check under the hood area to

make certain all filler caps are in

place and all loose items (e.g.

tools, oil containers, etc.) have

been removed.

2. Lift the hood, grasp the padded

area on the support rod, and secure

the support rod in the clip. Verify

that the support rod is secured in

the clip before closing the hood.

1. Clip

6-13

Maintenance and Care

Owner Maintenance

Only use SAE 0W-20 oil “Certified For

Engine Oil

Gasoline Engines” by the American

Petroleum Institute (API).

▼ Engine Oil

Oil with this trademark symbol

conforms to the current engine and

NOTE

emission system protection standards

Changing the engine oil should be

and fuel economy requirements of the

performed by an Authorized Mazda

International Lubricant Standardization

Dealer.

and Approval Committee (ILSAC),

Refer to Introduction on page 6-2 for

comprised of U.S. and Japanese

owner's responsibility in protecting

automobile manufacturers.

your investment.

▼ Recommended Oil

U.S.A., Canada

SKYACTIV-G 2.0 and SKYACTIV-G

2.5

Use ILSAC GF-V or higher/ SAE

0W-20 engine oil.

Mazda Genuine Oil is used in your

Mazda vehicle. Mazda Genuine

SKYACTIV-G 2.5T

0W-20 Oil is required to achieve

optimum fuel economy.

Use SAE 5W-30 engine oil.

Mazda Genuine Oil is used in your

For maintenance service, Mazda

Mazda vehicle. Mazda Genuine

recommends Genuine Mazda Parts

5W-30 Oil is required to achieve

and Genuine Mazda Premium Oil.

optimum fuel economy.

For maintenance service, Mazda

recommends Genuine Mazda Parts

and Genuine Mazda Premium Oil.

6-16

Maintenance and Care

Owner Maintenance

Only use SAE 5W-30 oil “Certified For

(Mexico)

Gasoline Engines” by the American

SKYACTIV-G 2.0 and SKYACTIV-G

Petroleum Institute (API).

2.5

Oil with this trademark symbol

conforms to the current engine and

Use API SM or higher, SAE 5W-30

emission system protection standards

engine oil. If SAE 5W-30 engine oil is

and fuel economy requirements of the

not available, use SAE 5W-20, SAE

International Lubricant Standardization

0W-30 or SAE 10W-30 engine oil.

and Approval Committee (ILSAC),

comprised of U.S. and Japanese

The quality designation SM, SN or SP

automobile manufacturers.

must be on the label.

Except U.S.A., Canada

SKYACTIV-G 2.5T

Use SAE 5W-30 engine oil.

Use API SM or higher, SAE 5W-30

Oil container labels provide important

engine oil. If SAE 5W-30 engine oil is

information.

not available, use SAE 0W-30 or SAE

A chief contribution this type of oil

10W-30 engine oil.

makes to fuel economy is reducing the

amount of fuel necessary to overcome

The quality designation SM, SN or SP

engine friction.

must be on the label.

For maintenance service, Mazda

▼ Inspecting Engine Oil Level

recommends Mazda Genuine Parts.

NOTE

^ If the engine oil level warning

indication/warning light turns on,

add 1 L (0.26 US gal, 0.22 Imp gal)

of engine oil.

1. Be sure the vehicle is on a level

surface.

2. Warm up the engine to normal

operating temperature.

3. Turn it off and wait at least 5

minutes for the oil to return to the

oil pan.

6-17

Maintenance and Care

Owner Maintenance

Pull out the dipstick, wipe it clean,

Engine Coolant

and reinsert it fully.

▼ Inspecting Coolant Level

WARNING

Do not use a match or live flame in

the engine compartment. DO NOT

ADD COOLANT WHEN THE ENGINE

IS HOT:

A hot engine is dangerous. If the

engine has been running, parts of the

engine compartment can become very

hot. You could be burned. Carefully

inspect the engine coolant in the

1. MAX

2. OK

coolant reservoir, but do not open it.

3. MIN

Pull it out again and examine the

level.

Pull over to a safe location, then

The level is normal if it is between

switch the ignition off and make sure

the MIN and MAX marks.

the fan is not running before

If it is near or below MIN, add

attempting to work near the cooling

enough oil to bring the level to

fan:

MAX.

Working near the cooling fan when it is

running is dangerous. The fan could

CAUTION

continue running indefinitely even if

the engine has stopped and the engine

Do not overfill the engine oil. This

compartment temperature is high. You

may cause engine damage.

could be hit by the fan and seriously

Make sure the O-ring on the

injured.

dipstick is positioned properly

before reinserting the dipstick.

Reinsert the dipstick fully.

Do not remove either

cooling system cap when the engine

and radiator are hot:

When the engine and radiator are hot,

scalding coolant and steam may shoot

out under pressure and cause serious

injury.

6-18

Maintenance and Care

Owner Maintenance

NOTE

SKYACTIV-G 2.5T

Changing the coolant should be done

by an Authorized Mazda Dealer.

Inspect the antifreeze protection and

coolant level in the coolant reservoir at

least once a year―at the beginning of

the winter season―and before

traveling where temperatures may drop

below freezing.

Inspect the condition and connections

of all cooling system and heater hoses.

Replace any that are swollen or

deteriorated.

If it is at or near LOW, add enough

coolant to the coolant reservoir to

The coolant should be at full in the

radiator and between the FULL and

provide freezing and corrosion

protection and to bring the level to

LOW marks on the coolant reservoir

when the engine is cool.

FULL.

Securely tighten the coolant reservoir

SKYACTIV-G 2.0 and SKYACTIV-G

2.5

tank cap after adding coolant.

CAUTION

¾ Radiator coolant will damage paint.

Rinse it off quickly if spilled.

¾ If the “FL22” mark is shown on or

near the cooling system cap, use of

FL-22 is recommended when

replacing engine coolant. Using

engine coolant other than FL-22 may

cause serious damage to the engine

and cooling system.

If the coolant reservoir is empty or new

coolant is required frequently, consult

an Authorized Mazda Dealer.

6-19

Maintenance and Care

Owner Maintenance

Brake Fluid

Washer Fluid

▼ Inspecting Brake Fluid Level

▼ Inspecting Washer Fluid Level

WARNING

If the brake fluid level is low, have the

Use only windshield washer fluid or

brakes inspected:

plain water in the reservoir:

A low brake fluid level is dangerous.

Using radiator antifreeze as washer

A low level could indicate brake lining

fluid is dangerous. If sprayed on the

wear or a brake system leak which

windshield, it will dirty the windshield,

could cause the brakes to fail and lead

affect your visibility, and could result in

to an accident.

an accident.

Inspect the fluid level in the reservoir

Using Washer Fluid Without

regularly. It should be kept between

Anti-freeze Protection in Cold

the MAX and MIN lines.

Weather:

The level normally drops with

Operating your vehicle in temperatures

accumulated distance, a condition

below 4 °C (40 °F) using washer fluid

associated with wear of brake linings. If

without anti-freeze protection is

it is excessively low, have the brake

dangerous as it could cause impaired

system inspected by an Authorized

windshield vision and result in an

Mazda Dealer.

accident. In cold weather, always use

Without M Hybrid

washer fluid with anti-freeze

protection.

With M Hybrid

6-20

Maintenance and Care

Owner Maintenance

NOTE

Body Lubrication

State or local regulations may restrict

the use of volatile organic compounds

▼ Body Lubrication

(VOCs), which are commonly used as

anti-freeze agents in washer fluid. A

All moving points of the body, such as

washer fluid with limited VOC content

door and hood hinges and locks,

should be used only if it provides

should be lubricated each time the

adequate freeze resistance for all

engine oil is changed. Use a

regions and climates in which the

non-freezing lubricant on locks during

vehicle will be operated.

cold weather.

Add washer fluid under any of the

Make sure the hood's secondary latch

following conditions.

keeps the hood from opening when

^ The top of the fluid level is low.

the primary latch is released.

^ The Low Washer Fluid Level Warning

Indication/Warning Light (if

equipped) turns on.

^ The top of the fluid level is lower

than E (if equipped).

1. F

2. E

Use plain water if washer fluid is

unavailable.

But use only washer fluid in cold

weather to prevent it from freezing.

NOTE

Front and rear washer fluid is supplied

from the same reservoir.

6-21

Maintenance and Care

Owner Maintenance

Refer to the Replacing Windshield

Wiper Blades

Wiper Blades (page 6-22) section

for the procedure on how to move

▼ Wiper Blades

the windshield wiper blades to the

service position.

CAUTION

Contamination of either the

¾ Hot waxes applied by automatic car

windshield or the blades with foreign

washers have been known to affect

matter can reduce wiper effectiveness.

the wiper's ability to clean windows.

Common sources are insects, tree sap,

¾ An operation malfunction may occur

and hot wax treatments used by some

or the wiper effectiveness may be

commercial car washes.

reduced if a water-repellent coating

If the blades are not wiping properly,

is used.

clean the window and blades with a

¾ To prevent damage to the wiper

good cleaner or mild detergent; then

blades, do not use gasoline,

rinse thoroughly with clean water.

kerosene, paint thinner, or other

Repeat if necessary.

solvents on or near them.

▼ Replacing Windshield Wiper

¾ When the wiper lever is in the AUTO

Blades

position and the ignition is switched

ON, the wipers may move

When the wipers no longer clean well,

automatically in the following cases:

the blades are probably worn or

cracked.

¾ If the windshield above the rain

Replace them.

sensor is touched.

¾ If the windshield above the rain

CAUTION

sensor is wiped with a cloth.

¾ If the windshield is struck with a

¾ To prevent damaging a windshield

hand or other object.

wiper blade, wiper arm, or the hood,

¾ If the rain sensor is struck with a

perform the following procedure.

hand or other object from inside

¾ Before lifting the windshield wiper

the vehicle.

blades off the windshield, always

Be careful not to pinch hands or

move them to the service position.

fingers as it may cause injury, or

¾ When putting the windshield

damage the wipers. When washing

wiper blades back on the

or servicing the vehicle, make sure

windshield, make sure that they

the wiper lever is in the OFF

are in the service position before

position.

switching the ignition ON and

¾ Before lifting the windshield wiper

operating the windshield wipers.

blades off the windshield, always

¾ Replace with Mazda genuine wiper

follow the procedure for moving the

blades. If they are replaced with

windshield wiper blades. Otherwise,

wiper blades other than a Mazda

a wiper blade, wiper arm, or the

genuine product, they may not wipe

hood could be damaged.

with the same efficiency as the

genuine product.

6-22

Maintenance and Care

Owner Maintenance

¾ To prevent damage to the wiper

remove the blade component from

arms and other components, do not

the wiper arm.

try to sweep the wiper arm by hand.

¾ Do not bend the blade rubber

unnecessarily when replacing it.

Otherwise, the metal stiffener in the

blade may deform and the

windshield wiper operation may be

adversely affected.

¾ Do not hold a wiper blade by its end

when raising the wiper arm.

Otherwise, the part may deform and

the wiping performance may lower.

¾ Forcefully lowering the wiper arms

could damage the wiper arm and

Pull the blade rubber in the

blade, and may scratch or crack the

direction of the arrow and slide it

windshield.

to a position where the blade

holder groove can be checked.

NOTE

You can replace the wiper blades

yourself, however you cannot replace

the wiper arms.

If you want to replace the wiper arms,

consult an Authorized Mazda Dealer.

Replace the wiper blades using the

following procedure.

1. Move the wipers to the service

positions using the following

procedure.

a) Switch the ignition ON.

b) Switch the ignition OFF.

c) Press up the wiper switch to the

MIST position 2 times within 30

seconds after switching the

ignition OFF.

When the procedure is

completed, the wipers operate

and they stop at the service

positions.

2. Raise the wiper arms.

3. Slide the blade component in the

direction of the arrow while

pressing the wiper arm tab to

6-23

Maintenance and Care

Owner Maintenance

7. After pulling the blade rubber in the

8. Make sure that the blade rubber is

direction of the arrow and sliding

correctly installed to the blade

the blade rubber to a position to

holder.

check the blade holder groove,

9. Slide the blade component and

slide the blade rubber end in the

install it to the wiper arm.

opposite direction.

10.Slowly lower the wiper arms onto

the windshield.

CAUTION

To prevent damage to the

windshield let the wiper arm down

easily, do not let it slap down on

the windshield.

11.Move the wipers to their initial

positions using the following

procedure.

a) Make sure that the wipers are set

on the windshield.

b) Switch the ignition ON.

c) Press up the wiper switch to the

MIST position 1 time.

When the procedure is

completed, the wipers operate

and they stop at the initial

positions.

▼ Replacing Rear Window Wiper

Blade

When the wiper no longer cleans well,

the blade is probably worn or cracked.

Replace it.

6-25

Maintenance and Care

Owner Maintenance

CAUTION

To prevent damage to the wiper arm

To prevent damage to the rear

and other components, do not move

window, do not let the wiper arm

the wiper by hand.

fall on it.

4. Pull down the blade rubber and

1. Remove the cover.

slide it out of the blade holder.

2. Remove the stopper and raise the

wiper arm.

5. Remove the metal stiffeners from

the blade rubber and install them in

the new blade.

3. Firmly rotate the wiper blade to the

right until it unlocks, then remove

CAUTION

the blade.

Do not bend or discard the

stiffeners. You need to use them

again.

6. Carefully insert the new blade

rubber.

6-26

Maintenance and Care

Owner Maintenance

Then install the blade assembly in

Battery

the reverse order of removal.

▼ Battery

WARNING

Wash hands after handling the battery

and related accessories:

Battery posts, terminals and related

accessories contain lead and lead

compounds, chemicals known to the

State of California to cause cancer and

reproductive harm.

Read the following precautions

carefully before using the battery or

inspecting to ensure safe and correct

handling:

Always wear eye protection

when working near the battery:

Working without eye protection is

dangerous. Battery fluid contains

SULFURIC ACID which could cause

blindness if splashed into your eyes.

Also, hydrogen gas produced during

normal battery operation, could ignite

and cause the battery to explode.

Wear eye protection and

protective gloves to prevent contact

with battery fluid:

Spilled battery fluid is dangerous.

Battery fluid contains SULFURIC ACID

which could cause serious injuries if it

gets in eyes, or on the skin or clothing.

If this happens, immediately flush your

eyes with water for 15 minutes or wash

your skin thoroughly and get medical

attention.

6-27

Mazda CX-30 (2022 year). Manual in english - page 14
