Specifications
9
Technical information about your Mazda.
Identification Numbers
9-2
Specifications
9-4
Vehicle Information Labels
9-2
Specifications
9-4
9-1
Specifications
Identification Numbers
▼ Chassis Number
Vehicle Information
Open the cover shown in the figure to
Labels
check the chassis number.
▼ Vehicle Identification Number
The vehicle identification number legally
identifies your vehicle. The number is on a
plate attached to the cowl panel located on
the left corner of the dashboard. This plate
can easily be seen through the windshield.
▼ Vehicle Emission Control
Information Label (U.S.A. and
Canada)
▼ Motor Vehicle Safety Standard
Label (U.S.A. and Canada)
▼ Tire Pressure Label
9-2
Specifications
Identification Numbers
▼ Engine Number
SKYACTIV-G 2.5, SKYACTIV-G 2.5T
Forward
SKYACTIV-D 2.2
Forward
9-3
Specifications
Specifications
Specifications
▼ Engine
Gasoline engine
Specification
Item
SKYACTIV-G 2.5
SKYACTIV-G 2.5T
Type
DOHC-16V in-line, 4-cylinder
Bore × Stroke
89.0 × 100 mm (3.50 × 3.94 in)
Displacement
2,488.5 ml (2,488.5 cc)
Compression ratio
13.0
10.5
Diesel engine
Specification
Item
SKYACTIV-D 2.2
Type
DOHC-16V in-line, 4-cylinder
Bore × Stroke
86.0 × 94.3 mm (3.39 × 3.71 in)
Displacement
2,191.1 ml (2,191.1 cc)
Compression ratio
14.4
▼ Electrical System
Battery*1
Classification
Specification
SKYACTIV-G 2.5,
12V-60Ah/20HR or 12V-65Ah/20HR
SKYACTIV-G 2.5T
SKYACTIV-D 2.2
12V-65Ah/20HR or 12V-80Ah/20HR
Spark-plug
Classification
Specification
SKYACTIV-G 2.5
PE5R-18-110 or PE5S-18-110
Mazda Genuine spark plug*2
SKYACTIV-G 2.5T
PY8V-18-110
*1
Check the battery installed on the vehicle and use a battery with an equal or higher performance. However, the
performance of the battery may vary even among the same battery types, consult an Authorized Mazda Dealer
for replacement.
*2
The spark plugs provide the SKYACTIV-G its optimum performance. Consult an Authorized Mazda Dealer
for details.
9-4
Specifications
Specifications
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The fine particulate coating on the
iridium alloy and platinum tips could be damaged.
▼ Lubricant Quality
Lubricant
Classification
Engine oil
Refer to Recommended Oil on page 6-22.
Coolant
FL-22 type
Automatic transaxle fluid
Mazda Genuine ATF FZ
Transfer case oil
Mazda Long Life Hypoid Gear Oil SG1
Rear differential oil
Mazda Long Life Hypoid Gear Oil SG1
Brake fluid
SAE J1703 or FMVSS116 DOT-3
NOTE
Refer to Introduction on (page 6-2) for owner's responsibility in protecting your investment.
▼ Capacities
(Approximate Quantities)
Item
Capacity
SKYACTIV-G
With oil filter replacement
4.5 L (4.8 US qt, 4.0 Imp qt)
2.5
Without oil filter replacement
4.3 L (4.5 US qt, 3.8 Imp qt)
SKYACTIV-G
With oil filter replacement
4.8 L (5.1 US qt, 4.2 Imp qt)
Engine oil
2.5T
Without oil filter replacement
4.6 L (4.9 US qt, 4.0 Imp qt)
SKYACTIV-D
With oil filter replacement
5.1 L (5.4 US qt, 4.5 Imp qt)
2.2
Without oil filter replacement
4.8 L (5.1 US qt, 4.2 Imp qt)
SKYACTIV-G 2.5
7.0 L (7.4 US qt, 6.2 Imp qt)/7.1 L (7.5 US qt, 6.2
Imp qt)
U.S.A. and
Canada
SKYACTIV-G 2.5T
8.3 L (8.8 US qt, 7.3 Imp qt)
Coolant
SKYACTIV-D 2.2
8.6 L (9.1 US qt, 7.6 Imp qt)
SKYACTIV-G 2.5
7.1 L (7.5 US qt, 6.2 Imp qt)
Mexico
SKYACTIV-G 2.5T
8.2 L (8.7 US qt, 7.2 Imp qt)
Automatic
7.8 L (8.2 US qt, 6.9 Imp qt)/8.0 L (8.5 US qt, 7.0
SKYACTIV-G 2.5
transaxle
Imp qt)
fluid
SKYACTIV-G 2.5T, SKYACTIV-D 2.2
8.0 L (8.5 US qt, 7.0 Imp qt)
Transfer case oil
0.45 L (0.48 US qt, 0.40 Imp qt)
Rear differential oil
0.35 L (0.37 US qt, 0.31 Imp qt)
9-5
Specifications
Specifications
Item
Capacity
FWD
62.0 L (16.4 US gal, 13.6 Imp gal)
Fuel tank
AWD
52.0 L (13.7 US gal, 11.4 Imp gal)
Check oil and fluid levels with dipsticks or reservoir gauges.
▼ Dimensions
Item
Vehicle specification
Without license plate holder
4,865 mm (191.5 in)
Overall length
With license plate holder
4,895 mm (192.7 in)
Overall width
1,840 mm (72.4 in)
Overall height
1,450 mm (57.1 in)
17 inch wheel vehicle
1,585 mm (62.4 in)
Front tread
19 inch wheel vehicle
1,595 mm (62.8 in)
17 inch wheel vehicle
1,575 mm (62.0 in)
Rear tread
19 inch wheel vehicle
1,585 mm (62.4 in)
Wheelbase
2,830 mm (111.4 in)
▼ Weights
U.S.A. and Canada
SKYACTIV-G 2.5
Item
Weight
GVWR (Gross Vehicle Weight Rating)
2,029 kg (4,473 lbs)
Front
1,078 kg (2,377 lbs)
GAWR (Gross Axle Weight Rating)
Rear
957 kg (2,110 lbs)
SKYACTIV-G 2.5T
Item
Weight
GVWR (Gross Vehicle Weight Rating)
2,065 kg (4,552 lbs)
Front
1,107 kg (2,440 lbs)
GAWR (Gross Axle Weight Rating)
Rear
963 kg (2,123 lbs)
SKYACTIV-D 2.2
Item
Weight
GVWR (Gross Vehicle Weight Rating)
2,185 kg (4,817 lbs)
Front
1,166 kg (2,571 lbs)
GAWR (Gross Axle Weight Rating)
Rear
1,024 kg (2,258 lbs)
9-6
Specifications
Specifications
Mexico
SKYACTIV-G 2.5
Item
Weight
Total
2,032 kg (4,480 lbs)
GVW (Gross Vehicle Weight)
Front
1,037 kg (2,286 lbs)
Rear
995 kg (2,194 lbs)
Front
1,072 kg (2,363 lbs)
GAW (Permissible axle load)
Rear
1,061 kg (2,339 lbs)
SKYACTIV-G 2.5T
Item
Weight
Total
2,118 kg (4,669 lbs)
GVW (Gross Vehicle Weight)
Front
1,121 kg (2,471 lbs)
Rear
997 kg (2,198 lbs)
Front
1,156 kg (2,549 lbs)
GAW (Permissible axle load)
Rear
1,063 kg (2,344 lbs)
▼ Light Bulbs
Exterior light
Category
Light bulb
Wattage
UN-R*1 (SAE)
Headlights
LED
Daytime running lights
LED
― (―)
LED type
LED
Parking lights
Bulb type
21/5*2
W21/5W (7444)
Front turn signal lights
Front side-marker lights
Side turn signal lights
High-mount brake light
Rear turn signal lights
LED
― (―)
Rear side-marker lights
Brake lights
Taillights
Reverse lights
License plate lights
*1
UN-R stands for United Nations Regulation.
*2
Double-filament light bulb, however, only 5 W filament bulb is used in the parking lights.
9-7
Specifications
Specifications
Interior light
Category
Light bulb
Wattage
UN-R*1
Bulb type
3
―
Trunk light
LED type
LED
―
Bulb type
8
―
Overhead light (Front)/Map lights
LED type
LED
―
Bulb type
8
―
Rear map lights
LED type
LED
―
Bulb type
2
―
Vanity mirror lights*
LED type
LED
―
Courtesy lights
LED
―
Ambient lights*
LED
―
*1
UN-R stands for United Nations Regulation.
▼ Tires
NOTE
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type originally
fitted to your vehicle. For details, contact an Authorized Mazda Dealer.
Check the tire pressure label for tire size and inflation pressure.
Refer to Tire Pressure Label on page 9-2.
Refer to Tire Inflation Pressure on page 6-44.
Standard tire
(U.S.A. and Canada)
Inflation pressure
Tire size
Front
Rear
P225/55R17 95V
250 kPa (36 psi)
250 kPa (36 psi)
P225/45R19 92W*1
240 kPa (35 psi)
240 kPa (35 psi)
9-8
*Some models.
Specifications
Specifications
(Mexico)
Inflation pressure
Tire size
Up to 3 persons
―Full load
Front
230 kPa (2.3 bar, 33 psi)
250 kPa (2.5 bar, 36 psi)
225/55R17 97V
Rear
230 kPa (2.3 bar, 33 psi)
320 kPa (3.2 bar, 46 psi)
Front
230 kPa (2.3 bar, 33 psi)
250 kPa (2.5 bar, 36 psi)
225/45R19 92W*2
Rear
230 kPa (2.3 bar, 33 psi)
320 kPa (3.2 bar, 46 psi)
1 person's weight: About 75 kg
*1
P225/45R19 92W
(SKYACTIV-G 2.5, SKYACTIV-G 2.5T)
Before driving at high speeds, increase the pressure of the front tires. For speeds above 200 km/h (124 mph),
increase the pressure of the front tires by 20 kPa (0.2 bar, 2.9 psi).
(SKYACTIV-D 2.2)
Before driving at high speeds, increase the pressure of the front tires. For speeds above 180 km/h (111 mph),
increase the pressure of the front tires by 40 kPa (0.4 bar, 5.8 psi).
*2
225/45R19 92W (SKYACTIV-G 2.5T)
Before driving at high speeds, increase the pressure of the front tires. For speeds above 210 km/h (130 mph),
increase the pressure of the front tires by 20 kPa (0.2 bar, 2.9 psi).
Temporary spare tire
(U.S.A. and Canada)
Tire size
Inflation pressure
T125/70R17 98M
420 kPa (60 psi)
T135/80D17 103M
420 kPa (60 psi)
(Mexico)
Tire size
Inflation pressure
185/55R16 87M
320 kPa (3.2 bar, 46 psi)
T125/70R17 98M
420 kPa (4.2 bar, 60 psi)
Lug nut tightening torque
When installing a tire, tighten the lug nut to the following torque.
108―147 N·m (12―14 kgf·m, 80―108 ft·lbf)
▼ Fuses
Refer to Fuses on page 6-52.
