Black plate (376,1) DESCRIPTION FUSE RATING PROTECTED COMPONENT 17 BTN 30 A For protection of various circuits 18 MAIN 120 A For protection of all circuits 19 EGI INJ 10 A Injector 20 EGI COMP1 10 A Engine control system 21 EGI COMP2 10 A Engine control system 22 HEAD LOW L 15 A Headlight low beam (LH) 23 HEAD LOW R 15 A Headlight low beam (RH) 24 HEAD 15 A Headlight high beams 25 P.WIND 20 A Power windows 26 ENGINE 15 A Engine control system 27 WIPER 20 A Windshield wipers and washer 28 DRL 15 A DRL í 29 HORN 15 A Horn 30 STOP 10 A Brake lights 31 ETV 10 A Electric throttle valve 32 FUEL PUMP 15 A Fuel Pump 33 HAZARD 10 A Turn signals, Hazard warning flashers 34 P.WIND2 20 A Power windows í 35 IG KEY1 40 A For protection of various circuits 8-50 Maintenance and Care í Some models. Owner Maintenance MX-5_8EN7-EA-14E_Edition1 Page376 |
