NOTE

Depending on the device, the registration
status may be lost after a certain period of
time. If this occurs, repeat the entire process
from Step 1.

qMaking a call using a telephone

number

NOTE

Practice this while parked until you are
confident you can do it while driving in a non-
taxing road situation. If you are not completely
comfortable, make all calls from a safe
parking position, and move out only when fully
under control and you can devote your eyes
and mind to driving.

1. Press the voice recognition/hands-free

switch with a short press.

2. Say: [Beep]

“Dial”

3. Prompt:

“Number, please”

4. Say: [Beep]

“XXXXXXXXXXX (Ex.

“555-1234”) (Telephone number)”

5. Prompt:

“Dialing XXXXXXXXXXX

(Ex.

“555-1234”) (Telephone number)

is this correct?

”

6. Say: [Beep]

“Yes” or “No”.

7. When

“Yes” is spoken, the call is

made.
When

“No” is spoken, the procedure

returns to Step 3.

NOTE

The

“Dial” command and a telephone number

can be combined.
Ex. In Step 2, say,

“Dial 123-4567”, then,

Steps 3 and 4 can be skipped.

qReceiving an incoming call

1. Prompt:

“Incoming call, press the

phone button to answer

”.

2. To accept the call, press the voice

recognition/hands-free switch with a
short press.
To reject the call, press the voice
recognition/hands-free switch with a
long press.

Voice recognition/hands-free switch

qHanging up a call

Press the voice recognition/hands-free
switch during the call with a long press.
A beep sound will confirm that call is
ended.

6-68

Interior Comfort

Bluetooth® Hands-Free

MX-5_8EN7-EA-14E_Edition1 Page280
Friday, March 28 2014 3:40 PM

Black plate (281,1)

qVolume adjustment

The power/volume dial of the audio unit
is used to adjust the volume. Turn the dial
to the right to increase volume, to the left
to decrease it.

NOTE

The volume can also be adjusted using the
volume button on the steering wheel.

The music volume of the audio unit cannot
be adjusted while Bluetooth® Hands-Free
is being used.

qHelp function use

The help function informs the user of all
the available voice commands under the
current conditions.

1. Press the voice recognition/hands-free

switch with a short press.

2. Say: [Beep]

“Help”

3. Follow the prompts to receive the

appropriate voice guidance
instructions.

Convenient Use of the
Hands-Free System

qPhonebook Usage

Phone book registration

Phone numbers can be registered to the
Bluetooth

Hands-Free phone book.

NOTE

Do this function only when parked. It is too
distracting to attempt while driving and you
may make too many errors to be effective.

1. Press the voice recognition/hands-free

switch with a short press.

2. Say: [Beep]

“Phone book”

3. Prompt:

“Select one of the following:

new entry, edit, list names, delete or
erase all..., or say

“cancel” to return to

main menu.

”

4. Say: [Beep]

“New entry”

5. Prompt:

“Name please.”

6. Say: [Beep]

“XXXXX... (Ex. “Mary's

phone

”)” (Say a voice tag for the name

registered.)

7. Prompt:

“Adding XXXXX... (Ex.

“Mary's phone”) (Registered voice
tag). Is this correct?

”

8. Say: [Beep]

“Yes”

9. Prompt:

“Home, Work, Mobile, or

Pager?

”

10. Say: [Beep]

“Mobile” (Say “Home”,

“Work”, “Mobile”, or “Pager”, for the
desired location to be registered.)

11. Prompt:

“Mobile (Location to be

registered). Is this correct?

”

12. Say: [Beep]

“Yes”

Interior Comfort

Bluetooth® Hands-Free

6-69

MX-5_8EN7-EA-14E_Edition1 Page281
Friday, March 28 2014 3:40 PM

Black plate (282,1)

13. Prompt:

“Number, please.”

14. Say: [Beep]

“XXXXXXXXXXX

(Ex.

“555-1234”)” (Say the phone

number to be registered.)

15. Prompt:

“XXXXXXXXXXX (Ex.

“555-1234”) (Phone number
registration). Is this correct?

”

16. Say: [Beep]

“Yes”

17. Prompt:

“Number saved. Would you

like to add another number for this
entry?

”

18. Say: [Beep]

“Yes” or “No”.

19. If

“Yes”, an additional phone number

registration can be made for the same
entry.
If

“No”, the procedure proceeds to

Step 20.

20. Prompt:

“Returning to main menu.”

Making calls using the phone book

Telephone calls can be made by saying
the name of a person (voice tag) whose
phone number has been registered in
Bluetooth

Hands-Free in advance.

For the phone book setting method, refer
to (page 6-71).

1. Press the voice recognition/hands-free

switch with a short press.

2. Say: [Beep]

“Call”

3. Prompt:

“Name please.”

4. Say: [Beep]

“XXXXX... (Ex. “John's

phone

”)” (Say a voice tag registered in

the phone book.)

5. Prompt:

“Calling XXXXX... (Ex.

“John's phone”) XXXX (Ex. “at
home

”). Is this correct?” (Voice tag and

phone number location registered in
phone book).

6. Say: [Beep]

“Yes”

7. Prompt:

“Dialing”

NOTE

The

“Call” command and the voice tag can be

combined.
Ex. In Step 2, say,

“Call John's phone”, then,

Steps 3 and 4 can be skipped.

qRedialing function

Redialing the number of the person
previously dialed using the phone is
possible.

1. Press the voice recognition/hands-free

switch with a short press.

2. Say: [Beep]

“Redial”

3. Prompt:

“Dialing”

qEmergency calls

A call can be made to the emergency
phone number (911) using the voice input
command.

1. Press the voice recognition/hands-free

switch with a short press.

2. Say: [Beep]

“Emergency”

3. Prompt:

“Calling “911”, is this

correct?

”

4. Say: [Beep]

“Yes”

5. Prompt:

“Dialing”

qRefusing an incoming call

For incoming call refusal, refer to

“Receiving an incoming call” (page 6-68).

6-70

Interior Comfort

Bluetooth® Hands-Free

MX-5_8EN7-EA-14E_Edition1 Page282
Friday, March 28 2014 3:40 PM

Black plate (283,1)

qMute

The microphone can be muted during a
call.

1. Press the voice recognition/hands-free

switch with a short press.

2. Say: [Beep]

“Mute”

3. Prompt:

“Microphone muted”

Canceling mute

1. Press the voice recognition/hands-free

switch with a short press.

2. Say: [Beep]

“Mute off”

3. Prompt:

“Microphone unmuted”

qTransferring a call

Transferring a call from Hands-Free to
a mobile phone

Communication between the hands-free
unit and a mobile phone is canceled, and
the line can be switched to a standard call
using a mobile phone.

1. Press the voice recognition/hands-free

switch with a short press.

2. Say: [Beep]

“Transfer call”

3. Prompt:

“Transferred call to phone”

Transferring a call from a mobile
phone to Hands-Free

Communication between mobile phones
can be switched to the Bluetooth

Hands-

Free system.

1. Press the voice recognition/hands-free

switch with a short press.

2. Say: [Beep]

“Transfer call”

3. Prompt:

“Transferred call to Hands

Free system

”

Call waiting

A call can be interrupted to receive an
incoming call from a third party.

Call interrupt

A call can be switched to a new incoming
call.
Press the voice recognition/hands-free
switch with a short press.

NOTE

To refuse an incoming call, press the voice
recognition/hands-free switch with a long
press.

After receiving a new incoming call, the
previous call is placed on hold.

Switching calls

Switching back to the previous call can
also be done.
Press the voice recognition/hands-free
switch with a short press.

Ending the current call

Press the voice recognition/hands-free
switch during the call with a long press.

qVoice guidance interrupt operation

Voice guidance can be stopped by
pressing the voice recognition/hands-free
switch with a short press while it is being
heard. A new voice input command can
then be spoken by the user.
· Press the voice recognition/hands-free

switch with a short press.

qPhonebook Settings

Editing phone book

The data registered to the Bluetooth

Hands-Free phone book can be edited.

Interior Comfort

Bluetooth® Hands-Free

6-71

MX-5_8EN7-EA-14E_Edition1 Page283
Friday, March 28 2014 3:40 PM

Black plate (284,1)

NOTE

Do this function only when parked. It is too
distracting to attempt while driving and you
may make too many errors to be effective.

1. Press the voice recognition/hands-free

switch with a short press.

2. Say: [Beep]

“Phone book”

3. Prompt:

“Select one of the following:

new entry, edit, list names, delete or
erase all..., or say

“cancel” to return to

main menu.

”

4. Say: [Beep]

“Edit”

5. Prompt:

“Please say the name of the

entry you would like to edit, or say

“List names”..., or say “cancel” to
return to main menu.

”

6. Say: [Beep]

“XXXXX... (Ex. “Mary's

phone

”)” (Say the voice tag for the

registered name to be edited in the
phone book.)

7. Prompt:

“Home, Work, Mobile, or

Pager?

”

8. Say: [Beep]

“Home” (Say the

registered location to be edited:

“Home”, “Work”, “Mobile”, or

“Pager”).

9. Prompt:

“XXXXX... (Ex. “Mary's

phone

”) (Registered voice tag) XXXX

(Ex.

“Home”) (Registered location). Is

this correct?

”

10. Say: [Beep]

“Yes”

11. Prompt:

“The current number is

XXXXXXXXXXX (Ex.

“555-1234”)

(Currently registered number). New
number, please.

”

NOTE

If there was no previous phone number
registered to a location (Ex.

“Work”), the

prompt will only read out

“Number, please”.

12. Say: [Beep]

“XXXXXXXXXXX

(Ex.

“666-1234”)” (Say the new

phone number to be registered.)

13. Prompt:

“XXXXXXXXXXX (Ex.

“666-1234”) (The new phone number
to be registered). Is this correct?

”

14. Say: [Beep]

“Yes”

15. Prompt:

“Number changed. Would

you like to call this number, edit
another entry..., or say

“cancel” to

return to main menu.

”

Phone book data deletion

Erasing individual phone book data

Individual data registered to the
Bluetooth

Hands-Free phone book can

be cleared.

NOTE

Do this function only when parked. It is too
distracting to attempt while driving and you
may make too many errors to be effective.

1. Press the voice recognition/hands-free

switch with a short press.

2. Say: [Beep]

“Phone book”

3. Prompt:

“Select one of the following:

new entry, edit, list names, delete or
erase all..., or say

“cancel” to return to

main menu.

”

4. Say: [Beep]

“Delete”

5. Prompt:

“Please say the name of the

entry you would like to delete, or say

“List names”..., or say “cancel” to
return to main menu.

”

6-72

Interior Comfort

Bluetooth® Hands-Free

MX-5_8EN7-EA-14E_Edition1 Page284
Friday, March 28 2014 3:40 PM

Black plate (285,1)

6. Say: [Beep]

“XXXXX... (Ex. “John's

phone

”)” (Say the registered voice tag

to be deleted from the phone book.)

7. Prompt:

“Deleting XXXXX... (Ex.

“John's phone”) (Registered voice tag)
Home (Registered location). Is this
correct?

”

8. Say: [Beep]

“Yes”

9. Prompt:

“XXXXX... (Ex. “John's

phone

”) (Registered voice tag) Home

(Registered location) deleted, returning
to main menu.

”

Complete deletion of the phone book
data

All data registered to the Bluetooth

Hands-Free phone book can be erased.

NOTE

Do this function only when parked. It is too
distracting to attempt while driving and you
may make too many errors to be effective.

1. Press the voice recognition/hands-free

switch with a short press.

2. Say: [Beep]

“Phone book”

3. Prompt:

“Select one of the following:

new entry, edit, list names, delete or
erase all..., or say

“cancel” to return to

main menu.

”

4. Say: [Beep]

“Erase all”

5. Prompt:

“Are you sure you want to

erase everything from your Hands Free
system phone book?

”

6. Say: [Beep]

“Yes”

7. Prompt:

“You are about to delete

everything from your Hands Free
system phone book. Do you want to
continue?

”

8. Say: [Beep]

“Yes”

9. Prompt:

“Please wait, erasing the

Hands Free system phone book.

”

10. Prompt:

“Hands-Free system phone

book erased, returning to main
menu.

”

Read-out of names registered to the
Bluetooth

Hands-Free phone book

The Bluetooth

Hands-Free system can

read out the list of names registered to its
phone book.

1. Press the voice recognition/hands-free

switch with a short press.

2. Say: [Beep]

“Phone book”

3. Prompt:

“Select one of the following:

new entry, edit, list names, delete or
erase all..., or say

“cancel” to return to

main menu.

”

4. Say: [Beep]

“List names”

5. Prompt:

“XXXXX..., XXXXX...,

XXXXX... (Ex.

“John's phone”, Mary's

phone, Bill's phone)

” (Voice guidance

reads out the voice tags registered to
the phone book.)

Press the voice recognition/hands-free
switch during the read-out at the desired
name, and then say one of the following
voice commands to execute it.

“Continue”: Continues the voice
guidance.

“Call”: Calls the registered phone
number.

“Edit”: Edits the registered phone
number.

“Delete”: Deletes the registered phone
number.

“Previous”: Returns to the previous
phone number.

“Cancel”: Returns to main menu.

Interior Comfort

Bluetooth® Hands-Free

6-73

MX-5_8EN7-EA-14E_Edition1 Page285
Friday, March 28 2014 3:40 PM

Black plate (286,1)

6. Prompt:

“End of list, would you like

to start from the beginning?

”

7. Say: [Beep]

“No”

8. Prompt:

“Returning to main menu.”

Hands-Free Telephone Setting

qMobile phone

Mobile phone registration

For the registration of a Bluetooth

equipped mobile telephone to Bluetooth

Hands-Free.
Refer to Bluetooth® Hands-Free
Preparation on page 6-65.

Registered mobile phone read-out

Bluetooth

Hands-Free can read-out the

mobile phones registered to its system.

NOTE

Do this function only when parked. It is too
distracting to attempt while driving and you
may make too many errors to be effective.

1. Press the voice recognition/hands-free

switch with a short press.

2. Say: [Beep]

“Setup”

3. Prompt:

“Select one of the following:

pairing options, confirmation prompts,
select phone, language, or passcode...,
or say

“cancel” to return to main

menu.

”

4. Say: [Beep]

“Pairing options”

5. Prompt:

“Do you want to pair a

phone, delete a phone, or list paired
phones?

”

6. Say: [Beep]

“List phones”

7. Prompt:

“XXXXX..., XXXXX...,

XXXXX... (Ex. Phone A, phone B,
phone C)

” (The voice guidance reads

out the phone tags registered to the
hands-free system.)

6-74

Interior Comfort

Bluetooth® Hands-Free

MX-5_8EN7-EA-14E_Edition1 Page286
Friday, March 28 2014 3:40 PM

Black plate (287,1)

Press the voice recognition/hands-free
switch during the read-out at the desired
phone, and then say one of the following
voice commands to execute it.

“Select”: Programmed the mobile
phone when the voice recognition/
hands-free switch was pressed.

“Continue”: Continues the voice
guidance.

“Delete”: Deletes the registered mobile
phone.

“Previous”: Returns to the previous
mobile phone.

8. Prompt:

“End of list, would you like

to start from the beginning?

”

9. Say: [Beep]

“No”

10. Prompt:

“Returning to main menu.”

Mobile phone selection

This function is for switching to a
different mobile phone which has been
registered beforehand. The selected
mobile phone will remain in effect until
the ignition is switched off.

1. Press the voice recognition/hands-free

switch with a short press.

2. Say: [Beep]

“Setup”

3. Prompt:

“Select one of the following:

pairing options, confirmation prompts,
select phone, language, or passcode...,
or say

“cancel” to return to main

menu.

”

4. Say: [Beep]

“Select phone”

5. Prompt:

“Please say 1 (priority 1) for

XXXXX... (Ex. phone A), 2 (priority
2) for XXXXX... (Ex. phone B...)

”

6. Say: [Beep]

“2” (Say the priority

number for the mobile phone to be
used as first priority.)

7. Prompt:

“XXXXX... (Ex. phone B...)

(Registered phone tag) selected, is this
correct?

”

8. Say: [Beep]

“Yes”

9. Prompt:

“XXXXX... (Ex. phone B...)

(Phone tag) will temporarily override
phone priorities, returning to main
menu.

”

Registered mobile phone deletion

Registered mobile phones can be deleted
individually or collectively.

NOTE

Do this function only when parked. It is too
distracting to attempt while driving and you
may make too many errors to be effective.

1. Press the voice recognition/hands-free

switch with a short press.

2. Say: [Beep]

“Setup”

3. Prompt:

“Select one of the following:

pairing options, confirmation prompts,
select phone, language, or passcode...,
or say

“cancel” to return to main

menu.

”

4. Say: [Beep]

“Pairing options”

5. Prompt:

“Do you want to pair a

phone, delete a phone, or list paired
phones?

”

NOTE

A registered mobile phone can be deleted
using the registration list.

6. Say: [Beep]

“Delete phone”

7. Prompt:

“Please say 1 (priority 1) for

XXXXX... (Ex. phone A), 2 (priority
2) for XXXXX... (Ex. phone B...)

”

(The voice guidance reads out each
phone in the order of priority and the
phone tag).

Interior Comfort

Bluetooth® Hands-Free

6-75

MX-5_8EN7-EA-14E_Edition1 Page287
Friday, March 28 2014 3:40 PM

Black plate (288,1)

8. Say: [Beep]

“2” (Say the order of

priority of the mobile phone to be
deleted.)

NOTE

Say

“All” to delete all mobile phones.

9. Prompt:

“Removing XXXXX... (Ex.

phone B...) (Registered phone tag). Is
this correct?

”

10. Say: [Beep]

“Yes”

11. Prompt:

“Deleted”

qSecurity Setting

If a passcode is set, the system cannot be
activated unless the passcode is input.

NOTE

Do this function only when parked. It is too
distracting to attempt while driving and you
may make too many errors to be effective.

Passcode setting

1. Press the voice recognition/hands-free

switch with a short press.

2. Say: [Beep]

“Setup”

3. Prompt:

“Select one of the following:

pairing options, confirmation prompts,
select phone, language, or passcode...,
or say

“cancel” to return to main

menu.

”

4. Say: [Beep]

“Passcode”

5. Prompt:

“Passcode is disabled. Would

you like to enable it?

”

6. Say: [Beep]

“Yes”

7. Prompt:

“Please say a 4-digit passcode.

Remember this passcode. It will be
required to use this system.

”

8. Say: [Beep]

“XXXX” (Say a desired 4-

digit passcode,

“PCode”.)

9. Prompt:

“Passcode XXXX (Passcode,

PCode). Is this correct?

”

10. Say: [Beep]

“Yes”

11. Prompt:

“Passcode is enabled,

returning to main menu.

”

Using Bluetooth

Hands-Free with a

passcode

1. Press the voice recognition/hands-free

switch with a short press.

2. Prompt:

“Hands-Free system is locked.

State the passcode to continue.

”

3. Say: [Beep]

“XXXX” (Say the set

passcode

“PCode”.)

4. If the correct passcode is input, voice

guidance

“XXXXXX... (Ex. “Mary's

phone

”) (Phone tag) is connected” is

announced.
If the passcode is incorrect, voice
guidance

“XXXX (4-digit passcode,

Pcode) incorrect passcode, please try
again

” is announced.

Canceling the passcode

NOTE

Do this function only when parked. It is too
distracting to attempt while driving and you
may make too many errors to be effective.

1. Press the voice recognition/hands-free

switch with a short press.

2. Say: [Beep]

“Setup”

3. Prompt:

“Select one of the following:

pairing options, confirmation prompts,
select phone, language, or passcode...,
or say

“cancel” to return to main

menu.

”

6-76

Interior Comfort

Bluetooth® Hands-Free

MX-5_8EN7-EA-14E_Edition1 Page288
Friday, March 28 2014 3:40 PM

Black plate (289,1)

4. Say: [Beep]

“Passcode”

5. Prompt:

“Passcode is enabled. Would

you like to disable it?

”

6. Say: [Beep]

“Yes”

7. Prompt:

“Passcode is disabled,

returning to main menu.

”

Confirmation Prompts

The confirmation prompt confirms the
command content to the user before
advancing to the operation requested by
the user. When this function is turned on,
the system reads out the voice input
command previously received and
confirms whether the command is correct
before advancing to the command
execution.
When the confirmation prompt function is
turned on:
(Ex.

“Calling John's phone. Is this

correct?

”)

When the confirmation prompt function is
turned off:
(Ex.

“Calling John's phone.”)

NOTE

If the confirmation prompt function is turned
off when making an emergency call, the system
reads out and confirms the command before
executing it.

1. Press the voice recognition/hands-free

switch with a short press.

2. Say: [Beep]

“Setup”

3. Prompt:

“Select one of the following:

pairing options, confirmation prompts,
select phone, language, or passcode...,
or say

“cancel” to return to main

menu.

”

4. Say: [Beep]

“Confirmation prompts”

5. Prompt:

“Confirmation prompts are

on/off. Would you like to turn
confirmation prompts off/on?

”

6. Say: [Beep]

“Yes”

7. Prompt:

“Confirmation prompts are

off/on, returning to main menu.

”

qVoice recognition learning

function (Speaker enrollment)

The voice recognition learning function
enables voice recognition appropriate to
the characteristics of the user's voice.
If the recognition of the voice input
commands to the system is not adequate,
this function can largely improve the
system's voice recognition of the user. If
your voice can be recognized sufficiently
without using this function, you may not
realize the added benefit of the function.
To register your voice, the voice input
command list must be read out. Read out
the list when the vehicle is parked.
Perform the registration in as quiet a place
as possible (page 6-64).
The registration must be performed
completely. The required time is a few
minutes. The user needs to be seated in
the driver's seat with the voice input
command list for voice recognition
learning open to the page indicated below.

1. Press the voice recognition/hands-free

switch with a short press.

2. Say: [Beep]

“Voice training”

3. Prompt:

“This operation must be

performed in a quiet environment while
the vehicle is stopped. See the owner's
manual for the list of required training
phrases. Press and release the phone
button when you are ready to begin.
Press and hold the phone button to
cancel at any time.

”

Interior Comfort

Bluetooth® Hands-Free

6-77

MX-5_8EN7-EA-14E_Edition1 Page289
Friday, March 28 2014 3:40 PM

Black plate (290,1)

4. Press the voice recognition/hands-free

switch with a short press.

5. The voice guidance reads out the voice

input command number (refer to the
voice input command list for voice
recognition learning). (Ex.

“Please read

phrase 1

”)

6. Say: [Beep]

“0123456789” (Say the

voice input command for voice
recognition learning (1 to 8) according
to the voice guidance.)

7. Prompt:

“Speaker enrollment is

complete, returning to main menu.

”

Voice input command list for voice
recognition learning

When reading out, the following points
must be observed:

Read out the numbers one at a time
correctly and naturally.

(For example,

“1234” must be read out

“one, two, three, four”, not “twelve, thirty
four

”.)

Do not read out parentheses.

“ (” and

hyphens

“-” are used for separating

numbers in a phone number.

Ex.

“ (888) 555-1212” must be spoken “Eight, eight,
eight, five, five, five, one, two, one, two.

”

Phrase

Command

0123456789

(888) 555-1212

Call

Dial

Setup

Cancel

Continue

Help

NOTE

After user voice registration is completed,
voice guidance

“Speaker enrollment is

complete, returning to main menu

” is

announced.

qDTMF (dual tone multi-

frequency signal) transmission

This function is used when transmitting
DTMF via the user's voice. The receiver
of a DTMF transmission is generally a
home telephone answering machine or a
company's automated guidance call center
(When you send tone signals back
according to the voice guidance
recording).

1. Press the voice recognition/hands-free

switch with a short press.

2. Say: [Beep]

“XXXX... send” (Say

DTMF code)

3. Prompt:

“Sending XXXX... (DTMF

code)

”

6-78

Interior Comfort

Bluetooth® Hands-Free

MX-5_8EN7-EA-14E_Edition1 Page290
Friday, March 28 2014 3:40 PM

Black plate (291,1)

When Bluetooth® Hands-
Free cannot be used

Bluetooth

Hands-Free cannot be used

under the following conditions:

The mobile telephone is outside of the
communication area.

The mobile telephone has a
malfunction.

The mobile telephone is not connected
to the hands-free unit equipped on the
vehicle.

The mobile telephone battery is weak.

The mobile telephone is turned off.

The mobile telephone is placed where
radio reception is difficult.

Safety Certification

FCC ID: CB2MBLUEC07 IC:279B-
MBLUEC07
This device complies with Part 15 of the
FCC Rules and with RSS-210 of Industry
Canada. Operation is subject to the
following two conditions:
(1) This device may not cause harmful

interference, and

(2) This device must accept any

interference received, including
interference that may cause undesired
operation.

WARNING

Changes or modifications not
expressively approved by the party
responsible for compliance could void
the user's authority to operate the
equipment.

The term

“IC: ” before the radio

certification number only signifies that
Industry Canada technical specifications
were met.
The antenna used for this transmitter must
not be co-located or operating in
conjunction with any other antenna or
transmitter. End-users and installers must
be provided with installation instructions
and transmitter operating conditions for
satisfying RF exposure compliance.

Interior Comfort

Bluetooth® Hands-Free

6-79

MX-5_8EN7-EA-14E_Edition1 Page291
Friday, March 28 2014 3:40 PM

Black plate (293,1)

Sunvisors

When you need a sunvisor, lower it for
use in front.

qVanity Mirrors

To use the vanity mirror, lower the
sunvisor.

Interior Lights

qOverhead Light

Switch

Position

Overhead Light

Light off

Light is on when any door is open

Light on

qTrunk Light

Switch

Position

Trunk Light

Light off

Light on when the trunk is open

Interior Comfort

6-81

MX-5_8EN7-EA-14E_Edition1 Page293
Friday, March 28 2014 3:40 PM

Black plate (294,1)

Cup Holder

WARNING

Never use a cup holder to hold hot
liquids while the vehicle is moving:

Using a cup holder to hold hot liquids
while the vehicle is moving is
dangerous. If the contents spill, you
could be scalded.

Do not put anything other than cups or
drink cans in cup holders:

Putting objects other than cups or
drink cans in a cup holder is
dangerous.
During sudden braking or
maneuvering, occupants could be hit
and injured, or objects could be
thrown around the vehicle, causing
interference with the driver and the
possibility of an accident. Only use a
cup holder for cups or drink cans.

CAUTION

To reduce the possibility of injury in
an accident or a sudden stop, keep
cup holders closed when not in use.

To open the cup holder lid, press the
switch rearward and slide the lid open.

Switch

Multi-Pocket

Multi-pockets are on the inside of the
doors.

Multi-pocket

CAUTION

Do not use the multi-pockets for
containers without caps. The
contents may spill when the door is
opened or closed.

6-82

Interior Comfort

MX-5_8EN7-EA-14E_Edition1 Page294
Friday, March 28 2014 3:40 PM

Black plate (295,1)

Storage Compartments

WARNING

Keep storage boxes closed when
driving:

Driving with the storage boxes open
is dangerous. To reduce the
possibility of injury in an accident or
a sudden stop, keep the storage
boxes closed when driving.

Do not put articles in storage spaces
with no lid:

Putting articles in storage spaces
with no lid is dangerous as they
could be thrown around the cabin if
the vehicle is suddenly accelerated
and cause injury depending on how
the article is stored.

CAUTION

Do not leave lighters or eyeglasses in
the storage boxes while parked under
the sun. A lighter could explode or
the plastic material in eyeglasses
could deform and crack from high
temperature.

qGlove Compartment

To open the glove compartment, pull the
latch toward you.
Insert the key (auxiliary key

) and turn it

clockwise to lock, counterclockwise to
unlock.
* Advanced key equipped vehicle

Lock

Unlock

To close the glove compartment, firmly
press in the center of the glove
compartment lid.

qSeat Side Box

To open, pull the release catch.
Insert the key and turn it clockwise to
lock, counterclockwise to unlock.

Lock

Unlock

Interior Comfort

6-83

MX-5_8EN7-EA-14E_Edition1 Page295
Friday, March 28 2014 3:40 PM

Mazda MX-5 PRHT (2015 year). Instruction - part 18
