Mazda MX-5 PRHT (2015 year). Instruction

Black plate (248,1)

SIRIUS service uses an ID code to
identify your radio. This code is needed to
activate SIRIUS service, and report any
problems.

To activate you SIRIUS radio tuner, call a
SIRIUS customer service specialist at 1-
888-539-7474 or you can visit SIRIUS
online at www.siriusxm.com.

Please have the following information
ready:

SIRIUS ID (12-digit electronic serial
no., or ESN

)

Valid credit card information (may not
be required at initial sign-up)

*ESN: Electronic Serial Number

Displaying the SIRIUS ID (ESN)

When the ESN button (

) is pressed

for 1.5 seconds or longer, a 12-digit
Electronic Serial Number (ESN) for the
SIRIUS tuner is displayed.

(If the SIRIUS ID (ESN) for the tuner
does not display)
If

“ESN

FAIL

” is displayed after

pressing the ESN button (

) for 1.5

seconds or longer, contact an Authorized
Mazda Dealer.

Be sure you are parked outside with a
clear view of open sky, you will be
instructed to turn on your radio (in SAT
mode and tuned to channel 184).
Activation typically takes only 2

―5

minutes.

SIRIUS operation

All operations of the satellite radio are
conducted by means of the audio unit.

SIRIUS radio mode selection

When the satellite button (

) is

pressed during ACC ON, it will play the
last SIRIUS channel in use before the
mode was switched over to another mode
or the power was turned off.
When the satellite button (

) is

pressed in a mode other than the SIRIUS
mode, the last channel in use will be
received.
Every time the satellite button (

)

is pressed, the bank changes in the order
shown below.

SR2

SR1

SR3

NOTE

SR1, SR2 and SR3: six stations can be stored
in each bank for convenient access to your
favorite stations.

Operation in the initial state

It may take some time to start up the
equipment when it is in the initial state,
when there is a change in the user's
subscription condition, or when the
SIRIUS channel map is changed.

6-36

Interior Comfort

Audio System

MX-5_8EN7-EA-14E_Edition1 Page248
Friday, March 28 2014 3:40 PM

Black plate (249,1)

“UPDATING xx%” is displayed when the
SIRIUS channel map is changed. If the
unit is initialized or the user contract
content is changed,

“UPDATING” is

displayed. Updating could take as long as
three minutes depending on the
geographical area. When the unit is in an
initialized state, channel 184 is displayed
after the display indicates

“UPDATING 100%”. If the SIRIUS
channel map or the user contract content
is changed, the channel prior to the
change is displayed after

“UPDATING” is

displayed. After the initialization display,
it may take as long as 12 seconds to
receive channel 184.

NOTE

Do not perform the following operation while
“UPDATING” is displayed. Otherwise, the
updating procedure will be cancelled.

Turning off the audio power

Switching to other modes

Switching the ignition off

When the SIRIUS mode is switched to
another mode, or when the power is
turned off, the present channel which is
being received is stored as the last
channel.

Channel selection

Turning the manual tuning dial allows you
to select the desired receiving channel.

Turn the knob clockwise: Channel Up

Turn the knob counterclockwise:
Channel Down

Unsubscribed channel

When a selected station has not been
subscribed to, the display indicates the
following:
[CALL

888] and [539

SIRI]

(Flashes alternately)

NOTE

When the subscription contract is canceled, all
of the channels including channel 184 appear
as unsubscribed.

Invalid channel

When a selected channel is not
broadcasting, [SR

(bank number)

INVALID] is displayed for one second,
followed by [SR

(bank number)

CHANNEL], which is also displayed for
one second. The display then returns to
the previous valid channel.

NOTE

If the last channel selected has become
unavailable because of a channel update the
above indication is displayed until any button
is pressed.

Preset channel programming

(Programming with

“channel number”

display)

1. Select the desired channel to be

programmed. At this point, the
following is displayed:
[SR

(bank number)

(channel

number)]

2. Keep pressing the channel preset

button for 1.5 seconds or more.
The programming process is complete
after the channel number flashes. Then,
[SR

(bank number)] is displayed

and a beep sound is heard at the same
time.

3. [SR

(bank number)

(preset number)

(channel number)]

are displayed.

Interior Comfort

Audio System

6-37

MX-5_8EN7-EA-14E_Edition1 Page249
Friday, March 28 2014 3:40 PM

Black plate (250,1)

(Programming with

“text” display (e.g.

channel name))

1. Select the desired channel to be

programmed. At this point, the
following is displayed:
[SR

(bank number)

(selected text

(e.g. channel name))]

2. Keep pressing the channel preset

button for 1.5 seconds or more.
The programming process is complete
after the text (e.g. channel name)
flashes. Then, [SR

(bank number)]

is displayed and you will hear beep
sound at the same time.

3. [SR

(bank number)

(preset number)

(channel number)]

are displayed.

4. Three seconds later, it returns to normal

display. [SR

(bank number)

(text

(e.g. channel name))]

NOTE

Six stations can be stored in each bank, SR1,
SR2, and SR3 for convenient access to your
favorite stations.

Preset channel call-up

Press and release the channel preset
button,
[SR

(bank number)

(preset

number)

(channel number)] appears.

When the preset button is pressed during
text mode, its channel number is
displayed first for three second and then
its text is displayed.

NOTE

In the initial setting, all channels are preset to
184.

Category change

Press the category button (

)

and select the desired category.

Press the category button (

Category up

Press the category button (

Category down

Every time the category button (

) is

pressed, the category is changed over in
the order shown below.
At this time, the lowest (smallest-number)
channel within the category indicated is
received.
When the highest (or lowest) category is
reached, the category is changed over in
the order shown below.
Highest category

→ All categories →

Lowest category

NOTE

While all categories are selected, all channels
covering a category can be accessed
(Category off condition).

Channel selection within a category

If you are in a selected category and the
channel number is displayed, turning the
manual tuning dial moves the channel
number up/down in that category.

Turn the manual tuning dial clockwise:
Channel Up

Turn the manual tuning dial
counterclockwise: Channel Down

NOTE

The channel number needs to be indicated in
the display to use manual tuning dial for this
function.

6-38

Interior Comfort

Audio System

MX-5_8EN7-EA-14E_Edition1 Page250
Friday, March 28 2014 3:40 PM

Black plate (251,1)

Scan tuning

Press the scan button (

) to

automatically sample stations. Scanning
stops at each station for about five
seconds. To hold a station, press the scan
button (

) again during this interval.

NOTE

Unsubscribed channels, invalid channels
and parental lock channels are not subject
to the scan, therefore these channels will be
skipped automatically.

You can scan all channels while all
categories are selected. If you are in a
selected category, you can only scan the
channels in that category.

Channel number, channel name,
category, artist, song titles and info
display

Each time the text button (

) is

pressed during SIRIUS reception, the
display of the text data is changed over in
the order shown below.

Channel number

Channel name

Category
name

Artist name

Info

Song title

NOTE

Ten characters are displayed on one screen.

To display the rest of the characters of a
long title, press and hold the text button
(

). The display scrolls the next ten

characters. Press and hold the text button
(

) again after the last ten

characters have been displayed to return to
the beginning of the title.

(Channel number display)

When the text button (

) is

pressed while in info display mode, the
mode changes to the channel number
display mode.

(Channel name display)

When the text button (

) is

pressed while in channel number
display mode, it changes to channel
name display mode.

There are short (eight fixed characters)
and long names for the channel name.

The long name is displayed first, and
three seconds later the short name is
displayed. If there is no short name, the
long name is displayed.

To display the rest of the characters of
the channel name, press and hold the
text button (

). The display

scrolls the next ten characters. Press
and hold the text button (

) again

after the last ten characters have been
displayed to return to the beginning of
the title.

Press and hold the text button (

)

while the short name is displayed to
switch the display to the long name.

Three seconds after scrolling the long
name, the display automatically returns
to the first part of the long name. Three
more seconds and the short name
appears.

Interior Comfort

Audio System

6-39

MX-5_8EN7-EA-14E_Edition1 Page251
Friday, March 28 2014 3:40 PM

Black plate (252,1)

If there is no channel name,

“NO TITLE” is displayed.

(Category name display)

When the text button (

) is

pressed while in channel name display
mode, it changes to the category name
display mode.

There are short (eight fixed characters)
and long names for the category name.

The long name is displayed first, and
three seconds later the short name is
displayed. If there is no short name, the
long name is displayed.

To display the rest of the characters of
the category name, press and hold the
text button (

). The display

scrolls the next ten characters. Press
and hold the text button (

) again

after the last ten characters have been
displayed to return to the beginning of
the title.

Press and hold the text button (

)

while the short name is displayed to
switch the display to the long name.

Three seconds after scrolling the long
name, the display automatically returns
to display the first part of the long
name. Three more seconds and the
short name appears.

If there is no category name,

“NO CATEGORY” is displayed.

(Artist name display)

When the text button (

) is

pressed while in category name display
mode, it changes to the artist name
display mode.

To display the rest of the characters of
the artist's name, press and hold the
text button (

). The display

scrolls the next ten characters. Press
and hold the text button (

) again

after the last ten characters have been
displayed to return to the beginning of
the title.

Three seconds after scrolling the artist
name, the display automatically return
to display the first part of the artist's
name.

If there is no artist's name,

“NO ARTIST” is displayed.

(Song title display)

When the text button (

) is

pressed while in artist name display
mode, it changes to the song title
display mode.

To display the rest of the characters of
the song title, press and hold the text
button (

). The display scrolls the

next ten characters. Press and hold the
text button (

) again after the last

ten characters have been displayed to
return to the beginning of the title.

Three more seconds after scrolling the
song title, the display automatically
returns to display the first part of the
song title.

If there is no song title,

“NO SONG” is

displayed.

(INFO (such as composer's name)
display)

When the text button (

) is

pressed while in song title display
mode, it changes to the INFO display
mode.

6-40

Interior Comfort

Audio System

MX-5_8EN7-EA-14E_Edition1 Page252
Friday, March 28 2014 3:40 PM

Black plate (253,1)

To display the rest of the characters of
the composer's name, press and hold
the text button (

). The display

scrolls the next ten characters. Press
and hold the text button (

) again

after the last ten characters have been
displayed to return to the beginning of
the title.

Three seconds after scrolling the text,
the display automatically returns to
display the first part of the text.

If there is no composer name,

“NO INFO” is displayed.

Instant replay

This function allows you to rewind and
replay the program that you were
previously or are currently listening to.
Press the instant replay button (

When the seek tuning button (

) is

pressed (about 1.5 seconds), playback
starts from the beginning of the current
program.
When the seek tuning button (

) is

pressed twice, playback starts from the
beginning of the previous program.
When the seek tuning button (

) is

pressed for about 1.5 seconds or longer,
the program is reversed while the button
is being pressed.
When the seek tuning button (

) is

pressed (about 1.5 seconds), playback
starts from the beginning of the next
program. When the seek tuning button
(

) is pressed (about 1.5 seconds) while

the last program is being played, the
instant replay mode is cancelled.
When the seek tuning button (

) is

pressed for 1.5 seconds or longer, the
program is fast-forwarded while the
button is being pressed. When pressing
and holding the button until the end of the
program, the instant replay mode is
cancelled.

When the instant replay button (

) is

pressed again, playback is paused, or
playback starts if it has been paused.
Instant replay (PAUSE)
If the instant replay button (

) is

pressed while the instant replay mode is
off, instant replay mode is turned on in a
paused condition (PAUSE). Press the
instant replay button (

) again to

resume playback from the point at which
it was paused.

NOTE

If the channel is changed, the instant replay
buffer data is deleted.

After turning on the power and switching to
SIRIUS digital satellite radio mode, the
instant replay mode is not available for
several seconds after changing channels.

Initialization of ID code

If the registered ID code is forgotten,
return the ID code to the default [0000] by
performing the following steps:
Setting condition: SAT mode

(Master code input preparation)

1. Press and hold the scan button (

then press channel preset button 4.
Hold both buttons together for 1.5
seconds.

“ENTER PIN” appears for three
seconds which indicates that it is in
code input mode.

“SR1 - - - -” appears, which indicates
that it is ready for code input.

(Master code input)

4. Input the master code using the channel

preset buttons 1-4.
(The master code is already set at the
time of factory shipment.)

Interior Comfort

Audio System

6-41

MX-5_8EN7-EA-14E_Edition1 Page253
Friday, March 28 2014 3:40 PM

Black plate (254,1)

(Master code input determination)

5. Determine the master code which has

been input by pressing the scan button
(

“PIN CLEARED” appears which
indicates that the master code input has
been completed.

7. The ID code is set to the default [0000]

and the initialization process is
completed.

NOTE

Master code:
The Master Code is used to initialize or re-
initialize the ID code in the event that the code
is not set to [0000] and/or the personalized ID
code is not known. The initialization process
resets the ID code to [0000]. The master code
can potentially defeat the intent of the security
of the parental lock if it is located by persons
not authorized by the owner to access certain
channels.

SIRIUS Satellite Radio Master Code: [0913]

NOTE

When a numeric value other than the
master code is input and the scan button
(

) is pressed,

“SR1 Err” is displayed

and then it returns to the

“SR1 - - - -”

display again.

If an ID code is not input for ten seconds,
“Err” is displayed and it returns to the
former display.

Channel preset buttons 1, 2, 3, 4 and the
scan button (

) are used for inputting

the ID code. Buttons 5 and 6 cannot be
used.

Change of ID code

Setting condition: SAT mode

When changing the ID code, the new ID
code is input after the previous one is
input first.

(Registered ID code input)

1. Press and hold the scan button (

then press channel preset button 5.
Hold both buttons together for 1.5
seconds.

“ENTER PIN” appears for three
seconds which indicates that it is in
code input mode.

“SR1 - - - -” appears, which indicates
that it is ready for code input.

4. Input the registered ID code using

channel preset buttons 1-4.
Example: When the registered ID code
is

“2323”, input “2323”. At this time

“SR1 2323” is displayed.
Press 1 for the first digit, 2 for the
second, 3 for the third, and 4 for the
last digit. For example, if your number
is 2323, press 1 three times (includes
0), 2 four times, 3 three times, and 4
four times. If the display goes off while
inputting, begin from Step 1.

NOTE

The registered ID code is the default [0000] at
the time of factory shipment. If [0000] results
in

“Err” on the display, go to the

“INITIALIZATION OF ID CODE” section to
reset to [0000].

(Verification with the registered ID
code)

5. Determine the input code by pressing

the scan button (

6. If it does not match with the previously

registered code,

“SR1 Err” is displayed

and then it returns to

“SR1 - - - -”.

6-42

Interior Comfort

Audio System

MX-5_8EN7-EA-14E_Edition1 Page254
Friday, March 28 2014 3:40 PM

Black plate (255,1)

7. If it matches with the previously

registered code,

“ENTER PIN” appears

again and it switches to code input
mode.

“SR1 - - - -” appears, and it is ready for
input of the new ID code.

(New ID code input)

9. Input the new ID code using channel

preset buttons 1-4.
Example: If

“1234” is input as the new

code,

“SR1 1234” is displayed.

(New ID code input determination)

10. Determine the new ID code which

has been input by pressing the scan
button (

11.

“PIN CHANGED” appears for three
seconds which indicates that the new
ID code input has been completed.

12. It returns to the former display.

NOTE

If an ID code is not input for ten seconds,
“Err” is displayed and it returns to the
former display.

Channel preset buttons 1, 2, 3, 4 and the
scan button (

) are used for input of

the ID code. Buttons 5 and 6 cannot be
used.

Individual channel locking

If a channel is locked, the channel is
muted.

NOTE

If the registered ID code is forgotten, return
the ID code to the default [0000]. (See
“INTIALIZATION OF ID CODE” section)

(Locking a channel)

1. Select a channel to be locked by

turning the manual tuning dial.
Example: Select channel 100

(Registered ID code input preparation)

2. Press and hold the scan button (

then press channel preset button 6.
Hold both buttons together for 1.5
seconds.

“ENTER PIN” appears for three
seconds which indicates that it is in
code input mode.

“SR1 - - - -” appears which indicates
that it is ready for code input.

(Registered ID code input)

5. Input the registered ID code using

channel preset buttons 1-4. Example: If
the registered ID code is

“2323”, input

“2323”. At this time “SR1 2323” is
displayed.

(Registered ID code input
determination)

6. Determine the code which has been

input by pressing the scan button
(

7. If it does not match the registered code,

“SR1 Err” is displayed and then it
returns to

“SR1 - - - -”.

8. If it matches the registered code,

“SR1 LOCK” appears for three
seconds which indicates that the code
input has been completed.

“SR1 LOCK 100” appears which
indicates that the parental lock is
activated. At this time, mute is on and
no sound is heard.

Interior Comfort

Audio System

6-43

MX-5_8EN7-EA-14E_Edition1 Page255
Friday, March 28 2014 3:40 PM

Black plate (256,1)

NOTE

If an ID code is not input for ten seconds,
“Err” is displayed and it returns to the
former display.

Channel preset buttons 1, 2, 3, 4 and the
scan button (

) are used for input of

the ID code. Buttons 5 and 6 cannot be
used.

Lock cancellation

Setting condition: SAT mode

(Releasing a locked channel)

1. Select a channel to be released by

turning the manual tuning dial.
Example: Select the locked channel
(i.e. 100). At this time,

“SR1 LOCK 100” is displayed.

(Registered ID code input preparation)

2. Press and hold the scan button (

then press channel preset button 6.
Hold both buttons together for 1.5
seconds.

“ENTER PIN” appears for three
seconds which indicates that it is in
code input mode.

“SR1 - - - -” appears, which indicates
that it is ready for code input.

(Registered ID code input)

5. Input the registered ID code using

channel preset buttons 1-4. Example:
When the registered ID code is

“2323”,

input

“2323”. At this time “SR1 2323”

is displayed.

NOTE

“Err” is displayed, go to the

“INITIALIZATION OF ID CODE” section to
reset the ID code to [0000].

(Registered ID code input
determination)

6. Determine the input code by pressing

the scan button (

7. If it does not match the registered code,

“SR1 Err” is displayed and then it
returns to

“SR1 - - - -”.

8. If it matches the registered code,

“SR1 UNLOCK” appears for three
seconds which indicates that the code
input has been completed.

“SR1 100” appears which indicates that
the parental lock is off. At this time,
sound is heard.

NOTE

If an ID code is not input for ten seconds,
“Err” is displayed and it returns to the
former display.

Channel preset buttons 1, 2, 3, 4 and the
scan button (

) are used for input of

the ID code. Buttons 5 and 6 cannot be
used.

6-44

Interior Comfort

Audio System

MX-5_8EN7-EA-14E_Edition1 Page256
Friday, March 28 2014 3:40 PM

Black plate (258,1)

qOperating the Compact Disc (CD) Player

CD play button

Display

Repeat button

CD eject button

Play/Pause button

Random button

Folder up button

CD slot

Load button

Folder down button

Scan button

Text button

Track up/Fast-forward button

Track down/Reverse button

Type

Playable data

Music/MP3/WMA CD
player

Music data (CD-DA)

MP3/WMA file

NOTE

If a disc has both music data (CD-DA) and
MP3/WMA files, playback of the two or three
file types differs depending on how the disc
was recorded.

Inserting the CD

Insert the CD into the slot, label-side up.
The auto-loading mechanism will set the
CD and begin play.

NOTE

There will be a short lapse before play begins
while the player reads the digital signals on
the CD.

Ejecting the CD

Press the CD eject button (

) to eject the

CD.

Playback

Press the CD play button (

) to start

play when a CD is in the unit.
If a CD is not in the unit when the CD
play button (

) is pressed,

“NO DISC”

will flash on and off.

NOTE

When the load button (

) is pressed, the

CD will load and play even if the CD eject
button (

) had been previously pressed.

Pause

To stop playback, press the Play/Pause
button (

Press the button again to resume
playback.

6-46

Interior Comfort

Audio System

MX-5_8EN7-EA-14E_Edition1 Page258
Friday, March 28 2014 3:40 PM

Black plate (259,1)

Fast-forward/Reverse

Press and hold the fast-forward button
(

) to advance through a track at high

speed.
Press and hold the reverse button (

) to

reverse through a track at high speed.

Track search

Press the track up button (

) once to skip

forward to the beginning of the next track.
Press the track down button (

) once to

skip back to the beginning of the current
track.

Folder search (during MP3/WMA CD
playback)

To change to the previous folder, press the
folder down button (

), or press the

folder up button (

) to advance to the

next folder.

Music scan

During music CD playback

This function scans the titles on a CD and
plays 10 seconds of each song to aid you
in finding a song you want to listen to.

During MP3/WMA CD playback

This function scans the titles in a folder
currently being played and plays 10
seconds of each song to aid you in finding
a song you want to listen to.

Press the scan button (

) during

playback to start the scan play operation
(the track number will flash).
Press the scan button (

) again to

cancel scan playback.

NOTE

If the unit is left in scan, normal playback will
resume where scan was selected.

Repeat playback

During music CD playback

1. Press the repeat button (

) during

playback to play the current track
repeatedly.

“RPT” is displayed.

2. Press the button again to cancel the

repeat playback.

During MP3/WMA CD playback

(Track repeat)

1. Press the repeat button (

) during

playback to play the current track
repeatedly. After

“TRACK RPT” is

displayed,

“RPT” is displayed.

2. To cancel the repeat playback, press the

button again after 3 seconds.

(Folder repeat)

1. Press the repeat button (

) during

playback, and then press the button
again within 3 seconds to play the
tracks in the current folder repeatedly.
After

“FOLDER RPT” is displayed,

“F-RPT” is displayed.

2. Press the button again to cancel the

repeat playback.

Random playback

Tracks are randomly selected and played.

During music CD playback

1. Press the random button (

) during

playback to play the tracks on the CD
randomly.

“RDM” is displayed.

2. Press the button again to cancel the

random playback.

Interior Comfort

Audio System

6-47

MX-5_8EN7-EA-14E_Edition1 Page259
Friday, March 28 2014 3:40 PM

Black plate (260,1)

During MP3/WMA CD playback

(Folder random)

1. Press the random button (

) during

playback to play the tracks in the folder
randomly. After

“FOLDER RDM” is

displayed,

“RDM” is displayed.

2. To cancel the random playback, press

the button again after 3 seconds.

(CD random)

1. Press the random button (

) during

playback, and then press the button
again within 3 seconds to play the
tracks on the CD randomly. After

“DISC RDM” is displayed, “D-RDM”
is displayed.

2. Press the button again to cancel the

random playback.

Switching the display

For files with a file name and other
information that have been input, the
display switches between display of the
file name and other information each time
the text button (

) is pressed during

playback.
Music CD (If CD-TEXT capable)

Track name

Album name

Artist name

Track number/Elapsed time

MP3/WMA CD

File name

Folder name

Album name (ID3 Tag)

Song name (ID3 Tag)

Artist name (ID3 Tag)

Folder number/File number

File number/Elapsed time

NOTE

The information viewable in the display is
only CD information (such as artist name,
song title) which has been recorded to the
CD.

The system can only display one-byte
alphabetic characters. If two-byte or other
types of characters have been recorded to
the CD, they may not display correctly.

Display scroll

Only 13 characters can be displayed at
one time. To display the rest of the
characters of a long title, press and hold
the text button (

). The display

scrolls the next 13 characters. Press and
hold the text button (

) again after

the last 13 characters have been displayed
to return to the beginning of the title.

6-48

Interior Comfort

Audio System

MX-5_8EN7-EA-14E_Edition1 Page260
Friday, March 28 2014 3:40 PM

Black plate (262,1)

qOperating the In-Dash CD Changer

Disc up/Folder up button

Track down/Reverse button

Channel preset buttons

Text button

Scan button

Random button

Disc down/Folder down button

Track up/Fast-forward button

Play/Pause button

Load button

CD slot

Channel
preset buttons

Display

CD play button

CD eject button

Repeat button

Type

Playable data

Music/MP3/WMA CD
player

Music data (CD-DA)

MP3/WMA file

NOTE

If a disc has both music data (CD-DA) and
MP3/WMA files, playback of the two or three
file types differs depending on how the disc
was recorded.

Inserting the CD

The CD must be label-side up when
inserting. The auto-loading mechanism
will set the CD and begin play.

NOTE

The CD will begin playback automatically
after insertion.
A CD cannot be inserted while the display
reads

“WAIT”. A beeping sound can be heard

during this waiting time.
There will be a short lapse before play begins
while the player reads the digital signals on
the CD.

Normal insertion

1. Press the load button (

2. When

“IN” is displayed, insert the CD.

Inserting CDs into desired tray number

1. Press and hold the load button (

)

for about 2 seconds until a beep sound
is heard.

6-50

Interior Comfort

Audio System

MX-5_8EN7-EA-14E_Edition1 Page262
Friday, March 28 2014 3:40 PM

Black plate (263,1)

2. Press the channel preset button for the

desired tray number while

“WAIT” is

displayed.

3. When

“IN” is displayed, insert the CD.

NOTE

The CD cannot be inserted to the desired tray
number if the number is already occupied.

Multiple insertion

1. Press and hold the load button (

)

for about 2 seconds until a beep sound
is heard.

2. When

“IN” is displayed, insert the CD.

3. When

“IN” is displayed again, insert

the next CD.

NOTE

The first-inserted CD will be played
automatically when:

No other CD is inserted within 15 seconds
after

“IN” is displayed.

The CD trays are full.

Ejecting the CD

Normal ejection

1. Press the CD eject button (

). The

disc number and

“DISC OUT” will be

displayed.

2. Pull out the CD.

NOTE

When the CD is ejected during play, the next
CD will be played automatically.

Ejecting CDs from desired tray number

1. Press and hold the CD eject button (

)

for about 2 seconds until a beep sound
is heard.
The

“DISC OUT” display flashes.

2. Press the channel preset button for the

desired CD number for less than 5
seconds after the beep sound is heard.

3. Pull out the CD.

Multiple ejection

1. Press and hold the CD eject button (

)

for about 2 seconds until a beep sound
is heard.
The

“DISC OUT” display flashes.

2. Pull out the CD, then the next CD will

be ejected.

NOTE

CDs will be ejected starting with the one
with the lowest number.

All CDs in the tray will be ejected
continuously.

CDs can be ejected when the ignition is
switched off. Press and hold the CD eject
button (

) for about 2 seconds and all

CDs will eject.

Playback

Press the CD play button (

) to start

play when a CD is in the unit.
If a CD is not in the unit when the CD
play button (

) is pressed,

“NO DISC”

will flash on and off.

Pause

To stop playback, press the Play/Pause
button (

Press the button again to resume
playback.

Fast-forward/Reverse

Press and hold the fast-forward button
(

) to advance through a track at high

speed.
Press and hold the reverse button (

) to

reverse through a track at high speed.

Interior Comfort

Audio System

6-51

MX-5_8EN7-EA-14E_Edition1 Page263
Friday, March 28 2014 3:40 PM

Mazda MX-5 PRHT (2015 year). Instruction - part 16
