If it is low, look for coolant leaks from
the radiator and hoses.

If you find a leak or other damage, or if
coolant is still leaking:
Stop the engine and call an Authorized
Mazda Dealer.

Cooling system cap

Coolant reservoir

Cooling fan

If you find no problems, the engine is
cool, and no leaks are obvious:
Carefully add coolant as required (page
6-25).

CAUTION

If the engine continues to overheat or
frequently overheats, have the cooling
system inspected. The engine could be
seriously damaged unless repairs are
made. Consult an Authorized Mazda
Dealer.

If Trouble Arises

Overheating

7-24

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Towing Description

We recommend that towing be done only
by an Authorized Mazda Dealer or a
commercial tow-truck service.

Proper lifting and towing are necessary to
prevent damage to the vehicle. Particularly
when towing an AWD vehicle, where all
the wheels are connected to the drive train,
proper transporting of the vehicle is
absolutely essential to avoid damaging the
drive system. Government and local laws
must be followed.

Wheel dollies

A towed 2WD vehicle should have its
drive wheels (front wheels) off the ground.
If excessive damage or other conditions
prevent this, use wheel dollies.

When towing a 2WD vehicle with the rear
wheels on the ground, release the parking
brake.
Refer to Electric Parking Brake (EPB) on
page 4-90.

A towed AWD vehicle must have all its
wheels off the ground.

WARNING

Always tow an AWD vehicle with all four
wheels off the ground:
Towing an AWD vehicle with either the
front or rear wheels on the ground is
dangerous as the drive train could be
damaged, or the vehicle could trail away
from the tow truck and cause an accident.
If the drive train has been damaged,
transport the vehicle on a flatbed truck.

CAUTION

Do not tow the vehicle pointed backward

with driving wheels on the ground. This
may cause internal damage to the
transaxle.

If Trouble Arises

Emergency Towing

7-25

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Do not tow with sling-type equipment.

This could damage your vehicle. Use
wheel-lift or flatbed equipment.

If the parking brake cannot be released

when towing the vehicle, transport the
vehicle with all front and rear wheels
raised off the ground as shown in the
figure. If the vehicle is towed without
raising the wheels off the ground, the
brake system could be damaged.

Wheel dollies

Towing Hooks (Mexico)

CAUTION

The towing eyelet should be used in an

emergency (to get the vehicle out of a
ditch or a snow bank, for example).

When using the towing eyelets, always

pull the cable or chain in a straight
direction with respect to the eyelet. Never
apply a sideways force.

NOTE
When towing with chain or cable, wrap
the chain or cable with a soft cloth near
the bumper to prevent damage to the
bumper.

▼ Towing Hooks

1. Remove the towing eyelet and the lug

wrench from the luggage compartment
(page 7-3).

2. Wrap a flathead screwdriver or similar

tool with a soft cloth to prevent
damage to a painted bumper, and open
the cap located on the front or rear
bumper.
Front

If Trouble Arises

Emergency Towing

7-26

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Rear

CAUTION

Do not use excessive force as it may
damage the cap or scratch the painted
bumper surface.

NOTE
Remove the cap completely and store it
so as not to lose it.

3. Securely install the towing eyelet using

the lug wrench.
Front

Lug wrench

Towing eyelet

Rear

Lug wrench

Towing eyelet

4. Hook the towing rope to the towing

eyelet.

CAUTION

If the towing eyelet is not securely

tightened, it may loosen or
disengage from the bumper when
towing the vehicle. Make sure that
the towing eyelet is securely
tightened to the bumper.

Be careful not to damage the towing

eyelet and towing hook, vehicle body,
or transaxle system when towing
under the following conditions:

Do not tow a vehicle heavier than

yours.

Do not suddenly accelerate your

vehicle as it will apply a severe
shock to the towing eyelet and
towing hook or rope.

Do not attach any rope other than

to the towing eyelet and towing
hook.

If Trouble Arises

Emergency Towing

7-27

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

If a Warning Light Turns On or Flashes

If any warning light turns on/flashes, take appropriate action for each light. There is no
problem if the light turns off, however if the light does not turn off or turns on/flashes again,
consult an Authorized Mazda Dealer.
The details for some warnings can be viewed on the center display or multi-information
display (Type A/Type B) in the instrument cluster.

Center display

1. If the warning light is turned on, select the icon on the home screen to display the

Application screen.

2. Select “Vehicle Status Monitor”.
3. Select “Warning Guidance” to display the current warnings.
4. Select the applicable warning to view the warning details.

Multi-information display (Type A/Type B)

1. Press the INFO switch on the steering switch to display the warning indication screen.

Refer to Multi-information Display (Type A) on page 4-13.
Refer to Multi-information Display (Type B) on page 4-30.

▼ Stop Vehicle in Safe Place Immediately

If any of the following warning lights turns on, the system may have a malfunction. Stop the
vehicle in a safe place immediately and contact an Authorized Mazda Dealer.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-28

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Signal

Warning

Brake System Warning

Indication/Warning

Light

This warning has the following functions:
Parking brake warning/Warning light inspection
The light illuminates when the parking brake is applied with the ignition switched to
START or ON. It turns off when the parking brake is released.
When the light turns on
If the brake system warning light remains turned on even though the parking brake is
released, the brake fluid may be low or there could be a problem with the brake sys‐
tem. Park the vehicle in a safe place immediately and contact an Authorized Mazda
Dealer.
When the light is flashing
The light flashes if the Electric Parking Brake (EPB) has a malfunction.
If the light remains flashing even if the Electric Parking Brake (EPB) switch is oper‐
ated, consult an Authorized Mazda Dealer as soon as possible.

WARNING

Do not drive with the brake system warning light illuminated. Contact an Authorized
Mazda Dealer to have the brakes inspected as soon as possible:
Driving with the brake system warning light illuminated is dangerous. It indicates that
your brakes may not work at all or that they could completely fail at any time. If this
light remains illuminated, after checking that the parking brake is fully released, have
the brakes inspected immediately.

CAUTION

In addition, the effectiveness of the braking may diminish so you may need to depress
the brake pedal more strongly than normal to stop the vehicle.

Electronic Brake Force

Distribution System

Warning

If the electronic brake force distribution control unit determines that some compo‐
nents are operating incorrectly, the control unit may illuminate the brake system
warning light and the ABS warning light simultaneously. The problem is likely to be
the electronic brake force distribution system.

WARNING

Do not drive with both the ABS warning light and brake warning light illuminated.
Have the vehicle towed to an Authorized Mazda Dealer to have the brakes inspected as
soon as possible:
Driving when the brake system warning light and ABS warning light are illuminated
simultaneously is dangerous.
When both lights are illuminated, the rear wheels could lock more quickly in an emer‐
gency stop than under normal circumstances.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-29

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Signal

Warning

Charging System Warn‐

ing Indication/Warning

Light

If the warning light illuminates while driving, it indicates a malfunction of the alter‐
nator or of the charging system.
Drive to the side of the road and park off the right-of-way. Consult an Authorized
Mazda Dealer.

CAUTION

Do not continue driving when the charging system warning light is illuminated be‐
cause the engine could stop unexpectedly.

Engine Oil Warning

Light

This warning light indicates low engine oil pressure.

CAUTION

Do not run the engine if the oil pressure is low. Otherwise, it could result in extensive
engine damage.

If the light illuminates or the warning indication is displayed while driving:
1. Drive to the side of the road and park off the right-of-way on level ground.
2. Turn off the engine and wait 5 minutes for the oil to drain back into the oil pan.
3. Inspect the engine oil level (page 6-24). If it's low, add the appropriate amount of

engine oil while being careful not to overfill.

CAUTION

Do not run the engine if the oil level is low. Otherwise, it could result in extensive
engine damage.

4. Start the engine and check the warning light.

If the light remains illuminated even though the oil level is normal or after adding oil,
stop the engine immediately and have your vehicle towed to an Authorized Mazda
Dealer.

(Red)

High Engine Coolant

Temperature Warning

Indication/Warning

Light

The light flashes when the engine coolant temperature is extremely high, and illumi‐
nates when the engine coolant temperature increases further.
Handling Procedure
Flashing light
Drive slowly to reduce engine load until you can find a safe place to stop the vehicle
and wait for the engine to cool down.
Illuminated light
This indicates the possibility of overheating. Park the vehicle in a safe place immedi‐
ately and stop the engine.
Refer to Overheating on page 7-23.

CAUTION

Do not drive the vehicle with the high engine coolant temperature warning light illumi‐
nated. Otherwise, it could result in damage to the engine.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-30

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Signal

Warning

Power Steering Mal‐

function Indication

The message is displayed if the electric power steering has a malfunction.
If the message is displayed, stop the vehicle in a safe place and do not operate the
steering wheel. There is no problem if the message in the display turns off after a
while. Contact an Authorized Mazda Dealer if the message is displayed continuously.

NOTE



If the message is displayed, the power steering will not operate normally. In this
case, the steering wheel can still be operated, however, the operation may feel
heavy compared to normal, or the steering wheel could vibrate when turning.



Repeatedly jerking the steering wheel left and right while the vehicle is stopped or
moving extremely slowly will cause the power steering system to go into protective
mode which will make the steering feel heavy, but this does not indicate a problem.
If this occurs, park the vehicle safely and wait several minutes for the system to
return to normal.

Power Steering Mal‐

function Indicator

Light

The light illuminates/flashes if the electric power steering has a malfunction.
If the light illuminates/flashes, stop the vehicle in a safe place and do not operate the
steering wheel. There is no problem if the light turns off after a while. Contact an Au‐
thorized Mazda Dealer if the light illuminates/flashes continuously.

NOTE



If the indicator light illuminates/flashes, the power steering will not operate nor‐
mally. If this happens, the steering wheel can still be operated, however, the opera‐
tion may feel heavy compared to normal, or the steering wheel could vibrate when
turning.



▼ Contact Authorized Mazda Dealer and Have Vehicle Inspected

If any of the following warning lights or the indicator light turns on/flashes, the system may
have a malfunction. Contact an Authorized Mazda Dealer to have your vehicle inspected.

Signal

Warning

ABS Warning Light

If the ABS warning light stays on while you're driving, the ABS control unit has detected
a system malfunction. If this occurs, your brakes will function normally as if the vehicle
had no ABS.
Should this happen, consult an Authorized Mazda Dealer as soon as possible.

NOTE



When the engine is jump-started to charge the battery, uneven rpm occurs and the ABS
warning light may illuminate. If this occurs, it is the result of the weak battery and does
not indicate an ABS malfunction.
Recharge the battery.



The brake assist system does not operate while the ABS warning light is illuminated.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

7-31

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Signal

Warning

Master Warning In‐

dication/Warning

Light

With Multi-information Display (Type A/Type B)

Displays when notification of the system malfunctions is required.
Check the message indicated in the display and consult an Authorized Mazda Dealer.

Master warning
indication

Master
warning light

Master warning
indication

Multi-information Display

Type A

Type B

Indication in display and master warning light in instrument cluster are illuminated at
same time.
This indicates a malfunction with the vehicle system. Check the message indicated in the
display and consult an Authorized Mazda Dealer.
For details, refer to the explanations for the warning/indicator lights, in the warning/indi‐
cator lights section, which match the symbol in the upper part of the display.
If a message is not indicated in the display, operate the INFO switch to display the “Warn‐
ing” screen.
Refer to Message Indicated in Multi-information Display (Type A) on page 4-13.
Refer to Message Indicated in Multi-information Display (Type B) on page 4-30.

With Multi-information Display (Type C)

The light illuminates continuously if any one of the following occurs. Consult an Author‐
ized Mazda Dealer.



There is a malfunction in the battery management system.



There is a malfunction in the brake switch.

Electric Parking

Brake (EPB) Warn‐

ing Indication/
Warning Light

The warning light illuminates when the system has a malfunction. Have your vehicle in‐
spected at an Authorized Mazda Dealer.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-32

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Signal

Warning

Check Engine Light

If this light illuminates while driving, the vehicle may have a problem. It is important to
note the driving conditions when the light illuminated and consult an Authorized Mazda
Dealer.
The check engine light may illuminate in the following cases:



The engine's electrical system has a problem.



The emission control system has a problem.



The fuel tank level being very low or approaching empty.



The fuel-filler cap is missing or not tightened securely.

If the check engine light remains on, or it flashes continuously , do not drive at high
speeds and consult an Authorized Mazda Dealer as soon as possible.

WARNING

If the check engine light turns on, do not disconnect the battery cables.
If the battery cables are disconnected and then reconnected, the engine could be damaged
and catch on fire.

Automatic Trans‐

axle Warning Indi‐

cation/Warning

Light

The indication/light illuminates when the transaxle has a problem.

CAUTION

If the automatic transaxle warning indication/light illuminates, the transaxle has an electri‐
cal problem. Continuing to drive your Mazda in this condition could cause damage to your
transaxle. Consult an Authorized Mazda Dealer as soon as possible.

AWD Warning Indi‐

cation

“4WD system malfunction” is displayed

The indication is displayed under the following conditions. The system may have a mal‐
function. Have the vehicle checked at an Authorized Mazda Dealer.



When there is a malfunction in the AWD system.



When there is a large difference between the tire size of the front and rear wheels.

“4WD system high-load” is displayed

The indication is displayed under the following conditions. Park the vehicle in a safe place
and check that the warning indication light turns off, and then drive the vehicle. Contact
an Authorized Mazda Dealer if the indication is continuously displayed.



When the differential oil temperature is excessively high.



When there is a large difference between the front and rear wheel rotation, such as
when trying to remove the vehicle from mud.

(Turns on)

TCS/DSC Indicator

Light

If the light stays on, the TCS, DSC or the brake assist system may have a malfunction and
they may not operate correctly. Take your vehicle to an Authorized Mazda Dealer.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

7-33

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Signal

Warning

Air Bag/Front Seat

Belt Pretensioner

System Warning

Light

A system malfunction is indicated if the warning light constantly flashes, constantly illu‐
minates or does not illuminate at all when the ignition is switched ON. If any of these oc‐
cur, consult an Authorized Mazda Dealer as soon as possible. The system may not operate
in an accident.

WARNING

Never tamper with the air bag/pretensioner systems and always have an Authorized Mazda
Dealer perform all servicing and repairs:
Self-servicing or tampering with the systems is dangerous. An air bag/pretensioner could
accidentally activate or become disabled causing serious injury or death.

(Flashing)

Tire Pressure Moni‐

toring System

Warning Light

If the tire pressure monitoring system has a malfunction, the tire pressure warning light
flashes. Have your vehicle checked by an Authorized Mazda Dealer as soon as possible.

WARNING

If the tire pressure monitoring system warning light illuminates or flashes, or the tire pres‐
sure warning beep sound is heard, decrease vehicle speed immediately and avoid sudden
maneuvering and braking:
If the tire pressure monitoring system warning light illuminates or flashes, or the tire pres‐
sure warning beep sound is heard, it is dangerous to drive the vehicle at high speeds, or
perform sudden maneuvering or braking. Vehicle drivability could worsen and result in an
accident.
To determine if you have a slow leak or a flat, pull over to a safe position where you can
check the visual condition of the tire and determine if you have enough air to proceed to a
place where air may be added and the system monitored again by an Authorized Mazda
Dealer or a tire repair station.

Do not ignore the TPMS Warning Light:
Ignoring the TPMS warning light is dangerous, even if you know why it is illuminated. Have
the problem taken care of as soon as possible before it develops into a more serious situa‐
tion that could lead to tire failure and a dangerous accident.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-34

*Some models.

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Signal

Warning

(Amber)

KEY Warning Indi‐

cation

“Keyless System Malfunction” is displayed

This message is displayed if the advanced keyless entry & push button start system has a
problem.
Contact an Authorized Mazda Dealer.

CAUTION

If the message is indicated, or the push button start indicator light (amber) flashes, the en‐
gine may not start. If the engine cannot be started, try starting it using the emergency oper‐
ation for starting the engine, and have the vehicle inspected at an Authorized Mazda Deal‐
er as soon as possible.
Refer to Emergency Operation for Starting the Engine on page 4-9.

“Ignition is On” is displayed

This message is displayed when the driver's door is opened without switching the ignition
off.

“Key Not Detected” is displayed

This message is displayed when any of the following operations is performed with the key
out of the operational range or placed in areas inside the cabin where it is difficult for the
key to be detected.



The push button start is pressed with the ignition switched off



The ignition is switched on



All doors are closed without switching the ignition off

(Red)

(Turns on)

KEY Warning

Light

If any malfunction occurs in the keyless entry system, it illuminates continuously.

CAUTION

If the key warning indicator light illuminates or the push button start indicator light (amber)
flashes, the engine may not start. If the engine cannot be started, try starting it using the
emergency operation for starting the engine, and have the vehicle inspected at an Author‐
ized Mazda Dealer as soon as possible.
Refer to Emergency Operation for Starting the Engine on page 4-9.

(Amber)

High Beam Control

System (HBC)

Warning Indication/

Warning Light

The light remains turned on if there is a problem with the system. Have your vehicle in‐
spected at an Authorized Mazda Dealer.

NOTE

If the Forward Sensing Camera (FSC) field of view is impaired during bad weather condi‐
tions (such as rain, fog, and snow) and when the windshield is dirty, the warning indica‐
tion/warning light for the High Beam Control System (HBC) may display/turn on. Howev‐
er, this does not indicate a problem.

Blind Spot Monitor‐

ing (BSM) Warning

Indication

The Warning indication turns on if there is any malfunction in the Blind Spot Monitoring
(BSM). Have your vehicle inspected by an Authorized Mazda Dealer.

NOTE

If the vehicle is driven on a road with less traffic and few vehicles that the radar sensors
can detect, the system may pause. However, it does not indicate a malfunction.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

7-35

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Signal

Warning

Blind Spot Monitor‐

ing (BSM) OFF In‐

dicator Light

A problem in the system may be indicated under the following conditions.
Have your vehicle inspected at an Authorized Mazda Dealer.



The light does not turn on when the ignition is switched ON.



The light remains on even when the Blind Spot Monitoring (BSM) system can be oper‐
ated.



It turns on while driving the vehicle.

NOTE

If the vehicle is driven on a road with less traffic and few vehicles that the radar sensors
can detect, the system may pause (The Blind Spot Monitoring (BSM) OFF indicator light
in the instrument cluster illuminates). However, it does not indicate a malfunction.

(Amber)

Mazda Radar Cruise
Control with Stop &

Go function

(MRCC with Stop

& Go function)

Warning Indication

The message is displayed when the system has a malfunction. Have your vehicle inspect‐
ed at an Authorized Mazda Dealer.

Lane-keep Assist

System (LAS) &

Lane Departure

Warning System

(LDWS) Warning

Indication

The message is displayed when the system has a malfunction. Have your vehicle inspect‐
ed at an Authorized Mazda Dealer.
The system does not operate when the warning message is displayed.

CAUTION

 Always use tires for all wheels that are of the specified size, and the same manufacture,

brand, and tread pattern. In addition, do not use tires with significantly different wear
patterns on the same vehicle. If such improper tires are used, the system may not operate
normally.

 When an emergency spare tire is used, the system may not operate normally.

LED Headlight

Warning Light

This light illuminates if there is a malfunction in the LED headlight. Have your vehicle
inspected by an Authorized Mazda Dealer.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-36

*Some models.

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

▼ Taking Action

Take the appropriate action and verify that the warning light turns off.

Signal

Warning

Action to be taken

(Amber)

Smart Brake Support/

Smart City Brake Sup‐

port (SBS/SCBS)

Warning Indication

The light turns on if the windshield or the
radar sensor are dirty, or there is a malfunc‐
tion in the system.

Verify the reason why the warning light is
illuminated on the center display.
If the reason why the warning light is illu‐
minated is due to a dirty windshield, clean
the windshield.
If the warning light is illuminated because
of a dirty radar sensor, clean the front em‐
blem.
For any other reasons, have the vehicle in‐
spected at an Authorized Mazda Dealer.

Low Fuel Warning In‐

dication/Warning

Light

The light turns on when the remaining fuel
is about 9.0 L (2.3 US gal, 1.9 Imp gal).

NOTE

The light illumination timing may vary be‐
cause fuel inside the fuel tank moves
around according to the driving conditions
and the vehicle posture.

Add fuel.

Check Fuel Cap Warn‐

ing Indication/Warning

Light

If the check fuel cap warning light illumi‐
nates while driving, the fuel-filler cap may
not be installed properly.

Stop the engine and reinstall the fuel-filler
cap.
Refer to Refueling on page 3-30.

Engine Oil Level

Warning Light

This warning light indicates that the engine
oil level is around the MIN mark (page
6-24).

Add 1 L (0.3 US gal, 0.2 Imp gal) of en‐
gine oil (page 6-23).

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

7-37

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Signal

Warning

Action to be taken

Seat Belt Warning

Light (Front seat)

Except Mexico
The seat belt warning light turns on if the
driver or front passenger's seat is occupied
and the seat belt is not fastened with the ig‐
nition switched ON.
If the driver or front passenger's seat belt is
unfastened (only when the front passenger's
seat is occupied) and the vehicle is driven at
a speed faster than about 20 km/h (12 mph),
the warning light flashes. After a short time,
the warning light stops flashing, but re‐
mains illuminated.

NOTE



The warning light flashes for about 6
seconds if the driver's seat belt is not fas‐
tened when the ignition is switched ON.



To allow the front passenger occupant
classification sensor to function properly,
do not place and sit on an additional seat
cushion on the front passenger's seat.
The sensor may not function properly be‐
cause the additional seat cushion could
cause sensor interference.



If a small child is seated on the front pas‐
senger's seat, the warning light may not
operate.

Fasten the seat belts.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-38

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Signal

Warning

Action to be taken

Seat Belt Warning

Light (Front seat)

Mexico
The seat belt warning light turns on if the
driver or front passenger's seat is occupied
and the seat belt is not fastened with the ig‐
nition switched ON.
If the driver or front passenger's seat belt is
unfastened (only when the front passenger's
seat is occupied) and the vehicle is driven at
a speed faster than about 20 km/h (12 mph),
the warning light flashes. After a short time,
the warning light stops flashing, but re‐
mains illuminated. If a seat belt remains un‐
fastened, the warning light flashes again for
a given period of time.

NOTE



Placing heavy items on the front pas‐
senger's seat may cause the front pas‐
senger's seat belt warning function to op‐
erate depending on the weight of the
item.



To allow the front passenger seat weight
sensor to function properly, do not place
and sit on an additional seat cushion on
the front passenger's seat. The sensor
may not function properly because the
additional seat cushion could cause sen‐
sor interference.



If a small child is seated on the front pas‐
senger's seat, the warning light may not
operate.

Fasten the seat belts.

(Red)

Seat Belt Warning

Light (Rear seat)

If the rear seat belts are not fastened while
the ignition is switched ON , the driver and
the passenger are alerted by the warning
light.
The warning light operates even if there is
no passenger on the rear seat.

NOTE

If a rear seat belt is not fastened by a cer‐
tain period of time after the engine has
been started, the warning light turns off.

Fasten the seat belts.

Low Washer Fluid

Level Warning Indica‐

tion

This warning light indicates that little wash‐
er fluid remains.

Add washer fluid (page 6-27).

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

7-39

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Mazda CX-9 (2019 year). Instruction - part 37
