SRS Air Bag Deployment Criteria This chart indicates the applicable SRS equipment that will deploy depending on the type of SRS equip- ment Types of collision A severe frontal/near frontal colli- sion A severe side colli- sion *4 A roll-over/near roll-over *3 A rear collision Front seat belt preten- sioner X *1 (both sides) X *1 (impact side only) X *1 (both sides) No air bag and Driver air bag X Front pas- senger air bag X *1 Side air bag * X *2 X *1 (impact side only) Curtain air bag * X *2 X (impact side on- ly) X (both sides) X: The SRS air bag equipment is designed to deploy in a collision. * 1 (With Front Passenger Occupant Classification System) The front passenger front and side air bags and the seat belt pretensioner are designed to deploy when the front * 2 (With Front Passenger Occupant Classification System) In an angled collision, the side air bag and curtain air bag may deploy. * 3 (With Front Passenger Occupant Classification System) In a roll-over accident, the seat belt pretensioners and the curtain air bags deploy. * 4 (With Side/Curtain Air Bags) In a side collision, the seat belt pretensioners and the side/curtain air bags deploy (only on the side in which the Essential Safety Equipment SRS Air Bags 2-58 *Some models. Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21 |
