SEATS

09-13–5

09-13

Lumber support lever disassembly note

1. Remove the pin from the lumber support lever

installation part with rag.

PIN

LEVER

acxuuw00000711

SEATS

09-13–6

Passenger's Seat

.

End Of Sie

N·m {kgf·m, ft·lbf}

1

2

4

3

14

14

10

11

12

13

6

5

5

7

8

9

15

40.0—50.0
{4.08—5.09,
29.5—36.8}

21.0—26.0
{2.15—2.65,
15.5—19.7}

36.0—54.0
{3.68—5.50,
26.6—39.8}

36.0—54.0
{3.68—5.50,
26.6—39.8}

acxuuw00000926

1

Side air bag module
(See 08-10-8 SIDE AIR BAG MODULE REMOVAL/
INSTALLATION.)

2

Seat weight sensor control module
(See 08-10-11 SEAT WEIGHT SENSOR CONTROL
MODULE REMOVAL/INSTALLATION.)

3

Recliner lever

4

Front buckle

5

Side  cover

6

Headrest

7

Pole guide

8

Seat back trim

9

Seat back pad

10

Seat back frame

11

Seat cushion frame

12

Seat cushion trim

13

Seat cushion pad

14

Reverse cover

15

Slide adjuster

SEATS

09-13–7

09-13

WM: REAR SEAT

REAR SEAT REMOVAL/INSTALLATION

id091300800400

1. Remove in the order indicated in the table.
2. Install in the reverse order of removal.

.

End Of Sie

3

2

A

A

1

38.3—54.0
{3.91—5.51,
28.3—39.8}

38.3—54.0
{3.91—5.51,
28.3—39.8}

38.3—54.0
{3.91—5.51,
28.3—39.8}

38.3—54.0
{3.91—5.51,
28.3—39.8}

N·m {kgf·m, ft·lbf}

5

4

4

4

4

acxuuw00000927

1

Rear seat cushion

2

Cover

3

Remote wire

4

Bolt,Nut

5

Rear seat back

SEATS

09-13–8

REAR SEAT DISASSEMBLY/ASSEMBLY

id091300800500

1. Disassemble in the order indicated in the table.
2. Assemble in the reverse order of disassembly.

.

Child seat anchor cover disassembly note

1. Remove tab A, then remove the child seat anchor

cover.

End Of Sie

9

8

7

8

7

5

4

3

13

6

1

2

13

11

10

11

10

17

14

14

15

16

15

16

40.0—50.0
{4.08—5.09,
29.5—36.8}

21.0—26.0
{2.15—2.65,
15.5—19.7}

21.0—26.0
{2.15—2.65,
15.5—19.7}

40.0—50.0
{4.08—5.09,
29.5—36.8}

N·m {kgf·m, ft·lbf}

12

12

acxuuw00000929

1

Plate

2

Seat cushion trim

3

Seat cushion pad

4

Armrest board

5

Armrest

6

Armrest hinge

7

Seat back catch cover

8

Remote button cover

9

Child seat anchor cover
(See 09-13-8 Child seat anchor cover disassembly
note.)

10

Headrest

11

Pole guide

12

Seat back trim

13

Seat back pad

14

Seat back catch

15

Rear seat belt

16

Seat belt guide

17

Seat back frame

TAB A

TAB A

acxuuw00000931
