ON-BOARD DIAGNOSTIC [AW6A-EL, AW6AX-EL]

05-02–5

05-02

iii. Drive the vehicle in D range, at 40 km/h {25 mph} or more for 2 s or more.
iv. Go to Step 6.

• For P0736

i. Start the engine.

ii. Warm up the engine to normal operating temperature.

iii. Drive the vehicle in R range.
iv. Go to Step 6.

• For P0819

i. Start the engine.

ii. Warm up the engine to normal operating temperature.

iii. Drive the vehicle in M range, and shift the selector lever (operate up and down switches) between 1GR

to 6GR for 10 s or more.

iv. Go to Step 6.

• For P2757

i. Start the engine.

ii. Warm up the engine and ATX.

iii. Drive the vehicle in D range and make sure that the gears shift smoothly from 1GR to 6GR and TCC is

operated.

iv. Go to Step 6.

• For P2758

i. Start the engine.

ii. Warm up the engine to normal operating temperature.

iii. Drive the vehicle in D range and make sure that the gears shift smoothly from 1GR to 6GR and TCC is

no operated.

iv. Go to Step 6.

6. Gradually slow down and stop the vehicle.
7. Make sure that no DTCs occur.

End Of Sie

DTC TABLE[AW6A-EL, AW6AX-EL]

id050211800500

X: Available

DTC No.

Condition

MIL

AT

warning

light

DC

Monitor

item

Memory

function

Page

P0601

Flash ROM malfunction

X

X

1

CCM

X

 (See 05-02-10
DTC
P0601[AW6A-
EL, AW6AX-
EL])

P0603

EEPROM malfunction

X

X

1

–

X

 (See 05-02-10
DTC
P0603[AW6A-
EL, AW6AX-
EL])

P0604

RAM malfunction

X

X

1

CCM

X

 (See 05-02-11
DTC
P0604[AW6A-
EL, AW6AX-
EL])

P0706

Transaxle range (TR) switch circuit range/
performance

X

X

1

Other

X

 (See 05-02-12
DTC
P0706[AW6A-
EL, AW6AX-
EL])

P0707

Transaxle range (TR) switch circuit low input

X

X

1

CCM

X

 (See 05-02-12
DTC
P0707[AW6A-
EL, AW6AX-
EL])

P0708

Transaxle range (TR) switch circuit high input

X

X

1

CCM

X

 (See 05-02-13
DTC
P0708[AW6A-
EL, AW6AX-
EL])

1871-1U-06B(05-02).fm  5 ページ  ２００６年３月１５日　水曜日　午前１１時１８分

ON-BOARD DIAGNOSTIC [AW6A-EL, AW6AX-EL]

05-02–6

P0711

Transaxle fluid temperature (TFT) sensor
malfunction (stuck)

X

X

1

CCM

X

 (See 05-02-14
DTC
P0711[AW6A-
EL, AW6AX-
EL])

P0712

Transaxle fluid temperature (TFT) sensor circuit
malfunction (short to ground)

X

X

1

CCM

X

 (See 05-02-15
DTC
P0712[AW6A-
EL, AW6AX-
EL])

P0713

Transaxle fluid temperature (TFT) sensor circuit
malfunction (short to power/open circuit)

X

X

1

CCM

X

 (See 05-02-17
DTC
P0713[AW6A-
EL, AW6AX-
EL])

P0717

Input/turbine speed sensor circuit malfunction
(open circuit/short circuit)

X

X

1

CCM

X

 (See 05-02-18
DTC
P0717[AW6A-
EL, AW6AX-
EL])

P0722

Vehicle speed sensor (VSS) circuit malfunction
(open circuit/short circuit)

X

X

1

CCM

X

 (See 05-02-20
DTC
P0722[AW6A-
EL, AW6AX-
EL])

P0729

Gear 6 incorrect (incorrect gear ratio detected)

X

X

1

CCM

X

 (See 05-02-22
DTC
P0729[AW6A-
EL, AW6AX-
EL])

P0730

Gear 1 and engine brake operation incorrect
(incorrect gear ratio detected)

–

X

1

CCM

X

 (See 05-02-24
DTC
P0730[AW6A-
EL, AW6AX-
EL])

P0731

Gear 1 incorrect (incorrect gear ratio detected)

X

X

1

CCM

X

 (See 05-02-26
DTC
P0731[AW6A-
EL, AW6AX-
EL])

P0732

Gear 2 incorrect (incorrect gear ratio detected)

X

X

1

CCM

X

 (See 05-02-27
DTC
P0732[AW6A-
EL, AW6AX-
EL])

P0733

Gear 3 incorrect (incorrect gear ratio detected)

X

X

1

CCM

X

 (See 05-02-29
DTC
P0733[AW6A-
EL, AW6AX-
EL])

P0734

Gear 4 incorrect (incorrect gear ratio detected)

X

X

1

CCM

X

 (See 05-02-30
DTC
P0734[AW6A-
EL, AW6AX-
EL])

P0735

Gear 5 incorrect (incorrect gear ratio detected)

X

X

1

CCM

X

 (See 05-02-32
DTC
P0735[AW6A-
EL, AW6AX-
EL])

DTC No.

Condition

MIL

AT

warning

light

DC

Monitor

item

Memory

function

Page

1871-1U-06B(05-02).fm  6 ページ  ２００６年３月１５日　水曜日　午前１１時１８分

ON-BOARD DIAGNOSTIC [AW6A-EL, AW6AX-EL]

05-02–7

05-02

P0736

Gear reverse incorrect (incorrect gear ratio
detected)

–

X

1

–

X

 (See 05-02-33
DTC
P0736[AW6A-
EL, AW6AX-
EL])

P0780

Valve control solenoid circuit malfunction (valve
stuck)

–

X

1

CCM

X

 (See 05-02-35
DTC
P0780[AW6A-
EL, AW6AX-
EL])

P0817

Starter relay No.2 circuit malfunction (open
circuit/short circuit)

–

X

1

–

X

 (See 05-02-36
DTC
P0817[AW6A-
EL, AW6AX-
EL])

P0819

Manual switch/up switch/down switch circuit
malfunction (open circuit/short circuit)

–

X

1

–

X

 (See 05-02-38
DTC
P0819[AW6A-
EL, AW6AX-
EL])

P0882

TCM B+ low

–

–

1

CCM

X

 (See 05-02-40
DTC
P0882[AW6A-
EL, AW6AX-
EL])

P0883

TCM B+ high

–

–

1

CCM

X

 (See 05-02-42
DTC
P0883[AW6A-
EL, AW6AX-
EL])

P0942

Valve control solenoid circuit malfunction at D
range (valve stuck)

X

X

1

CCM

X

 (See 05-02-42
DTC
P0942[AW6A-
EL, AW6AX-
EL])

P0961

Line pressure control solenoid range/
performance (stuck)

X

X

1

CCM

X

 (See 05-02-44
DTC
P0961[AW6A-
EL, AW6AX-
EL])

P0962

Line pressure control solenoid circuit
malfunction (short to ground/open circuit)

X

X

1

CCM

X

 (See 05-02-45
DTC
P0962[AW6A-
EL, AW6AX-
EL])

P0963

Line pressure control solenoid circuit
malfunction (short to power)

X

X

1

CCM

X

 (See 05-02-47
DTC
P0963[AW6A-
EL, AW6AX-
EL])

P0973

Shift solenoid A circuit malfunction (short to
ground)

X

X

1

CCM

X

 (See 05-02-49
DTC
P0973[AW6A-
EL, AW6AX-
EL])

P0974

Shift solenoid A circuit malfunction (short to
power/open circuit)

X

X

1

CCM

X

 (See 05-02-51
DTC
P0974[AW6A-
EL, AW6AX-
EL])

DTC No.

Condition

MIL

AT

warning

light

DC

Monitor

item

Memory

function

Page

1871-1U-06B(05-02).fm  7 ページ  ２００６年３月１５日　水曜日　午前１１時１８分

ON-BOARD DIAGNOSTIC [AW6A-EL, AW6AX-EL]

05-02–8

P0976

Shift solenoid B circuit malfunction (short to
ground)

–

X

1

–

X

 (See 05-02-53
DTC
P0976[AW6A-
EL, AW6AX-
EL])

P0977

Shift solenoid B circuit malfunction (short to
power/open circuit)

–

X

1

–

X

 (See 05-02-55
DTC
P0977[AW6A-
EL, AW6AX-
EL])

P0978

Shift solenoid C range/performance (stuck)

X

X

1

CCM

X

 (See 05-02-57
DTC
P0978[AW6A-
EL, AW6AX-
EL])

P0979

Shift solenoid C circuit malfunction (short to
ground/open circuit)

X

X

1

CCM

X

 (See 05-02-59
DTC
P0979[AW6A-
EL, AW6AX-
EL])

P0980

Shift solenoid C circuit malfunction (short to
power)

X

X

1

CCM

X

 (See 05-02-61
DTC
P0980[AW6A-
EL, AW6AX-
EL])

P0981

Shift solenoid D range/performance (stuck)

X

X

1

CCM

X

 (See 05-02-63
DTC
P0981[AW6A-
EL, AW6AX-
EL])

P0982

Shift solenoid D circuit malfunction (short to
ground/open circuit)

X

X

1

CCM

X

 (See 05-02-64
DTC
P0982[AW6A-
EL, AW6AX-
EL])

P0983

Shift solenoid D circuit malfunction (short to
power)

X

X

1

CCM

X

 (See 05-02-66
DTC
P0983[AW6A-
EL, AW6AX-
EL])

P0984

Shift solenoid E range/performance (stuck)

X

X

1

CCM

X

 (See 05-02-68
DTC
P0984[AW6A-
EL, AW6AX-
EL])

P0985

Shift solenoid E circuit malfunction (short to
ground/open circuit)

X

X

1

CCM

X

 (See 05-02-69
DTC
P0985[AW6A-
EL, AW6AX-
EL])

P0986

Shift solenoid E circuit malfunction (short to
power)

X

X

1

CCM

X

 (See 05-02-71
DTC
P0986[AW6A-
EL, AW6AX-
EL])

P0997

Shift solenoid F range/performance (stuck)

X

X

1

CCM

X

 (See 05-02-73
DTC
P0997[AW6A-
EL, AW6AX-
EL])

DTC No.

Condition

MIL

AT

warning

light

DC

Monitor

item

Memory

function

Page

1871-1U-06B(05-02).fm  8 ページ  ２００６年３月１５日　水曜日　午前１１時１８分
