SECURITY AND LOCKS [KEYLESS ENTRY SYSTEM]
09–14B–11
09–14B
End Of Sie
ON-BOARD DIAGNOSTIC SYSTEM (IMMOBILIZER SYSTEM) PID/DATA MONITOR FUNCTION
E5U091467000N17
• The following items can be verified:
— Number of key ID numbers registered with the vehicle
• Use the WDS or equivalent to read the PID/data monitor.
PID/Data Monitor Table
End Of Sie
14
B1602
P1260
The instrument cluster cannot read key ID number
data normally.
15
B1601
P1260
The instrument cluster has detected unregistered
key ID number.
16
U2510
P1260
Communication error between the instrument
cluster and the PCM (no response)
U1147
P1260
Communication error between the instrument
cluster and the PCM (mismatched conditions)
21
B1213
P1260
Only one key ID number is registered.
22
B2141
P1260
Communication error between the instrument
cluster and the PCM (data transfer error)
23
B2139
P1260
ID number data in the PCM and the instrument
cluster do not match.
Not illuminated
B1342
-
Instrument cluster malfunction
DTC
Detection condition
Security light flashing pattern
WDS or equivalent
display
*
Instrument
cluster
PCM
PID name (definition)
Detected condition
NUMKEYS
(Number of key ID numbers registered with the
vehicle)
Number of key ID numbers registered: 0—8
