LEXUS RX 350 L (2019 year). Instruction - part 35

557

6-5. Using the other interior features

Inte
rior fe

ature

RX350/RX350L_U

The HomeLink

wireless control system in your vehicle has 3 buttons which can

be programmed to operate 3 different devices. Refer to the programming meth-
ods on the following pages to determine the method which is appropriate for the
device.

HomeLink

indicator light

Garage door operation indicators
HomeLink

icon

Illuminates while HomeLink

is operat-

ing.

Buttons

■

Before programming HomeLink

●

During programming, it is possible that garage doors, gates, or other
devices may operate. For this reason, make sure that people and objects
are clear of the garage door or other devices. (

P. 563)

●

It is recommended that a new battery be placed in the remote control
transmitter for more accurate programming.

●

Garage door opener motors manufactured after 1995 may be equipped
with rolling code protection. If this is the case, you may need a stepladder
or other sturdy, safe device to reach the “Learn” or “Smart” button on the
garage door opener motor.

Garage door opener

The garage door opener can be programmed to operate garage doors, gates,
entry doors, door locks, home lighting systems, security systems, and other
devices.

Programming the HomeLink

2
3

558

6-5. Using the other interior features

RX350/RX350L_U

■

Programming HomeLink

Steps

through

must

performed

within 60 seconds, otherwise the

indicator light will stop flashing and programming will not be able to be com-
pleted.

Press and release the HomeLink

button you want to program and check

that the HomeLink

indicator light flashes (orange).

Point the remote control transmit-
ter for the device at the rear view
mirror, 1 to 3 in. (25 to 75 mm)
from the HomeLink

buttons.

Keep the HomeLink

indicator light

in view while programming.

Program a device.



Programming a device other than an entry gate (for U.S.A. owners)

Press and hold the handheld transmitter button until the HomeLink

indi-

cator light changes from slowly flashing orange to rapidly flashing green
(rolling code) or continuously lit green (fixed code), then release the but-
ton.



Programming an entry gate (for U.S.A. owners)/Programming a device
in the Canadian market

Press and release the remote control transmitter button at 2 second inter-
vals, repeatedly, until the HomeLink

indicator light changes from slowly

flashing (orange) to rapidly flashing (green) (rolling code) or continuously
lit (green) (fixed code).

559

6-5. Using the other interior features

Inte
rior fe

ature

RX350/RX350L_U

Test the HomeLink

operation by pressing the newly programmed button

and observing the indicator light:

●

Indicator light illuminates: Programming of a fixed code device has com-
pleted. The garage door or other device should operate when a Home-
Link

button is pressed and released.

●

Indicator light flashes rapidly: The garage door opener motor or other
device is equipped with a rolling code. To complete programming, firmly
press and hold the HomeLink

button for 2 seconds then release it.

●

If the garage door or other device does not operate, proceed to “Pro-
gramming a rolling code system”.

Repeat the steps above to program another device for any of the remaining
HomeLink

buttons.

■

Programming a rolling code system
2 or more people may be necessary to complete rolling code programming.

Locate the “Learn” or “Smart”
button on the garage door
opener motor in the garage.

This button can usually be found

where the hanging antenna wire is

attached to the unit. The name and

color of the button may vary by man-

ufacturer. Refer to the Owner’s man-

ual supplied with the garage door

opener motor for details.

Press and release the “Learn” or
“Smart” button.
Perform within 30 seconds
after performing .

560

6-5. Using the other interior features

RX350/RX350L_U

Press and hold the desired
HomeLink

button (inside the

vehicle) for 2 seconds and
release it. Repeat this sequence
(press/hold/release) up to 3
times to complete programming.
If the garage door opener motor
operates when the HomeLink

button is pressed, the garage
door opener motor recognizes
the HomeLink

signal.

■

Enabling 2-way communication with a garage door (only available for com-
patible devices)
When enabled, 2-way communication allows you to check the status of the
opening and closing of a garage door through indicators in your vehicle.
2-way communication is only available if the garage door opener motor used
is a compatible device. (To check device compatibility, refer to www.Home-
Link.com.)

Within 5 seconds after programming the garage door opener has been
completed, if the garage door opener motor is trained to HomeLink

both garage door operation indicators will flash rapidly (green) and the
light on the garage door opener motor will blink twice, indicating that
2-way communication is enabled.

If the indicators do not flash, perform and within the first 10 presses of
the HomeLink

button after programming has been completed.

Press a programmed HomeLink

button to operate a garage door.

Within 1 minute of pressing the HomeLink

button, after the garage door

operation has stopped, press the “Learn” or “Smart” button on the garage
door opener motor. Within 5 seconds of the establishment of 2-way com-
munication with the garage door opener, both garage door operation indi-
cators in the vehicle will flash rapidly (green) and the light on the garage
door opener motor will blink twice, indicating that 2-way communication is
enabled.

2
3

561

6-5. Using the other interior features

Inte
rior fe

ature

RX350/RX350L_U

■

Reprogramming a single HomeLink

button

When the following procedure is performed, buttons which already have
devices registered to them can be overwritten:

With one hand, press and hold the desired HomeLink

button.

When the HomeLink

indicator starts flashing (orange), continue to hold

the HomeLink

button and perform “Programming HomeLink

”

(it

takes 20 seconds for the HomeLink

indicator to start flashing).

Press the appropriate HomeLink

button. The HomeLink

indicator light

should turn on.

The status of the opening and closing of
a garage door is shown by the indica-
tors.

Opening
Closing

This function is only available if the

garage door opener motor used is a

compatible device. (To check device

compatibility, refer to www.Home-

Link.com.)

The indicators can operate within approximately 820 ft. (250 m) of the garage
door. However, if there are obstructions between the garage door and the vehi-
cle, such as houses and trees, feedback signals from the garage door may not be
received.
To recall the previous door operation status, press and release either Home-

Link

buttons

and

simultaneously. The

last recorded status will be displayed for 3 seconds.

Operating HomeLink

Garage door operation indicators

Color

Status

Orange (flashing)

Currently opening/closing

Green

Opening/closing has completed

Red (flashing)

Feedback signals cannot be received

562

6-5. Using the other interior features

RX350/RX350L_U

Press and hold the 2 outside buttons for
10 seconds until the HomeLink

indi-

cator light changes from continuously
lit (orange) to rapidly flashing (green).

If you sell your vehicle, be sure to erase

the programs stored in the HomeLink

memory.

■

Codes stored in the HomeLink

memory

●

The registered codes are not erased even if the battery cable is disconnected.

●

If learning failed when registering a different code to a HomeLink

button that already

has a code registered to it, the already registered code will not be erased.

■

Before programming

●

Install a new battery in the transmitter.

●

The battery side of the transmitter must be pointed away from the HomeLink

■

Certification for the garage door opener



For vehicles sold in the U.S.A.

Erasing the entire HomeLink

memory (all three codes)

563

6-5. Using the other interior features

Inte
rior fe

ature

RX350/RX350L_U



For vehicles sold in Canada

■

When support is necessary
Visit on the web at www.homelink.com/lexus or call 1-800-355-3515.

WARNING

■

When programming a garage door or other remote control device
The garage door or other device may operate, so ensure people and objects are out of

danger to prevent injury or potential harm.

■

Conforming to federal safety standards
Do not use the HomeLink

compatible transceiver with any garage door opener or

device that lacks safety stop and reverse features as required by federal safety stan-

dards.

This includes any garage door that cannot detect an interfering object. A door or

device without these features increases the risk of death or serious injury.

■

When operating or programming HomeLink

Never allow a child to operate or play with the HomeLink

buttons.

564

6-5. Using the other interior features

RX350/RX350L_U

To turn the compass on or off, press and
hold the switch for 3 seconds.

Compass



: If equipped

The compass on the inside rear view mirror indicates the direction in which
the vehicle is heading.

Operation

Displays and directions

Display

Direction

“N”

North

“NE”

Northeast

“E”

East

“SE”

Southeast

“S”

South

“SW”

Southwest

“W”

West

“NW”

Northwest

565

6-5. Using the other interior features

Inte
rior fe

ature

RX350/RX350L_U

The direction display deviates from the true direction determined by the earth’s
magnetic field. The amount of deviation varies according to the geographic posi-
tion of the vehicle.

If you cross over a map boundary shown in illustration, the compass will deviate.

To obtain higher precision or perfect calibration, refer to the following.

■

Deviation calibration

Stop the vehicle.
Press and hold the switch for 6
seconds.

A number (1 to 15) appears on the

compass display.

Press the switch and, referring to the map above, select the number of the
zone where you are.

If the direction is displayed several seconds after adjustment, the calibration is

complete.

Calibrating the compass

566

6-5. Using the other interior features

RX350/RX350L_U

■

Circling calibration

Stop the vehicle in a place where it is safe to drive in a circle.
Press and hold the button for 9
seconds.

“C” appears on the compass display.

Drive the vehicle at 5 mph (8 km/h)
or less in a circle until a direction is
displayed.

If there is not enough space to drive

in a circle, drive around the block

until a direction is displayed.

■

Conditions unfavorable to correct operation
The compass may not show the correct direction in the following conditions:

●

The vehicle is stopped immediately after turning.

●

The vehicle is on an inclined surface.

●

The vehicle is in a place where the earth’s magnetic field is subject to interference by

artificial magnetic fields (underground car park/parking lot, under a steel tower,

between buildings, roof car park/parking lot, near an intersection, near a large vehicle,

etc.).

●

The vehicle has become magnetized.

(There is a magnet or metal object near the inside rear view mirror.)

●

The battery has been disconnected.

●

A door is open.

567

6-5. Using the other interior features

Inte
rior fe

ature

RX350/RX350L_U

WARNING

■

While driving the vehicle
Do not adjust the display. Adjust the display only when the vehicle is stopped.

■

When doing the circling calibration
Secure a wide space, and watch out for people and vehicles in the vicinity. Do not vio-

late any local traffic rules while performing circling calibration.

NOTICE

■

To avoid compass malfunctions
Do not place magnets or any metal objects near the inside rear view mirror.

Doing this may cause the compass sensor to malfunction.

■

To ensure normal operation of the compass

●

Do not perform a circling calibration of the compass in a place where the earth’s

magnetic field is subject to interference by artificial magnetic fields.

●

During calibration, do not operate electric systems (moon roof, panoramic moon

roof, power windows, etc.) as they may interfere with the calibration.

568

6-5. Using the other interior features

RX350/RX350L_U

Microphone
“SOS” button
LED light indicators

LEXUS Enform Safety Connect



: If equipped

Safety Connect is a subscription-based telematics service that uses Global
Positioning System (GPS) data and embedded cellular technology to provide
safety and security features to subscribers. Safety Connect is supported by
Lexus’ designated response center, which operates 24 hours per day, 7 days
per week.
Safety Connect service is available by subscription on select, telematics hard-
ware-equipped vehicles.
By using the Safety Connect service, you are agreeing to be bound by the
Telematics Subscription Service Agreement and its Terms and Conditions, as
in effect and amended from time to time, a current copy of which is available
at Lexus.com. All use of the Safety Connect service is subject to such then-
applicable Terms and Conditions.

System components

2
3

569

6-5. Using the other interior features

Inte
rior fe

ature

RX350/RX350L_U

Subscribers have the following Safety Connect services available:

●

Automatic Collision Notification

Helps drivers receive necessary response from emergency service providers.
(

P. 571)

: U.S. Patent No. 7,508,298 B2

●

Stolen Vehicle Location
Helps drivers in the event of vehicle theft. (

P. 571)

●

Emergency Assistance Button (“SOS”)
Connects drivers to response-center support. (

P. 571)

●

Enhanced Roadside Assistance
Provides drivers various on-road assistance. (

P. 571)

After you have signed the Telematics Subscription Service Agreement and are
enrolled, you can begin receiving services.
A variety of subscription terms is available for purchase. Contact your Lexus
dealer, call 1-800-25-LEXUS (1-800-255-3987) in the United States (1-877-
539-8777 in Puerto Rico, 1-800-26-LEXUS in Canada) or push the “SOS”
button in your vehicle for further subscription details.

Services

Subscription

570

6-5. Using the other interior features

RX350/RX350L_U

■

Safety Connect Services Information

●

Phone calls using the vehicles Bluetooth

technology will not be possible during Safety

Connect.

●

Safety Connect is available beginning Fall 2009 on select Lexus models (in the contig-

uous United States only). Contact with the Safety Connect response center is depen-

dent upon the telematics device being in operative condition, cellular connection

availability, and GPS satellite signal reception, which can limit the ability to reach the

response center or receive emergency service support. Enrollment and Telematics

Subscription Service Agreement required. A variety of subscription terms is available;

charges vary by subscription term selected and location.

●

Automatic Collision Notification, Emergency Assistance and Stolen Vehicle Location

will function in the United States, including Hawaii and Alaska, Puerto Rico and in Can-

ada, and Enhanced Roadside Assistance will function in the United States, Puerto Rico

and in Canada.

●

Automatic Collision Notification, Emergency Assistance, Stolen Vehicle Location and

Enhanced Roadside Assistance will not function in the United States Virgin Islands.

No Safety Connect services will function outside of the United States in countries other

than Canada.

For vehicles first sold in the USVI, no Safety Connect services will function in and out-

side the United States Virgin Islands.

●

Safety Connect services are not subject to section 255 of the Telecommunications Act

and the device is not TTY compatible.

■

Languages
The Safety Connect response center will offer support in multiple languages. The Safety

Connect system will offer voice prompts in English, Spanish and French. Please indicate

your language of choice when enrolling.

■

When contacting the response center
You may be unable to contact the response center if the network is busy.

When the engine switch is turned to IGNITION ON mode, the red indicator
light comes on for 2 seconds then turns off. Afterward, the green indicator light
comes on, indicating that the service is active.
The following indicator light patterns indicate specific system usage conditions:

●

Green indicator light on = Active service

●

Green indicator light flashing = Safety Connect call in process

●

Red indicator light (except at vehicle start-up) = System malfunction (contact
your Lexus dealer)

●

No indicator light (off) = Safety Connect service not active

Safety Connect LED light Indicators

571

6-5. Using the other interior features

Inte
rior fe

ature

RX350/RX350L_U

■

Automatic Collision Notification
In case of either airbag deployment or severe rear-end collision, the system is
designed to automatically call the response center. The responding agent
receives the vehicle’s location and attempts to speak with the vehicle occu-
pants to assess the level of emergency. If the occupants are unable to commu-
nicate, the agent automatically treats the call as an emergency, contacts the
nearest emergency services provider to describe the situation, and requests
that assistance be sent to the location.

■

Stolen Vehicle Location
If your vehicle is stolen, Safety Connect can work with local authorities to
assist them in locating and recovering the vehicle. After filing a police report,
call the Safety Connect response center at 1-800-25-LEXUS
(1-800-255-3987) and follow the prompts for Safety Connect to initiate this
service.
In addition to assisting law enforcement with recovery of a stolen vehicle,
Safety-Connect-equipped vehicle location data may, under certain circum-
stances, be shared with third parties to locate your vehicle. Further informa-
tion is available at Lexus.com.

■

Emergency Assistance Button (“SOS”)
In the event of an emergency on the road, push the “SOS” button to reach the
Safety Connect response center. The answering agent will determine your
vehicle’s location, assess the emergency, and dispatch the necessary assis-
tance required.

If you accidentally press the “SOS” button, tell the response-center agent that you

are not experiencing an emergency.

■

Enhanced Roadside Assistance
Enhanced Roadside Assistance adds GPS data to the already included war-
ranty-based Lexus roadside service.
Subscribers can press the “SOS” button to reach a Safety Connect response-
center agent, who can help with a wide range of needs, such as: towing, flat
tire, fuel delivery, etc. For a description of the Roadside Assistance services
and their limitations, please see the Safety Connect Terms and Conditions,
which are available at Lexus.com.

Safety Connect services

572

6-5. Using the other interior features

RX350/RX350L_U

Important! Read this information about exposure to radio frequency signals
before using Safety Connect;
The Safety Connect system installed in your vehicle is a low-power radio trans-
mitter and receiver. It receives and also sends out radio frequency (RF) signals.
In August 1996, the Federal Communications Commission (FCC) adopted RF
exposure guidelines with safety levels for mobile wireless phones. Those guide-
lines are consistent with the safety standards previously set by the following U.S.
and international standards bodies.

●

ANSI (American National Standards Institute) C95.1 [1992]

●

NCRP (National Council on Radiation Protection and Measurement) Report
86 [1986]

●

ICNIRP (International Commission on Non-Ionizing Radiation Protection)
[1996]

Those standards were based on comprehensive and periodic evaluations of the
relevant scientific literature. Over 120 scientists, engineers, and physicians from
universities, and government health agencies and industries reviewed the avail-
able body of research to develop the ANSI Standard (C95.1).
The design of Safety Connect complies with the FCC guidelines in addition to
those standards.

■

Certification for Lexus Enform
FCC ID: O6Y-CDMRF101

FCC ID: XOECDMRF101B

FCC ID: N7NGTM2
FCC WARNING:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled

environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supple-

ment C to OET65. This equipment should be installed and operated keeping the radia-

tor at least 20cm or more away from person’s body (excluding extremities: hands, wrists,

feet and ankles).

Safety information for Safety Connect

Content .. 33 34 35 36 ..
