Rear Stabilizer Bar

 Carry out the manual bleed procedure.

Active Stabilization System Bleeding (60.60.13)

C11197B Hydraulic pressure

Low fluid
Leak in high
pressure primary
circuit
Leaking reservoir
Leak in secondary
circuit
Blocked filter
Low pump flow
Blocked or kinked
suction hose

Check and top up the fluid. Rectify leaks as necessary.
Install a new filter as necessary.

Valve Block Filter (60.60.21)

 Check and replace the pump

as necessary.

Fluid Pump - 4.2L/4.4L (60.60.10)

 Check the suction hose,

rectify as necessary.

C111991 Hydraulic pressure

Pressure control
valve fault
Contaminated fluid
Kinked or blocked
return pipe
Pressure
transducer fault

For sticking/faulty valves, install a new valve block.

Valve Block (60.60.20)

 Clean the system, replace the fluid.

Check and replace the return pipe as necessary. For a
pressure transducer fault, install a new pressure transducer.

Valve Block Transducer (60.60.22)

C1A0001

Dynamic response
control module

Harness fault
Damaged isolation
switch

Check the control module harness. Refer to the electrical
guides.

C1A0004

Dynamic response
control module

Internal control
module fault

Refer to the warranty policy and procedures manual if a
module is suspect.

C1A0043

Dynamic response
control module

Internal control
module fault

Refer to the warranty policy and procedures manual if a
module is suspect.

C1A0045

Dynamic response
control module

Internal control
module fault

Refer to the warranty policy and procedures manual if a
module is suspect.

C1A0047

Dynamic response
control module

Internal control
module fault

Refer to the warranty policy and procedures manual if a
module is suspect.

C1A0052

Dynamic response
control module

New control
module

Configure the new module using the approved diagnostic
system

C1A0054

Dynamic response
control module

New control
module

Configure the new module using the approved diagnostic
system

C1A0916

Pressure transducer
signal

Pressure
transducer signal
circuit: short circuit
to ground
Pressure
transducer fault

Check the pressure transducer circuit, rectify as necessary.
Install a new pressure transducer as necessary.

Valve Block Transducer (60.60.22)

C1A0917

Pressure transducer
signal

Pressure
transducer signal
circuit: short circuit
to power
Pressure
transducer fault

Check the pressure transducer circuit, rectify as necessary.
Install a new pressure transducer as necessary.

Valve Block Transducer (60.60.22)

Pressure transducer
signal

Pressure control
valve circuit: short
circuit to power
Pressure control
valve fault
Pressure
transducer fault

For sticking/faulty valves, install a new valve block.

Valve Block (60.60.20)

 Install a new pressure transducer as

necessary.

Valve Block Transducer (60.60.22)

C1A0926

Pressure transducer
signal

Low fluid
Pressure
transducer fault
Blocked filter

Check and top up the fluid. Install a new filter as necessary.

Valve Block Filter (60.60.21)

 Install a new pressure

transducer as necessary.

Valve Block Transducer (60.60.22)

C1A9762

Lateral
accelerometer circuit

Damaged
accelerometers
Bent brackets

Check the accelerometers and brackets. Rectify as
necessary.

C1B0312

Directional control
valve 1

Directional control
valve 1 circuit:
short circuit/very
low resistance
Directional control
valve 1 circuit:
short circuit to
power

Check the directional control valve circuit. For sticking/faulty
valves, install a new valve block.

Valve Block (60.60.20)

C1B0314

Directional control
valve 1

Directional control
valve 1 circuit:
short circuit to
ground

Check the directional control valve circuit. Refer to the
electrical guides.

C1B0318

Directional control
valve 1

Directional control
valve 1 circuit: high
resistance

Check the directional control valve circuit. Refer to the
electrical guides.

C1B0319

Directional control
valve 1

Directional control
valve 1 circuit: very
low resistance
Directional control
valve 1 circuit:
short circuit to
power

Check the directional control valve circuit. Refer to the
electrical guides.

C1B031D

Directional control
valve 1

Directional control
valve 1 circuit: high
resistance

Check the directional control valve circuit. Refer to the
electrical guides.

C1B0400

Hit current
directional control
valve 1

Directional control
valve 1 circuit: high
resistance

Check the directional control valve circuit. Refer to the
electrical guides.

C1B0500

Hold current
directional control
valve 1

Directional control
valve 1 circuit: high
resistance
Air in system

Check the directional control valve circuit. Carry out the
manual bleed procedure.

Active Stabilization System Bleeding (60.60.13)

C1B0600

Off current
directional control
valve 1

Directional control
valve 1 circuit:
short circuit to
other circuits

Check the directional control valve circuit with the control
module connector disconnected. Refer to the electrical
guides.

Directional control

Directional control
valve 2

valve 2 circuit:
short circuit/very
low resistance
Directional control
valve 2 circuit:
short circuit to
power

Check the directional control valve circuit. For sticking/faulty
valves, install a new valve block.

Valve Block (60.60.20)

C1B0714

Directional control
valve 2

Directional control
valve 2 circuit:
short circuit to
ground

Check the directional control valve circuit. Refer to the
electrical guides.

C1B0718

Directional control
valve 2

Directional control
valve 2 circuit: high
resistance

Check the directional control valve circuit. Refer to the
electrical guides.

C1B0719

Directional control
valve 2

Directional control
valve 2 circuit: very
low resistance
Directional control
valve 2 circuit:
short circuit to
power

Check the directional control valve circuit. Refer to the
electrical guides.

C1B071D

Directional control
valve 2

Directional control
valve 2 circuit: high
resistance

Check the directional control valve circuit. Refer to the
electrical guides.

C1B0800

Hit current
directional control
valve 2

Directional control
valve 2 circuit: high
resistance

Check the directional control valve circuit. Refer to the
electrical guides.

C1B0900

Hold current
directional control
valve 2

Directional control
valve 2 circuit: high
resistance
Air in system

Check the directional control valve circuit. Carry out the
manual bleed procedure.

Active Stabilization System Bleeding (60.60.13)

C1B1000

Off current
directional control
valve 2

Directional control
valve 2 circuit:
short circuit to
other circuits

Check the directional control valve circuit with the control
module connector disconnected. Refer to the electrical
guides.

C1B1112

Pressure control
valve (PCV)

PCV circuit: very
low resistance
PCV circuit: short
circuit to power

Check the PCV circuit. Refer to the electrical guides.

C1B1114

Pressure control
valve (PCV)

PCV circuit: short
circuit to ground

Check the PCV circuit. Refer to the electrical guides.

C1B1118

Pressure control
valve (PCV)

PCV circuit: high
resistance

Check the PCV circuit. Refer to the electrical guides.

C1B1119

Pressure control
valve (PCV)

PCV circuit: very
low resistance
PCV circuit: short
circuit to power

Check the PCV circuit. Refer to the electrical guides.

C1B111D

Pressure control
valve (PCV)

PCV circuit: high
resistance

Check the PCV circuit. Refer to the electrical guides.

Pressure control
valve (PCV)

Low/Contaminated
fluid
PCV fault
Low flow/low
pressure pump
Pressure
transducer fault
Air in system

Check fluid level and condition. For sticking/faulty valves,
install a new valve block.

Valve Block (60.60.20)

 Check the pump operation and

hoses, rectify as necessary. Install a new pressure
transducer as necessary.

Valve Block Transducer (60.60.22)

 Carry out the manual

bleed procedure.

Active Stabilization System Bleeding (60.60.13)

C1B1164

Pressure control
valve (PCV)

PCV circuit: high
resistance

Check the PCV circuit. Refer to the electrical guides.

C1B1212

Lower lateral
accelerometer circuit

Lower lateral
accelerometer
signal circuit: short
circuit to other
circuit or power

Check the lower lateral accelerometer circuit. Refer to the
electrical guides.

C1B1214

Lower lateral
accelerometer circuit

Lower lateral
accelerometer
signal circuit: short
circuit to other
circuit or ground
Lower lateral
accelerometer fault

Check the lower lateral accelerometer circuit. Carry out the
accelerometer tests using the approved diagnostic system.
Install a new lower lateral accelerometer as necessary.

Lower Accelerometer (60.60.03)

C1B1222

Lower lateral
accelerometer circuit

Lower lateral
accelerometer
loose
Lower lateral
accelerometer
signal circuit: short
circuit to other
circuit or ground
Lower lateral
accelerometer fault

Check the lower lateral accelerometer fitment, rectify as
necessary. Check the lower lateral accelerometer circuit.
Carry out the accelerometer tests using the approved
diagnostic system. Install a new lower lateral accelerometer
as necessary.

Lower Accelerometer (60.60.03)

C1B1226

Lower lateral
accelerometer circuit

Lower lateral
accelerometer
signal circuit: short
circuit to other
circuit
Lower lateral
accelerometer fault

Check the lower lateral accelerometer circuit. Carry out the
accelerometer tests using the approved diagnostic system.
Install a new lower lateral accelerometer as necessary.

Lower Accelerometer (60.60.03)

C1B1228

Lower lateral
accelerometer circuit

Lower lateral
accelerometer
mounting damaged
Lower lateral
accelerometer
loose
Lower lateral
accelerometer fault

Check the lower lateral accelerometer fitment, rectify as
necessary. Carry out the accelerometer tests using the
approved diagnostic system. Install a new lower lateral
accelerometer as necessary.

Lower Accelerometer (60.60.03)

C1B1276

Lower lateral
accelerometer circuit

Lower lateral
accelerometer
mounting damaged
Lower lateral
accelerometer fault

Check the lower lateral accelerometer fitment, rectify as
necessary. Carry out the accelerometer tests using the
approved diagnostic system. Install a new lower lateral
accelerometer as necessary.

Lower Accelerometer (60.60.03)

Upper lateral
accelerometer
signal circuit: short Check the upper accelerometer circuit. Carry out the
