Discovery Series II

WORKSHOP MANUAL - 1999MY ON

Publication Part No. VDR 100330 NAS (6)

© Land Rover 2003

All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form,

electronic, mechanical, recording or other means without prior written permission from Land Rover.

STEERING

DESCRIPTION AND OPERATION

57-1

STEERING

DESCRIPTION AND OPERATION

Steering system component layout

RH drive shown LH drive similar

1 Fluid reservoir
2 Return line
3 Steering damper
4 Drag link
5 Drop arm
6 Steering box
7 Universal joint and split adapter

8 Universal joint and coupling
9 Steering column

10 Decouple joint
11 Intermediate shaft
12 Pressure line
13 Suction (inlet) line
14 PAS pump

STEERING

57-2

DESCRIPTION AND OPERATION

Steering column assembly and
intermediate shaft
