B183A–PASSENGER DOORS UNLOCK CONTROL CIRCUIT HIGH– CLUSTER (CONTINUED) 3. (P292) DOOR UNLOCK RELAY CONTROL CIRCUIT SHORTED TO BATTERY Disconnect the Junction Block C2 connector (on top of junction block). Turn the ignition on. Measure the voltage between ground and the (P292) Door Unlock Is there any voltage present? Yes >> Repair the (P292) Door Unlock Relay Control circuit for a short to voltage. Perform BODY VERIFICATION TEST - VER 1. (Refer to 8 No >> Replace the Junction Block in accordance with service information. Perform BODY VERIFICATION TEST - VER 1. (Refer to 8 8N - 72 POWER LOCKS - ELECTRICAL DIAGNOSTICS WK |
