INSTALLATION

1. Install the line (1) into place from the front of the

vehicle by rotating the line in order to clear
components.

2. Install the fluid cooler quick connect line (3) to the

fluid cooler (4).

3. Move the radiator, A/C assembly back in place.

4. Install the radiator, A/C assembly mounting bolts

(1).

19 - 94

PUMP - SERVICE INFORMATION

WK

5. Install the radiator core support (1).

6. Raise and support the vehicle.

7. Reconnect the rubber hose 1) to the fluid cooler

line (3) and reclamp (2) secure the line in place at
the radiator.

8. Lower the vehicle.

9. Refill the power steering fluid and bleed the sys-

tem, (Refer to 19 - STEERING/PUMP - STAN-
DARD PROCEDURE).

10. Start engine and check for leaks.

WK

PUMP - SERVICE INFORMATION

19 - 95

11. Install the grille and the 6 grille push pins (1).

12. Install the hood weather-strip seal (2) at the radi-

ator cowl.

LINE FROM COOLER TO RESERVOIR

1. install the fluid cooler hose (3) to the reservoir (1).

2. Reinstall the reservoir (1) into the mounting slot.

19 - 96

PUMP - SERVICE INFORMATION

WK

3. Install the fluid cooler quick connect line (3) to the

fluid cooler (1).

4. Refill the power steering fluid and bleed the sys-

tem, (Refer to 19 - STEERING/PUMP - STAN-
DARD PROCEDURE).

5. Start engine and check for leaks.

6. Install the grille and the 6 grille push pins (1).

7. Install the hood weather-strip seal (2) at the radia-

tor cowl.

WK

PUMP - SERVICE INFORMATION

19 - 97
