(20) Assemble front band strut. ing screw (Fig. 146). (22) Tighten band adjusting screw until band just grips clutch retainer. Verify that front/rear clutches (23) Check seal rings on reaction shaft support hub. Verify that seal rings are hooked together and that front clutch thrust washer is properly positioned (24) Lubricate oil pump body seal with petroleum jelly. Lubricate pump shaft seal lip with petroleum (25) Thread two Pilot Stud Tools C-3288-B into bolt holes in oil pump bore flange (Fig. 148). (26) Align and install oil pump gasket (Fig. 148). (27) Install oil pump (Fig. 149). Align and position pump on pilot studs. Slide pump down studs and Fig. 144 Aligning Rear Clutch Disc Lugs 1 – REAR CLUTCH DISCS TEETH Fig. 145 Installing Front/Rear Clutch Assemblies 1 – INPUT SHAFT Fig. 146 Front Band Linkage Installation 1 – BAND LEVER Fig. 147 Reaction Shaft Support Seal Rings And Front Clutch Thrust Washer 1 – REACTION SHAFT SUPPORT HUB 21 - 78 TRANSMISSION AND TRANSFER CASE WJ DISASSEMBLY AND ASSEMBLY (Continued) 2000 JEEP GRAND CHEROKEE |
