19. Disconnect the roof opening panel motor electrical connector. 20. Disconnect the rear washer hose connector. 21. NOTE: Headliner shown removed for clarity. Using a suitable adhesive tape, protect both front corners of the 22. NOTE: Headliner shown removed for clarity. Using a suitable adhesive tape, protect both rear corners of the 23. CAUTIONS: Make sure the headliner is not creased or folded where it is not protected by adhesive tape. Failure to follow this instruction may result in Make sure the headliner is fully supported during removal. Failure to follow this instruction may result in damage to the component. W ith the aid of an assistant, remove the headliner. |
