44. Install the left-hand halfshaft. 45. NOTE: Left-hand shown, right-hand similar. • NOTE: Make sure the halfshaft is aligned to the front wheel hub. Attach the wheel knuckles. 1. Reposition the lower arm. 2. Attach the wheel knuckles. 3. Install the lower arm ball joint retaining bolt. 1. Tighten to 83 Nm. 46. NOTE: Right-hand shown, left-hand similar. Attach the stabilizer bar link arms. Tighten to 48 Nm. 47. NOTE: Left-hand shown, right-hand similar. Attach the tie rod ends. Tighten to 35 Nm. 48. NOTE: Left-hand shown, right-hand similar. • NOTE: Do not tighten the front wheel hub retaining nuts at this stage. Install the front wheel hub retaining nuts. |
