81. Remove the transfer case Y bracket. 82. Remove the halfshaft seal. 83. CAUTION: To prevent damage to the transfer case internal seal, make sure the link shaft is not retracted further that 200 mm (7.87 inches) Using the special tools, remove the halfshaft. 1. Attach the special tools to the halfshaft. 2. Lever the special tools, to detach the halfshaft. 3. Install the transfer case Y bracket retaining bolt. 4. Remove the halfshaft. 84. Remove and discard the halfshaft snap ring. 85. Disconnect the right-hand catalyst monitor sensor electrical connector. |
