7A–72 AUTOMATIC TRANSMISSION (4L30–E) 3–4 Accumulator Piston Disassembled View 244RS005 Legend (1) Snap Ring (3) Spring Disassembly 1. Install the 5–8840–2277–1 (J–38559–A) cover compressor on adapter case. D Compress piston cover then remove snap ring. 242RW009 2. Install the 5–8840–2403–0 (J–41096) cover remover and 5–8840–2266–0 (J–38584) adapter to center D Use the 5–8840–0019–0 and 5–8840–2000–0 3. Remove spring and piston assembly. 242RW010 |
