6E–110 6VE1 3.5 ENGINE DRIVEABILITY AND EMISSIONS Electric Throttle Control (ETC) System Check (Cont'd) Step No Yes Value(s) Action 8 1. Warming up the engine until the ECT rise at 80 ° C 2. Ignition “OFF”. NOTE: The value check of TPS must be performed in Was a problem found? Closed throttle APS1 = 11 ∼ 15% APS2 = 85 ∼ 89% APS3 = 85 ∼ 89% TPS1 = 6 ∼ 12% TPS2 = 88 ∼ 94% Wide open throttle APS1 = 85 ∼ 89% APS2 = 11 ∼ 15% APS3 = 32 ∼ 36% TPS1 = 79 ∼ 83% TPS2 = 19 ∼ 23% Go to Step 9 System O.K. 9 1. Replace the faulty sensor. procedure in step 8. Was the problem found? — Go to Step 10 Verify repair 10 Replace the PCM. IMPORTANT: The replacement PCM must be On–Vehicle Service in Powertrain Control Module and Sensors for And also refer to letest Service Bulletin. Check to see if the Latest software is releasec or not. — Verify repair — |
