6A–42 ENGINE MECHANICAL Crankshaft and Main Bearings Removal F06RW010 Legend (1) Engine Assembly (8) Oil Pump Assembly (10) Oil Gallery (11) Flywheel (12) Rear Oil Seal Retainer 1. Remove engine assembly. D Refer to removal procedure for Engine Assembly in 2. Remove timing belt. D Refer to removal procedure for Timing Belt in this 3. Remove oil pan and crankcase. D Refer to removal procedure for Oil Pan and 4. Remove oil pipe with O-ring. |
