9A–16 SEAT BELT SYSTEM Rear Seat Strikers Removal 1. Fold the rear seat assembly to the front direction. Remove the striker cover(3) (S·W·B). 3. Remove the rear seat striker(2). Installation To install, follow the removal steps in the reverse order, 1. Tighten the striker fixing bolts to the specified torque. Torque: 40 N·m (4.1 kg·m/30 lb ft) L.W.B 1 2 S.W.B 3 2 755RW045 Removal 1. Disconnect the battery ground cable. Installation To install, follow the removal steps in the reverse order, 1. Tighten the striker fixing nuts to the specified torque. Torque: 39 N·m (4.0 kg·m/29 lb ft) Third Seat Striker 1 2 755RW041 |
