7A–52 AUTOMATIC TRANSMISSION (4L30–E) 24. Install retainer and spring assembly (22) into fourth clutch piston (21). 25. Install snap ring (23) in adapter case. D Install J–23327 and J–23327–90 fourth clutch D Seat snap ring in groove. D Remove compressor. 252RW002 252RS004 26. Install selective washer using petroleum jelly. case/main case seal ring (25). 28. Install J–38588 guide pins. D Install adapter case and center support assembly to 242RS004 29. Install thrust washer (26) into adapter case, with tangs pointing downwards. 30. Preassemble overdrive internal gear (27) and thrust bearing assembly (28) onto the turbine shaft and NOTE: Install bearing assembly, black side up. Use 31. Install overdrive carrier (30) and internal gear assembly into adapter case. 32. Install fourth clutch plates (29) in the following order: Steel, Lined, Steel, Steel, Lined, Steel. Steel plates |
