Infiniti M45 (2010 year). Manual

In order to maintain the appearance of your

vehicle, it is important to take proper care of it.
To protect the paint surfaces, wash your vehicle

as soon as you can:
● after a rainfall to prevent possible damage

from acid rain

● after driving on coastal roads
● when contaminants such as soot, bird drop-

pings, tree sap, metal particles or bugs get

on the paint surface

● when dust or mud builds up on the surface
Whenever possible, store or park your vehicle

inside a garage or in a covered area.
When it is necessary to park outside, park in a

shady area or protect the vehicle with a body

cover.
Be careful not to scratch the paint surface when

putting on or removing the body cover.

WASHING

Wash dirt off the vehicle with a wet sponge and

plenty of water. Clean the vehicle thoroughly

using a mild soap, a special vehicle soap or

general purpose dishwashing liquid mixed with

clean, lukewarm (never hot) water.

CAUTION

● Do not use car washes that use acid in the

detergent. Some car washes, especially

brushless ones, use some acid for cleaning.

The acid may react with some plastic vehicle

components, causing them to crack. This

could affect their appearance, and also could

cause them not to function properly. Always

check with your car wash to confirm that acid

is not used.

● Do not wash the vehicle with strong house-

hold soap, strong chemical detergents,

gasoline or solvents.

● Do not wash the vehicle in direct sunlight or

while the vehicle body is hot, as the surface

may become water-spotted.

● Avoid using tight-napped or rough cloths,

such as washing mitts. Care must be taken

when removing caked-on dirt or other for-

eign substances so the paint surface is not

scratched or damaged.

Rinse the vehicle thoroughly with plenty of

clean water.
Inside flanges, seams and folds on the doors,

hatches and hood are particularly vulnerable to

the effects of road salt. Therefore, these areas

must be regularly cleaned. Take care that the

drain holes in the lower edge of the door are

open. Spray water under the body and in the

wheel wells to loosen the dirt and wash away

road salt.
Avoid leaving water spots on the paint surface

by using a damp chamois to dry the vehicle.

WAXING

Regular waxing protects the paint surface and

helps retain new vehicle appearance. Polishing

is recommended to remove built-up wax residue

and to avoid a weathered appearance before

reapplying wax.
An INFINITI retailer can assist you in choosing

the proper product.
● Wax your vehicle only after a thorough wash-

ing. Follow the instructions supplied with

the wax.

● Do not use a wax containing any abrasives,

cutting compounds or cleaners that may

damage the vehicle finish.

Machine compound or aggressive polishing on

a base coat/clear coat paint finish may dull the

finish or leave swirl marks.

CLEANING EXTERIOR

7-2

Appearance and care

—

05/15/09—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

REMOVING SPOTS

Remove tar and oil spots, industrial dust, in-

sects, and tree sap as quickly as possible from

the paint surface to avoid lasting damage or

staining. Special cleaning products are avail-

able at an INFINITI retailer or any automotive

accessory stores.

UNDERBODY

In areas where road salt is used in winter, the

underbody must be cleaned regularly. This will

prevent dirt and salt from building up and

causing the acceleration of corrosion on the

underbody and suspension. Before the winter

period and again in the spring, the underseal

must be checked and, if necessary, re-treated.

GLASS

Use glass cleaner to remove smoke and dust

film from the glass surfaces. It is normal for

glass to become coated with a film after the

vehicle is parked in the hot sun. Glass cleaner

and a soft cloth will easily remove this film.

CAUTION

When cleaning the inside of the windows, do

not use sharp-edged tools, abrasive cleaners or

chlorine-based disinfectant cleaners. They

could damage the electrical conductors, radio

antenna elements or rear window defroster

elements.

ALUMINUM ALLOY WHEELS

Wash regularly with a sponge dampened in a

mild soap solution, especially during winter

months in areas where road salt is used. Salt

could discolor the wheels if not removed.

CAUTION

Follow the directions below to avoid staining or

discoloring the wheels:
● Do not use a cleaner that uses strong acid or

alkali contents to clean the wheels.

● Do not apply wheel cleaners to the wheels

when they are hot. The wheel temperature

should be the same as ambient temperature.

● Rinse the wheel to completely remove the

cleaner within 15 minutes after the cleaner is

applied.

CHROME PARTS

Clean chrome parts regularly with a non- abra-

sive chrome polish to maintain the finish.

TIRE DRESSING

INFINITI does not recommend the use of tire

dressings. Tire manufacturers apply a coating

to the tires to help reduce discoloration of the

rubber. If a tire dressing is applied to the tires,

it may react with the coating and form a com-

pound. This compound may come off the tire

while driving and stain the vehicle paint.
If you choose to use a tire dressing, take the

following precautions:
● Use a water-based tire dressing. The coating

on the tire dissolves more easily with an

oil-based tire dressing.

● Apply a light coat of tire dressing to help

prevent

from

entering

the

tire

tread/grooves (where it would be difficult to

remove).

● Wipe off excess tire dressing using a dry

towel. Make sure the tire dressing is com-

pletely removed from the tire tread/grooves.

● Allow the tire dressing to dry as recom-

mended by tire dressing manufacturer.

Appearance and care

7-3

—

05/15/09—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Occasionally remove loose dust from the inte-

rior trim, plastic parts and seats using a vacuum

cleaner or soft bristled brush. Wipe the vinyl

and leather surfaces with a clean, soft cloth

dampened in mild soap solution, then wipe

clean with a dry soft cloth.
Regular care and cleaning is required in order to

maintain the appearance of the leather.
Before using any fabric protector, read the

manufacturer’s recommendations. Some fabric

protectors contain chemicals that may stain or

bleach the seat material.
Use a cloth dampened only with water, to clean

the meter and gauge lens.

WARNING

Do not use water or acidic cleaners (hot steam

cleaners) on the seat. This can damage the seat

or occupant classification sensor. This can also

affect the operation of the air bag system and

result in serious personal injury.

CAUTION

● Never use benzine, thinner, or any similar

material.

● Small dirt particles can be abrasive and dam-

aging to the leather surfaces and should be

removed promptly. Do not use saddle soap,

car waxes, polishes, oils, cleaning fluids,

solvents, detergents or ammonia-based

cleaners as they may damage the leather’s

natural finish.

● Never use fabric protectors unless recom-

mended by the manufacturer.

● Do not use glass or plastic cleaner on meter

or gauge lens covers. It may damage the lens

cover.

AIR FRESHENERS

Most air fresheners use a solvent that could

affect the vehicle interior. If you use an air

freshener, take the following precautions:
● Hanging-type air fresheners can cause per-

manent discoloration when they contact ve-

hicle interior surfaces. Place the air fresh-

ener in a location that allows it to hang free

and not contact an interior surface.

● Liquid-type air fresheners typically clip on

the vents. These products can cause imme-

diate damage and discoloration when

spilled on interior surfaces.

Carefully read and follow the manufacturer’s

instructions before using air fresheners.

FLOOR MATS

The use of INFINITI floor mats can extend the life

of your vehicle carpet and make it easier to

clean the interior.

No matter what mats are

used, be sure they are fitted for your vehicle and

are properly positioned in the footwell to pre-

vent interference with pedal operation. Mats

should be maintained with regular cleaning and

replaced if they become excessively worn.

CLEANING INTERIOR

7-4

Appearance and care

—

05/15/09—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Floor mat positioning aid

This vehicle includes front floor mat brackets to

act as floor mat positioning aid. INFINITI floor

mats have been specially designed for your

vehicle model. The front floor mats have grom-

met holes in them. To install, position the mat

by placing the floor mat bracket hook through

the floor mat grommet hole while centering the

mat in the footwell.
Periodically check to make certain that the mats

are properly positioned.

SEAT BELTS

The seat belts can be cleaned by wiping them

with a sponge dampened in a mild soap solu-

tion. Allow the belts to dry completely in the

shade before using them.
See “SEAT BELTS” in the “1. Safety — Seats,

seat belts and supplemental restraint system”

section.

WARNING

Do not allow wet seat belts to roll up in the

retractor. NEVER use bleach, dye, or chemical

solvents to clean the seat belts, since these

materials may severely weaken the seat belt

webbing.

REAR SUNSHADE (if so equipped)

Screen

To clean, fully extend the rear sunshade screen

and clean dust or dirt off using a vacuum

cleaner from the inside of the compartment.

See “REAR SUNSHADE” in the “2. Instruments

and controls” section for rear sunshade opera-

tion.

CAUTION

Be careful not to damage the screen while

cleaning.

Cover

Wipe the rear sunshade cover with a clean, dry

cloth.

CAUTION

Never use benzine, thinner or any other neutral

detergent as this may deform the cover.

SAI0031

Appearance and care

7-5

—

05/19/09—tbrooks

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOST COMMON FACTORS

CONTRIBUTING TO VEHICLE

CORROSION

● The accumulation of moisture-retaining dirt

and debris in body panel sections, cavities,

and other areas.

● Damage to paint and other protective coat-

ings caused by gravel and stone chips or

minor traffic accidents.

ENVIRONMENTAL FACTORS INFLUENCE

THE RATE OF CORROSION
Moisture

Accumulation of sand, dirt and water on the

vehicle body underside can accelerate corro-

sion. Wet floor coverings will not dry completely

inside the vehicle, and should be removed for

drying to avoid floor panel corrosion.

Relative humidity

Corrosion will be accelerated in areas of high

relative humidity, especially those areas where

the temperatures stay above freezing where

atmospheric pollution exists, or where road salt

is used.

Temperature

A temperature increase will accelerate the rate

of corrosion to those parts which are not well

ventilated.

Air pollution

Industrial pollution, the presence of salt in the

air in coastal areas, or heavy road salt use will

accelerate the corrosion process. Road salt will

also accelerate the disintegration of paint sur-

faces.

TO PROTECT YOUR VEHICLE FROM

CORROSION

● Wash and wax your vehicle often to keep the

vehicle clean.

● Always check for minor damage to the paint

and repair it as soon as possible.

● Keep drain holes at the bottom of the doors

open to avoid water accumulation.

● Check the underbody for accumulation of

sand, dirt or salt. If present, wash with water

as soon as possible.

CAUTION

● NEVER remove dirt, sand or other debris from

the passenger compartment by washing it

out with a hose. Remove dirt with a vacuum

cleaner.

● Never allow water or other liquids to come in

contact with electronic components inside

the vehicle as this may damage them.

Chemicals used for road surface deicing are

extremely corrosive. They accelerate corrosion

and deterioration of underbody components

such as the exhaust system, fuel and brake

lines, brake cables, floor pan and fenders.
In winter, the underbody must be cleaned peri-

odically.
For additional protection against rust and cor-

rosion, which may be required in some areas,

consult an INFINITI retailer.

CORROSION PROTECTION

7-6

Appearance and care

—

05/15/09—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Your new INFINITI has been designed to have

minimum maintenance requirements with long

service intervals to save you both time and

money. However, some day-to-day and regular

maintenance is essential to maintain your IN-

FINITI’s fine mechanical condition, as well as its

emission and engine performance.
It is the owner’s responsibility to make sure that

the scheduled maintenance, as well as general

maintenance, is performed.
As the vehicle owner, you are the only one who

can ensure that your vehicle receives the proper

maintenance. You are a vital link in the mainte-

nance chain.

SCHEDULED MAINTENANCE

For your convenience, both required and op-

tional scheduled maintenance items are de-

scribed and listed in your “INFINITI Service and

Maintenance Guide”. You must refer to that

guide to ensure that necessary maintenance is

performed on your INFINITI at regular intervals.

GENERAL MAINTENANCE

General maintenance includes those items

which should be checked during normal day-to-

day operation. They are essential for proper

vehicle operation. It is your responsibility to

perform these procedures regularly as pre-

scribed.
Performing general maintenance checks re-

quires minimal mechanical skill and only a few

general automotive tools.
These checks or inspections can be done by

yourself, a qualified technician or, if you prefer,

an INFINITI retailer.

WHERE TO GO FOR SERVICE

If maintenance service is required or your ve-

hicle appears to malfunction, have the systems

checked and serviced by an INFINITI retailer.
INFINITI technicians are well-trained specialists

and are kept up-to-date with the latest service

information through technical bulletins, service

tips, and in-retailer information systems. They

are completely qualified to work on INFINITI

vehicles

before work begins.

You can be confident that an INFINITI retailer’s

service department performs the best job to

meet the maintenance requirements on your

vehicle — in a reliable and economical way.

During the normal day-to-day operation of the

vehicle, general maintenance should be per-

formed regularly as prescribed in this section. If

you detect any unusual sounds, vibrations or

smell, be sure to check for the cause or have an

INFINITI retailer do it promptly. In addition, you

should notify an INFINITI retailer if you think

that repairs are required.
When performing any checks or maintenance

work, see “MAINTENANCE PRECAUTIONS” later

in this section.

EXPLANATION OF MAINTENANCE

ITEMS

Additional information on the following items

with “*” is found later in this section.

Outside the vehicle

The maintenance items listed here should be

performed from time to time, unless otherwise

specified.
Doors and engine hood: Check that all doors

and the engine hood operate properly. Also

ensure that all latches lock securely. Lubricate

hinges, latches, latch pins, rollers and links if

necessary. Make sure that the secondary latch

keeps the hood from opening when the primary

latch is released.

MAINTENANCE REQUIREMENT

GENERAL MAINTENANCE

8-2

Maintenance and do-it-yourself

—

05/15/09—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

When driving in areas using road salt or other

corrosive materials, check lubrication fre-

quently.
Lights*: Clean the headlights on a regular

basis. Make sure that the headlights, stop

lights, tail lights, turn signal lights, and other

lights are all operating properly and installed

securely. Also check headlight aim.
Road wheel nuts (lug nuts)*: When checking the

tires, make sure no wheel nuts are missing, and

check for any loose wheel nuts. Tighten if

necessary.
Tire rotation*: Tires should be rotated every

7,500 miles (12,000 km).
Tires*: Check the pressure with a gauge often

and always prior to long distance trips. If nec-

essary, adjust the pressure in all tires, includ-

ing the spare, to the pressure specified. Check

carefully for damage, cuts or excessive wear.
Tire Pressure Monitoring System (TPMS) trans-

mitter components: Replace the TPMS transmit-

ter grommet seal, valve core and cap when the

tires are replaced due to wear or age.
Wheel alignment and balance: If the vehicle

should pull to either side while driving on a

straight and level road, or if you detect uneven

or abnormal tire wear, there may be a need for

wheel alignment.

If the steering wheel or seat vibrates at normal

highway speeds, wheel balancing may be

needed.
For additional information regarding tires, refer

to “Important Tire Safety Information” (US) or

“Tire Safety Information” (Canada) in the

INFINITI Warranty Information Booklet.
Windshield: Clean the windshield on a regular

basis. Check the windshield at least every six

months for cracks or other damage. Have a

damaged windshield repaired by a qualified

repair facility.
Windshield wiper blades*: Check for cracks or

wear if they do not wipe properly.

Inside the vehicle

The maintenance items listed here should be

checked on a regular basis, such as when

performing scheduled maintenance, cleaning

the vehicle, etc.
Accelerator pedal: Check the pedal for smooth

operation and make sure the pedal does not

catch or require uneven effort. Keep the floor

mat away from the pedal.
Automatic transmission P (Park) position

mechanism: On a fairly steep hill, check that

the vehicle is held securely with the selector

lever in the P (Park) position without applying

any brakes.
Brake pedal: Check the pedal for smooth opera-

tion. If the brake pedal suddenly goes down

further than normal, the pedal feels spongy or

the vehicle seems to take longer to stop, see an

INFINITI retailer immediately. Keep the floor mat

away from the pedal.
Brakes: Check that the brakes do not pull the

vehicle to one side when applied.
Parking brake: Check the parking brake opera-

tion regularly. The vehicle should be securely

held on a fairly steep hill with only the parking

brake applied. If the parking brake needs ad-

justment, see an INFINITI retailer.
Seat belts: Check that all parts of the seat belt

system (for example, buckles, anchors, adjust-

ers and retractors) operate properly and

smoothly, and are installed securely. Check the

belt webbing for cuts, fraying, wear or damage.
Seats: Check seat position controls such as

seat adjusters, seatback recliner, etc. to ensure

they operate smoothly and that all latches lock

securely in every position. Check that the head

restraints move up and down smoothly and that

the locks (if so equipped) hold securely in all

latched positions.

Maintenance and do-it-yourself

8-3

—

05/15/09—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Steering wheel: Check for changes in the steer-

ing conditions, such as excessive free play,

hard steering or strange noises.
Warning lights and chimes: Make sure that all

warning lights and chimes are operating prop-

erly.
Windshield defroster: Check that the air comes

out of the defroster outlets properly and in

sufficient quantity when operating the heater or

air conditioner.
Windshield wiper and washer*: Check that the

wipers and washer operate properly and that

the wipers do not streak.

Under the hood and vehicle

The maintenance items listed here should be

checked periodically (for example, each time

you check the engine oil or refuel).
Battery*: Check the fluid level in each cell. It

should be between the MAX and MIN lines.

Vehicles operated in high temperatures or un-

der severe condition require frequent checks of

the battery fluid level.
Brake fluid level*: Make sure that the brake

fluid level is between the MAX and MIN lines on

the reservoir.
Engine coolant level*: Check the coolant level

when the engine is cold.

Engine drive belts*: Make sure that the drive

belts are not frayed, worn, cracked or oily.
Engine oil level*: Check the level after parking

the vehicle on a level surface and turning off the

engine. Wait more than 10 or 15 minutes for the

oil to drain back into the oil pan.
Exhaust system: Make sure there are no loose

supports, cracks or holes. If the sound of the

exhaust seems unusual or there is a smell of

exhaust fumes, immediately have the exhaust

system inspected by an INFINITI retailer. (See

“PRECAUTIONS WHEN STARTING AND DRIVING”

in the “5. Starting and driving” section for

exhaust gas (carbon monoxide).)
Fluid leaks: Check under the vehicle for fuel, oil,

water or other fluid leaks after the vehicle has

been parked for a while. Water dripping from

the air conditioner after use is normal. If you

should notice any leaks or if gasoline fumes are

evident, check for the cause and have it cor-

rected immediately.
Power steering fluid level* and lines: Check the

level when the fluid is cold, with the engine off.

Check the lines for proper attachment, leaks,

cracks, etc.
Radiator and hoses: Check the front of the

radiator and clean off any dirt, insects, leaves,

etc., that may have accumulated. Make sure the

hoses have no cracks, deformation, rot or loose

connections.
Underbody: The underbody is frequently ex-

posed to corrosive substances such as those

used on icy roads or to control dust. It is very

important to remove these substances, other-

wise rust will form on the floor pan, frame, fuel

lines and around the exhaust system. At the

end of winter, the underbody should be thor-

oughly flushed with plain water, being careful

to clean those areas where mud and dirt may

accumulate. For additional information, see

“CLEANING EXTERIOR” in the “7. Appearance

and care” section.
Windshield washer fluid*: Check that there is

adequate fluid in the reservoir.

8-4

Maintenance and do-it-yourself

—

05/19/09—tbrooks

-------------------------------------------------------------------------------------------------------------------------------------------------------------

When performing any inspection or mainte-

nance work on your vehicle, always take care to

prevent serious accidental injury to yourself or

damage to the vehicle. The following are gen-

eral precautions which should be closely ob-

served.

WARNING

● Park the vehicle on a level surface, apply the

parking brake securely and block the wheels

to prevent the vehicle from moving. Move

the selector lever to P (Park).

● Be sure the ignition switch is in the LOCK

position when performing any parts replace-

ment or repairs.

● If you must work with the engine running,

keep your hands, clothing, hair and tools

away from moving fans, belts and any other

moving parts.

● It is advisable to secure or remove any loose

clothing and remove any jewelry, such as

rings, watches, etc. before working on your

vehicle.

● Always wear eye protection whenever you

work on your vehicle.

● If you must run the engine in an enclosed

space such as a garage, be sure there is

proper ventilation for exhaust gases to

escape.

● Never get under the vehicle while it is sup-

ported only by a jack. If it is necessary to

work under the vehicle, support it with

safety stands.

● Keep smoking materials, flame and sparks

away from fuel tank and the battery.

● Your vehicle is equipped with an automatic

engine cooling fan. It may come on at any

time without warning, even if the ignition

key is in the OFF position and the engine is

not running. To avoid injury, always discon-

nect the negative battery cable before work-

ing near the fan.

● The fuel filter or fuel lines should be serviced

by an INFINITI retailer because the fuel lines

are under high pressure even when the en-

gine is off.

CAUTION

● Do not work under the hood while the engine

is hot. Turn the engine off and wait until it

cools down.

● Avoid direct contact with used engine oil and

coolant. Improperly disposed engine oil, en-

gine coolant and/or other vehicle fluids can

damage the environment. Always conform to

local regulations for disposal of vehicle

fluid.

● Never connect or disconnect the battery or

any transistorized component while the ig-

nition switch is in the ON position.

● Never leave the engine or automatic trans-

mission related component harnesses dis-

connected while the ignition switch is in the

ON position.

This “8. Maintenance and do-it-yourself” sec-

tion gives instructions regarding only those

items which are relatively easy for an owner to

perform.
A genuine INFINITI Service Manual is also avail-

able.

(See

“OWNER’S

MANUAL/SERVICE

MANUAL ORDER INFORMATION” in the “9. Tech-

nical and consumer information” section.)
You should be aware that incomplete or im-

proper servicing may result in operating diffi-

culties or excessive emissions, and could affect

warranty coverage.

If in doubt about any servic-

ing, we recommend that it be done by an INFINITI

retailer.

MAINTENANCE PRECAUTIONS

Maintenance and do-it-yourself

8-5

—

05/19/09—tbrooks

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The engine cooling system is filled at the factory

with a high-quality, year-round, anti-freeze

coolant solution. The antifreeze solution con-

tains rust and corrosion inhibitors, therefore

additional cooling system additives are not

necessary.

WARNING

● Never remove the radiator or coolant reser-

voir cap when the engine is hot. Wait until

the engine and radiator cool down. Serious

burns could be caused by high pressure fluid

escaping from the radiator. See precautions

in “IF YOUR VEHICLE OVERHEATS” in the “6.

In case of emergency” section of this

manual.

● The radiator is equipped with a pressure

type radiator cap. To prevent engine dam-

age, use only a genuine NISSAN radiator cap.

CAUTION

When adding or replacing coolant, be sure to

use only a Genuine NISSAN Long Life

Antifreeze/Coolant (green) or equivalent with

the proper mixture ratio of 50% antifreeze and

50% demineralized or distilled water. The use

of other types of coolant solutions may damage

the engine cooling system.

Outside

temperature

down to

Anti-freeze

Demineral-

ized water

or distilled

water

°F

°C

230

235

50%

VK45DE engine

SDI1818B

VQ35HR engine

SDI2309

ENGINE COOLING SYSTEM

8-10

Maintenance and do-it-yourself

—

05/19/09—tbrooks

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CHECKING ENGINE COOLANT LEVEL

Check the coolant level

in the reservoir when the

engine is cold. If the coolant level is below the

MIN level

, open the reservoir cap and add

coolant up to the MAX level

. If the reservoir

is empty, check the coolant level in the radiator

when the engine is cold.

For VK45DE engine model, remove the engine

cover by removing the 4 clips

If there is insufficient coolant in the radiator, fill

the radiator with coolant up to the filler opening

and also add it to the reservoir up to the MAX

level

If the cooling system frequently requires cool-

ant, have it checked by an INFINITI retailer.

CHANGING ENGINE COOLANT

Major cooling system repairs should be per-

formed by an INFINITI retailer. The service pro-

cedures can be found in the appropriate INFINITI

Service Manual.
Improper servicing can result in reduced heater

performance and engine overheating.

WARNING

● To avoid the danger of being scalded, never

change the coolant when the engine is hot.

● Never remove the radiator cap when the en-

gine is hot. Serious burns could be caused by

high pressure fluid escaping from the

radiator.

● Avoid direct skin contact with used coolant.

If skin contact is made, wash thoroughly

with soap or hand cleaner as soon as

possible.

● Keep coolant out of reach of children and

pets.

Engine coolant must be disposed of properly.

Check your local regulations.

SDI2310

Maintenance and do-it-yourself

8-11

—

05/19/09—tbrooks

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Infiniti M45 (2010 year). Manual - part 23
