GENERAL MAINTENANCE

MA-3

< SERVICE INFORMATION >

GENERAL MAINTENANCE

Explanation of General Maintenance

INFOID:0000000001328893

General maintenance includes those items which should be checked during the normal day-to-day operation
of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform
checks and inspections themselves or have their INFINITI dealers do them.

OUTSIDE THE VEHICLE

The maintenance items listed here should be performed from time to time, unless otherwise specified.

INSIDE THE VEHICLE

The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the vehicle,
etc.

Item

Reference page

Tires

Check the pressure with a gauge, including the spare, at least once a month
and always prior to a long distance trips. Adjust to the specified pressure if nec-
essary. Check carefully for damage, cuts or excessive wear.

—

Wheel nuts

When checking the tires, make sure no nuts are missing, and check for any
loose nuts. Tighten if necessary.

—

Windshield

Clean the windshield on a regular basis. Check the windshield at least every six
months for cracks or other damage. Repair as necessary.

—

Tire rotation

Tires should be rotated every 12,000 km (7,500 miles).

MA-31

Transmitter compo-
nents in tire pressure
monitoring system
(TPMS)

Replace grommet seal, valve core and cap of the transmitter in TPMS every tire
replacement by reaching wear limit of tire.

WT-10

Wheel alignment and
balance

If the vehicle pulls to either side while driving on a straight and level road, or if
you detect uneven or abnormal tire wear, there may be a need for wheel align-
ment. If the steering wheel or seat vibrates at normal highway speeds, wheel
balancing may be needed.

MA-30

FSU-5

Windshield wiper
blades

Check for cracks or wear if they do not wipe properly.

—

Doors and engine
hood

Check that all doors and the engine hood operate smoothly as well as the trunk
lid and back hatch. Also make sure that all latches lock securely. Lubricate if
necessary. Make sure that the secondary latch keeps the hood from opening
when the primary latch is released.
When driving in areas using road salt or other corrosive materials, check lubri-
cation frequently.

MA-35

Lamps

Make sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and
other lamps are all operating properly and installed securely. Also check head-
lamp aim. Clean the headlamps on a regular basis.

—

Item

Reference page

Warning lamps and
chimes

Make sure that all warning lamps and chimes are operating properly.

—

Windshield wiper and
washer

Check that the wipers and washer operate properly and that the wipers do not
streak.

—

Windshield defroster

Check that the air comes out of the defroster outlets properly and in sufficient
quantity when operating the heater or air conditioner.

—

Steering wheel

Check that it has the specified play. Be sure to check for changes in the steering
condition, such as excessive play, hard steering or strange noises.
Free play: Less than 35 mm (1.38 in)

—

Seats

Check seat position controls such as seat adjusters, seatback recliner, etc. to
make sure they operate smoothly and that all latches lock securely in every po-
sition. Check that the head restrains move up and down smoothly and that the
locks (if equipped) hold securely in all latched positions. Check that the latches
lock securely for folding-down rear seatbacks.

—

Seat belts

Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters
and retractors) operate properly and smoothly, and are installed securely.
Check the belt webbing for cuts, fraying, wear or damage.

MA-35

2008 FX35/FX45

MA-4

< SERVICE INFORMATION >

GENERAL MAINTENANCE

UNDER THE HOOD AND VEHICLE
The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).

Accelerator pedal

Check the pedal for smooth operation and make sure the pedal does not catch
or require uneven effort. Keep the floor mats away from the pedal.

—

Brakes

Check that the brake does not pull the vehicle to one side when applied.

—

Brake pedal and
booster

Check the pedal for smooth operation and make sure it has the proper distance
under it when depressed fully. Check the brake booster function. Be sure to
keep the floor mats away from the pedal.

BR-5

BR-14

Parking brake

Check that the pedal has the proper travel and make sure that the vehicle is
held securely on a fairly steep hill when only the parking brake is applied.

PB-3

Automatic transmis-
sion "Park" mecha-
nism

Check that the lock release button on the selector lever operates properly and
smoothly. On a fairly steep hill check that the vehicle is held securely with the
selector lever in the P (Park) position without applying any brakes.

—

Item

Reference page

Item

Reference page

Windshield washer
fluid

Check that there is adequate fluid in the tank.

—

Engine coolant level

Check the coolant level when the engine is cold.

MA-12

MA-19

Radiator and hoses

Check the front of the radiator and clean off any dirt, insects, leaves, etc., that
may have accumulated. Make sure the hoses have no cracks, deformation, de-
terioration or loose connections.

—

Brake fluid level

Make sure that the brake fluid level is between the “MAX” and “MIN” lines on the
reservoir.

MA-32

Battery

Check the fluid level in each cell. It should be between the “MAX” and “MIN”
lines. Vehicles operated in high temperatures or under severe conditions re-
quire frequent checks of the battery fluid level.

SC-4

Engine drive belts

Make sure that no belt is frayed, worn, cracked or oily.

MA-11

MA-19

Engine oil level

Check the level on the oil level gauge after parking the vehicle on a level spot
and turning off the engine.

MA-15

MA-22

Power steering fluid
level and lines

Check the level on the dipstick with the engine off. Check the lines for improper
attachment, leaks, cracks, etc.

MA-33

Exhaust system

Make sure there are no loose supports, cracks or holes. If the sound of the ex-
haust seems unusual or there is a smell of exhaust fumes, immediately locate
the trouble and correct it.

MA-26

Underbody

The underbody is frequently exposed to corrosive substances such as those
used on icy roads or to control dust. It is very important to remove these sub-
stances, otherwise rust will form on the floor pan, frame, fuel lines and around
the exhaust system. At the end of winter, the underbody should be thoroughly
flushed with plain water, being careful to clean those areas where mud and dirt
can easily accumulate.

—

Fluid leaks

Check under the vehicle for fuel, oil, water or other fluid leaks after the vehicle
has been parked for a while. Water dripping from the air conditioner after use is
normal. If you should notice any leaks or gasoline fumes are evident, check for
the cause and correct it immediately.

—

2008 FX35/FX45

PERIODIC MAINTENANCE

MA-5

< SERVICE INFORMATION >

PERIODIC MAINTENANCE

Introduction of Periodic Maintenance

INFOID:0000000001328894

Two different maintenance schedules are provided, and should be used, depending upon the conditions in
which the vehicle is mainly operated. After 60,000 miles (96,000 km) or 48 months, continue the periodic
maintenance at the same mileage/time intervals.

Schedule 1

INFOID:0000000001328895

EMISSION CONTROL SYSTEM MAINTENANCE

Abbreviations: R = Replace.

I = Inspect. Correct or replace if necessary.

[ ]: At the mileage intervals only

Schedule 1

Follow Periodic Maintenance Schedule 1 if the driving habits frequently include
one or more of the following driving conditions:
• Repeated short trips of less than 5 miles (8 km).
• Repeated short trips of less than 10 miles (16 km) with outside temperatures

remaining below freezing.

• Operating in hot weather in stop-and-go “rush hour” traffic.
• Extensive idling and/or low speed driving for long distances, such as police, taxi

or door-to-door delivery use.

• Driving in dusty conditions.
• Driving on rough, muddy, or salt spread roads.
• Towing a trailer, using a camper or a car-top carrier.

Emission Control Sys-
tem Maintenance

MA-5

Chassis and Body
Maintenance

MA-5

Schedule 2

Follow Periodic Maintenance Schedule 2 if none of driving conditions shown in
Schedule 1 apply to the driving habits.

Emission Control Sys-
tem Maintenance

MA-7

Chassis and Body
Maintenance

MA-7

MAINTENANCE OPERATION

MAINTENANCE INTERVAL

Reference

Section -

Page or -

Content Title

Perform at number of miles,
kilometers or months, which-
ever comes first.

Miles x 1,000

(km x 1,000)

Months

3.75

(6)

7.50

(12)

11.25

(18)

(24)

18.75

(30)

22.5

(36)

26.25

(42)

(48)

Drive belts

NOTE (1)

MA-11

MA-

Air cleaner filter

NOTE (2)

[R]

EVAP vapor lines

Fuel lines

Fuel filter

NOTE (3)

Engine coolant

NOTE (4)

Engine oil

Engine oil filter (Use genuine
NISSAN engine oil filter or
equivalent.)

MA-16

MA-

Spark plugs (PLATINUM-
TIPPED type)

Replace every 105,000 miles (169,000 km).

MA-17

MA-

Intake & exhaust valve clear-
ance*

NOTE (5)

EM-91

EM-

218

2008 FX35/FX45

MA-6

< SERVICE INFORMATION >

PERIODIC MAINTENANCE

NOTE:

(1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found

damaged or if the auto belt tensioner reading (only for VK45DE engine) reaches the maximum limit.

(2) If operating mainly in dusty conditions, more frequent maintenance may be required.

(3) Maintenance-free item. For service procedures, refer to FL section.

(4) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.

(5) If valve noise increases, inspect valve clearance.

* Maintenance items and intervals with “*” are recommended by INFINITI for reliable vehicle operation. The owner need not perform
such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are
required.

CHASSIS AND BODY MAINTENANCE

Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary.

MAINTENANCE OPERATION

MAINTENANCE INTERVAL

Reference

Section -

Page or -

Content Title

Perform at number of miles,
kilometers or months, which-
ever comes first.

Miles x 1,000

(km x 1,000)

Months

33.75

(54)

37.5

(60)

41.25

(66)

(72)

48.75

(78)

52.5

(84)

56.25

(90)

(96)

Drive belts

NOTE (1)

MA-11

MA-

Air cleaner filter

NOTE (2)

[R]

EVAP vapor lines

Fuel lines

Fuel filter

NOTE (3)

Engine coolant

NOTE (4)

Engine oil

Engine oil filter (Use genuine
NISSAN engine oil filter or
equivalent.)

MA-16

MA-

Spark plugs (PLATINUM-
TIPPED type)

Replace every 105,000 miles (169,000 km).

MA-17

MA-

Intake & exhaust valve clear-
ance*

NOTE (5)

EM-91

EM-

218

MAINTENANCE OPERATION

MAINTENANCE INTERVAL

Reference

Section -

Page or - Con-

tent Title

Perform at number of miles,
kilometers or months,
whichever comes first.

Miles x 1,000

(km x 1,000)

Months

3.75

(6)

7.50

(12)

11.25

(18)

(24)

18.75

(30)

22.5

(36)

26.25

(42)

(48)

Brake lines & cables

MA-32

Brake pads & rotors

MA-32

Automatic transmission &
transfer fluid & differential
gear oil

NOTE (1)

MA-26

MA-28

MA-29

Steering gear, linkage &
transfer gear, axle & sus-
pension parts

MA-33

MA-34

Tire rotation

NOTE (2)

MA-3

MA-31

2008 FX35/FX45

PERIODIC MAINTENANCE

MA-7

< SERVICE INFORMATION >

NOTE:

(1) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) fluid (A/T, trans-
fer)/oil at every 30,000 miles (48,000 km) or 24 months. Using automatic transmission fluid other than Genuine Nissan Matic J
ATF will cause deterioration in driveability and automatic transmission durability, and may damage the automatic transmis-
sion, which is not covered by the INFINITI new vehicle limited warranty.

(2) Refer to “Tire rotation” under the “GENERAL MAINTENANCE” heading earlier in this section.

Schedule 2

INFOID:0000000001328896

EMISSION COMTROL SYSTEM MAINTENANCE

Abbreviations: R = Replace.

I = Inspect. Correct or replace if necessary.

[ ]: At the mileage intervals only

Drive shaft boots and pro-
peller shaft (AWD models)

Exhaust system

In-cabin microfilter

MAINTENANCE OPERATION

MAINTENANCE INTERVAL

Reference

Section -

Page or - Con-

tent Title

Perform at number of miles,
kilometers or months,
whichever comes first.

Miles x 1,000

(km x 1,000)

Months

3.75

(6)

7.50

(12)

11.25

(18)

(24)

18.75

(30)

22.5

(36)

26.25

(42)

(48)

MAINTENANCE OPERATION

MAINTENANCE INTERVAL

Reference

Section - Page

or - Content

Title

Perform at number of miles,
kilometers or months,
whichever comes first.

Miles x 1,000

(km x 1,000)

Months

33.75

(54)

37.5

(60)

41.25

(66)

(72)

48.75

(78)

52.5

(84)

56.25

(90)

(96)

Brake lines & cables

MA-32

Brake pads & rotors

MA-32

Automatic transmission &
transfer fluid & differential
gear oil

NOTE (1)

MA-26

MA-28

MA-29

Steering gear, linkage &
transfer gear, axle & sus-
pension parts

MA-33

MA-34

Tire rotation

NOTE (2)

MA-3

MA-31

Drive shaft boots and pro-
peller shaft (AWD models)

Exhaust system

In-cabin microfilter

MAINTENANCE OPERATION

MAINTENANCE INTERVAL

Reference Sec-

tion - Page or -

Content Title

Perform at number of miles, kilo-
meters or months, whichever
comes first.

Miles x 1,000

(km x 1,000)

Months

7.5

(12)

(24)

22.5

(36)

(48)

37.5

(60)

(72)

52.5

(84)

(96)

Drive belts

NOTE (1)

MA-11

MA-19

Air cleaner filter

[R]

EVAP vapor lines

Fuel lines

Fuel filter

NOTE (2)

2008 FX35/FX45

MA-8

< SERVICE INFORMATION >

PERIODIC MAINTENANCE

NOTE:

(1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found

damaged or if the auto belt tensioner reading (only for VK45DE engine) reaches the maximum limit.

(2) Maintenance-free item. For service procedures, refer to FL section.

(3) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.

(4) If valve noise increases, inspect valve clearance.

CHASSIS AND BODY MAINTENANCE

Abbreviations: R = Replace.

I = Inspect. Correct or replace if necessary.

NOTE:

(1) Using automatic transmission fluid other than Genuine NISSAN Matic J ATF will cause deterioration in driveability and
automatic transmission durability, and may damage the automatic transmission, which is not covered by the INFINITI new
vehicle limited warranty.

(2) Refer to “Tire rotation” under the “GENERAL MAINTENANCE” heading earlier in this section.

Engine coolant

NOTE (3)

Engine oil

Engine oil filter (Use genuine
NISSAN engine oil filter or equiv-
alent.)

MA-16

MA-23

Spark plugs (PLATINUM-
TIPPED type)

Replace every 105,000 miles (169,000 km).

MA-17

MA-24

Intake & exhaust valve clear-
ance*

NOTE (4)

EM-91

EM-218

MAINTENANCE OPERATION

MAINTENANCE INTERVAL

Reference Sec-

tion - Page or -

Content Title

Perform at number of miles, kilo-
meters or months, whichever
comes first.

Miles x 1,000

(km x 1,000)

Months

7.5

(12)

(24)

22.5

(36)

(48)

37.5

(60)

(72)

52.5

(84)

(96)

MAINTENANCE OPERATION

MAINTENANCE INTERVAL

Reference Sec-

tion - Page or -

Content Title

Perform at number of miles, kilo-
meters or months, whichever
comes first.

Miles x 1,000

(km x 1,000)

Months

7.5

(12)

(24)

22.5

(36)

(48)

37.5

(60)

(72)

52.5

(84)

(96)

Brake lines & cables

MA-32

Brake pads & rotors

MA-32

Automatic transmission & trans-
fer fluid & differential gear oil

NOTE (1)

MA-26

MA-28

MA-29

Steering gear, linkage & transfer
gear, axle & suspension parts

MA-33

MA-34

Tire rotation

NOTE (2)

MA-3

MA-31

Drive shaft boots and propeller
shaft (AWD models)

Exhaust system

In-cabin microfilter

2008 FX35/FX45

RECOMMENDED FLUIDS AND LUBRICANTS

MA-9

< SERVICE INFORMATION >

RECOMMENDED FLUIDS AND LUBRICANTS

Fluids and Lubricants

INFOID:0000000001328897

*1: For further details, see “Engine Oil Recommendation”.

*2: Using automatic transmission fluid other than Genuine NISSAN Matic J ATF will cause deterioration in driveability and
automatic transmission durability, and may damage the automatic transmission, which is not covered by the INFINITI new
vehicle limited warranty.

*3: For hot climates, viscosity SAE 90 is suitable for ambient temperatures above 0

C (32

F).

*4: Canada NISSAN Automatic Transmission Fluid or DEXRON

VI type ATF may also be used.

*5: Available in mainland U.S.A. through your INFINITI dealer.

Engine Oil Recommendation

INFOID:0000000001328898

NISSAN recommends the use of an energy conserving oil in order to improve fuel economy.
Select only engine oils that meet the American Petroleum Institute (API) certification and International Lubri-
cant Standardization and Approval Committee (ILSAC) certification and SAE viscosity standard. These oils
have the API certification mark on the front of the container. Oils which do not have the specified quality label
should not be used as they could cause engine damage.

Capacity (Approximate)

Recommended Fluids/Lubricants

US measure

Imp mea-

sure

Liter

Engine oil
Drain and
refill

With oil fil-
ter change

VK45DE

6-1/8 qt

5-1/8 qt

5.8

• Engine oil with API Certification Mark*1
• Viscosity SAE 5W-30

VQ35DE

5 qt

4 - 1/8 qt

4.7

Without oil
filter
change

VK45DE

5-1/2 qt

4-5/8 qt

5.2

VQ35DE

4-5/8 qt

3-7/8 qt

4.4

Dry engine (Overhaul)

VK45DE

7-3/8 qt

6-1/8 qt

7.0

VQ35DE

5-3/4 qt

4-3/4 qt

5.4

Cooling
system

With res-
ervoir tank

VK45DE

10-5/8 qt

8-3/4 qt

10.0

Genuine NISSAN Long Life Antifreeze/ Coolant
or equivalent

VQ35DE

9-1/8 qt

7-5/8 qt

8.6

Reservoir
tank

VK45DE

7/8 qt

3/4 qt

0.8

VQ35DE

7/8 qt

3/4 qt

0.8

Automatic transmission fluid

10-7/8 qt

9-1/8 qt

10.3

Genuine NISSAN Matic J ATF *2

Differential gear oil

Front

1-3/8 pt

1-1/8 pt

0.65

Genuine NISSAN Differential Oil Hypoid Super
GL-5 80W-90 or API GL-5, Viscosity SAE 80W-
90 *3

Rear

3 pt

2-1/2 pt

1.40

Transfer fluid

2-5/8 pt

2-1/4 pt

1.25

Genuine NISSAN Matic D ATF (Continental U.S.
and Alaska) or Canada NISSAN Automatic
Transmission Fluid or equivalent (if available)

Power steering fluid (PSF)

1-1/8 qt

7/8 qt

1.0

Genuine NISSAN PSF or equivalent*4

Brake fluid

—

Genuine NISSAN Super Heavy Duty Brake Flu-
id*5 or equivalent
DOT 3 (US FMVSS No. 116)

Multi-purpose grease

—

NLGI No. 2 (Lithium soap base)

Windshield washer fluid

—

Genuine NISSAN Windshield Washer Concen-
trate Cleaner & Antifreeze or equivalent

Fuel
recommendation

VK45DE

—

Refer to

GI-5, "Precaution for Fuel (Unleaded

Premium Gasoline Required)"

VQ35DE

—

Refer to

GI-5, "Precaution for Fuel (Unleaded

Premium Gasoline Recommended)"

2008 FX35/FX45

ENGINE MAINTENANCE (VQ35DE ENGINE)

MA-11

< SERVICE INFORMATION >

ENGINE MAINTENANCE (VQ35DE ENGINE)

Checking Drive Belts

INFOID:0000000001328900

WARNING:

Be sure to perform when engine is stopped.
1.

Inspect belts for cracks, fraying, wear and oil. If necessary, replace.

Inspect drive belt deflection or tension at a point on belt midway
between pulleys.

• Inspection should be done only when engine is cold, or over

30 minutes after engine is stopped.

• Measure the belt tension with belt tension gauge (Commercial

service tool: BT3373-F or equivalent) (A) at points marked
shown in the figure.

• When measuring the deflection, apply 98 N (10 kg, 22 lb) at

the marked point.

• Adjust if the belt deflection exceeds the limit or if the belt ten-

sion is not within specifications.

CAUTION:

• When checking the belt deflection or the tension immedi-

ately after installation, first adjust it to the specified value.
Then, after turning crankshaft two turns or more, re-adjust
to the specified value to avoid variation in deflection
between pulleys.

• Tighten idler pulley lock nut by hand and measure the deflection or the tension without loose-

ness.

Belt Deflection and Tension

*: If belt tension gauge cannot be installed at check points shown, check drive belt tension at different location on belt.

Drive Belts Tension Adjustment

INFOID:0000000001328901

CAUTION:

1 : Power steering oil pump

2 : Alternator

3 : Idler pulley

4 : Crankshaft pulley

5 : A/C compressor

JPBIA0421ZZ

JPBIA0422ZZ

Items

Deflection adjustment

Unit: mm (in)

Tension adjustment*

Unit: N (kg, lb)

Used belt

New belt

Used belt

New belt

Limit

After adjustment

Limit

After adjustment

Alternator and
power steering
oil pump belt

12 (0.47)

7 - 8

(0.28 - 0.31)

6 - 7

(0.24 - 0.28)

294 (30, 66)

730 - 818

(74.5 - 83.5,

164 - 184)

838 - 926

(85.5 - 94.5,

188 - 208)

A/C compressor
belt

12 (0.47)

9 - 10

(0.35 - 0.39)

8 - 9

(0.31 - 0.35)

196 (20, 44)

348 - 436

(35.5 - 44.5,

78 - 98)

470 - 559

(48 - 57,

106 - 126)

Applied pushing
force

98 N (10 kg, 22 lb)

—

Portion

Belt tightening method for adjustment

Alternator and power steering oil pump belt

Adjusting bolt on idler pulley

A/C compressor belt

Adjusting bolt on idler pulley

2008 FX35/FX45

MA-12

< SERVICE INFORMATION >

ENGINE MAINTENANCE (VQ35DE ENGINE)

• When belt is replaced with a new one, adjust it to value for “New belt” to accommodate for insuffi-

cient adaptability with pulley grooves.

• When deflection or tension of belt being used exceeds “Limit”, adjust it to value for “After adjust-

ment”.

• When checking belt deflection or tension immediately after installation, first adjust it to the specified

value. Then, after turning crankshaft two turns or more, re-adjust to the specified value to avoid vari-
ation in deflection between pulleys.

• When installing belt, make sure that it is correctly engaged with pulley grooves.
• Keep engine oil, working fluid and engine coolant away from belt and pulley grooves.
• Do not twist or bend belt excessively.

ALTERNATOR AND POWER STEERING OIL PUMP BELT

Remove front engine undercover with power tool.

Loosen idler pulley lock nut (A) and adjust tension by turning
adjusting bolt (B).
• For the specified belt tension, refer to

EM-14, "Checking Drive

Belts"

Tighten nut (A).

A/C COMPRESSOR BELT

Remove front engine undercover with power tool.

Loosen idler pulley lock nut (C) and adjust tension by turning adjusting bolt (D).
• For the specified belt tension, refer to

EM-14, "Checking Drive Belts"

Tighten nut (C).

Changing Engine Coolant

INFOID:0000000001328902

WARNING:

• To avoid being scalded, do not change engine coolant when the engine is hot.
• Wrap a thick cloth around radiator cap and carefully remove radiator cap. First, turn radiator cap a

quarter of a turn to release built-up pressure. Then turn radiator cap all the way.

• Be careful not to allow engine coolant to contact drive belts.

DRAINING ENGINE COOLANT

Remove front engine undercover with power tool.

: Alternator and power steering oil pump belt

: A/C compressor belt

: Power steering oil pump

: Idler pulley

: Alternator

: Crankshaft pulley

: A/C compressor

: 34.8 N·m (3.5 kg-m, 26 ft-lb)

JPBIA0423ZZ

: 34.8 N·m (3.5 kg-m, 26 ft-lb)

2008 FX35/FX45

ENGINE MAINTENANCE (VQ35DE ENGINE)

MA-13

< SERVICE INFORMATION >

Open radiator drain plug at the bottom of radiator, and then
remove radiator cap.

When draining all of engine coolant in the system, open water drain plugs on cylinder block. Refer
to

EM-123, "Disassembly and Assembly"

Remove reservoir tank as necessary, drain engine coolant and clean reservoir tank before installing.

Check drained engine coolant for contaminants such as rust, corrosion or discoloration.
If contaminated, flush the engine cooling system. Refer to

CO-10, "Changing Engine Coolant"

REFILLING ENGINE COOLANT

Install reservoir tank if removed, and radiator drain plug.

CAUTION:

Be sure to clean drain plug and install with new O-ring.

If water drain plugs on cylinder block are removed, close and tighten them. Refer to

EM-123, "Dis-

assembly and Assembly"

Make sure that each hose clamp has been firmly tightened.

Remove air relief plug on heater hose.

Fill radiator, and reservoir tank if removed, to specified level.
• Pour engine coolant through engine coolant filler neck

slowly of less than 2 (2-1/8 US qt, 1-3/4 lmp qt) a minute
to allow air in system to escape.

• Use Genuine NISSAN Long Life Antifreeze/Coolant or

equivalent mixed with water (distilled or demineralized).
Refer to

MA-9

SBIA0444E

Radiator drain plug:

: 1.18 N·m (0.12 kg-m, 10 in-lb)

SBIA0445E

Engine coolant capacity
(With reservoir tank at “MAX” level)

: Approximately 8.6 (9-1/8 US qt, 7-5/8 lmp qt)

SMA182B

2008 FX35/FX45

MA-14

< SERVICE INFORMATION >

ENGINE MAINTENANCE (VQ35DE ENGINE)

• When engine coolant overflows air relief hole on heater hose,

install air relief plug with new O-ring.

Install radiator cap.

Warm up until opening thermostat. Standard for warming-up time is approximately 10 minutes at 3,000
rpm.
• Make sure thermostat opening condition by touching radiator hose (lower) to see a flow of warm water.

CAUTION:

Watch water temperature gauge so as not to overheat engine.

Stop the engine and cool down to less than approximately 50

C (122

F).

• Cool down using fan to reduce the time.
• If necessary, refill radiator up to filler neck with engine coolant.

Refill reservoir tank to “MAX” level line with engine coolant.

Repeat steps 4 through 7 two or more times with radiator cap installed until engine coolant level no longer
drops.

10. Check cooling system for leaks with engine running.

11. Warm up the engine, and check for sound of engine coolant flow while running engine from idle up to

3,000 rpm with heater temperature controller set at several position between “COOL” and “WARM”.
• Sound may be noticeable at heater unit.

12. Repeat step 11 three times.

13. If sound is heard, bleed air from cooling system by repeating step 4 through 7 until engine coolant level no

longer drops.

FLUSHING COOLING SYSTEM

Install reservoir tank, and radiator drain plug.

If water drain plugs on cylinder block are removed, close and tighten them. Refer to

EM-123, "Dis-

assembly and Assembly"

Remove air relief plug on heater hose.

Fill radiator with water until water spills from the air relief hole, then close air relief plug. Fill radiator and
reservoir tank with water and reinstall radiator cap.

Reservoir tank engine coolant capacity
(At “MAX” level)

: 0.8 (7/8 US qt, 3/4 lmp qt)

Air relief plug:

: 1.19 N·m (0.12 kg-m, 11 in-lb)

SMA412B

Radiator drain plug:

: 1.18 N·m (0.12 kg-m, 10 in-lb)

SBIA0445E

Air relief plug:

: 1.19 N·m (0.12 kg-m, 11 in-lb)

2008 FX35/FX45

ENGINE MAINTENANCE (VQ35DE ENGINE)

MA-15

< SERVICE INFORMATION >

Run the engine and warm it up to normal operating temperature.

Rev engine two or three times under no-load.

Stop the engine and wait until it cools down.

Drain water from the system. Refer to

CO-10, "Changing Engine Coolant"

Repeat steps 1 through 7 until clear water begins to drain from radiator.

Checking Fuel Line

INFOID:0000000001328903

Inspect fuel lines, filler cap and tank for improper attachment, leaks,
cracks, damage, loose connections, chafing or deterioration.
If necessary, repair or replace damaged parts.

Changing Air Cleaner Filter

INFOID:0000000001328904

VISCOUS PAPER TYPE

The viscous paper type filter does not need cleaning between
replacement intervals. Refer to

MA-5

Changing Engine Oil

INFOID:0000000001328905

WARNING:

• Be careful not to burn yourself, as engine oil may be hot.
• Prolonged and repeated contact with used engine oil may cause skin cancer. Try to avoid direct skin

contact with used engine oil. If skin contact is made, wash thoroughly with soap or hand cleaner as
soon as possible.

Remove front engine undercover with power tool.

Warm up the engine, and check for engine oil leakage from engine components. Refer to

LU-5, "Inspec-

tion"

Stop the engine and wait for 10 minutes.

Loosen oil filler cap and then remove drain plug.

Drain engine oil.

Install drain plug with new washer. Refer to

EM-30

CAUTION:

Be sure to clean drain plug and install with new washer.

Refill with new engine oil.
Engine oil specification and viscosity:
Refer to

MA-9

SMA803A

SBIA0463E

Oil pan drain plug:

: 34.3 N·m (3.5 kg-m, 25 ft-lb)

2008 FX35/FX45

MA-16

< SERVICE INFORMATION >

ENGINE MAINTENANCE (VQ35DE ENGINE)

Engine oil capacity (Approximate):

Unit:

(US qt, lmp qt)

CAUTION:

• When filling engine oil, do not pull out oil level gauge.
• The refill capacity depends on the engine oil temperature and drain time. Use these specifica-

tions for reference only.

• Always use oil level gauge to determine the proper amount of engine oil in engine.

Warm up the engine and check area around drain plug and oil filter for engine oil leakage.

Stop the engine and wait for 10 minutes.

10. Check the engine oil level.

Changing Oil Filter

INFOID:0000000001328906

REMOVAL

WARNING:

Be careful not to get burned when the engine and engine oil may be hot.
1.

Remove front engine undercover with power tool.

Using oil filter wrench (SST), remove oil filter.

CAUTION:

• Oil filter is provided with relief valve. Use genuine NISSAN

oil filter or equivalent.

• When removing, prepare a shop cloth to absorb any

engine oil leakage or spillage.

• Do not allow engine oil to adhere to drive belts.
• Completely wipe off any engine oil that adheres to engine

and vehicle.

INSTALLATION

Remove foreign materials adhering to oil filter installation surface.

Drain and refill

With oil filter change

4.7 (5, 4-1/8)

Without oil filter change

4.4 (4-5/8, 3-7/8)

Dry engine (Overhaul)

5.4 (5-3/4, 4-3/4)

PBIC3101E

SBIA0454E

SBIA0455E

2008 FX35/FX45

Infiniti FX45. Maintenance (2008 year). Manual - part 1
