WW-16 < FUNCTION DIAGNOSIS > DIAGNOSIS SYSTEM (IPDM E/R) ACTIVE TEST Test item TAIL&CLR REQ × Displays the status of the position light request signal received from BCM via CAN HL LO REQ × Displays the status of the low beam request signal received from BCM via CAN HL HI REQ × Displays the status of the high beam request signal received from BCM via CAN FR FOG REQ × Displays the status of the front fog lamp request signal received from BCM via FR WIP REQ × Displays the status of the front wiper request signal received from BCM via CAN WIP AUTO STOP × Displays the status of the front wiper auto stop signal judged by IPDM E/R. WIP PROT × Displays the status of the front wiper fail-safe operation judged by IPDM E/R. ST RLY REQ Displays the status of the starter request signal received from ECM via CAN com- IGN RLY × Displays the status of the ignition relay judged by IPDM E/R. RR DEF REQ × Displays the status of the rear defogger request signal received from AV control OIL P SW Displays the status of the oil pressure switch judged by IPDM E/R. DTRL REQ Displays the status of the daytime light request signal received from BCM via CAN HOOD SW Displays the status of the hood switch judged by IPDM E/R. THFT HRN REQ Displays the status of the theft warning horn request signal received from BCM HORN CHIRP Displays the status of the horn reminder signal received from BCM via CAN com- Monitor Item [Unit] MAIN SIG- NALS Description Test item Operation Description REAR DEFOGGER OFF OFF ON Operates rear window defogger relay. FRONT WIPER OFF OFF LO Operates the front wiper relay. HI Operates the front wiper relay and front wiper high relay. MOTOR FAN 1 OFF 2 OFF 3 Operates the cooling fan relay. 4 Operates the cooling fan relay. |
