VEHICLE INFORMATION AND INTEGRATED SWITCH SYSTEM /WITHOUT
NAVIGATION SYSTEM
DI-103
C
D
E
F
G
H
I
J
L
M
A
B
DI
34
LG
Ground
Communi-
cation
signal (AV
- ME)
Output
ON
Display the vehi-
cle information
screen.
Vehicle infor-
mation
screen is not
shown.
35
PU
Ground
Communi-
cation
signal (ME
- AV)
Input
ON
Perform various
settings on the
vehicle informa-
tion screen.
Vehicle infor-
mation
screen is not
shown.
40
—
—
Shield
ground
—
—
—
—
—
41
P
Ground
CONSULT-
II commu-
nication
signal (AV -
CN)
Output
ON
Perform CON-
SULT-II.
Diagnosis
with CON-
SULT-II is
not possible.
42
BR/Y
Ground
CONSULT-
II commu-
nication
signal (CN
- AV)
Input
ON
Perform CON-
SULT-II.
Diagnosis
with CON-
SULT-II is
not possible.
43
R
Ground
A/C com-
munica-
tion signal
(AV-AC)
Output
ON
—
A/C opera-
tion is not
possible.
44
W
Ground
A/C com-
munica-
tion signal
(AC-AV)
Input
ON
—
A/C status is
not indi-
cated cor-
rectly.
45
B
Ground
A/C clock
signal
Input
ON
—
A/C status is
not indi-
cated cor-
rectry.
Terminals
Signal
Signal
input/
output
Condition
Reference value (V)
Example of
symptom
(+)
(–)
Terminal
No.
Wire
color
Ignition
switch
Operation
SKIA0169E
SKIA0170E
SKIA0169E
SKIA0170E
SKIA0172E
SKIA0173E
SKIA0174E
