SAT707J 4. Install viscous coupling — RE4F04W. a. After choosing the side gear washer, tighten down differential CAUTION: Make sure that A and B alignment marks are positioned cor- Install viscous coupling. SAT313D 5. Install speedometer drive gear on differential case. I Align the projection of speedometer drive gear with the AAT663 6. Press on differential side bearings. SAT546F 7. Install final gear and tighten fixing bolts in a crisscross pattern. GI MA EM LC EC FE AX SU BR ST RS BT HA SC EL IDX REPAIR FOR COMPONENT PARTS Final Drive (Cont’d) AT-361 |
