CO-10 < ON-VEHICLE MAINTENANCE > ENGINE COOLANT 7. When engine coolant overflows air relief hole on radiator, install 8. Repeat step 6. 9. When engine coolant overflows air relief hole on heater hose, install air relief plug with new O-ring. Then 10. Install air cleaner case (LH). Refer to . 11. Install radiator cap. 3,000 rpm. CAUTION: Watch water temperature gauge so as not to overheat engine. 13. Stop the engine and cool down to less than approximately 50 ° C (122 ° F). • Cool down using fan to reduce the time. 14. Refill reservoir tank to “MAX” level line with engine coolant. 15. Repeat steps 11 through 14 two or more times with radiator cap installed until engine coolant level no longer drops. 16. Check cooling system for leaks with engine running. 17. Warm up the engine, and check for sound of engine coolant flow while running engine from idle up to 3,000 rpm with heater temperature controller set at several position between “COOL” and “WARM”. 18. Repeat step 17 three times. coolant level no longer drops. 20. Check that the reservoir tank cap is tightened. Flushing INFOID:0000000001547683 1. Install reservoir tank if removed, and radiator drain plug. CAUTION: Be sure to clean drain plug and install with new O-ring. If water drain plugs on cylinder block are removed, close and tighten them. Refer to . A : MAX B : MIN Tightening torque : Refer to . JPBIA0102ZZ : 1.2 N·m (0.12 kg-m, 11 in-lb) Tightening torque : Refer to |
