AV PRECAUTIONS AV-341 < PRECAUTION > [BOSE AUDIO WITHOUT NAVIGATION] C D E F G H I J K L M B A O P PRECAUTION PRECAUTIONS Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT INFOID:0000000001836878 The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along WARNING: • To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by • Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag • Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or har- Precaution for Trouble Diagnosis INFOID:0000000001837005 AV COMMUNICATION SYSTEM • Do not apply voltage of 7.0 V or higher to the measurement terminals. checking the circuit. Precaution for Harness Repair INFOID:0000000001837009 AV COMMUNICATION SYSTEM • Solder the repaired parts, and wrap with tape. [Frays of twisted line must be within 110 mm (4.33 in).] • Do not perform bypass wire connections for the repair parts. (The spliced wire will become separated and the characteristics of PKIA0306E PKIA0307E |
