GI-30 < PRECAUTION > LIFTING POINT LIFTING POINT Commercial Service Tools INFOID:0000000000956196 CAUTION: • Every time the vehicle is lifted up, maintain the complete vehicle curb condition. transmission, suspension etc.), support a jack up point on the rear side garage jack with a mission • Since the vehicle's center of gravity changes when removing main parts on the rear side (rear axle, suspension, etc.), support a jack up point on the front side garage jack with a mission jack or equiv- • Be careful not to smash or do not do anything that would affect piping parts. Garage Jack and Safety Stand and 2-Pole Lift INFOID:0000000000956197 WARNING: • Park the vehicle on a level surface when using the jack. Make sure to avoid damaging pipes, tubes, etc. under the vehicle. • Never get under the vehicle while it is supported only by the jack. Always use safety stands when you have to get under the vehicle. • Place wheel chocks at both front and back of the wheels on the ground. the vehicle are well balanced. • When setting the lift arm, do not allow the arm to contact the brake tubes, brake cable, fuel lines and sill spoiler. Tool name Description Board on attachment Safety stand attachment S-NT001 S-NT002 |
