EXL-166
< ECU DIAGNOSIS >
[XENON TYPE]
AFS CONTROL UNIT
25
(B)
Ground
Ground
—
The ignition switch ON
0 V
27
(BR)
Ground
Left swivel position sensor
ground
Input
The ignition switch ON
0 V
28
(SB)
Ground
Height sensor signal
Output
Vehicle rear height
Unloaded ve-
hicle condition
2.5 V
Low (Leveling
operation
downward
edge)
1.4 V
29
(O)
Ground
Left swivel position sensor sig-
nal
Output
Left headlamp swivel
angle
0
°
1.0 V
20
°
2.8 V
30
(L)
Ground
CAN-H
Input/
output
—
—
32
(G)
Ground
Right swivel motor 2-phase (+)
Output
Right headlamp
swivel
Activation
Reference waveform
8 - 12 V
34
(W)
Ground
Right swivel motor 1-phase (+)
Output
Right headlamp
swivel
Stopped
9.5 - 11.5 V
36
(R)
Ground
Left swivel motor 2-phase (-)
Output
Left headlamp swivel
Activation
Reference waveform
8 - 12 V
37
(O)
Ground
Reverse signal
Input
Back-up lamp switch
ON
Battery voltage
OFF
0 V
38
(B)
Ground
Left swivel motor 1-phase (-)
Output
Left headlamp swivel
Stopped
9.5 - 11.5 V
40
(O)
Ground
Left levelizer signal
Output
Left headlamp level-
ing
(17-inch wheel mod-
els)
Unloaded ve-
hicle condition
8.8 V
Leveling oper-
ation down-
ward edge
4.3 V
Left headlamp level-
ing
(18-inch wheel mod-
els)
Unloaded ve-
hicle condition
8.8 V
Leveling oper-
ation down-
ward edge
4.5 V
Terminal No.
(Wire color)
Description
Condition
Value
(Approx.)
+
−
Signal name
Input/
output
SKIB2408J
SKIB2408J
