BCM (BODY CONTROL MODULE)

76

(V)

Ground

Driver door antenna
(-)

Output

When the driver
door request
switch is operat-
ed with ignition
switch OFF

When Intelligent Key is in
the antenna detection area

When Intelligent Key is not
in the antenna detection
area

77

(LG)

Ground

Driver door antenna
(+)

Output

When the driver
door request
switch is operat-
ed with ignition
switch OFF

When Intelligent Key is in
the antenna detection area

When Intelligent Key is not
in the antenna detection
area

78

(Y)

Ground

Room antenna (-) (in-
strument panel)

Output

Ignition switch
OFF

When Intelligent Key is in
the passenger compart-
ment

When Intelligent Key is not
in the passenger compart-
ment

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

–

JMKIA0062GB

JMKIA0063GB

JMKIA0062GB

JMKIA0063GB

JMKIA0062GB

JMKIA0063GB

BCM (BODY CONTROL MODULE)

RF-27

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

J

L

M

A

B

RF

N

O

P

79

(BR)

Ground

Room antenna (+)
(instrument panel)

Output

Ignition switch
OFF

When Intelligent Key is in
the passenger compart-
ment

When Intelligent Key is not
in the passenger compart-
ment

80

(GR)

Ground

NATS antenna amp
(built in key slot)

Input/

Output

During waiting

Ignition switch is pressed
while inserting the Intelli-
gent Key into the key slot.

Just after pressing ignition
switch. Pointer of tester should
move.

81

(W)

Ground

NATS antenna amp
(built in key slot)

Input/

Output

During waiting

Ignition switch is pressed
while inserting the Intelli-
gent Key into the key slot.

Just after pressing ignition
switch. Pointer of tester should
move.

82

(R)

Ground

Ignition relay (relay
box) control

Output

Ignition switch

OFF or ACC

0 V

ON

Battery voltage

83

(Y)

Ground

Remote keyless entry
receiver signal

Input/

Output

During waiting

When operating either button on Intelligent Key

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

–

JMKIA0062GB

JMKIA0063GB

JMKIA0064GB

JMKIA0065GB

RF-28

< ECU DIAGNOSIS >

BCM (BODY CONTROL MODULE)

87

(BR)

Ground

Combination switch
INPUT 5

Input

Combination
switch

All switch OFF
(Wiper intermittent dial 4)

1.4 V

Front fog lamp switch ON
(Wiper intermittent dial 4)

1.3 V

Any of the conditions below
with all switch OFF
• Wiper intermittent dial 1
• Wiper intermittent dial 2
• Wiper intermittent dial 6
• Wiper intermittent dial 7

1.3 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

–

JPMIA0041GB

JPMIA0037GB

JPMIA0040GB

BCM (BODY CONTROL MODULE)

RF-29

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

J

L

M

A

B

RF

N

O

P

88

(V)

Ground

Combination switch
INPUT 3

Input

Combination
switch

All switch OFF
(Wiper intermittent dial 4)

1.4 V

Lighting switch HI
(Wiper intermittent dial 4)

1.3 V

Lighting switch 2ND
(Wiper intermittent dial 4)

1.3 V

Any of the conditions below
with all switches OFF
• Wiper intermittent dial 1
• Wiper intermittent dial 2
• Wiper intermittent dial 3

1.3 V

89

(BR)

Ground

Push-button ignition
switch (push switch)

Input

Push-button igni-
tion switch (push
switch)

Pressed

0 V

Not pressed

Battery voltage

90

(P)

Ground

CAN - L

Input/

Output

—

—

91

(L)

Ground

CAN - H

Input/

Output

—

—

92

(LG)

Ground

Key slot illumination

Output

Key slot illumina-
tion

OFF

0 V

Blinking

6.5 V

ON

Battery voltage
