RF-14

< SERVICE INFORMATION >

SUNROOF

Terminal and Reference Value for BCM

INFOID:0000000001328038

Terminal and Reference Value for Sunroof Motor Assembly

INFOID:0000000001328039

Ter-

minal

Wire

color

Item

Signal

Input/

Output

Condition

Voltage (V)

(Approx.)

Ignition

switch

OPeration or condition

12 P/B

Front door switch
(passenger side) signal

Input

OFF

OPEN (ON)

0

CLOSE (OFF)

Battery voltage

38

W/L

Ignition switch (ON)

Input

Ignition switch (ON or START) position

Battery voltage

42

L/R

Power source (Fuse)

Input

OFF

—

Battery voltage

49

B

Ground (signal)

—

ON

—

0

52

B

Ground (power)

—

ON

—

0

53 Y/B

RAP

signal

Output

Ignition switch ON

Battery voltage

OFF

Within 45 seconds after ignition switch is
turned to OFF position

Battery voltage

When driver side or passenger side door
open in power window timer is operates.

0

54

W

Power window power supply

Output

OFF

—

Battery voltage

55

G

Power source (Fusible link)

Input

OFF

—

Battery voltage

62 W

Front door switch
(driver side) signal

Input

OFF

OPEN (ON)

0

CLOSE (OFF)

Battery voltage

Ter-

minal

Wire

color

Item

Signal

Input/

Output

Condition

Voltage (V)

(Approx.)

Ignition

switch

Operation or condition

1

BR

Sunroof switch (Tilt up/
Slide close) signal

Input

ON

Ignition switch ON and sunroof
switch in TILT UP/SLIDE
CLOSE position

0

Other than above

Battery voltage

5

LG

Sunroof switch
(Tilt down/Slide open)
signal

Input

ON

Ignition switch ON and sunroof
switch in TILT DOWN/SLIDE
OPEN position

0

Other than above

Battery voltage

7

W

Power window power
supply

Input

OFF

—

Battery voltage

8

G

Vehicle speed signal

Input

ON

Speedometer operated
[When vehicle speed is approx.
40 km/h (25 MPH)]

9

SB

RAP signal

Input

Ignition switch ON

Battery voltage

OFF

Within 45 seconds after ignition
switch is turned to OFF position

Battery voltage

When driver side or passenger
side door open in power window
timer is operates.

0

10

B

Ground

—

ON

—

0

ELF1080D

SUNROOF

RF-15

< SERVICE INFORMATION >

C

D

E

F

G

H

J

K

L

M

A

B

RF

N

O

P

Work Flow

INFOID:0000000001328040

1.

Check the symptom and customer's requests.

2.

Understand the outline of system. Refer to

RF-10, "System Description"

.

3.

According to the trouble diagnosis chart, repair or replace the cause of the malfunction. Refer to

RF-15,

"Trouble Diagnosis Chart by Symptom"

.

4.

Does sunroof system operate normally? If Yes, GO TO 5. If No, GO TO 3.

5.

INSPECTION END.

CONSULT-III Function (BCM)

INFOID:0000000001328041

ACTIVE TEST

WORK SUPPORT

DATA MONITOR

Trouble Diagnosis Chart by Symptom

INFOID:0000000001328042

BCM diagnostic test item

Check item diagnostic test mode

Content

Refer to page

RETAINED PWR

Work support

Changes setting of each function.

“WORK SUP-

PORT”

Data monitor

Displays the input data of BCM in real time.

“DATA MONI-

TOR”

Active test

Gives a drive signal to a load to check the operation.

“ACTIVE

TEST”

Test Item

Description

RETAINED PWR

This test is able to supply RAP signal (power) from BCM (body control module) to power window
system and power sunroof system (if equipped). Those systems can be operated when turning on
“RETAINED PWR” on CONSULT-III screen even if the ignition switch is turned OFF.
NOTE:
During this test, CONSULT-III can be operated with ignition switch in OFF position. “RETAINED
PWR” should be turned ON or OFF on CONSULT-III screen when ignition switch is ON. Then turn
ignition switch OFF to check retained power operation. CONSULT-III might be stuck if “RETAINED
PWR” is turned to ON or OFF on CONSULT-III screen when ignition switch is OFF.

Work item

Description

RETAINED PWR

Rap signal’s power supply period can be changed by mode setting. Selects rap signal’s power sup-
ply period between three steps
• MODE1 (45 sec.) / MODE2 (OFF) / MODE 3 (2 min.).

Monitor item

Description

IGN ON SW

Indicates [ON / OFF] condition of ignition switch

DOOR SW–DR

Indicates [ON / OFF] condition of front door switch driver side

DOOR SW–AS

Indicates [ON / OFF] condition of front door switch passenger side

Symptom

Diagnostic procedure and repair order

Refer to page

Sunroof does not operate.

1. Check BCM power supply and ground circuit.

RF-16

2. Check sunroof motor assembly power supply and ground circuit.

RF-16

3. Check sunroof switch system.

RF-18

4. Replace sunroof motor assembly.

RF-22

Motor does not stop at the sunroof fully -open or
fully- closed position.

1. Check initialization procedure.

RF-10

2. Replace sunroof motor assembly.

RF-22

RF-16

< SERVICE INFORMATION >

SUNROOF

Check BCM Power Supply and Ground Circuit

INFOID:0000000001328043

1.

CHECK FUSE

• Check 15A fuse [No.1, located in the fuse block (J/B)]
• Check 15A fuse [No.22, located in the fuse block (J/B)]
• Check 50A fusible link (letter M, located in the fuse and fusible link box).

NOTE:
Refer to

RF-10, "Component Parts and Harness Connector Location"

.

OK or NG

OK

>> GO TO 2.

NG

>> If fuse is blown out, be sure to eliminate cause of malfunction before installing new fuse. Refer to

RF-10, "Component Parts and Harness Connector Location"

.

2.

CHECK POWER SUPPLY CIRCUIT

1.

Turn ignition switch ON.

2.

Check voltage between BCM connector M3, M4 terminal 38, 42, 55 and ground.

OK or NG

OK

>> GO TO 3.

NG

>> Check BCM power supply circuit for open or short.

3.

CHECK GROUND CIRCUIT

1.

Turn ignition switch OFF.

2.

Disconnect BCM connector.

3.

Check continuity between BCM connector M4 terminal 49, 52 and ground.

OK or NG

OK

>> Power supply and ground circuit are OK.

NG

>> Check BCM ground circuit for open or short.

Check Sunroof Motor Assembly Power Supply and Ground Circuit

INFOID:0000000001328044

1.

CHECK POWER SUPPLY CIRCUIT

1.

Turn ignition switch ON.

2.

Check voltage between sunroof motor assembly connector R5 terminal 7, 9 and ground.

Retained power operation does not operate
properly.

1. Check the retained power operation mode setting.

RF-15

2. Check door switch.

RF-19

3. Replace sunroof motor assembly.

RF-22

Sunroof does not operate the interruption de-
tection function.

Replace sunroof motor assembly.

RF-22

Symptom

Diagnostic procedure and repair order

Refer to page

38 (W/L) – Ground

: Battery voltage

42 (L/R) – Ground

: Battery voltage

55 (G) – Ground

: Battery voltage

PIIA6160E

49 (B) – Ground

: Continuity should exist.

52 (B) – Ground

: Continuity should exist.

PIIA6161E

SUNROOF

RF-17

< SERVICE INFORMATION >

C

D

E

F

G

H

J

K

L

M

A

B

RF

N

O

P

OK or NG

OK

>> GO TO 2.

NG

>> GO TO 3.

2.

CHECK GROUND CIRCUIT

1.

Turn ignition switch OFF.

2.

Disconnect sunroof motor assembly connector.

3.

Check continuity between sunroof motor assembly connector R5 terminal 10 and ground.

OK or NG

OK

>> Sunroof motor assembly power supply and ground cir-

cuit are OK. Further inspection is necessary. Refer to

RF-15, "Trouble Diagnosis Chart by Symptom"

.

NG

>> Repair or replace harness.

3.

CHECK SONROOF MOTOR CIRCUIT

1.

Turn ignition switch OFF.

2.

Disconnect BCM and sunroof motor assembly connector.

3.

Check continuity between BCM connector M4 terminal 53, 54 and sunroof motor assembly connector R5
terminal 7, 9.

4.

Check continuity between BCM connector M4 terminal 53, 54
and ground.

OK or NG

OK

>> GO TO 4.

NG

>> Repair or replace harness.

4.

CHECK BCM OUTPUT SIGNAL

1.

Connect BCM connector.

2.

Turn ignition switch ON.

7 (W) – Ground

: Battery voltage

9 (SB) – Ground

: Battery voltage

PIIA6151E

10 (B) – Ground

: Continuity should exist.

PIIA6152E

53 (Y/B) – 9 (SB)

: Continuity should exist.

54 (W) – 7 (W)

: Continuity should exist.

53 (Y/B) – Ground

: Continuity should not exist.

54 (W) – Ground

: Continuity should not exist.

PIIA6153E
