Infiniti EX35. Manual - part 814

EXL-300

< ECU DIAGNOSIS >

[HALOGEN TYPE]

BCM (BODY CONTROL MODULE)

66

(R)

Ground

Back door switch

Input

Back door switch

OFF (Door close)

11.8 V

ON (Door open)

0 V

67

(GR)

Ground

Back door opener
switch

Input

Back door opener
switch

Pressed

0 V

Not pressed

11.8 V

68

(BR)

Ground

Rear RH door switch

Input

Rear RH door
switch

OFF (Door close)

11.8 V

ON (Door open)

0 V

69

(R)

Ground

Rear LH door switch

Input

Rear LH door
switch

OFF (Door close)

11.8 V

ON (Door open)

0 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

–

JPMIA0011GB

JPMIA0011GB

JPMIA0011GB

JPMIA0011GB

BCM (BODY CONTROL MODULE)

EXL-301

< ECU DIAGNOSIS >

[HALOGEN TYPE]

C

D

E

F

G

H

I

J

K

M

A

B

EXL

N

O

P

72

(R)

Ground

Room antenna 2 (

−

)

(Center console)

Output

Ignition switch
OFF

When Intelligent Key is in
the passenger compart-
ment

When Intelligent Key is not
in the passenger compart-
ment

73

(G)

Ground

Room antenna 2 (+)
(Center console)

Output

Ignition switch
OFF

When Intelligent Key is in
the passenger compart-
ment

When Intelligent Key is not
in the passenger compart-
ment

74

(SB)

Ground

Passenger door an-
tenna (

−

)

Output

When the pas-
senger door re-
quest switch is
operated with ig-
nition switch OFF

When Intelligent Key is in
the antenna detection area

When Intelligent Key is not
in the antenna detection
area

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

–

JMKIA0062GB

JMKIA0063GB

JMKIA0062GB

JMKIA0063GB

JMKIA0062GB

JMKIA0063GB

EXL-302

< ECU DIAGNOSIS >

[HALOGEN TYPE]

BCM (BODY CONTROL MODULE)

75

(GR)

Ground

Passenger door an-
tenna (+)

Output

When the pas-
senger door re-
quest switch is
operated with ig-
nition switch OFF

When Intelligent Key is in
the antenna detection area

When Intelligent Key is not
in the antenna detection
area

76

(V)

Ground

Driver door antenna
(

−

)

Output

When the driver
door request
switch is operat-
ed with ignition
switch OFF

When Intelligent Key is in
the antenna detection area

When Intelligent Key is not
in the antenna detection
area

77

(LG)

Ground

Driver door antenna
(+)

Output

When the driver
door request
switch is operat-
ed with ignition
switch OFF

When Intelligent Key is in
the antenna detection area

When Intelligent Key is not
in the antenna detection
area

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

–

JMKIA0062GB

JMKIA0063GB

JMKIA0062GB

JMKIA0063GB

JMKIA0062GB

JMKIA0063GB

BCM (BODY CONTROL MODULE)

EXL-303

< ECU DIAGNOSIS >

[HALOGEN TYPE]

C

D

E

F

G

H

I

J

K

M

A

B

EXL

N

O

P

78

(Y)

Ground

Room antenna (

−

)

(Instrument panel)

Output

Ignition switch
OFF

When Intelligent Key is in
the passenger compart-
ment

When Intelligent Key is not
in the passenger compart-
ment

79

(BR)

Ground

Room antenna (+)
(Instrument panel)

Output

Ignition switch
OFF

When Intelligent Key is in
the passenger compart-
ment

When Intelligent Key is not
in the passenger compart-
ment

80

(GR)

Ground

NATS antenna amp
(Built in key slot)

Input/

Output

During waiting

Ignition switch is pressed
while inserting the key into
the key slot.

Just after pressing ignition
switch. Pointer of tester should
move.

81

(W)

Ground

NATS antenna amp
(Built in key slot)

Input/

Output

During waiting

Ignition switch is pressed
while inserting the key into
the key slot.

Just after pressing ignition
switch. Pointer of tester should
move.

82

(R)

Ground

Ignition relay [Fuse
block (J/B)] control

Output

Ignition switch

OFF or ACC

0 V

ON

Battery voltage

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

–

JMKIA0062GB

JMKIA0063GB

JMKIA0062GB

JMKIA0063GB
