Infiniti EX35. Manual - part 813





EXL-296

< ECU DIAGNOSIS >

[HALOGEN TYPE]

BCM (BODY CONTROL MODULE)

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

1

(W)

Ground

Battery power supply

Input

Ignition switch OFF

Battery voltage

2

(Y)

Ground

P/W power supply
(BAT)

Output

Ignition switch OFF

Battery voltage

3

(O)

Ground

P/W power supply
(RAP)

Output

Ignition switch ON

Battery voltage

4

(LG)

Ground

Interior room lamp
power supply

Output

Interior room lamp battery saver is activated.
(Cuts the interior room lamp power supply)

0 V

Interior room lamp battery saver is not activat-
ed.
(Outputs the interior room lamp power supply)

Battery voltage

5

(L)

Ground

Passenger door UN-
LOCK

Output

Passenger door

UNLOCK
(Actuator is activated)

Battery voltage

Other than UNLOCK
(Actuator is not activated)

0 V

7

(Y)

Ground

Step lamp

Output

Step lamp

ON

0 V

OFF

Battery voltage

8

(V)

Ground

All doors, fuel lid
LOCK

Output

All doors

LOCK
(Actuator is activated)

Battery voltage

Other than LOCK
(Actuator is not activated)

0 V

9

(G)

Ground

Driver door, fuel lid
UNLOCK

Output

Driver door

UNLOCK
(Actuator is activated)

Battery voltage

Other than UNLOCK
(Actuator is not activated)

0 V

10

(BR)

Ground

Rear RH door and
rear LH door UN-
LOCK

Output

Rear RH door
and rear LH door

UNLOCK
(Actuator is activated)

Battery voltage

Other than UNLOCK
(Actuator is not activated)

0 V

11

(R)

Ground

Battery power supply

Input

Ignition switch OFF

Battery voltage

13

(B)

Ground

Ground

Ignition switch ON

0 V

14

(W)

Ground

Push-button ignition
switch illumination
ground

Output

Tail lamp

OFF

0 V

ON

NOTE:
When the illumination brighten-
ing/dimming level is in the neutral
position

15

(Y)

Ground

ACC indicator lamp

Output

Ignition switch

OFF or ON

Battery voltage

ACC

0 V

JSNIA0010GB

BCM (BODY CONTROL MODULE)

EXL-297

< ECU DIAGNOSIS >

[HALOGEN TYPE]

C

D

E

F

G

H

I

J

K

M

A

B

EXL

N

O

P

17

(W)

Ground

Turn signal RH
(Front)

Output

Ignition switch
ON

Turn signal switch OFF

0 V

Turn signal switch RH

6.5 V

18

(O)

Ground

Turn signal LH
(Front)

Output

Ignition switch
ON

Turn signal switch OFF

0 V

Turn signal switch LH

6.5 V

19

(V)

Ground

Room lamp timer
control

Output

Interior room
lamp

OFF

Battery voltage

ON

0 V

20

(V)

Ground

Turn signal RH
(Rear)

Output

Ignition switch
ON

Turn signal switch OFF

0 V

Turn signal switch RH

6.5 V

23

(G)

Ground

Back door opening

Output

Back door

OPEN
(Back door opener actuator
is activated)

Battery voltage

Other than OPEN
(Back door opener actuator
is not activated)

0 V

25

(G)

Ground

Turn signal LH (Rear)

Output

Ignition switch
ON

Turn signal switch OFF

0 V

Turn signal switch LH

6.5 V

26

(G)

Ground

Rear wiper

Output

Rear wiper

OFF (Stopped)

0 V

ON (Operated)

Battery voltage

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

PKID0926E

PKID0926E

PKID0926E

PKID0926E

EXL-298

< ECU DIAGNOSIS >

[HALOGEN TYPE]

BCM (BODY CONTROL MODULE)

34

(SB)

Ground

Luggage room anten-
na 1 (

)

Output

Ignition switch
OFF

When Intelligent Key is in
the passenger compart-
ment

When Intelligent Key is not
in the passenger compart-
ment

35

(V)

Ground

Luggage room anten-
na 1 (+)

Output

Ignition switch
OFF

When Intelligent Key is in
the passenger compart-
ment

When Intelligent Key is not
in the passenger compart-
ment

38

(B)

Ground

Rear bumper anten-
na (

)

Output

When the back
door request
switch is operat-
ed with ignition
switch OFF

When Intelligent Key is in
the antenna detection area

When Intelligent Key is not
in the antenna detection
area

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

JMKIA0062GB

JMKIA0063GB

JMKIA0062GB

JMKIA0063GB

JMKIA0062GB

JMKIA0063GB

BCM (BODY CONTROL MODULE)

EXL-299

< ECU DIAGNOSIS >

[HALOGEN TYPE]

C

D

E

F

G

H

I

J

K

M

A

B

EXL

N

O

P

39

(W)

Ground

Rear bumper anten-
na (+)

Output

When the back
door request
switch is operat-
ed with ignition
switch OFF

When Intelligent Key is in
the antenna detection area

When Intelligent Key is not
in the antenna detection
area

47

(Y)

Ground

Ignition relay (IPDM
E/R) control

Output

Ignition switch

OFF or ACC

Battery voltage

ON

0 V

52

(SB)

Ground

Starter relay control

Output

Ignition switch
ON

When selector lever is in P
or N position

Battery voltage

When selector lever is not
in P or N position

0 V

61

(W)

Ground

Back door opener re-
quest switch

Input

Back door re-
quest switch

ON (Pressed)

0 V

OFF (Not pressed)

1.0 V

64

(V)

Ground

Request switch buzz-
er

Output

Request switch
buzzer

Sounding

0 V

Not sounding

Battery voltage

65

(O)

Ground

Rear wiper stop posi-
tion

Input

Rear wiper

In stop position

1.0 V

Not in stop position

0 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

JMKIA0062GB

JMKIA0063GB

JPMIA0016GB

JPMIA0016GB
