Driver assistance system
• Size, thickness, height, or shape of the
• Objects generating excessive noise,
object does not reflect ultrasonic waves
such as vehicle horns, loud motorcycle
well (e.g., pole, bush, curbs, carts, edge
engines, or truck air brakes, are near
of a wall, etc.).
your vehicle.
• The pedestrian or object is moving very
• Your vehicle is backing toward a narrow
quickly.
passage or parking space.
• The pedestrian or object is very close to
• Your vehicle is backing towards an
the rear of your vehicle.
uneven road surface, such as unpaved
road, gravel, bump, gradient, etc.
• There is a wall is behind the pedestrian
or object.
• An ultrasonic sensor with similar
frequency is near your vehicle.
• The object is not located at the rear
center of your vehicle.
• Pedestrians or objects are near the path
of your vehicle.
• The object is not parallel to the rear
bumper.
• The pedestrian or object is moving very
quickly.
• The road is slippery or inclined.
• You accelerate your vehicle or drive in
• The pedestrian is in a state that is
circles.
difficult detect.
• You back up the vehicle immediately
WARNING
after shifting to R (Reverse).
Reverse Parking Collision-Avoidance
• You accelerate your vehicle or drive in
Assist may not operate in all situations
circles.
and cannot avoid all collisions.
Reverse Parking Collision-Avoidance
To prevent serious injury or death:
Assist may unnecessarily warn you or
assist braking even if there are no
• Always exercise extreme caution while
pedestrians or objects if:
driving. The driver is responsible for
braking and safe driving.
• Any non-factory equipment or
accessory is installed on the rear of your
• Always pay attention to road and traffic
vehicle.
conditions while driving. Brake as
needed to avoid collisions. Do not
• Your vehicle has been damaged due to
solely rely on Reverse Parking
an accident or other causes.
Collision-Avoidance Assist.
• Bumper height or rear ultrasonic sensor
• Always look around your vehicle to
installation locations have been
make sure there are no pedestrians or
modified.
objects before parking.
• Your vehicle height is lower or higher
• The performance of Reverse Parking
than normal due to heavy loads,
Collision-Avoidance Assist may differ
abnormal tire pressure, etc.
under certain conditions. If your vehicle
• Rear view camera or rear ultrasonic
speed is greater than 2 mph (4 km/h),
sensor(s) is covered or blocked with
Reverse Parking Collision- Avoidance
snow, water, or dirt.
Assist provides collision avoidance
• The pattern on the road is mistaken for
assist only when pedestrians are
a pedestrian.
detected.
• There are shadows or light reflecting on
the ground.
7-118
CarManuals2.com
7
Reverse Parking Collision-Avoidance
• The brake control may not operate
Assist may operate differently under
properly depending on the status of
certain conditions. If the vehicle moves
ESC (Electronic Stability Control).
forward and backward repeatedly,
There will only be a warning when:
Reverse Parking Collision-Avoidance
- The ESC (Electronic Stability Control)
Assist may fail to assist braking or to
warning light is on
warn the driver. Always pay attention
when driving your vehicle.
- ESC (Electronic Stability Control) is
engaged in a different function
Some objects may not be detected by
the rear ultrasonic sensors due to the
object's distance, size, or material.
Reverse Parking Collision-Avoidance
CAUTION
Assist may not operate properly or may
Take the following precautions to
operate unnecessarily depending on
maintain optimal performance of the
the road conditions and the
detecting sensors:
surroundings.
Always keep the wide-rear view
Do not solely rely on Parking
cameras and ultrasonic sensors clean.
Collision-Avoidance Assist. Doing so
Do not use any cleanser containing acid
may lead to vehicle damage or injuries.
or alkaline detergents when cleaning
the camera lens. Use only a mild soap or
neutral detergent, and rinse thoroughly
CAUTION
with water.
Noise may be heard when sudden
Do not spray the wide-rear view
braking occurs to avoid a collision.
cameras or the rear ultrasonic sensors
or their surrounding area directly with a
If any other warning sound such as the
high pressure washer. It may cause the
seat belt warning chime is already
wide angle cameras or the ultrasonic
generated, Parking
sensors to malfunction.
Collision-Avoidance Assist warning
may not sound.
Do not apply objects, such as a bumper
sticker or a bumper guard, near the
Parking Collision-Avoidance Assist may
wide angle cameras or ultrasonic
not work properly if the bumper has
sensors or apply paint to the bumper.
been damaged, replaced or repaired.
Doing so may adversely affect the
Parking Collision-Avoidance Assist may
performance of Parking
not operate properly if interfered by
Collision-Avoidance Assist.
strong electromagnetic waves.
Never disassemble or apply impact on
Playing the vehicle audio system at
the wide angle cameras or the
high volume may prevent passengers
ultrasonic sensors components.
from hearing Parking
Do not apply unnecessary force on the
Collision-Avoidance Assist warning
wide-rear view cameras or the
sounds.
ultrasonic sensors. Reverse Parking
Collision-Avoidance Assist may not
operate properly if the wide angle
cameras or the ultrasonic sensor(s) is
forcibly moved out of proper
alignment. Have the vehicle inspected
by an authorized HYUNDAI dealer.
7-119
CarManuals2.com
Driver assistance system
Driver assistance system
Information
Reverse Parking Collision-Avoidance
sensors
Assist can detect a pedestrian or an
The Driver Assistance system on your
object when:
vehicle uses cameras and sensors to
• A pedestrian is standing behind the
detect potential hazards in the vicinity of
vehicle.
your vehicle.
• A large obstacle, such as a vehicle, is
parked in the rear center of your
vehicle.
Cameras
Front view camera
OCN7073252N
The front view camera is mounted near
the top of the windshield inside your
vehicle.
Wide-front view camera
if equipped
OCN7073254N
The wide-front view camera is mounted
on the front grill outside your vehicle.
7-120
CarManuals2.com
7
Wide-side view camera
WARNING
if equipped
To prevent serious injury or death:
• Never disassemble the camera sensors
or camera sensor assemblies.
• Only have the detecting sensor
replaced or repaired by an authorized
HYUNDAI dealer.
• Never install any accessories, stickers,
or tint the front windshield.
• Always keep the camera dry.
• Never place any reflective objects (e.g.
OCN7073253N
white paper, mirror) on the dashboard.
The wide-side view cameras are mounted
• Do not use any cleanser containing acid
at bottom of the side view mirrors.
or alkaline detergents when cleaning
the camera lenses. Use only a mild soap
or neutral detergent, and rinse
Wide-rear view camera
thoroughly with water.
if equipped
Radars
if equipped
Front radar
OCN7073255N
The wide-rear view camera is mounted
above the license plate holder outside
your vehicle.
OCN7073256N
The front radar is mounted behind the
front grill.
7-121
CarManuals2.com
Driver assistance system
Rear corner radar
• Driver Assistance system may not work
properly if the bumper has been
replaced, or the surroundings of the
radar has been damaged or painted.
• If a trailer or hitch mounted carrier is
attached, it may adversely affect the
performance of the rear corner radar or
Driver Assistance system may not
operate.
Ultrasonic sensors
OCN7073257N
if equipped
The rear corner radars are mounted near
the rear corners of your vehicle above the
Front ultrasonic sensors
bumper.
WARNING
To prevent serious injury or death:
• Never disassemble the radar or radar
assembly, and never apply any impact
on it.
• If there is impact on or near the radar,
the sensors may be damaged or not be
properly aligned near the radar, even
though a warning message does not
appear on the instrument cluster,
OCN7073192N
Driver Assistance system may not
These ultrasonic sensors are mounted to
operate properly. Have the vehicle
the front bumper outside your vehicle.
inspected by an authorized HYUNDAI
dealer.
Rear ultrasonic sensors
• If the radars have been replaced or
repaired, have the vehicle inspected by
an authorized HYUNDAI dealer.
• Use only genuine HYUNDAI parts to
repair the bumper where the radar is
located.
• Do not install a license plate frame or
other objects such as bumper sticker,
film, bumper guard, or bumper wrap
near the radar.
OCN7073258N
These ultrasonic sensors are mounted to
the rear bumper outside your vehicle.
7-122
CarManuals2.com
7
Declaration of conformity
WARNING
if equipped
To prevent serious injury or death:
The radio frequency components
• Always keep the ultrasonic sensors
complies:
clean.
• Do not spray the ultrasonic sensors or
the surrounding area directly with high
Front radar
pressure water.
• For USA
• Do not apply objects such as bumper
sticker or bumper guard, near the
ultrasonic sensors or never apply paint
to the bumper or other locations.
• Never disassemble or strike the
ultrasonic sensors components.
• Do not modify the vehicle bumper
height or ultrasonic sensor installations.
Any non-factory installed equipment or
accessories may also interfere with the
sensor performance.
• If the ultrasonic sensors have been
forcibly moved out of proper alignment
or are damaged, have the vehicle
inspected by an authorized HYUNDAI
dealer.
OANATEL125
7-123
CarManuals2.com
Driver assistance system
• For Canada
Rear corner radar
• For USA
OANATEL124
• For Canada
OANATEL126
OANATEL123
7-124
CarManuals2.com
8. Emergency situations
Hazard warning flasher
8-2
In case of an emergency while driving
8-2
If the engine stalls while driving
8-2
If the engine stalls at a crossroad or crossing
8-2
If you have a flat tire while driving
8-3
If the engine does not start
8-3
Jump starting
8-4
If the engine overheats
8-6
Tire Pressure Monitoring System (TPMS)
8-8
Check tire pressure
8-8
Tire pressure monitoring system
8-9
Low tire pressure warning light
8-10
Low tire pressure position and tire pressure telltale
8-10
TPMS malfunction indicator
8-11
Changing a tire with TPMS
8-11
If you have a flat tire
8-13
Jack and tools
8-13
Jack label
8-14
Changing tires
8-15
Towing
8-18
Towing service
8-18
Removable towing hook
8-19
Emergency towing
8-20
8
CarManuals2.com
Emergency situations
Hazard warning flasher
In case of an emergency
while driving
If the engine stalls while
driving
• Reduce the speed gradually, keeping a
straight line. Move cautiously off the
road to a safe place.
• Turn on your hazard warning flasher.
• Try to start the engine again. If your
OCN7070001
vehicle does not start, contact an
The hazard warning flashers warn other
authorized HYUNDAI dealer or seek
drivers to exercise extreme caution when
other qualified assistance.
approaching, overtaking, or passing your
vehicle.
If the engine stalls at a
It should be used whenever making
crossroad or crossing
emergency repairs or when stopped near
the edge of a roadway.
If the engine stalls at a crossroad or
intersection, if safe to do so, shift the gear
To turn on or off the hazard warning
to N (Neutral) and then push the vehicle
flasher, press the hazard warning flasher
to a safe location.
button with the ignition switch in any
position. The hazard warning flasher
button is located in the center fascia
panel. All turn signal lights flash
simultaneously.
• The hazard warning flasher operates
whether your vehicle is running or not.
• The turn signals do not work when the
hazard flasher is on.
8-2
CarManuals2.com
8
If you have a flat tire while
If the engine does not
driving
start
If a tire goes flat while you are driving:
• Be sure to shift the gear to N (Neutral)
• Take your foot off the accelerator pedal
or P (Park). The engine starts only when
and let the vehicle slow down while
the gear is in N (Neutral) or P (Park).
driving straight ahead. Do not apply the
brakes immediately or attempt to pull
• Turn on the interior light. If the light
off the road because this may cause
dims or goes out when you operate the
loss of vehicle control resulting in a
starter, the battery is drained.
collision. When the vehicle has slowed
Refer to the instructions in "Jump
to such a speed that it is safe to do so,
starting" provided in this chapter.
brake carefully and pull off the road.
• Check the fuel level and add fuel if
Drive off the road as far as possible and
necessary.
park on a firm, level ground. If you are
on a divided highway, do not park in the
If the vehicle still does not start, contact
median area between the two traffic
an authorized HYUNDAI dealer for
lanes.
assistance.
• When the vehicle is stopped, press the
NOTICE
hazard warning flasher button, shift the
gear to P (Park), apply the parking
Starting the vehicle by pushing or pulling
brake, and move the ignition switch to
may cause the catalytic converter to
the LOCK/OFF position.
overload and damage the emission
control system.
• Have all passengers get out of the
vehicle. Make sure they all get out on
the side of the vehicle that is away from
traffic.
• When replacing a flat tire, follow the
instructions provided later in this
chapter.
8-3
CarManuals2.com
Emergency situations
If acid gets into your eyes, flush your eyes
Jump starting
with clean water for at least 15 minutes
Jump starting can be dangerous if done
and get immediate medical attention. If
incorrectly. Follow the jump starting
acid gets on your skin, thoroughly wash
procedure in this section to avoid serious
the area. If you feel pain or a burning
injury or damage to your vehicle. If in
sensation, get medical attention
doubt about how to properly jump start
immediately.
your vehicle, have a service technician or
• When lifting a plastic-cased battery,
towing service do it for you.
excessive pressure on the case may
cause battery acid to leak. Lift with a
WARNING
battery carrier or with your hands on
To prevent SERIOUS INJURY or DEATH to
opposite corners.
you or bystanders, always follow these
• Do not attempt to jump start your
precautions when working near or
vehicle if your battery is frozen.
handling the battery:
• NEVER attempt to recharge the battery
when the vehicle’s battery cables are
connected to the battery.
• The electrical ignition system works
Always read and follow instructions
with high voltage.
carefully when handling a battery.
NEVER touch these components with
the engine running or when the ignition
switch is in the ON position.
Wear eye protection designed to protect
Jump starting procedure
the eyes from acid splashes.
1. Position the vehicles close enough that
the jumper cables can reach. Do not
allow the vehicles to touch.
2. Avoid fans or any moving parts in the
Keep all flames, sparks, or smoking
engine compartment at all times, even
materials away from the battery.
when the vehicles are turned off.
3. Turn off all electrical devices such as
radios, lights, air conditioning, etc. Put
the vehicles in P (Park) and apply the
Hydrogen is always present in battery
parking brake. Turn both vehicles OFF.
cells, is highly combustible, and may
explode if ignited.
4. Open the engine hood.
CAUTION
Before jump starting, make sure to
correctly identify the positive (+) and
Keep batteries out of reach of children.
negative (-) terminals to avoid reverse
polarity connections.
Batteries contain sulfuric acid that is
highly corrosive. Do not allow acid to
contact your eyes, skin, or clothing.
8-4
CarManuals2.com
8
10.Keep your vehicle operating for at least
30 minutes at idle or driving to make
sure your battery receives enough
charge to be able to start on its own
after the vehicle is shut off. A
completely discharged battery may
require as long as 60 minutes runtime
to fully recharge. If the vehicle is run for
less, the vehicle may not restart.
If your vehicle does not start after a few
attempts, it probably requires service.
OCN7083097
Have your vehicle inspected by an
authorized HYUNDAI dealer.
5. Connect the jumper cables in the exact
sequence shown in the illustration. First
Disconnect the jumper cables in the exact
connect one jumper cable to the red,
reverse order you connected them:
positive (+) battery terminal of your
1. Disconnect the jumper cable from the
vehicle (1).
chassis ground of your vehicle (4).
6.Connect the other end of the jumper
2. Disconnect the other end of the jumper
cable to the red, positive (+)
cable from the black, negative (-)
battery/jumper terminal of the
battery/jumper terminal of the
assisting vehicle (2).
assisting vehicle (3).
7. Connect the second jumper cable to
3. Disconnect the second jumper cable
the black, negative (-) battery/jumper
from the red, positive (+)
terminal of the assisting vehicle (3).
battery/jumper terminal of the
8.Connect the other end of the second
assisting vehicle (2).
jumper cable to the chassis ground of
4. Disconnect the other end of the jumper
your vehicle (4).
cable from the red, positive (+) battery
Do not allow the jumper cables to
terminal of your vehicle (1).
contact anything except the correct
battery or jumper terminals or the
Information
correct ground. Do not lean over the
battery when making connections.
WARNING
An inappropriately disposed battery may
Do not connect the jumper cable to the
be harmful to the environment and
negative (-) jumper terminal of the
human health. Always dispose of a used
discharged battery. A spark could
battery according to your local law(s) or
cause the battery to explode and lead
regulations.
to a personal injury or vehicle damage.
9.Start the engine of the assisting vehicle
and let it run at approximately 2,000
RPM for a few minutes. Then start your
vehicle.
8-5
CarManuals2.com
Emergency situations
NOTICE
If the engine overheats
To prevent damage to your vehicle:
If your temperature gauge indicates
overheating, you experience a loss of
• Only use a 12 V power supply (battery or
power, hear loud pinging or knocking, or
jumper system) to jump start your
the engine may be overheating. If this
vehicle.
happens, you must:
• Do not attempt to jump start your
1. Pull off the road and stop as soon as it is
vehicle by push-starting.
safe to do so.
2. Shift the gear to P (Park) and apply the
parking brake. If the air conditioning is
WARNING
ON, turn it OFF.
While jump starting your vehicle, avoid
3. If engine coolant is running out under
the positive (+) and negative (-) cables to
the vehicle or steam is coming out from
come in contact. A spark could cause
the hood, stop the engine. Do not open
personal injury.
the hood until the coolant has stopped
running or the steaming has stopped. If
there is no visible loss of engine coolant
and no steam, leave the engine running
and check to make sure the engine
cooling fan is operating. If the fan is not
running, turn off the engine.
WARNING
While the engine is running, keep
hands, clothing, and tools away from
the moving parts such as cooling fan
and drive belt to prevent serious injury.
4. Check for coolant leaking from the
radiator, hoses, or under the vehicle. (If
air conditioning has been used, it is
normal for cold water to be draining
from it when you stop.)
5. If the water pump drive belt is broken or
engine coolant is leaking out, stop the
engine immediately and call the
nearest authorized HYUNDAI dealer for
assistance.
8-6
CarManuals2.com
8
WARNING
NOTICE
Serious loss of coolant indicates a leak
in the cooling system. Have the system
inspected by an authorized HYUNDAI
dealer as soon as possible.
Never remove the radiator cap, engine
When the engine overheats from low
coolant cap, or the drain plug while the
engine coolant, suddenly adding
engine and radiator are hot.
engine coolant may cause cracks in the
Hot coolant and steam may blow out
engine. To prevent damage, add engine
under pressure, causing serious injury.
coolant slowly in small quantities. It
may require several refilling cycles to
Turn off the engine and wait until the
properly fill the engine cooling system.
engine cools down. Use extreme care
If necessary, contact an authorized
when removing the coolant cap. Wrap a
HYUNDAI dealer.
thick towel around it, and turn it
counterclockwise slowly to the first
stop. Step back while the pressure is
released from the cooling system.
When you are sure all the pressure has
been released, press down on the cap,
using a thick towel, and continue
turning counterclockwise to remove it.
6.If you cannot find the cause of the
overheating, wait until the engine
temperature has returned to normal.
Then, if coolant has been lost, carefully
add coolant to the reservoir to bring the
fluid level in the reservoir up to the
halfway mark.
7. Proceed with caution, keeping alert for
further signs of overheating. If
overheating happens again, contact an
authorized HYUNDAI dealer for
assistance.
8-7
CarManuals2.com
Emergency situations
Tire Pressure Monitoring
Check tire pressure
System (TPMS)
OCN7083056N
• You can check the tire pressure in the
OCN7073020N
Driving Assist mode in the instrument
cluster.
Refer to the "View modes" section in
chapter 4.
• Tire pressure appears after a few
minutes of driving. If the tire pressure
does not appear when the vehicle is
stopped, the message, "Drive to
display" appears.
• The displayed tire pressure values may
differ from those measured with a tire
pressure gauge.
OCN7083055N
(1) Low Tire Pressure Telltale/TPMS
• You can change the tire pressure unit
Malfunction Indicator
from the Settings menu in the
(2) Low Tire Pressure Position Telltale and
instrument cluster or infotainment
Tire Pressure Telltale (Shown on the
system. Select:
cluster display)
- User Settings > Units > Tire Pressure
Unit > psi, kpa, bar (for instrument
cluster)
- Settings > General > Units > Tire
Pressure Unit > psi, kpa, bar (for
infotainment system)
8-8
CarManuals2.com
8
Your vehicle has also been equipped with
Tire pressure monitoring
a TPMS malfunction indicator to indicate
system
when the system is not operating
properly. The TPMS malfunction indicator
WARNING
is combined with the low tire pressure
Over-inflation or under-inflation can
telltale. When the system detects a
reduce tire life, adversely affect vehicle
malfunction, the telltale flashes for about
handling, and lead to sudden tire failure
one minute and then remains
that may cause loss of vehicle control
continuously illuminated. This sequence
resulting in an collision.
continues upon subsequent vehicle
Each tire, including the spare (if
start-ups as long as the malfunction
provided), should be checked monthly
exists.
when cold and inflated to the inflation
When the malfunction indicator is
pressure recommended by the vehicle
illuminated, the system may not be able
manufacturer on the vehicle placard or
to detect or signal low tire pressure as
tire inflation pressure label. (If your
intended. TPMS malfunctions may occur
vehicle has tires of a different size than
for a variety of reasons, including the
the size indicated on the vehicle placard
installation of replacement or alternate
or tire inflation pressure label, you should
tires or wheels on the vehicle that prevent
determine the proper tire inflation
the TPMS from functioning properly.
pressure for those tires.)
Always check the TPMS malfunction
As an added safety feature, your vehicle
telltale after replacing one or more tires or
has been equipped with a tire pressure
wheels on your vehicle to ensure that the
monitoring system (TPMS) that
replacement or alternate tires and wheels
illuminates a low tire pressure telltale
allow the TPMS to continue to function
when one or more of your tires is
properly.
significantly under-inflated. Accordingly,
when the low tire pressure telltale
illuminates, you should stop and check
NOTICE
your tires as soon as possible, and inflate
them to the proper pressure. Driving on a
Have the system inspected by an
significantly under-inflated tire causes
authorized HYUNDAI dealer if:
the tire to overheat and can lead to tire
1. The Low Tire Pressure Telltale/TPMS
failure.
Malfunction Indicator does not
Under-inflation also reduces fuel
illuminate for 3 seconds when the
efficiency and tire tread life, and may
ignition switch is moved to the ON
affect the vehicle’s handling and stopping
position or the engine is running.
ability.
2. The TPMS Malfunction Indicator
Please note that the TPMS is not a
remains illuminated after blinking for
substitute for proper tire maintenance,
about 1 minute.
and it is the driver’s responsibility to
3. The Low Tire Pressure Position Telltale
maintain correct tire pressure, even if
remains illuminated.
under-inflation has not reached the level
to trigger illumination of the TPMS low
tire pressure telltale.
8-9
CarManuals2.com
Emergency situations
Low tire pressure warning
If either telltale illuminates, immediately
reduce the vehicle speed, avoid hard
light
cornering and anticipate increased
stopping distances. Stop and check your
tires as soon as possible. Inflate the tires
to the proper pressure as indicated on the
vehicle’s placard or tire inflation pressure
label located on the driver’s side center
pillar outer panel.
If you cannot reach a service station or
the tire cannot hold the newly added air,
replace the low pressure tire with the
spare tire.
OIK083054
The Low Tire Pressure Telltale remains on
and the TPMS Malfunction Indicator may
Low tire pressure position and
blink for one minute and then remain
tire pressure telltale
illuminated (when the vehicle is driven
about 10 minutes at the speed above 15.5
mph (25 km/h)) until you have the low
pressure tire repaired and replaced on the
vehicle.
WARNING
In winter or cold weather, the Low Tire
Pressure Telltale may be illuminated if the
tire pressure was adjusted to the
recommended tire inflation pressure in
warm weather. It does not mean your
OCN7083057N
TPMS is malfunctioning because the
decreased temperature leads to a
TPMS is not a substitute for manually
proportional lowering of tire pressure.
checking the tire pressure with a tire
gauge. Changes in temperature affect tire
When you drive your vehicle from a warm
pressure. Refer to "Check tire pressure" in
area to a cold area or from a cold area to a
the Maintenance chapter for proper tire
warm area, or the outside temperature is
inflation and tire pressure measurement
greatly higher or lower, check the tire
procedure.
inflation pressure and adjust the tires to
the recommended tire inflation pressure.
When the tire pressure monitoring
system warning indicators illuminate and
a warning message appears on the cluster
display, one or more of your tires are
significantly under-inflated. The Low Tire
Pressure Position Telltale indicates which
tire is significantly under-inflated by
illuminating the corresponding position
light.
8-10
CarManuals2.com
8
WARNING
NOTICE
Low pressure damage
The TPMS Malfunction Indicator may
illuminate after blinking for one minute if
Significantly low tire pressure makes the
the vehicle is near electric power supply
vehicle unstable and may contribute to
cables or radio transmitters such as police
loss of vehicle control and increased
stations, government and public offices,
braking distances.
broadcasting stations, military
Continued driving on low pressure tires
installations, airports, transmitting
may cause the tires to overheat and fail.
towers, etc.
Additionally, the TPMS Malfunction
Indicator may illuminate if snow chains
TPMS malfunction indicator
are used or if electronic devices such as
computers, chargers, remote starters,
navigation, etc. are near the vehicle. This
may interfere with normal operation of
the TPMS.
Changing a tire with TPMS
If you have a flat tire, the Low Tire
Pressure and Position telltales come on.
Have the flat tire repaired by an
OIK083054
authorized HYUNDAI dealer as soon as
The TPMS Malfunction Indicator
possible or replace the flat tire with the
illuminates after it blinks for about one
spare tire.
minute when there is a problem with the
Tire Pressure Monitoring System.
NOTICE
Have the system inspected by an
Do not use a puncture-repair kit not
authorized HYUNDAI dealer as soon as
approved by HYUNDAI. Tire sealant not
possible.
approved by HYUNDAI or the equivalent
sealant specified for your vehicle may
NOTICE
damage the tire pressure sensor.
If there is a malfunction with the TPMS,
The spare tire (if equipped) does not
the individual tire pressures on the cluster
come with a tire pressure monitoring
display are not be available. Have the
sensor. When the low pressure tire or the
system inspected by an authorized
flat tire is replaced with the spare tire, the
HYUNDAI dealer as soon as possible.
Low Tire Pressure Telltale remains on.
Also, the TPMS Malfunction Indicator
illuminates after blinking for one minute if
the vehicle is driven at the speed above
15.5 mph (25 km/h) for about 10 minutes.
8-11
CarManuals2.com
Emergency situations
Once the original wheel equipped with a
WARNING
tire pressure monitoring sensor is
reinflated to the recommended pressure
• The TPMS cannot alert you to severe
and reinstalled on the vehicle, the Low
and sudden tire damage caused by
Tire Pressure Telltale and TPMS
external factors such as nails or road
Malfunction Indicator goes off within a
debris.
few minutes of driving.
• If you feel any vehicle instability,
If the indicators do not turn off after a few
immediately take your foot off the
minutes, visit an authorized HYUNDAI
accelerator pedal, apply the brakes
dealer.
gradually with light force, and slowly
Each wheel is equipped with a tire
move to a safe position off the road.
pressure sensor mounted inside the tire
behind the valve stem (except for the
spare tire). You must use TPMS specific
WARNING
wheels. It is recommended that you
always have your tires serviced by an
Tampering with, modifying, or disabling
authorized HYUNDAI dealer.
the Tire Pressure Monitoring System
(TPMS) components may interfere with
You may not be able to identify a tire with
the system’s ability to warn the driver of
low pressure by simply looking at it.
low tire pressure conditions and/or TPMS
Always use a good quality tire pressure
malfunctions and may void the warranty.
gauge to measure. Note that a tire that is
hot (from being driven) has a higher
pressure measurement than a tire that is
cold.
A cold tire means the vehicle has been
sitting for 3 hours and driven for less than
1 mi. (1.6 km) in that 3 hour period.
Allow the tire to cool before measuring
the inflation pressure. Always make sure
the tire is cold before inflating to the
recommended pressure.
8-12
CarManuals2.com
8
Turn the winged hold down bolt
If you have a flat tire
counterclockwise to remove the spare
tire.
WARNING
Store the spare tire in the same
Follow the instructions in this section
compartment by turning the winged hold
when replacing a tire to reduce the risk of
down bolt clockwise.
serious injury or death. Changing a tire
To prevent the spare tire and tools from
can be dangerous.
"rattling", store them in their proper
locations.
Jack and tools
OLF064005
If it is hard to loosen the tire hold down
OLF064004N
wing bolt by hand, you can loosen it easily
(1) Jack handle
using the jack handle.
(2) Jack
1. Put the jack handle (1) inside of the tire
(3) Wheel lug wrench
hold-down wing bolt.
The jack and wheel lug wrench are stored
2. Turn the tire hold-down wing bolt
in the cargo area under the luggage box
counterclockwise with the jack handle.
cover.
The jack is provided for emergency tire
changing only.
OLF064031N
8-13
CarManuals2.com
Emergency situations
Jack label
OHYK065011
The actual jack label in the vehicle may differ from the illustration.
For more detailed specifications, refer to the label attached to the jack.
1. Model Name
2. Maximum allowable load
3. Always apply the parking brake before using a jack.
4. Always turn off the engine before using a jack.
5. Never put any portion of your body under the vehicle supported by a jack.
6.Only use the designated jacking locations on the frame.
7. When supporting the vehicle, have the base plate of the jack flat on the ground under
the lifting point.
8.Shift to the P (Park) position with the gear.
9.Do not jack the vehicle on an incline. Only jack the vehicle on a firm level ground.
10.Jack manufacturer
11.Production date
12.Representative company and address
8-14
CarManuals2.com
8
Changing tires
WARNING
Because the vehicle may slip or roll off of
a jack causing serious injury or death, take
the following safety precautions:
• NEVER place any portion of your body
under the vehicle that is supported by a
jack.
• NEVER attempt to change a tire in the
lane of traffic. ALWAYS move the
OCN7083058L
vehicle completely off the road on a
[A] Block
level, firm ground away from traffic
6. Loosen the wheel nuts
before trying to change a tire. If you
counterclockwise one turn each in the
cannot find a level, firm place off the
order shown above, but do not remove
road, call a towing service for
any wheel nuts until the tire has been
assistance.
raised off of the ground.
• ONLY use the jack provided with the
vehicle.
• ALWAYS place the jack on the
designated jacking positions on the
vehicle and NEVER on the bumpers or
any other part of the vehicle for jacking
support.
• Do not start or run the engine while the
vehicle is on the jack.
• Do not allow anyone to remain in the
vehicle while it is on the jack.
OCN7083059L
• Keep children away from the road and
7. Place the jack at the designated jacking
the vehicle.
position under the frame closest to the
tire you are changing. The jacking
positions are plates welded to the
Follow these steps to change your
frame with two notches. Never jack at
vehicle’s tire:
any other position or part of the vehicle
1. Park on a level, firm surface.
to prevent the vehicle slipping off of the
2. Shift the gear to P (Park), apply the
jack or damaging the vehicle.
parking brake, and move the ignition
switch to the LOCK/OFF position.
3. Press the hazard warning flasher
button.
4. Remove the wheel lug wrench, jack,
jack handle, and spare tire from the
vehicle.
5. Block both the front and rear of the tire
diagonally opposite of the tire you are
changing.
8-15
CarManuals2.com
Emergency situations
WARNING
Because the wheels may have sharp
edges, handle them carefully to avoid
possible severe injury. Before putting
the wheel into place, make sure that
there is nothing on the hub or wheel
(such as mud, tar, gravel, etc.) that
interferes with the wheel from fitting
solidly against the hub.
If there is, remove it. If there is not good
OCN7083060L
contact on the mounting surface
between the wheel and hub, the wheel
8.Insert the jack handle into the jack and
nuts may come loose and cause the
turn it clockwise, raising the vehicle
loss of a wheel. Loss of a wheel may
until the tire clears the ground. Make
result in loss of control of the vehicle.
sure the vehicle is stable on the jack.
This may cause serious injury or death.
10.Install the spare tire onto the studs of
the hub.
11.Tighten the wheel nuts with your
fingers onto the studs with the smaller
end of the wheel nuts closest to the
wheel.
12.Lower the vehicle to the ground by
turning the jack handle
OCN7083061L
counterclockwise.
9.Loosen the wheel nuts with the wheel
lug wrench and remove them with your
fingers. Remove the wheel from the
studs and lay it flat on the ground out of
the way. Remove any dirt or debris from
the studs, mounting surfaces, and
spare tire.
OCN7083062L
13.Use the wheel lug wrench to tighten
the wheel nuts in the order shown.
Double-check each wheel nuts until
they are tight. After changing tires,
have an authorized HYUNDAI dealer
tighten the wheel nuts to their proper
torque as soon as possible. Tighten the
wheel nuts to 79-94 lbf.ft (11-13 kgf.m).
8-16
CarManuals2.com
8
Check the tire pressure after installing the
Use of compact spare tires
compact spare tire. The compact spare
Compact spare tires are designed for
tire should be inflated to 60 psi (420 kPa).
emergency use only. Drive carefully on
If you have a tire gauge, check the spare
the compact spare tire and always follow
tire pressure (refer to the "Tires and
the safety precautions.
Wheels" section in chapter 10 for tire
pressure instructions.). If the spare tire
WARNING
pressure is lower or higher than the
To prevent compact spare tire failure and
recommended, drive slowly to the
loss of control possibly resulting in a
nearest service station and adjust to the
collision:
recommended pressure.
• Use the compact spare tire only in an
Always reinstall the valve cap after
emergency.
checking or adjusting the tire pressure. If
• NEVER operate your vehicle over 50
the cap is not replaced, air may leak from
mph (80 km/h).
the tire. If you lose a valve cap, buy
another and install it as soon as possible.
• Do not exceed the vehicle’s maximum
After changing tires, secure the flat tire
load rating or the load carrying capacity
and return the jack and tools to their
shown on the sidewall of the compact
proper storage locations.
spare tire.
• Do not use the compact spare tire
NOTICE
continuously. Repair or replace the
Check the tire pressure as soon as
original tire as soon as possible to avoid
possible after installing a spare tire.
failure of the compact spare tire.
Adjust it to the recommended pressure.
WARNING
When driving on the compact spare tire
mounted to your vehicle:
• Your vehicle has metric threads on the
• Do not take this vehicle through an
studs and wheel nuts. During tire
automatic car wash after the compact
changing, make sure that the nuts that
spare tire has been installed.
were removed are reinstalled. If you
have to replace your wheel nuts, make
• Do not use the compact spare tire on
sure they have metric threads to avoid
any other vehicle because this tire has
damaging the studs and make sure the
been designed especially for your
wheel is properly secured to the hub.
vehicle.
Contact an authorized HYUNDAI dealer
• The compact spare tire’s tread life is
for assistance.
shorter than a regular tire. Inspect your
• If the wheel studs are damaged, they
compact spare tire regularly and
may lose their ability to retain the
replace worn compact spare tires with
wheel. This may cause loss of the wheel
the same size and design, mounted on
and a collision resulting in serious
the same wheel.
injuries.
• Do not use more than one compact
spare tire at a time.
• Do not tow a trailer while the compact
If any of the equipment such as jack,
spare tire is installed.
wheel nuts, studs, or other equipment is
damaged or in poor condition, do not
attempt to change the tire and call for
assistance.
8-17
CarManuals2.com
Emergency situations
Towing
Information
When the original tire and wheel are
repaired and reinstalled on the vehicle,
Towing service
the wheel nut torque must be set
correctly. The correct wheel nut
tightening torque is 79-94 lbf.ft (11-13
kgf.m).
NOTICE
To prevent damaging the compact spare
tire and your vehicle:
Drive slowly enough for the road
conditions to avoid all hazards, such as
a potholes or debris.
Avoid driving over obstacles. The
compact spare tire diameter is smaller
than the diameter of a conventional tire
and reduces the ground clearance
OCN7073240N
about 1 in. (25 mm).
[A] Dollies
Do not use tire chains on the compact
If towing is necessary, contact an
spare tire. Because of the smaller size, a
authorized HYUNDAI dealer or a
tire chain will not fit properly.
commercial tow-truck service.
Do not use the compact spare tire on
2WD vehicles can be towed with the rear
any other wheels, nor should standard
wheels on the ground (without dollies)
tires, snow tires, wheel covers or trim
and the front wheels off the ground. The
rings be used with the compact spare
use of wheel dollies or flatbed is
wheel.
recommended. If any of the loaded
Do not suddenly accelerate or
wheels or suspension components are
decelerate (0 <-> 25 mph (0 <-> 40
damaged or the vehicle is towed with the
km/h)) in any driving mode. It may
front wheels on the ground, use a towing
cause leakage of transfer oil.
dolly under the front wheels.
NOTICE
To prevent damage when towing:
• Do not lift using the trailer hitch or body
and chassis parts.
• Do not tow the vehicle with the front
wheels on the ground.
8-18
CarManuals2.com
8
WARNING
If your vehicle is equipped with a rollover
sensor, place the ignition switch in the
LOCK/OFF or ACC position when the
vehicle is being towed. The side impact
and curtain air bag may deploy if the
OCN7073012N
sensor detects the situation as a rollover.
• Do not tow vehicles with sling-type
equipment. Only use wheel lift or
flatbed equipment.
NOTICE
Always shift the gear to N (Neutral) to
prevent damage to the transmission
before towing.
Removable towing hook
OCN7073011N
1. Open the trunk, and remove the towing
hook from the tool case.
• Your vehicle is not designed to be
dinghy towed (with 4 wheels on the
ground) behind a motor home. To avoid
serious damage to your vehicle, do not
tow your vehicle with four wheels on
the ground.
2. Remove the hole cover by pressing the
OCN7073095N
lower part of the cover on the bumper.
When towing your vehicle without wheel
dollies:
1. Turn off the engine.
2. Place the ignition switch to the
LOCK/OFF position.
3. Change the gear to N (Neutral) while
depressing the brake pedal. Place the
ignition switch to the LOCK/OFF
position.
4. Place the ignition switch to the
LOCK/OFF position.
5. Release the parking brake (hand type).
3. Install the towing hook by turning it
clockwise into the hole until it is fully
secured.
8-19
CarManuals2.com
Emergency situations
4. Remove the towing hook and install the
WARNING
cover after use.
Use extreme caution when towing the
vehicle with a cable or chain. A driver
Emergency towing
must be in the vehicle to steer it and
Front
operate the brakes. Passengers other
than the driver must not be in the vehicle.
Always keep the following emergency
towing precautions:
Place the ignition switch in the ACC
position so the steering wheel is not
locked.
Shift the gear to N (Neutral).
Release the parking brake.
OCN7083101
Depress the brake pedal with more
Rear
force than normal because you have
reduced braking performance.
More steering effort is required
because the power steering system is
disabled.
Use a vehicle heavier than your own to
tow your vehicle.
The drivers of both vehicles must
communicate with each other
frequently.
Before emergency towing, check the
removable hook is not broken or
If emergency towing is necessary,
damaged.
contact an authorized HYUNDAI dealer or
Fasten the towing cable or chain
a commercial tow-truck service.
securely to the hook.
If a tow-truck service is not available in an
Do not jerk the cables, chains, or
emergency, your vehicle can be
removable hook. Apply steady and
temporarily towed using a cable or chain
even force.
secured to the removable towing hook at
the front (or rear) of the vehicle.
Perform emergency towing using cables
or chains on hard-surfaced roads for a
short distance and at low speeds. The
wheels, axles, power train, steering, and
brakes must all be in good working
condition.
8-20
CarManuals2.com
8
NOTICE
To avoid damage to your vehicle and
vehicle components when towing:
Always pull straight ahead when using
the towing hooks. Do not pull from the
side or at a vertical angle.
Do not use the towing hooks to pull the
vehicle out of mud, sand, or other
conditions from which the vehicle
cannot be driven out under its own
OCN7073017N
power.
• Use a towing cable or chain less than 16
Limit the vehicle speed to 10 mph (15
ft. (5 m) long. Attach a white or red cloth
km/h) and drive less than 1 mi. (1.5 km)
(about 12 in. (30 cm) wide) in the middle
when towing to avoid serious damage
of the cable or chain for easy visibility.
to the transmission.
• Drive carefully so the towing cable or
chain remains tight during towing.
• Before towing, check the Intelligent
Variable Transmission (IVT)/Dual clutch
transmission for fluid leaks under your
vehicle. If the Intelligent Variable
Transmission (IVT)/Dual clutch
transmission fluid is leaking, flatbed
equipment or a towing dolly must be
used.
NOTICE
Accelerate or decelerate the vehicle in a
slow and gradual manner while
maintaining tension on the tow rope or
chain to start or drive the vehicle.
Otherwise, tow hooks and the vehicle
may be damaged.
8-21
CarManuals2.com
CarManuals2.com
9. Maintenance
Engine Compartment
9-4
Maintenance services
9-5
Guide to hyundai genuine parts
9-5
Owner’s responsibility
9-6
Owner maintenance precautions
9-6
Owner maintenance
9-7
Owner maintenance schedule
9-7
Scheduled maintenance services
9-9
Normal maintenance schedule
9-11
Maintenance under severe usage conditions
9-15
Explanation of scheduled maintenance items
9-17
Engine oil and filter
9-17
Drive belts
9-17
Fuel lines, fuel hoses and connections
9-17
Fuel filter
9-17
Vapor hose and fuel filler cap
9-17
Vacuum crankcase ventilation hoses
9-17
Air cleaner filter
9-17
Spark plugs
9-17
Cooling system
9-17
Engine coolant
9-18
Intelligent Variable Transmission fluid
9-18
Dual Clutch Transmission fluid
9-18
Brake hoses and lines
9-18
Brake fluid
9-18
Parking brake
9-18
Brake discs, pads, calipers, and rotors
9-18
9
Drive shaft and related
9-18
Suspension mounting bolts
9-18
Steering gear box, linkage & boots/lower arm ball joint
9-18
Air conditioning refrigerant
9-18
Engine oil
9-19
Checking the engine oil level
9-19
Checking the engine oil and filter
9-20
Engine coolant
9-21
Checking the coolant level
9-21
CarManuals2.com
Changing coolant
9-23
Brake fluid
9-23
Checking the brake fluid level
9-23
Parking brake
9-24
Checking the parking brake
9-24
Washer fluid
9-25
Checking the washer fluid level
9-25
Air cleaner
9-25
Filter replacement
9-25
Cabin air filter
9-27
Filter inspection
9-27
Filter replacement
9-27
Wiper blades
9-28
Blade inspection
9-28
Blade replacement
9-28
Battery
9-29
For longer battery life
9-30
Battery capacity label
9-31
Battery recharging
9-31
Reset items
9-32
Tires and wheels
9-33
Tire care
9-33
Recommended cold tire inflation pressures
9-33
Check tire inflation pressure
9-34
Tire rotation
9-35
Wheel alignment and tire balance
9-35
9
Tire replacement
9-36
Wheel replacement
9-37
Tire traction
9-37
Tire maintenance
9-37
Tire sidewall labeling
9-37
Tire terminology and definitions
9-40
All season tires
9-43
Summer tires
9-43
Snow tires
9-43
CarManuals2.com
9. Maintenance
Radial-ply tires
9-44
Low aspect ratio tires
9-44
Fuses
9-45
Instrument panel fuse replacement
9-46
Engine compartment panel fuse replacement
9-46
Fuse/Relay panel description
9-48
Light bulbs
9-55
Headlight, parking light, Daytime Running Light, turn signal light, side marker
replacement
9-56
Side repeater light replacement
9-57
Rear combination light replacement
9-57
High mounted stop light replacement
9-60
License plate light bulb replacement
9-60
Interior light replacement
9-61
Appearance care
9-62
Exterior care
9-62
Interior care
9-66
Emission control system
9-69
1. Crankcase emission control system
9-69
2. Evaporative emission control system including onboard refueling vapor recovery
(ORVR)
9-69
3. Exhaust emission control system
9-70
Fuel requirements
9-71
Gasoline engine
9-71
California perchlorate notice
9-73
9
CarManuals2.com
Maintenance
Engine Compartment
Smartstream G2.0
O
Smartstream G1.6 T-GDI
O
The actual engine compartment in the vehicle may differ from the illustration.
(1) Engine coolant reservoir
(2) Brake fluid reservoir
(3) Air cleaner
(4) Engine oil dipstick
(5) Engine oil filler cap
(6) Windshield washer fluid reservoir
(7) Fuse box
(8) Battery
(9) Radiator cap
9-4
CarManuals2.com
9
Maintenance services
Exercise the utmost care to prevent
damage to your vehicle and injury to
yourself whenever performing any
maintenance or inspection procedures.
Have your vehicle maintained and
repaired by an authorized HYUNDAI
dealer. An authorized HYUNDAI dealer
meets HYUNDAI’s high service quality
standards and receives technical support
from HYUNDAI in order to provide you
with a high level of service satisfaction.
A100A02L
2. Why Hyundai Genuine Parts?
Guide to hyundai genuine
HYUNDAI Genuine Parts are engineered
parts
and built to meet rigid manufacturing
requirements. Damage caused by using
1. What are HYUNDAI Genuine Parts?
imitation, counterfeit, or used salvage
HYUNDAI Genuine Parts are the parts
parts is not covered under the HYUNDAI
used by HYUNDAI Motor Company to
New Vehicle Limited Warranty or any
manufacture vehicles. They are designed
other HYUNDAI warranty.
and tested for the optimum safety,
In addition, any damage to or failure of
performance, and reliability for our
HYUNDAI Genuine Parts caused by the
customers.
installation or failure of an imitation,
counterfeit or used salvage part are not
covered by any HYUNDAI Warranty.
A100A01L
A100A04L
9-5
CarManuals2.com
Maintenance
3. How can you tell if you are purchasing
Owner’s responsibility
HYUNDAI Genuine Parts?
Maintenance service and record
Look for the HYUNDAI Genuine Parts
retention are the owner’s responsibility.
Logo on the package (see below).
Retain documents that show proper
HYUNDAI Genuine Parts exported to the
maintenance has been performed on
U.S. are packaged with labels written only
your vehicle in accordance with the
in English.
scheduled maintenance service charts on
HYUNDAI Genuine Parts are only sold
the following pages. You need this
through authorized HYUNDAI
information to establish your compliance
Dealerships.
with the servicing and maintenance
requirements of your vehicle warranties.
Detailed warranty information is provided
in your Owner’s Handbook & Warranty
Information booklet.
Repairs and adjustments required as a
result of improper maintenance or a lack
of required maintenance are not covered.
Owner maintenance
precautions
Inadequate, incomplete, or insufficient
A100A03L
servicing may result in operational
problems with your vehicle that could
cause vehicle damage or a collision that
results in serious injury or death.
Your vehicle must not be modified in any
way. Such modifications may adversely
affect the performance, safety, or
durability of your vehicle and may, in
addition, violate conditions of the limited
warranties covering the vehicle.
NOTICE
Improper owner maintenance during the
warranty period may affect warranty
coverage. For more information, read the
separate Owner’s Handbook & Warranty
Information Booklet provided with the
vehicle.
9-6
CarManuals2.com
9
Owner maintenance
Owner maintenance schedule
WARNING
When you stop for fuel:
Performing maintenance on the vehicle
• Check the coolant level in the engine
can be dangerous. If you lack sufficient
coolant reservoir.
knowledge, experience, or proper tools
• Check the windshield washer fluid
and equipment to do the work, have it
level.
done by an authorized HYUNDAI dealer.
• Check for low or under-inflated tires.
Before performing maintenance:
• Park your vehicle on level ground. Shift
While operating your vehicle:
the vehicle to P (Park), apply the
parking brake, and move the ignition
Note any changes in the sound of the
switch to the LOCK/OFF position.
exhaust or any smell of exhaust fumes
in the vehicle.
• Block the tires (front and back) to
prevent the vehicle from moving.
Check for vibrations in the steering
Remove loose clothing or jewelry that
wheel. Notice if there is any increased
can become entangled in moving parts.
steering effort or looseness in the
steering wheel, or change in its
• If you must run the engine during
straight-ahead position.
maintenance, do it in an outdoor area
or in an area with plenty of ventilation.
Notice if your vehicle constantly turns
slightly or "pulls" to one side when
• Keep flames, sparks, or smoking
traveling on a smooth, level road.
materials away from the battery and
fuel-related parts.
When stopping, listen and check for
unusual sounds, pulling to one side,
increased brake pedal travel, or
"hard-to-push" brake pedal.
WARNING
If any slipping or changes in the
Do not touch metal parts (including strut
operation of your transmission occurs,
bars) while the engine is operating or hot
check the transmission fluid level.
to prevent serious injury. Turn off the
Check the Intelligent Variable
engine and wait until the metal parts cool
Transmission (IVT)/Dual clutch
down before working on the vehicle.
transmission P (Park) function.
The following lists are vehicle checks and
Check the parking brake.
inspections that should be performed by
Check for fluid leaks under your vehicle
the owner or an authorized HYUNDAI
(water dripping from the air
dealer at the frequencies indicated to
conditioning system during or after use
help ensure safe and dependable
is normal).
operation of your vehicle.
Any adverse conditions should be
brought to the attention of your
authorized HYUNDAI dealer as soon as
possible.
These Owner Maintenance vehicle
checks are generally not covered by
warranties and you may be charged for
labor, parts, and lubricants used.
9-7
CarManuals2.com
Maintenance
At least monthly:
At least once a year:
• Check the coolant level in the engine
Clean the body and door drain holes.
coolant reservoir.
Lubricate the door hinges and hood
• Check the operation of all exterior
hinges.
lights, including the headlights, brake
Lubricate the door, hood locks, and
lights, turn signals, and hazard warning
latches.
flashers.
Lubricate the door rubber weather
• Check the inflation pressures of all tires
strips.
including the spare for tires that are
Lubricate the door checker.
worn, show uneven wear, or are
damaged.
Check the air conditioning system.
• Check for loose wheel nuts.
Inspect and lubricate the transmission
linkage and controls.
WARNING
Clean the battery and terminals.
Be careful when checking your coolant
Check the brake fluid level.
level if the engine is hot. This may result in
coolant being blown out of the opening
and cause serious burns and other
injuries.
At least twice a year:
• Check the radiator, heater, and air
conditioning hoses for leaks or
damage.
• Check the windshield washer spray and
wiper operation. Clean the wiper blades
with a clean cloth dampened with
washer fluid.
• Check the headlight alignment.
• Check the muffler, exhaust pipes,
shields, and clamps.
• Check the seat belts for wear and
function.
9-8
CarManuals2.com
9
Scheduled maintenance services
If any of the following conditions apply, follow the Maintenance Under Severe Usage
Conditions.
• Repeated driving short distance of less than 5 mi. (8 km) in normal temperature or less
than 10 mi. (16 km) in freezing temperature
• Extensive engine idling or low speed driving for long distances
• Driving on rough, dusty, muddy, unpaved, graveled, or salt-spread roads
• Driving in areas using salt or other corrosive materials or in very cold weather
• Driving in heavy dust conditions
• Driving in heavy traffic
• Driving on uphill, downhill, or mountain roads
• Towing a trailer or using a camper, or driving with loads on the roof
• Driving as a patrol car, taxi, or other commercial use of vehicle towing
• Frequently driving at high speeds or rapid acceleration/deceleration
• Frequently driving in stop-and-go traffic
• Using engine oil that is not recommended (mineral type, semi-synthetic, lower grade
spec, etc.)
Information
After 10 years or 100,000 mi., use severe maintenance schedule.
9-9
CarManuals2.com
Maintenance
Information
• As it is normal for engine oil to be consumed during driving, the engine oil level should
be checked on regular basis.
• The engine oil change interval for normal operating conditions is based on the use of
the recommended engine specification.
• The vehicle may be equipped with the Oil Life Management System that predicts
engine oil life based on the driver’s driving history and alerts the driver to change
engine oil.
- If the deterioration of the engine oil increases depending on the driver’s driving
severity, the remaining oil life alert appears on the instrument cluster before the
normal engine oil replacement interval. Have the engine oil and filter changed by an
authorized HYUNDAI dealer.
- Oil Life Management System works when the recommended engine oil is used. So,
if recommended engine oil is not used, replace the engine oil according to the
maintenance schedule under severe usage condition.
Also, check the amount of engine oil regularly as this system assumes that the engine
oil is being filled normally.
- Always reset the remaining engine oil life whenever the engine oil is changed.
Otherwise, the indication of remaining Oil life in the Oil Life Management System
may not be accurate. To reset the Engine Oil Change Reminder, select ‘RESET’ from
the infotainment system screen. Then, select ‘Yes’ when the message "Has the
engine oil been changed? Press [Yes] to reset the oil life." appears on the screen.
- If there is no alert until the maximum maintenance interval, have the vehicle checked
by an authorized HYUNDAI dealer.
9-10
CarManuals2.com
9
Normal maintenance schedule
Months
12
24
36
48
60
72
84
96
108
120
132
144
156
MAINTENANCE
Miles×1,000
8
16
24
32
40
48
56
64
72
80
88
96
104
INTERVALS
Km×1,000
13
26
39
52
65
78
91
104
117
130
143
156
169
MAINTENANCE
ITEM
Smartstrea
m G2.0
R
R
R
R
R
R
R
R
R
R
R
R
R
Engine oil and
Atkinson
engine oil filter
*1*2
Smartstrea
m G1.6
R
R
R
R
R
R
R
R
R
R
R
R
R
T-GDi
Add fuel additives every 8,000 mi. (13,000 km) or 12
Fuel additives *3
months
Smartstrea
At first, inspect at 5,000 mi. (8,000 km) or 6 months.
Intercooler,
m G1.6
Thereafter, inspect every 20,000 mi. (32,000 km) or 24
in/out hose
T-GDi
months
Air cleaner filter
I
I
R
I
I
R
I
I
R
I
I
R
I
Smartstrea
m G2.0
Replace every 96,000 mi.
Atkinson
Spark plugs
Smartstrea
m G1.6
Replace every 48,000 mi.
T-GDi
Rotate tires
Rotate tires every 8,000 mi. (13,000 km) or 12 months
Cabin air filter
R
R
R
R
R
R
At first, inspect at 48,000 mi. (78,000 km) or 72 months.
Drive belts *4
Thereafter, inspect every 8,000 mi. (13,000 km) or 12
months
*1 Requires <API SN PLUS (or above) Full synthetic> grade engine oil. If a lower grade engine oil (mineral oil
including Semi-synthetic) is used, then the engine oil and engine oil filter must be replaced as indicated severe
maintenance condition.
*2 Never add any additives to the engine oil. Engine oil additives can change the properties of engine oil and may
cause serious engine failure.
*3 If TOP TIER Detergent Gasoline is not available, one bottle of additive is recommended. Additives are available
from your authorized HYUNDAI dealer along with information on how to use them. Do not mix other additives.
*4 The drive belt should be replaced when cracks occur or tension is reduced excessively.
R: Replace or change.
I : Inspect and if necessary, adjust, correct, clean or replace.
9-11
CarManuals2.com
Maintenance
Information
• As it is normal for engine oil to be consumed during driving, the amount of engine oil
should be checked regularly.
• The replacement cycle of engine oil is set by the period which the performance of our
recommended engine oil is maintained. So, if recommended engine oil is not used, a
replacement is required as indicated severe usage condition.
9-12
CarManuals2.com
9
Months
12
24
36
48
60
72
84
96
108
120
132
144
156
MAINTENANCE
Miles×1,000
8
16
24
32
40
48
56
64
72
80
88
96
104
INTERVALS
Km×1,000
13
26
39
52
65
78
91
104
117
130
143
156
169
MAINTENANCE
ITEM
At first, replace at 120,000 mi. (200,000 km) or 120
months.
Engine coolant
After that, replace every 24,000 mi. (39,000 km) or 24
months
Battery condition
I
I
I
I
I
I
I
I
I
I
I
I
I
Brake lines, hoses and
I
I
I
I
I
I
I
I
I
I
I
I
I
connections
Disc brakes and pads
I
I
I
I
I
I
I
I
I
I
I
I
I
Steering gear rack, linkage
and boots / lower arm ball
I
I
I
I
I
I
I
I
I
I
I
I
I
joint, upper arm ball joint
Driveshaft and boots
I
I
I
I
I
I
Suspension mounting bolts
I
I
I
I
I
I
I
I
I
I
I
I
I
Air conditioner refrigerant
I
I
I
I
I
I
I
I
I
I
I
I
I
Air conditioner compressor
I
I
I
I
I
I
I
I
I
I
I
I
I
Exhaust pipe and muffler
I
I
I
I
I
I
I
I
I
I
I
I
I
Intelligent variable
transmission fluid (if
No check, No service required
equipped) *1
Dual clutch transmission fluid
I
I
I
(if equipped) *2
*1 Use only the specified intelligent variable transmission fluid. (Refer to "Recommended lubricants and
capacities" section in chapter 2 or the label in the engine compartment.)
*2 Dual clutch transmission fluid should be changed anytime they have been submerged in water.
R: Replace or change.
I : Inspect and if necessary, adjust, correct, clean or replace.
9-13
CarManuals2.com
Maintenance
Months
12
24
36
48
60
72
84
96
108
120
132
144
156
MAINTENANCE
Miles×1,000
8
16
24
32
40
48
56
64
72
80
88
96
104
INTERVALS
Km×1,000
13
26
39
52
65
78
91
104
117
130
143
156
169
MAINTENANCE
ITEM
Vapor hose, fuel filler cap and
I
I
I
I
I
I
fuel tank
Fuel tank air filter
I
I
I
I
I
I
Fuel filter *1
-
Fuel lines, hoses and
I
I
I
I
I
I
connections
Parking brake
I
I
I
I
I
I
Inspect every 8,000 mi. (13,000 km) or 12 months, Replace
Brake fluid
every 48,000 mi. (78,000 km) or 48 months
*1 The fuel filter is considered to be maintenance free but periodic inspection is recommended for this
maintenance schedule depends on fuel quality. If there are some important safety matters like fuel flow
restriction, surging, loss of power, hard starting problem etc, replace the fuel filter immediately regardless of
maintenance schedule and consult an authorized HYUNDAI dealer for details.
R: Replace or change.
I : Inspect and if necessary, adjust, correct, clean or replace.
9-14
CarManuals2.com
9
Maintenance under severe usage conditions
The following items must be serviced more frequently on cars mainly used under severe
driving conditions. Refer to the chart below for the appropriate maintenance intervals.
R : Replace
I : Inspect and if necessary, adjust, correct, clean or replace
Maintenance
Maintenance
Maintenance item
Driving condition
operation
intervals
Smartstream
A, B, C, D, E, F, G,
G2.0
Replace every
H, I, J, K, L
Engine oil
Atkinson
R
5,000 mi. (8,000
and filter *1
km) or 6 months
Smartstream
D, H, I, L
G1.6 T-GDi
Inspect more
frequently
Air cleaner filter
I
C, E
depending on the
condition
Inspect more
frequently
Spark plugs
R
A, B, F, G, H, I, K
depending on the
condition
Inspect more
Steering gear rack, linkage
frequently
I
C, D, E, F, G
and boots
depending on the
condition
Inspect more
frequently
Front suspension ball joints
I
C, D, E, F, G
depending on the
condition
Inspect more
Disc brakes and pads,
frequently
I
C, D, E, G, H
calipers and rotors
depending on the
condition
Inspect more
frequently
Parking brake
I
C, D, G, H
depending on the
condition
Inspect more
frequently
Driveshaft and boots
I
C, D, E, F, G, H, I, J
depending on the
condition
9-15
CarManuals2.com
Maintenance
Maintenance
Maintenance
Maintenance item
Driving condition
operation
intervals
Inspect more
frequently
Cabin air filter
R
C, E, G
depending on the
condition
Intelligent variable
Replace every
A, C, D, E, F, G, H,
transmission fluid (if
R
60,000 mi.
I, K
equipped)
(90,000 km)
Replace every
Dual clutch transmission
R
80,000 mi.
C, D, F, G, H, I, J
fluid (if equipped)
(120,000km)
*1 Requires <API SN PLUS (or above) Full synthetic> grade engine oil. If a lower grade engine oil (mineral oil
including Semi-synthetic) is used, then the engine oil and engine oil filter must be replaced as indicated severe
maintenance condition.
Severe driving conditions
A. Repeated driving short distance of less than 5 mi. (8 km) in normal temperature or less
than 10 mi. (16 km) in freezing temperature
B. Extensive engine idling or low speed driving for long distances
C. Driving on rough, dusty, muddy, unpaved, graveled, or salt-spread roads
D. Driving in areas using salt or other corrosive materials or in very cold weather
E. Driving in heavy dust conditions
F. Driving in heavy traffic
G. Driving on uphill, downhill, or mountain roads
H. Towing a trailer or using a camper, or driving with loads on the roof
I. Driving as a patrol car, taxi, or other commercial use of vehicle towing
J. Frequently driving at high speeds or rapid acceleration/deceleration
K. Frequently driving in stop-and-go traffic
L. Using engine oil that is not recommended (mineral type, semi-synthetic, lower grade
spec, etc.)
9-16
CarManuals2.com
9
Explanation of scheduled
Vapor hose and fuel filler cap
The vapor hose and fuel filler cap should
maintenance items
be inspected at intervals specified in the
maintenance schedule. Your HYUNDAI
dealer helps determine if replacement is
Engine oil and filter
needed.
The engine oil and filter should be
changed at the intervals specified in the
maintenance schedule. If the vehicle is
Vacuum crankcase ventilation
driven in severe conditions, more
hoses
frequent oil and filter changes are
Visually check for proper installation,
required.
chafing, cracks, deterioration, and any
leakage. Replace any deteriorated or
damaged parts immediately.
Drive belts
Inspect all drive belts for evidence of cuts,
cracks, excessive wear, or oil saturation.
Air cleaner filter
Replace them if necessary.
The air cleaner filter should be replaced
Check the drive belts periodically for
by an authorized HYUNDAI dealer.
proper tension and adjusted as
necessary.
Spark plugs
WARNING
Be sure to install new spark plugs with the
correct heat range.
Always turn off the engine before
inspecting the drive belts.
When installing new spark plugs, make
sure the ignition coils are clean and free of
any oil or debris. Clean and wipe off the
Fuel lines, fuel hoses and
bottom portion of the ignition coil to
prevent any contamination with the spark
connections
plug during installation.
Check the fuel lines, fuel hoses, and
connections for leakage and damage.
WARNING
Have an authorized HYUNDAI dealer
Do not remove spark plugs from the
replace any damaged or leaking parts
vehicle when the engine is hot. You may
immediately.
damage the engine and may also risk
burn injury.
Fuel filter
The fuel filter is considered to be
maintenance free but periodic inspection
Cooling system
is recommended depending on the fuel
Check the cooling system components
quality. If there is fuel flow restriction,
such as radiator, coolant reservoir, hoses,
surging, loss of power, or hard starting,
and connections for leakage and damage.
contact an authorized HYUNDAI dealer to
Replace any damaged parts.
have the fuel filter replaced immediately.
9-17
CarManuals2.com
Maintenance
Engine coolant
Parking brake
The coolant should be changed at
Inspect the parking brake system
intervals specified in the maintenance
including the parking brake pedal and
schedule.
cables.
Intelligent Variable
Brake discs, pads, calipers,
Transmission fluid
and rotors
if equipped
Check the pads, the disc, and the rotor for
Intelligent variable transmission fluid
any excessive wear-out. Inspect calipers
should not be checked under normal
for any fluid leakage.
usage conditions.
Have the Intelligent variable transmission
Drive shaft and related
fluid changed by an authorized HYUNDAI
Check the drive shaft, boots, clamps,
dealer according to the maintenance
rubber couplings, and center-bearing
schedule.
rubber for cracks, deterioration, or
damage. Replace any damaged parts and
Dual Clutch Transmission fluid
if necessary, repack the grease.
if equipped
Dual clutch transmission fluid should not
Suspension mounting bolts
be checked under normal usage
Check the suspension connections for
conditions.
looseness or damage. Retighten to the
Have the Dual clutch transmission fluid
specified torque.
changed by an authorized HYUNDAI
dealer according to the maintenance
schedule.
Steering gear box, linkage &
boots/lower arm ball joint
With the vehicle stopped and the engine
Brake hoses and lines
off, check for excessive free-play in the
Visually check for proper installation,
steering wheel. Check the linkage for
chafing, cracks, deterioration, and any
bends or damage. Check the dust boots
leakage. Replace any deteriorated or
and ball joints for deterioration, cracks, or
damaged parts immediately.
damage.
Replace any damaged parts.
Brake fluid
Check the brake fluid level in the brake
Air conditioning refrigerant
fluid reservoir. The level should be
Check the air conditioning lines and
between the MIN and the MAX marks on
connections for leakage and damage.
the side of the reservoir. Use only
hydraulic brake fluid conforming to DOT 4
specification.
9-18
CarManuals2.com
9
Smartstream G1.6 T-GDI
Engine oil
Checking the engine oil level
Engine oil is used for lubricating, cooling,
and operating various hydraulic
components in the engine. Engine oil
consumption while driving is normal, and
it is necessary to check and refill the
engine oil regularly. Also, check and refill
the oil level within the recommended
maintenance schedule to prevent
deterioration of oil performance.
7. If the oil level is below the L, add
Check the engine oil following the below
enough oil to bring the level to F.
procedure.
Smartstream G2.0
1. Follow all of the oil manufacturer’s
precautions.
2. Make sure the vehicle is on the level
ground in P (Park) with the parking
brake set and the wheels blocked.
3. Turn the engine on and warm the
engine up until the coolant
temperature reaches a constant normal
temperature.
4. Turn the engine off, and remove the oil
filler cap and pull the dipstick out. Wait
for 15 minutes for the oil to return to the
Smartstream G1.6 T-GDI
oil pan.
5. Wipe the dipstick clean and re-insert it
fully.
6.Pull the dipstick out again and check
the level. The level should be between F
(Full) and L (Low).
Smartstream G2.0
Information
Use only the specified engine oil (Refer to
the "Recommended lubricants and
capacities" section in chapter 10).
9-19
CarManuals2.com
Maintenance
• To keep the engine in optimal
NOTICE
condition, use the recommended
To prevent damage to your engine:
engine oil and filter. If the
recommended engine oil and filter are
• Do not spill engine oil when adding or
not used, replace them according to
changing engine oil. Wipe off spilled oil
the Maintenance Schedule Under
immediately.
Severe Usage Conditions.
• The engine oil consumption may
• The purpose of the maintenance
increase while you break in the new
schedule for engine oil replacement is
vehicle, and it should stabilize after
to prevent oil deterioration and it is
driving 4,000 mi. (6,000 km).
irrelevant to oil consumption. Check
• The engine oil consumption may be
and refill engine oil regularly.
affected by driving habits, climate
conditions, traffic conditions, and oil
Information
quality. Inspect the engine oil level
When the oil pressure is low due to
regularly and refill if necessary.
insufficient engine oil, the Engine Oil
Pressure (
) warning light will
Checking the engine oil and
illuminate.
filter
In addition, the enhanced engine
protection system, which limits the
engine’s power is activated and the
Malfunction Indicator Lamp (
) will
illuminate when the vehicle is driven in
this state continuously. When the engine
oil pressure is restored, the warning light
and the enhanced engine protection
system will turn off after the engine is
restarted. (Smartstream G1.6 T-GDi)
OCN7092026
• The lubrication, rust prevention,
WARNING
cooling, and cleaning effect of the
Allow the engine to cool before replacing
engine oil will gradually degrade during
the oil.
its use. Have the engine oil and filter
changed by an authorized HYUNDAI
dealer according to the Oil Life
Management System instructions or
NOTICE
the Maintenance Schedule at the
Never add any additives to the engine oil.
beginning of this chapter.
Engine oil additives can change the
• If the maintenance schedule to replace
properties of engine oil and may cause
engine oil is exceeded, the engine oil
serious engine failure.
performance may deteriorate, and the
engine condition may be affected.
Therefore, replace the engine oil
according to the maintenance
schedule.
9-20
CarManuals2.com
9
If the coolant level is low, add enough
Engine coolant
distilled (deionized) water mixed with
The high pressure cooling system has a
antifreeze to bring the level to the MAX
reservoir filled with year-round antifreeze
mark. If frequent additions are required,
coolant.
contact an authorized HYUNDAI dealer.
Check the antifreeze protection and
WARNING
coolant level at least once a year, before
the winter season or before traveling to a
colder climate.
Checking the coolant level
Never remove the engine coolant
Smartstream G2.0
reservoir cap, radiator cap, or drain plug
while the engine and radiator are hot. Hot
coolant and steam may blow out under
pressure, causing serious injury.
Turn the vehicle off and wait until the
engine cools down. Use extreme care
when removing the engine coolant
reservoir cap and radiator cap. Wrap a
thick towel around it, and turn it
counterclockwise slowly to the first stop.
Step back while the pressure is released
from the cooling system. When you are
sure all the pressure has been released,
Smartstream G1.6 T-GDI
press down on the cap using a thick
towel, and continue turning
counterclockwise to remove it.
Information
The coolant level is influenced by the
engine temperature. Before checking or
refilling the coolant, turn off the engine
and allow the engine to cool.
Check the condition and connections of
all cooling system hoses and heater
hoses. Replace any swollen or
deteriorated hoses.
The coolant level should be filled between
the MAX and the MIN marks on the side of
the coolant reservoir when the engine is
cool.
9-21
CarManuals2.com
Maintenance
WARNING
Keep hands, clothing, and tools away
from the rotating fan blades of the
cooling fan.
Always turn off the vehicle unless the
OJX1099046
vehicle has to be inspected with the
engine on. The cooling fan may operate
automatically if the negative (-) battery
Recommended coolant
terminal is not disconnected.
• When adding coolant, use only
deionized water, distilled water, or soft
water for your vehicle and never mix
WARNING
hard water in the coolant filled at the
factory.
Make sure the coolant cap is properly
closed after refilling coolant. Otherwise,
• An incorrect coolant mixture may result
the engine may be overheated while
in severe malfunction or engine
driving.
damage.
1. Check if the coolant cap label is straight
• The engine in your vehicle has
in front.
aluminum engine parts and must be
protected by an phosphate-based
Engine compartment front view
ethylene glycol coolant to prevent
corrosion and freezing.
• Do not use alcohol or methanol coolant
or mix them with the specified coolant.
• Do not use a solution that contains
more than 60 % antifreeze or less than
35 % antifreeze, which could reduce the
effectiveness of the solution.
2. Make sure that the tiny protrusions
inside the coolant cap is securely
interlocked.
9-22
CarManuals2.com
9
For mixing percentage, refer to the
Brake fluid
following table:
Mixture Percentage
Ambient
Checking the brake fluid level
(volume)
Temperature
Antifreeze
Water
5 °F (-15 °C)
35
65
-13 °F (-25 °C)
40
60
-31 °F (-35 °C)
50
50
-49 °F (-45 °C)
60
40
OCN7080006
Information
Check the fluid level in the reservoir
If in doubt about the mix ratio, a 50 %
periodically. The fluid level must be
water and 50 % antifreeze mix is the
between the MAX and the MIN marks on
easiest to mix together because it is the
the side of the reservoir.
same quantity for each.
Before removing the reservoir cap and
adding brake fluid, clean the area around
the reservoir cap thoroughly to prevent
Changing coolant
brake fluid contamination.
Have the coolant changed by an
If the level is low, add the specified brake
authorized HYUNDAI dealer according to
fluid to the MAX level. If the fluid level is
the Maintenance Schedule.
excessively low or frequent additions are
required, have the brake system
NOTICE
inspected by an authorized HYUNDAI
To prevent damage to engine parts, put a
dealer.
thick towel around the engine coolant
cap before refilling the coolant to prevent
WARNING
the coolant from overflowing into engine
If brake fluid comes in contact with your
parts, such as the alternator.
eyes, flush your eyes with clean water for
at least 15 minutes and get immediate
medical attention.
9-23
CarManuals2.com
Maintenance
NOTICE
Parking brake
• Do not allow brake fluid to contact the
vehicle’s body paint, because paint
Checking the parking brake
damage may occur.
• Never use brake fluid that has been
exposed to open air for an extended
time and dispose of it properly.
• Do not use the wrong type of brake
fluid. A few drops of mineral based oil
such as engine oil in your brake system
may damage the brake system parts.
Information
OCN7080072L
Use only the brake fluid specified in the
Check the stroke of the parking brake by
"Recommended lubricants and
counting the number of "clicks’’ heard
capacities" section in chapter 10.
while fully applying it from the released
position. Also, the parking brake alone
should securely hold the vehicle on a
fairly steep grade. If the stroke is more or
less than specified, have the system be
inspected by an authorized HYUNDAI
dealer.
Stroke : 5-8 "clicks’’ at a force of 44 lbs
(20 kg, 196 N)
9-24
CarManuals2.com
9
Washer fluid
Air cleaner
Checking the washer fluid
Filter replacement
level
Type A
OCN7080007
Type B (N Line)
Check the fluid level in the washer fluid
reservoir and add fluid if necessary. Plain
water can be used during summer
months if washer fluid is not available.
However, use washer fluid with antifreeze
in cold climates to prevent freezing.
WARNING
To prevent serious injury or death:
• Do not use engine coolant or antifreeze
in the washer fluid reservoir. Engine
coolant can severely limit your visibility
The air cleaner filter can be cleaned for
when sprayed on the windshield and
inspection using compressed air. Do not
may cause loss of vehicle control
attempt to wash or rinse it, because water
resulting in a collision.
can damage the filter. If soiled, replace
• Do not allow sparks or flame to contact
the air cleaner filter.
the washer fluid or the washer fluid
1. Loosen the air cleaner cover attaching
reservoir. Washer fluid may contain
clip (1) and open the cover.
alcohol and can be flammable.
• Do not drink washer fluid and avoid
contact with skin.
• Keep washer fluid away from children
and animals.
OCN7090011N
9-25
CarManuals2.com
Maintenance
2. Replace the air cleaner filter.
NOTICE
• Do not drive with the air cleaner filter
removed. This may result in excessive
engine wear.
• When removing the air cleaner filter, be
careful that dust or dirt does not enter
the air intake. It may cause damage.
• Use HYUNDAI genuine parts or the
equivalent specified for your vehicle.
Use of non-genuine parts may damage
the air flow sensor.
OCN7090012N
3. Insert the air cleaner cover in the hinge
(2) and engage the clip (1) after closing
the cover.
OCN7080088N
4. Check that the cover is firmly installed.
Information
If the vehicle is operated in extremely
dusty or sandy areas, replace the element
more often than the usual recommended
intervals (refer to the "Maintenance under
severe usage conditions" section in this
chapter).
9-26
CarManuals2.com
9
5. Replace the cabin air filter.
Cabin air filter
Filter inspection
The cabin air filter must be replaced
according to the Maintenance Schedule.
If the vehicle operates in severely
air-polluted cities or on dusty rough roads
for a long time, have it inspected more
frequently and replaced immediately.
Replace the cabin air filter by following
the procedure below and be careful to
avoid damaging other components.
OIK077021
6. Reassemble in the reverse order of
Filter replacement
disassembly.
1. Open the glove box.
NOTICE
2. Push in both sides of the glove box to
release the glove box stopper pins and
Install a new cabin air filter with the arrow
allow the glove box to hang open.
symbol (↓) facing down, to improve
effectiveness.
OCN7080013
3. Press and hold the lock on the right side
of the cover.
4. Pull out the cover.
OCN7080014
9-27
CarManuals2.com
Maintenance
Front windshield wiper blade
Wiper blades
replacement
This vehicle has a "hidden" wiper design
Blade inspection
that cannot be lifted when in their bottom
resting position.
Contamination of the windshield or wiper
blades with foreign substances may
1. Within 20 seconds of turning off the
reduce the effectiveness of the
engine, lift and hold the wiper lever up
windshield wipers.
to the MIST position for about 2
seconds until the wipers move to the
Common sources of contamination are
top wipe position.
insects, tree sap, and hot wax treatments
used by some commercial car washes. If
the blades are not wiping properly, clean
both the window and the blades with
glass cleaner or mild detergent, and rinse
thoroughly with clean water. Replace
blades as needed.
NOTICE
To prevent damage to the wiper blades,
arms, or other components, do not:
• Use gasoline, kerosene, paint thinner,
OCN7080015
or other solvents on or near them.
2. Lift the wipers off the windshield.
• Attempt to move the wipers manually.
3. Rotate the wiper blade to access the
clip.
Blade replacement
When the wipers no longer clean
adequately, the blades may be worn or
cracked. Replace the wipers with new
ones.
NOTICE
To prevent damage:
• Never use non-specified wiper blades.
• Lift the wiper arms when in the top
wiping position.
OGSR076067
• Always return the wiper arms to the
windshield before driving.
4. While pushing the clip (1), pull down the
wiper blade (2).
9-28
CarManuals2.com
9
Battery
WARNING
To prevent serious injury or death to you
or bystanders when working near or
handling the battery:
Always read and follow instructions
carefully when handling a battery.
OGSR076066
5. Remove the wiper blade from the wiper
arm.
Wear eye protection designed to protect
the eyes from acid splashes.
Keep all flames, sparks, or smoking
materials away from the battery.
Hydrogen is always present in battery
cells, is highly combustible, and may
OGSR076068
explode if ignited.
6.Install a new wiper blade assembly in
the reverse order of removal.
7. Gently put down the wiper back onto
the windshield.
Keep batteries out of reach of children.
8.Turn the wipers to any ON position to
return the wiper arms to the bottom
resting position.
Batteries contain sulfuric acid that is
highly corrosive. Do not allow acid to
contact your eyes, skin, or clothing.
If acid gets into your eyes, flush your eyes
with clean water for at least 15 minutes
and get immediate medical attention. If
acid gets on your skin, thoroughly wash
the area. If you feel pain or a burning
sensation, get medical attention
immediately.
9-29
CarManuals2.com
Maintenance
• Lift a battery with a battery carrier or
NOTICE
with your hands on opposite corners.
When lifting a plastic-cased battery,
To prevent battery damage:
excessive pressure on the case may
• Always fully charge the battery and
cause battery acid to leak.
store indoors when you do not plan to
• Do not attempt to jump start your
use the vehicle for a long time if the
vehicle if your battery is frozen.
outside temperature is low enough to
• Never attempt to recharge the battery
cause the battery to freeze.
when the vehicle’s battery cables are
• Never connect unauthorized devices to
connected to the battery.
the battery.
• The electrical ignition system works
• Always fully charge the battery to
with high voltage. Never touch these
prevent battery case damage in low
components with the engine running or
temperature areas.
when the ignition switch is in the ON
• Do not tilt the battery.
position.
• Do not allow the (+) and (-) jumper
cables to touch. It may cause sparks.
For longer battery life
• The battery may rupture or explode
when you jump start with a low or
frozen battery.
• Leaked battery electrolyte due to
repeated driving on sharp curves (for
example, on circuits) may cause safety
problem. Avoid repeated driving on
sharp curves.
OCN7080016
• Keep the battery top clean and dry.
• Keep the terminals and connections
clean, tight, and coated with petroleum
jelly or terminal grease.
• Rinse any spilled electrolyte from the
battery immediately with a solution of
water and baking soda.
• If the vehicle is not going to be used for
an extended period of time, disconnect
the battery cables.
9-30
CarManuals2.com
9
Battery capacity label
Battery recharging
Type A
By battery charger
Your vehicle has a maintenance-free,
calcium-based battery.
• If the battery becomes discharged over
a short time (because, for example, the
headlights or interior lights are left on
while the vehicle is not used), recharge
it by slow charging (trickle) for 10 hours.
• If the battery gradually discharges
because of high electrical load while
OCN7093040N
the vehicle is being used, recharge at
Type B
20-30 A for two hours.
WARNING
To prevent the risk of serious injury or
death from explosions or acid burns:
Before performing maintenance or
recharging the battery, turn off all
accessories and stop the engine.
Keep all flames, sparks, or smoking
materials away from the battery.
Always work outdoors or in an area with
plenty of ventilation.
• CMF60L-DIN/AGM70L-DIN: The
Wear eye protection when checking the
HYUNDAI model name of battery
battery during charging. Do not contact
• 12V: The nominal voltage
the battery. This may result in serious
9.60Ah (20HR)/70Ah (20HR): The
injury.
nominal capacity (in Ampere hours)
Remove the battery from the vehicle
10.CCA: The cold-test current in amperes
and place it in a well ventilated area.
by SAE
Watch the battery during charging, and
11.550A/760A: The cold-test current in
stop or reduce the charging rate if the
amperes by EN
battery cells begin boiling violently.
12.RC 92min/RC 120min: The nominal
Remove the negative battery cable first
capacity (in Ampere hours)
and install it last when the battery is
disconnected. Disconnect the battery
charger in the following order:
1. Turn off the battery charger main
switch.
2. Unhook the negative clamp from the
negative battery terminal.
3. Unhook the positive clamp from the
positive battery terminal.
9-31
CarManuals2.com
Maintenance
By jump starting
NOTICE
After a jump start from a good battery,
AGM battery (if equipped)
drive the vehicle for 30 minutes or
Absorbent Glass Mat (AGM) batteries are
operate at idle for at least 60 minutes
maintenance-free and should be serviced
before it is shut off. The vehicle may not
by an authorized HYUNDAI dealer. Only
restart if you shut it off before the battery
charge using fully automatic battery
had a chance to adequately recharge.
chargers that are specifically for AGM
Refer to the "Jump starting" section in
batteries.
chapter 8 for more information on jump
starting procedures.
Information
CAUTION
• Do not open or remove the cap on top
of the battery. This may cause leaks of
internal electrolyte that could result in
An inappropriately disposed battery may
severe injury.
be harmful to the environment and
• Do not charge the AGM battery with a
human health. Always dispose of a used
general charger. It may damage or
battery according to your local law(s) or
explode the AGM battery. Only charge
regulations.
the AGM battery with a charger that has
AGM battery setting.
Reset items
The following items may need to be reset
after the battery has been discharged or
disconnected:
• Auto up/down window (refer to chapter
5)
• Sunroof (refer to chapter 5)
• Trip computer (refer to chapter 4)
• Climate control additional features
(refer to chapter 5)
9-32
CarManuals2.com
9
Tires and wheels
Tire care
For proper maintenance, safety, and
WARNING
maximum fuel economy, always
maintain the recommended tire
Tire failure may cause loss of vehicle
inflation pressures and stay within
control and result in a collision. To
the load limits and weight
reduce risk of serious injury or death:
distribution recommended for your
Inspect your tires monthly for
vehicle.
proper inflation as well as wear and
damage.
The recommended cold tire
pressure for your vehicle can be
found in this manual and on the tire
label located on the driver’s side
center pillar. Always use a tire
pressure gauge to measure tire
pressure. Tires with too much or
too little pressure wear unevenly
causing poor handling.
OCN7010009L
Check the pressure of the spare
All specifications (sizes and
every time you check the pressure
pressures) can be found on a label
of the other tires on your vehicle.
attached to the driver’s side center
Replace tires that are worn, show
pillar.
uneven wear, or are damaged.
Worn tires may cause loss of
Recommended cold tire
braking effectiveness, steering
inflation pressures
control, or traction.
Check all tire pressures (including the
Always replace tires with the same
spare) when the tires are cold. "Cold
size, type, construction, and tread
tires" mean the vehicle has not been
pattern as each tire that was
driven for at least three hours or
originally supplied with this vehicle.
driven less than 1 mi. (1.6 km).
Using tires and wheels other than
the recommended sizes may cause
Warm tires normally exceed the
unusual handling characteristics,
recommended cold tire pressures by
poor vehicle control, or negatively
4 to 6 psi (28 to 41 kPa). Do not
affect your vehicle’s Anti-Lock
release air from warm tires to adjust
Brake System (ABS).
the pressure. The tires are
under-inflated. For the
recommended inflation pressure,
refer to the "Tires and Wheels"
section in chapter 10.
9-33
CarManuals2.com
Maintenance
Check tire inflation pressure
WARNING
Check your tires, including the spare
Recommended pressures must be
tire, at least once a month.
maintained for the best ride,
vehicle handling, and minimum tire
How to check
wear.
Use a good quality tire pressure
Over-inflation or under-inflation
gauge to check the tire pressure. You
can reduce tire life, adversely affect
cannot tell if your tires are properly
vehicle handling, and lead to
inflated simply by looking at them.
sudden tire failure that may result
Radial tires may look properly inflated
in loss of vehicle control resulting in
when they are under- inflated.
a collision.
Remove the valve cap from the tire
Severe under-inflation may lead to
valve stem. Press the tire gauge
severe heat build-up, causing
firmly onto the valve to get a pressure
blowouts, tread separation, and
measurement. If the cold tire inflation
other tire failures that result in loss
pressure matches the recommended
of vehicle control resulting in a
pressure on the tire and loading
collision. This risk is much higher on
information label, no further
hot days and when driving for a
adjustment is necessary. If the
long time at high speeds.
pressure is low, add air until it
Under-inflation may cause
reaches the recommended pressure.
excessive wear, poor handling, and
Be sure to put the valve caps back on
reduced fuel economy. Wheel
the valve stems. Without the valve
deformation is also possible. Keep
cap, dirt or moisture may get into the
your tire pressures at the proper
valve core and cause air leakage. If a
levels. If a tire frequently needs
valve cap is missing, install a new one
refilling, have it inspected by an
as soon as possible.
authorized HYUNDAI dealer.
If you overfill the tire, release air by
Over-inflation produces a harsh
pushing on the metal stem in the
ride, excessive wear at the center of
center of the tire valve. Recheck the
the tire tread, and a greater
tire pressure with the tire gauge. Be
possibility of damage from road
sure to put the valve caps back on the
hazards.
valve stems. Without the valve cap,
dirt or moisture may get into the
valve core and cause air leakage. If a
valve cap is missing, install a new one
as soon as possible.
9-34
CarManuals2.com
9
Tire rotation
WARNING
To equalize tread wear, HYUNDAI
• Do not use the compact spare tire
recommends that the tires be rotated
for tire rotation.
according to the maintenance
schedule or sooner if irregular wear
• Do not mix bias ply and radial ply
develops.
tires under any circumstances. This
may cause unusual handling
During rotation, check the tires for
characteristics that may cause loss
correct balance.
of vehicle control and result in a
When rotating tires, check for uneven
collision.
wear and damage. Abnormal wear is
usually caused by incorrect tire
pressure, improper wheel alignment,
Wheel alignment and tire
out-of-balance wheels, severe
balance
braking, or severe cornering. Look for
The wheels on your vehicle were
bumps or bulges in the tread or side
aligned and balanced carefully at the
of the tire. Replace the tire if you find
factory, and you may not need to
any of these conditions. Replace the
have your wheels aligned again. If
tire if fabric or cord is visible. After
you notice unusual tire wear or your
rotation, be sure to bring the front
vehicle pulling to one side, the
and rear tire pressures to
alignment may need to be adjusted.
specification and check wheel nut
torque (proper torque is 79.6-94.0
If you notice your vehicle vibrating
lbf.ft [11.0-13.0 kgf.m]).
when driving on a smooth road, your
wheels may need to be rebalanced.
NOTICE
Only use approved wheel weights or
your vehicle’s aluminum wheels may
be damaged.
OHI078078
Disc brake pads should be inspected
for wear whenever tires are rotated.
Information
When installing an unsymmetrical
tire, install the side marked "outside"
facing out.
9-35
CarManuals2.com
Maintenance
Tire replacement
• When replacing tires (or wheels), it
is recommended to replace the two
Tread wear indicator
front or two rear tires (or wheels) as
a pair. Replacing just one tire may
seriously affect your vehicle’s
handling.
• Tires degrade over time, even when
they are not being used. Regardless
of the remaining tread, HYUNDAI
recommends that tires be replaced
after six (6) years.
• Driving in hot climates or excessive
loading may accelerate the tire
OLMB073027
aging process.
If the tire is worn evenly, a tread wear
indicator appears as a solid band
across the tread. This shows there is
Compact spare tire replacement
less than 1/16 in. (1.6 mm) of tread left
if equipped
on the tire. Replace the tire when this
A compact spare tire has a shorter
happens.
tread life than a regular size tire.
Do not wait for the band to appear
Replace it when you can see the tread
across the entire tread before
wear indicator bars on the tire. The
replacing the tire.
replacement compact spare tire
should be the same size and design
WARNING
tire as the one provided with your
To reduce the risk of serious injury or
vehicle and must be mounted on the
death:
same compact spare tire wheel. The
• Replace tires that are worn, show
compact spare tire is not designed to
uneven wear, or are damaged.
be mounted on a regular size wheel,
Worn tires may cause loss of
and the compact spare tire wheel is
braking effectiveness, steering
not designed for mounting a regular
control, and traction.
size tire.
• Always replace tires with the same
WARNING
size as each tire that was originally
supplied with this vehicle. Using
The normal size tire should be
tires and wheels other than the
repaired or replaced as soon as
recommended sizes may cause
possible to avoid failure of the spare
unusual handling characteristics,
and loss of vehicle control resulting in
poor vehicle control, or negatively
a collision.
affect your vehicle’s Anti-Lock
The compact spare tire is for
Brake System (ABS).
emergency use only. Do not operate
your vehicle over 50 mph (80 km/h)
when using the compact spare tire.
9-36
CarManuals2.com
9
Wheel replacement
When replacing the metal wheels for
any reason, make sure the new
wheels are equivalent to the original
factory units in diameter, rim width,
and offset.
Tire traction
Tire traction can be reduced if you
B0464EU01
drive on worn tires or the tires that
are improperly inflated, or on slippery
1. Manufacturer or brand name
road surfaces. Replace the tires when
Manufacturer or brand name is
tread wear indicators appear. To
shown.
reduce the possibility of losing
control, slow down whenever there is
rain, snow, or ice on the road.
2. Tire size designation
A tire’s sidewall is marked with a tire
size designation. You need this
Tire maintenance
information when selecting
In addition to proper inflation, correct
replacement tires for your vehicle.
wheel alignment helps decrease the
The following explains what the
tire wear. If you find a tire is worn
letters and numbers in the tire size
unevenly, have your dealer check the
designation mean.
wheel alignment. When you have
Example tire size designation:
new tires installed, make sure they
are balanced. This may increase ride
(These numbers are provided as an
comfort and tire life. Additionally, a
example only. Your tire size
tire must always be rebalanced if it is
designator may vary depending on
removed from the wheel.
your vehicle.)
205/55R16 91H
Tire sidewall labeling
205 - Tire width in millimeters.
This information identifies and
55 - Aspect ratio. The tire’s section
describes the fundamental
height as a percentage of its width.
characteristics of the tire and also
R - Tire construction code (Radial).
provides the tire identification
16 - Rim diameter in inches.
number (TIN) for safety standard
certification. The TIN can be used to
91 - Load Index, a numerical code
identify the tire in case of a recall.
associated with the maximum load
the tire can carry.
H - Speed Rating Symbol. See the
speed rating chart in this section for
additional information.
9-37
CarManuals2.com
Maintenance
Wheel size designation
3. Checking tire life (TIN: Tire
Identification Number)
Wheels are also marked with
important information that you need
Any tires that are over six years old,
if you ever have to replace one.
based on the manufacturing date,
(including the spare tire) must be
Example wheel size designation:
replaced by new ones. You can find
6.5J X 16
the manufacturing date on the tire
6.5 - Rim width in inches.
sidewall (possibly on the inside of the
wheel), displaying the DOT Code. The
J - Rim contour designation.
DOT Code is a series of numbers on a
16 - Rim diameter in inches.
tire consisting of numbers and
English letters. The manufacturing
Tire speed ratings
date is designated by the last four
The chart below lists many of the
digits (characters) of the DOT code.
different speed ratings currently
being used for passenger vehicle
DOT: XXXX XXXX OOOO
tires. The speed rating is part of the
The front part of the DOT shows a
tire size designation on the sidewall
plant code number, tire size, and
of the tire. This symbol corresponds
tread pattern and the last four
to that tire’s designed maximum safe
numbers indicate the week and year
operating speed.
manufactured.
For example:
Speed Rating
Maximum Speed
Symbol
DOT XXXX XXXX 1423 represents that
the tire was produced in the 14th
S
112 mph (180 km/h)
week of 2023.
T
118 mph (190 km/h)
4. Tire ply composition and material
H
130 mph (210 km/h)
The number of layers or plies of
rubber-coated fabric in the tire. Tire
V
149 mph (240 km/h)
manufacturers also must indicate the
materials in the tire, which include
W
168 mph (270 km/h)
steel, nylon, polyester, and others.
Y
186 mph (300 km/h)
The letter "R" means radial ply
construction. The letter "D" means
diagonal or bias ply construction; and
the letter "B" means belted-bias ply
construction.
9-38
CarManuals2.com
9
5. Maximum permissible inflation
Tread wear
pressure
The tread wear grade is a
This number is the greatest amount
comparative rating based on the
of air pressure that should be put in
wear rate of the tire when tested
the tire. Do not exceed the maximum
under controlled conditions on a
permissible inflation pressure. Refer
specified government test course.
to the Tire and Loading Information
For example, a tire graded 150 would
label for recommended inflation
wear one-and-a-half times (1½) as
pressure.
well on the government course as a
tire graded 100.
6. Maximum load rating
The relative performance of tires
This number indicates the maximum
depends upon the actual conditions
load in kilograms and pounds that
of their use, however, and may depart
can be carried by the tire. When
significantly from the norm due to
replacing the tires on the vehicle,
variations in driving habits, service
always use a tire that has the same
practices, and differences in road
load rating as the factory installed
characteristics and climate.
tire.
These grades are molded on the
sidewalls of passenger vehicle tires.
7. DOT Tire Quality Grading (U.S.
The tires available as standard or
Vehicles)
optional equipment on your vehicle
may vary depending on the grade.
The tires on your vehicle meet all
U.S. Federal Safety Requirements.
Traction - AA, A, B & C
All tires are also graded for
The traction grades, from highest to
treadwear, traction, and
lowest, are AA, A, B, and C. Those
temperature performance
grades represent the tire’s ability to
according to Department of
stop on wet pavement as measured
Transportation (DOT) standards.
under controlled conditions on
Uniform tire quality grading
specified government test surfaces
of asphalt and concrete. A tire
Quality grades can be found where
marked C may have poor traction
applicable on the tire sidewall
performance.
between tread shoulder and
maximum section width.
WARNING
For example:
The traction grade assigned to this
TREADWEAR 200
tire is based on straight ahead
TRACTION AA
braking traction tests, and does not
include acceleration, cornering,
TEMPERATURE A
hydroplaning, or peak traction
characteristics.
9-39
CarManuals2.com
Maintenance
Temperature - A, B & C
Tire terminology and
The temperature grades are A (the
definitions
highest), B and C representing the
tire’s resistance to the generation of
Air pressure
heat and its ability to dissipate heat
The amount of air inside the tire
when tested under controlled
pressing outward on the tire. Air
conditions on a specified indoor
pressure is expressed in pounds per
laboratory test wheel.
square inch (psi) or kilopascal (kPa).
Sustained high temperature may
cause the material of the tire to
Accessory weight
degenerate and reduce tire life, and
This means the combined weight of
excessive temperature may lead to
optional accessories. Some examples
sudden tire failure. The grade C
of optional accessories are automatic
corresponds to a level of
transmission, power seats, and air
performance that all passenger car
conditioning.
tires must meet the Federal Motor
Vehicle Safety Standard No. 109.
Grades A and B represent higher
Aspect ratio
levels of performance on the
The relationship of a tire’s height to
laboratory test wheel than the
its width.
minimum required by law.
Belt
WARNING
A rubber coated layer of cords that is
The temperature grade for this tire is
located between the plies and the
established for a tire that is properly
tread. Cords may be made from steel
inflated and not overloaded.
or other reinforcing materials.
Excessive speed, under-inflation,
over-inflation, or excessive loading,
either separately or in combination,
Bead
may cause heat build-up and
The tire bead contains steel wires
possible sudden tire failure.
wrapped by steel cords that hold the
tire onto the rim.
Bias ply tire
A pneumatic tire in which the plies
are laid at alternate angles less than
90 degrees to the centerline of the
tread.
9-40
CarManuals2.com
9
Cold tire pressure
Kilopascal (kPa)
The amount of air pressure in a tire,
The metric unit for air pressure.
measured in pounds per square inch
(psi) or kilopascals (kPa) before a tire
Light Truck (LT) tire
has built up heat from driving.
A tire designated by its manufacturer
as primarily intended for use on
Curb weight
lightweight trucks or multipurpose
This means the weight of a motor
passenger vehicles.
vehicle with standard and optional
equipment including the maximum
Load ratings
capacity of fuel, oil and coolant, but
The maximum load that a tire is rated
without passengers and cargo.
to carry for a given inflation pressure.
DOT markings
Load index
A code molded into the sidewall of a
An assigned number ranging from 1 to
tire signifying that the tire is in
279 that corresponds to the load
compliance with the U.S. Department
carrying capacity of a tire.
of Transportation motor vehicle
safety standards. The DOT code
includes the Tire Identification
Maximum inflation pressure
Number (TIN), an alphanumeric
The maximum air pressure to which a
designator which can also identify
cold tire may be inflated. The
the tire manufacturer, production
maximum air pressure is molded onto
plant, brand and date of production.
the sidewall.
GVWR
Maximum load rating
Gross Vehicle Weight Rating
The load rating for a tire at the
maximum permissible inflation
pressure for that tire.
GAWR FRT
Gross Axle Weight Rating for the
Front Axle.
Maximum loaded vehicle weight
The sum of curb weight; accessory
weight; vehicle capacity weight; and
GAWR RR
production options weight.
Gross Axle Weight Rating for the Rear
axle.
Normal occupant weight
The number of occupants a vehicle is
Intended outboard sidewall
designed to seat multiplied by 150
The side of an asymmetrical tire, that
lbs. (68 kg).
must always face outward when
mounted on a vehicle.
9-41
CarManuals2.com
Maintenance
Occupant distribution
Recommended inflation pressure
Designated seating positions.
Vehicle manufacturer’s
recommended tire inflation pressure
as shown on the tire placard.
Outward facing sidewall
An asymmetrical tire has a particular
side that faces outward when
Radial ply tire
mounted on a vehicle. The outward
A pneumatic tire in which the ply
facing sidewall bears white lettering
cords that extend to the beads are
or bears manufacturer, brand, and/or
laid at 90 degrees to the centerline of
model name molding that is higher or
the tread.
deeper than the same moldings on
the inner facing sidewall.
Rim
A metal support for a tire and upon
Passenger (P-Metric) tire
which the tire beads are seated.
A tire used on passenger cars and
some light duty trucks and
Sidewall
multipurpose vehicles.
The portion of a tire between the
tread and the bead.
Ply
A layer of rubber-coated parallel
Speed rating
cords.
An alphanumeric code assigned to a
tire indicating the maximum speed at
Pneumatic tire
which a tire can operate.
A mechanical device made of rubber,
chemicals, fabric and steel or other
Traction
materials, that, when mounted on an
The friction between the tire and the
automotive wheel provides the
road surface. The amount of grip
traction and contains the gas or fluid
provided.
that sustains the load.
Tread
Pneumatic options weight
The portion of a tire that comes into
The combined weight of installed
contact with the road.
regular production options weighing
over 5 lb. (2.3 kg) in excess of the
standard items which they replace,
Treadwear indicators
not previously considered in curb
Narrow bands, sometimes called
weight or accessory weight,
"wear bars", that show across the
including heavy duty breaks, ride
tread of a tire when only 1/16 in. of
levelers, roof rack, heavy duty
tread remains.
battery, and special trim.
9-42
CarManuals2.com
9
UTQGS
All season tires
Uniform Tire Quality Grading
HYUNDAI specifies all season tires on
Standards is a tire information system
some models to provide good
that provides consumers with ratings
performance for use all year round,
for a tire’s traction, temperature and
including snowy and icy road
treadwear. Ratings are determined
conditions. All season tires are
by tire manufacturers using
identified by ALL SEASON and/or
government testing procedures. The
M+S (Mud and Snow) on the tire
ratings are molded into the sidewall
sidewall. Snow tires have better snow
of the tire.
traction than all season tires and may
be more appropriate in some areas.
Vehicle capacity weight
The number of designated seating
Summer tires
positions multiplied by 150 lbs. (68
HYUNDAI specifies summer tires on
kg) plus the rated cargo and luggage
some models to provide superior
load.
performance on dry roads. Summer
tire performance is substantially
Vehicle maximum load on the tire
reduced in snow and ice. Summer
Load on an individual tire due to curb
tires do not have the tire traction
and accessory weight plus maximum
rating M+S (Mud and Snow) on the
occupant and cargo weight.
tire side wall. If you plan to operate
your vehicle in snowy or icy
conditions, HYUNDAI recommends
Vehicle normal load on the tire
the use of snow tires or all season
Load on an individual tire that is
tires on all four wheels.
determined by distributing to each
axle its share of the curb weight,
accessory weight, and normal
Snow tires
occupant weight and dividing by 2.
If you use snow tires, they should be
the same size and have the same load
Vehicle placard
capacity as the original tires. Snow
tires should be installed on all four
A label permanently attached to a
wheels. Otherwise, poor handling
vehicle showing the original
may result. Snow tires should carry 4
equipment tire size and
psi (28 kPa) more air pressure than
recommended inflation pressure.
the pressure recommended for the
standard tires on the tire label located
on the driver’s side center pillar, or up
to the maximum pressure shown on
the tire sidewall, whichever is less. Do
not drive faster than 75 mph (120
km/h) when your vehicle is equipped
with snow tires.
9-43
CarManuals2.com
Maintenance
Radial-ply tires
Low aspect ratio tires
Radial-ply tires provide improved
The aspect ratio is lower than 50 on
tread life, road hazard resistance and
low aspect ratio tires.
smoother high speed ride. The
Because low aspect ratio tires are
radial-ply tires used on this vehicle
optimized for handling and braking,
are of belted construction, and are
their sidewall is a little stiffer than a
selected to complement the ride and
standard tire. Also low aspect ratio
handling characteristics of your
tires tend to be wider and
vehicle. Radial-ply tires have the
consequently have a greater contact
same load carrying capacity, as
patch with the road surface. In some
bias-ply or bias belted tires of the
instances they may generate more
same size, and use the same
road noise compared with standard
recommended inflation pressure.
tires.
Mixing of radial-ply tires with bias-ply
or bias belted tires is not
NOTICE
recommended. Any combinations of
Low aspect wheels and tires are
radial-ply and bias-ply or bias belted
easily damaged. To reduce the risk of
tires when used on the same vehicle
damage:
will seriously deteriorate vehicle
handling. The best rule to follow is to
• When driving on rough roads,
use identical radial-ply tires as a pair
passing over a pothole, speed
for the front tires and rear tires.
bump, manhole, or curb stone,
drive the vehicle slowly not to
Longer wearing tires can be more
damage the tires and wheels.
susceptible to irregular tread wear. It
Damage is not covered by your
is very important to follow the tire
vehicle warranty.
rotation interval in this chapter to
achieve the tread life potential of
• Inspect the tire condition and
these tires. Cuts and punctures in
pressure every 1,800 mi. (3,000
radial-ply tires are repairable only in
km).
the tread area, because of sidewall
• It is difficult to visually inspect for
flexing. Consult your tire dealer for
tire damage with your eyes. If any
radial-ply tire repairs.
damage is found, contact your
authorized HYUNDAI dealer to
WARNING
replace the tire.
Do not mix bias ply and radial ply tires
under any circumstances. This may
cause unusual handling
characteristics that may cause loss of
vehicle control and result in a
collision.
9-44
CarManuals2.com
9
If the electrical system does not work,
Fuses
first check the driver’s side fuse panel.
Blade type
Before replacing a blown fuse, turn off the
engine and all switches, and then
disconnect the negative battery cable.
Always replace a blown fuse with one of
the same rating.
If the replacement fuse blows, this
indicates an electrical problem. Avoid
using the system involved and contact an
authorized HYUNDAI dealer.
WARNING
Never replace a fuse with anything but
Cartridge type
another fuse of the same rating.
• A higher capacity fuse may cause
damage and possibly cause a fire.
• Do not install a wire or aluminum foil
instead of the proper fuse - even as a
temporary repair. It may cause
extensive wiring damage and possibly a
fire.
NOTICE
Multi type
Do not use a screwdriver or any other
metal object to remove fuses because it
may cause a short circuit and damage the
system.
A vehicle’s electrical system is protected
from electrical overload damage by fuses.
This vehicle has 2 (or 3) fuse panels, one
located in the driver’s side panel bolster,
the other in the engine compartment near
the battery.
If any of your vehicle’s lights, accessories,
or controls do not work, check the
appropriate circuit fuse. If a fuse has
blown, the element inside the fuse is
melted or broken.
9-45
CarManuals2.com
Maintenance
Instrument panel fuse
If the headlight, turn signal lights, tail
lights, interior lamps does not work and
replacement
the fuses are undamaged, contact an
authorized HYUNDAI dealer.
Engine compartment panel
fuse replacement
Blade fuse
OCN7080017
1. Turn off the vehicle.
2. Turn off all other switches.
3. Open the fuse panel cover.
4. Refer to the label on the inside of the
fuse panel cover to locate the
suspected fuse location.
Cartridge fuse
5. Pull the suspected fuse straight out.
Use the removal tool provided in the
engine compartment fuse panel cover.
1. Turn off the vehicle.
2. Turn off all other switches.
OCN7080018
3. Remove the fuse panel cover by
6.Check the removed fuse and replace it
pressing the tap and pulling up.
if it is blown. Spare fuses are provided in
4. Check the removed fuse and replace it
the engine compartment fuse panel.
if it is blown. To remove or insert the
7. Push in a new fuse of the same rating,
fuse, use the removal tool in the engine
and make sure it fits tightly in the clips.
compartment fuse panel.
If it is not tight, contact an authorized
5. Push in a new fuse of the same rating,
HYUNDAI dealer.
and make sure it fits tightly in the clips.
In an emergency, if you do not have a
If it is not tight, contact an authorized
spare fuse, use a fuse of the same rating
HYUNDAI dealer.
from a circuit you may not need for
operating the vehicle.
9-46
CarManuals2.com
9
NOTICE
Always securely install the fuse panel
cover. Water may contact the fuse and
cause an electrical failure.
Multi fuse (Main fuse)
OCN7080020
If the multi fuse or midi fuse is blown,
contact an authorized HYUNDAI dealer.
9-47
CarManuals2.com
Maintenance
Fuse/Relay panel description
Instrument panel fuse panel
OCN7080024
Inside the fuse panel cover, you can find the label describing fuse names and ratings.
Information
Not all fuse panel descriptions in this manual may be applicable to your vehicle. When
you inspect the fuse panel on your vehicle, refer to the fuse panel label.
OCN7093028N
9-48
CarManuals2.com
9
Driver’s side fuse panel
Fuse Name
Fuse Rating
Circuit Protected
Instrument Cluster, A/C Controller, A/C Control Module,
MEMORY1
10A
DRV/PASS Folding Outside Mirror, Crash Pad Switch,
Surround View Monitor
AIR BAG2
10A
SRS Control Module
Lane Keeping Assist Unit (LINE), Crash Pad Switch, IBU,
MODULE4
10A
A/T Shift Lever Indicator, Front Console Switch,
Surround View Monitor
MODULE7
7.5A
Rear Seat Warmer Control Module
Burglar Alarm Relay, Transaxle Range Switch,
START
7.5A
PCM/ECMIBU, E/R Junction Block (Start Relay)
CLUSTER
7.5A
Instrument Cluster
IBU2
7.5A
IBU
E/R Junction Block (PTC Heater Relay, Blower Relay),
A/C1
7.5A
A/C Control Module, A/C Controller
TRUNK
10A
Trunk Lid Latch
S/HEATER FRT
20A
Front Seat Warmer Control Module
P/WINDOW LH
25A
Power Window Main Switch
Audio, A/V & Navigation Head Unit, DC-DC Converter
MULTIMEDIA
15A
(Smartstream G 2.0 Atkinson ISG only)
FCA
10A
Forward Collision Avoidance Assist Unit
MDPS *1
7.5A
MDPS Unit
MODULE6
7.5A
IBU
S/HEATER RR
20A
Rear Seat Warmer Control Module
SAFETY
25A
Driver Safety Power Window Module
P/WINDOW DRV
Power Window Main Switch, Passenger Power Window
P/WINDOW RH
25A
Switch
BRAKE SWITCH
10A
Stop Light Switch, IBU
IBU1
15A
IBU
*1 : MDPS (Motor Driven Power Steering) is the same as EPS (Electric Power Steering)
9-49
CarManuals2.com
Maintenance
Driver’s side fuse panel
Fuse Name
Fuse Rating
Circuit Protected
E/R Junction Block (Power Outlet Relay), AMP, IBU, IAU,
Audio, Power Outside Mirror Switch, DC-DC Converter
MODULE2
10A
(Smartstream G 2.0 Atkinson ISG only), A/V & Navigation
Head Unit, Surround View Monitor
SRS Control Module, Passenger Occupant Detection
AIR BAG1
15A
Sensor
A/T Shift Lever Indicator, Front Wireless Charger, A/C
Controller,Electro Chromic Mirror, A/C Control Module,
Audio, A/V & Navigation Head Unit, AMP, DC-DC
MODULE5
10A
Converter (Smartstream G 2.0 Atkinson ISG only), Data
Link Connector, Rear Seat Warmer Control Module,
Front Seat Warmer Control Module
SAFETY
P/WINDOW
25A
Passenger Safety Power Window Module
PASS
AMP, DC-DC Converter (Smartstream G 2.0 Atkinson ISG
AMP
25A
only)
DRV/PAS Outside Mirror Heated, A/C Control Module,
HEATED MIRROR
10A
A/C Controller, ECU (N Line only)
DOOR LOCK
20A
Door Lock/Unlock Actuator
IAU
10A
BLE Unit, IAU, Driver/Passenger Door NFC Module
MODULE3
7.5A
Sport Mode Switch, Stop Light Switch, IAU
A/BAG IND
7.5A
Instrument Cluster, Overhead Console Lamp
WASHER
15A
Multifunction Switch
P/SEATPASS
30A
Power Seat
P/SEATDRV
30A
Power Seat
WIPER
10A
PCM/ECM, IBU
Driver/Passenger Smart Key Outside Handle, Data Link
MODULE1
10A
Connector, Hazard Switch, Key Solenoid
SUNROOF
20A
Sunroof Motor
USB CHARGER
15A
Front USB Charger, Rear Console USB Charger
IG1
25A
PCB Block (Fuse - ABS3, ECU5, EOP2, TCU2)
9-50
CarManuals2.com
9
Engine compartment fuse panel
ODN8089017
Inside the fuse panel cover, you can find the panel label describing fuse names and
ratings.
Information
Not all fuse panel descriptions in this manual may be applicable to your vehicle. When
you inspect the fuse panel on your vehicle, refer to the fuse panel label.
OCN7093029N
9-51
CarManuals2.com
Maintenance
Engine compartment fuse panel
Type
Fuse Name
Fuse Rating
Circuit Protected
[Smartstream G 2.0 Atkinson with AMS2]
Alternator, (Fuse - ABS1, ABS2, EOP1, POWER
OUTLET1) [Smartstream G 2.0 Atkinson &
ALT
150A180A
MULTI
Smartstream G1.6 T-GDi without AMS2]
FUSE-3
Alternator, (Fuse - ABS1, ABS2, POWER
OUTLET1)
MDPS1
80A
MDPS Unit
COOLING
60A
[G4FP] Cooling Fan Controller
FAN2
MULTI
DCT3
40A
[G4FP] SGA
FUSE-2
REAR
50A
Rear Glass Heated
HEATED
PCB Block (Engine Control Relay, Fuse - ECU3,
B+5
60A
ECU4, HORN, WIPER, A/C)
ICU Junction Block
B+1
60A
(IPS2/IPS3/IPS5/IPS6/IPS7/IPS14)
ICU Junction Block
B+2
60A
(IPS1/IPS4/IPS8/IPS9/IPS10)
ICU Junction Block (Fuse - TRUNK, AMP,
SAFETY P/WINDOW DRV, SAFETY P/WINDOW
B+3
50A
PASS, P/SEAT DRV, P/SEAT PASS, S/HEATER
MULTI
FRT, S/HEATER RR, Long Term Load Latch
Relay)
FUSE-1
EPB
60A
ESC Control Module
PTC HEATER
50A
PTC HEATER
BLOWER Motor, Multipurpose Check
BLOWER
40A
Connector
E/R Junction Block (PDM (IG1/ACC) Relay),
IG1
40A
Ignition Switch
E/R Junction Block (PDM (IG2) Relay, Start
IG2
40A
Relay), Ignition Switch
9-52
CarManuals2.com
9
Engine compartment fuse panel
Type
Fuse Name
Fuse Rating
Circuit Protected
POWER
20A
Front Power Outlet
OUTLET2
COOLING
Cooling Fan (Smartstream G 2.0 Atkinson
40A
FAN1
only)
DCT1
40A
[G4FP] TCM
DCT2
40A
[G4FP] TCM
ICU Junction Block (Fuse - AIR BAG2, IBU1,
B+4
40A
BRAKE SWITCH, DOOR LOCK, IAU, MODULE1,
SUNROOF,Power Window Relay)
AMS
10A
Battery Sensor
TCU1
10A
[DCT] TCM
FUSE
Fuel Pump Control Module (T-GDI), Fuel Pump
FUEL PUMP
20A
Motor (NU MPI AKS)
CVVD
40A
[G4FP] CVVD Actuator
ABS Control Module, ESC Control Module,
ABS1
40A
Multipurpose Check Connector
ABS Control Module, ESC Control Module,
ABS2
30A
Multipurpose Check Connector
Electronic Oil Pump (Smartstream G 2.0
EOP1
30A
Atkinson ISG only)
POWER
40A
P/OUTLET FRT
OUTLET1
9-53
CarManuals2.com
Maintenance
Engine compartment fuse panel
Fuse Name
Fuse Rating
Circuit Protected
WIPER
25A
Wiper Motor
ECU4
15A
PCM/ECM
[G4FM] A/C Compressor (Smartstream G 2.0 Atkinson
A/C
10A
only)
HORN
15A
Horn
IGN COIL
20A
Ignition Coil #1~#4
ECU3
15A
PCM/ECM
SENSOR3
10A
E/R Junction Block (Fuel Pump Relay)
ECU2
10A
PCM/ECM (Smartstream G1.6 T-GDi only)
[G4NS] Variable Intake Solenoid Valve, Oil Pump
Solenoid Valve, Oil Control Valve #1/#2, Canister Close
Valve, Purge Control Solenoid Valve,PCB Block (A/C
Relay), E/R Junction Block (Cooling Fan1/2 Relay), Oil
SENSOR2
10A
Level Sensor
[G4FP] Variable Oil Pump Solenoid, Oil Control Valve
#1/#2, Purge Control Solenoid Valve, RCV Control
Solenoid Valve, Canister Close Valve, Oil Level Sensor
CVVD Actuator (Smartstream G1.6 T-GDi only),
ECU5
10A
ECM/PCM
SENSOR1
15A
Oxygen Sensor (UP/DOWN)
ABS Control Module, ESC Control Module, Multipurpose
ABS3
10A
Check Connector
[G4FM/G4FG/G4NA] Injector #1~#4 (Smartstream G 2.0
INJECTOR
15A
Atkinson only)
ECU1
20A
PCM/ECM
Transaxle Range Switch, [G4FP] TCM (Smartstream G1.6
TCU2
15A
T-GDi & DCT only)
9-54
CarManuals2.com
9
Light bulbs
NOTICE
Contact an authorized HYUNDAI dealer to
• Be sure to replace the burned-out bulb
replace most vehicle light bulbs. It is
with one of the same wattage to
difficult to replace vehicle light bulbs
prevent damage to the fuse or electrical
because other parts of the vehicle must
wiring system.
be removed before you can get to the
• To prevent damage, do not clean the
bulb. This is especially true for removing
headlight lens with chemical solvents
the headlight assembly to get to the
or strong detergents.
bulb(s).
Removing/installing the headlight
assembly may result in damage to the
vehicle.
Information
The headlight and tail light lenses could
WARNING
appear to have condensation inside if the
• Prior to replacing a light bulb, depress
vehicle is washed after driving or if the
the brake pedal, shift to P (Park), apply
vehicle is driven in wet weather. This
the parking brake, move the ignition
condition is caused by a higher
switch to the LOCK/OFF position, and
temperature inside the light and a cooler
take the key with you when leaving the
outside temperature. Moisture that
vehicle to avoid sudden movement of
condenses in the light is removed after
the vehicle and to prevent possible
driving with the light on. If the moisture is
electric shock.
not removed, contact an authorized
HYUNDAI dealer.
• Be aware the bulbs may be hot and may
burn your fingers.
• When the bulb is disconnected or the
lamp connector is removed while the
Information
lamp is operating normally, the fuse
Adjust the headlight aim after an accident
box electronics may recognize the lamp
or the headlight is replaced.
as a malfunction. Therefore, a fault
record for the lamp may remain in the
Diagnostic Trouble Code (DTC)
recorded in the fuse box.
9-55
CarManuals2.com
Maintenance
Headlight, parking light,
Turn signal light (Bulb type, for A
type)
Daytime Running Light, turn
signal light, side marker
replacement
Type A
OCN7093037L
1. Turn off the engine.
2. Open the hood.
3. Remove the socket from the assembly
Type B
by turning the socket counterclockwise
until the tabs on the socket align with
the slots on the assembly.
4. Remove the bulb from the socket by
pushing it in and rotating it
counterclockwise until the tabs on the
bulb align with the slots in the socket.
Pull the bulb out of the socket.
5. Insert a new bulb by inserting it into the
socket and rotating it until it locks into
place.
6. Install the socket in the assembly by
(1) Headlight (Low)
aligning the tabs on the socket with the
slots in the assembly.
(2) Headlight (High)
(3) Daytime running light (DRL)/Parking
7. Push the socket into the assembly and
light
turn the socket clockwise.
(4) Turn signal light
8. Reinstall the light assembly to the body
(5) Side marker
of the vehicle.
Headlight/Daytime running light
(DRL)/Parking light/Turn signal
light/Side marker (LED type)
If the LED light does not operate, contact
an authorized HYUNDAI dealer for
replacement.
The LED light cannot be replaced as a
single unit. A skilled technician should
check or repair the LED light, for it may
damage related parts of the vehicle.
9-56
CarManuals2.com
9
Side repeater light
Rear combination light
replacement
replacement
if equipped
Type A
OCN7080074L
Type B
If the LED light (1) does not operate,
contact an authorized HYUNDAI dealer
for replacement.
The LED light cannot be replaced as a
single unit. A skilled technician should
check or repair the LED light, for it may
damage related parts of the vehicle.
(1) Stop light
(2) Tail light
(3) Turn signal light
(4) Reverse light
(5) Rear side marker
9-57
CarManuals2.com
Maintenance
Tail light/Stop light/Turn signal
6. Remove the socket from the assembly
light/Side marker (Outer lamp) (Bulb
by turning the socket counterclockwise
type)
until the tabs on the socket align with
the slots on the assembly.
1. Turn off the engine.
7. Remove the bulb from the socket by
2. Open the trunk lid.
pushing it in and rotating it
3. Remove the service cover by pulling it
counterclockwise until the tabs on the
out.
bulb align with the slots in the socket.
Pull the bulb out of the socket.
OCN7080045
4. Loosen the assembly retaining screws
OCN7080075L
with a cross-tip screwdriver.
OCN7090019N
OCN7080046
[A] Tail/Stop light
5. Remove the rear combination light
[B] Turn signal light
[C] Rear side marker
assembly from the body of the vehicle.
8. Insert a new bulb by inserting it into the
socket and rotating it until it locks into
place.
9. Install the socket in the assembly by
aligning the tabs on the socket with the
slots in the assembly. Push the socket
into the assembly and turn the socket
clockwise.
10.Reinstall the light assembly to the body
of the vehicle.
OCN7080047
9-58
CarManuals2.com
9
Tail light/Stop light (Inner lamp)
Reverse light (Inner lamp) (Bulb
(Bulb type)
type)
1. Turn off the engine.
1. Disconnect the connector and then
remove the nuts by turning the nuts
2. Open the trunk.
counter clockwise.
3. Loosen the retaining screw of the trunk
2. Take the light assembly out.
lid cover and then remove the cover.
3. Remove the socket from the assembly
4. Remove the socket from the assembly
by turning the socket counterclockwise
by turning the socket counterclockwise
until the tabs on the socket align with
until the tabs on the socket align with
the slots on the assembly. Pull the bulb
the slots on the assembly. Pull the bulb
out of the socket.
out of the socket.
OCN7080053
OCN7080040
4. Insert a new bulb by inserting it into the
5. Insert a new bulb by inserting it into the
socket.
socket.
5. Install the light assembly to the trunk.
6.Reinstall the trunk lid cover by pushing
in the screw.
6. Reinstall the trunk lid cover by pushing
in the screw.
Stop/Tail light/Rear side marker
(LED type)
If the LED light does not operate, contact
an authorized HYUNDAI dealer for
replacement.
The LED light cannot be replaced as a
single unit. A skilled technician should
check or repair the LED light, for it may
damage related parts of the vehicle.
9-59
CarManuals2.com
Maintenance
High mounted stop light
License plate light bulb
replacement
replacement
OCN7080032
OCN7083035
1. Turn off the engine.
2. Using a flat-blade screwdriver gently
pry the lens cover from the lamp
housing.
3. Remove the bulb by pulling it straight
out.
4. Install a new bulb.
5. Reinstall in the reverse order.
OAD075042
[A] High mounted stop light
1. Turn off the engine.
2. Open the trunk.
3. Remove the socket by turning it
counterclockwise until the tabs on the
socket align with the slots.
4. Remove the bulb from the socket by
pushing it in and rotating it
counterclockwise until the tabs on the
bulb align with the slots in the socket.
Pull the bulb out of the socket.
5. Insert a new bulb by inserting it into the
socket and rotating it until it locks into
place.
6.Install the socket in the assembly by
aligning the tabs on the socket with the
slots in the assembly.
Push the socket into the assembly and
turn the socket clockwise.
9-60
CarManuals2.com
9
Trunk room lamp
Interior light replacement
Map lamp, room lamp, sunvisor
lamp, and trunk room lamp (Bulb
type)
Map lamp
1. Turn off the engine.
2. Using a flat-blade screwdriver, gently
pry the lens from the interior lamp
housing.
3. Remove the bulb by pulling it straight
Room lamp
out.
4. Install a new bulb in the socket.
5. Align the lens tabs with the interior
lamp housing notches and snap the
lens into place.
WARNING
Prior to working on the Interior Lights,
ensure that the "OFF" button is depressed
to avoid burning your fingers or receiving
an electric shock.
Sunvisor lamp
NOTICE
Be careful not to damage the cover, tab,
and plastic housing.
9-61
CarManuals2.com
Maintenance
Mood lamp (LED type)
Appearance care
Exterior care
Exterior general caution
It is very important to follow the label
directions when using any chemical
cleaner or polish. Read all warning and
caution statements that appear on the
label.
OCN7C052041
If the LED light does not operate, contact
Finish maintenance
an authorized HYUNDAI dealer for
replacement.
Washing
The LED light cannot be replaced as a
To help protect your vehicle’s finish from
single unit. A skilled technician should
rust and deterioration, wash it thoroughly
check or repair the LED light, for it may
and frequently at least once a month with
damage related parts of the vehicle.
lukewarm or cold water.
If you use your vehicle for off-road
driving, wash it after each off-road trip.
Pay special attention to the removal of
any accumulation of salt, dirt, mud, and
other foreign materials. Make sure the
drain holes in the lower edges of the
doors and rocker panels are kept clear
and clean.
Insects, tar, tree sap, bird droppings,
industrial pollution, and similar deposits
may damage your vehicle’s finish if not
removed immediately.
Even prompt washing with plain water
may not completely remove all these
deposits. Use a mild soap, safe for use on
painted surfaces.
After washing, rinse the vehicle
thoroughly with lukewarm or cold water.
Do not allow soap to dry on the finish.
NOTICE
High pressure water may damage front
and rear cameras, sensors, vehicle trim,
and boots (rubber or plastic covers) or
connectors.
9-62
CarManuals2.com
9
WARNING
NOTICE
After washing the vehicle, dry the brakes
Matte paint finish vehicle (if equipped)
by applying them lightly while
To prevent damage the matte finish:
maintaining a slow forward speed.
• Do not go through an automatic car
wash with rotating brushes.
• Avoid using a steam cleaner. High
NOTICE
temperature steam may leave stains
that are difficult to remove.
• Do not use strong soap, chemical
detergents, or hot water, and do not
• Use a soft cloth (e.g. microfiber towel or
wash the vehicle in direct sunlight or
sponge) when washing your vehicle
when the body of the vehicle is warm.
and dry with a microfiber towel. When
you hand wash your vehicle, do not use
• To prevent damage to the plastic parts,
a cleaner that finishes with wax. If the
do not clean with chemical solvents or
vehicle surface is too dirty (sand, dirt,
strong detergents.
dust, contaminant, etc.), clean the
surface with water before washing the
vehicle.
NOTICE
Waxing
A good coat of wax helps protect your
paint from contaminants.
Wax the vehicle when water no longer
beads on the paint.
Always wash and dry the vehicle before
waxing. Use a good quality liquid or paste
wax, and follow the manufacturer’s
instructions. Wax all metal trim to protect
it and to maintain its luster.
OCN7083036
Removing oil, tar, and similar materials
• Water washing in the engine
with a spot remover usually strips the wax
compartment including high pressure
from the finish. Be sure to re-wax these
water washing may cause the failure of
areas even if the rest of the vehicle does
electrical circuits located in the engine
not yet need waxing.
compartment.
• Never allow water or other liquids to
NOTICE
come in contact with
• Do not wipe dust or dirt off the body
electrical/electronic components
with a dry cloth to prevent scratching
inside the vehicle to prevent damage.
the finish.
• Do not use steel wool, abrasive
cleaners, or strong detergents
containing highly alkaline or caustic
agents on chrome-plated or anodized
aluminum parts to prevent
discoloration or paint deterioration.
9-63
CarManuals2.com
Maintenance
Bright-metal maintenance
NOTICE
• To remove road tar and insects, use a
Matte paint finish vehicle (if equipped)
tar remover, not a scraper or other
Do not use any polish protector such as
sharp object.
detergent, abrasive, or polish. If wax is
• To protect the surfaces of bright metal
applied, remove the wax immediately
parts from corrosion, apply a coating of
using a silicone remover. If any tar or tar
wax or chrome preservative and rub to
contaminant is on the surface, use a tar
a high luster.
remover to clean.
• During winter weather or in coastal
Be careful not to apply too much pressure
areas, cover the bright metal parts with
on the painted area.
a heavier coating of wax or
preservative. If necessary, coat the
parts with non-corrosive petroleum
Finish damage repair
jelly or other protective compound.
Deep scratches or stone chips on the
painted surface must be repaired
Underbody maintenance
promptly. Exposed metal quickly rusts
Corrosive materials used for ice and snow
and may develop into a major repair
removal and dust control may collect on
expense.
the underbody. If these materials are not
removed, accelerated rusting may occur
Information
on underbody parts such as fuel lines,
If your vehicle is damaged and requires
frame, floor pan, and exhaust system,
any metal repair or replacement, make
even though they have been treated with
sure the body shop applies anti-corrosion
rust protection.
materials to the parts repaired or
Thoroughly flush the vehicle underbody
replaced.
and wheel openings with lukewarm or
cold water once a month, after off-road
driving and at the end of each winter. Pay
NOTICE
special attention to these areas because it
is difficult to see all the mud and dirt. It
Matte paint finish vehicle (if equipped)
does more harm than good to wet down
It is impossible to modify only repaint the
the road grime without removing it. The
damaged area. The whole part must be
lower edges of doors, rocker panels, and
repainted as necessary. If the vehicle is
frame members have drain holes that
damaged and painting is required,
must not be allowed to clog with dirt.
contact an authorized HYUNDAI dealer.
Trapped water in these areas may cause
rusting.
9-64
CarManuals2.com
9
Aluminum wheel maintenance
High-corrosion areas
The aluminum wheels are coated with a
If you live in an area where your vehicle is
clear protective finish.
regularly exposed to corrosive materials,
corrosion protection is particularly
NOTICE
important. Some of the common causes
of accelerated corrosion are road salts,
• Do not use abrasive cleaner, polishing
dust control chemicals, ocean air, and
compound, solvent, or wire brushes on
industrial pollution.
aluminum wheels.
• Use only a mild soap or neutral
Moisture breeds corrosion
detergent, and rinse thoroughly with
Moisture creates the conditions in which
water. Also, clean the wheels after
corrosion is most likely to occur. For
driving on salted roads.
example, corrosion is accelerated by high
• Do not wash the wheels with
humidity, particularly when temperatures
high-speed car wash brushes.
are just above freezing. In such
• Do not use any cleaners containing acid
conditions, the corrosive material is kept
or alkaline detergents.
in contact with the vehicle surfaces by
moisture that is slow to evaporate.
Mud is particularly corrosive because it is
Corrosion protection
slow to dry and holds moisture in contact
with the vehicle. Although the mud
Protecting your vehicle from corrosion
appears to be dry, it can still retain
By using the most advanced design and
moisture and promote corrosion.
construction practices to combat
High temperatures may also accelerate
corrosion, HYUNDAI produces vehicles of
corrosion of parts that are not properly
the highest quality. However, this is only
ventilated so the moisture can be
part of the job. To achieve the long-term
dispersed. For all these reasons, it is
corrosion resistance your vehicle can
particularly important to keep your
deliver, the owner’s cooperation and
vehicle clean and free of mud or
assistance are also required.
accumulation of other materials. This
applies not only to the visible surfaces but
Common causes of corrosion
particularly to the underside of the
The most common causes of corrosion on
vehicle.
your vehicle are:
• Road salt, dirt, and moisture that is
allowed to accumulate underneath the
vehicle.
• Removal of paint or protective coatings
by stones, gravel, abrasion, minor
scrapes, and dents that leave
unprotected metal exposed to
corrosion
9-65
CarManuals2.com
Maintenance
To help prevent corrosion
Keep paint and trim in good condition
Keep your vehicle clean
Scratches or chips in the finish must be
covered with "touch-up" paint as soon as
The best way to prevent corrosion is to
possible to reduce the possibility of
keep your vehicle clean and free of
corrosion. If bare metal is showing
corrosive materials. Attention to the
through, the attention of a qualified body
underside of the vehicle is particularly
and paint shop is recommended.
important.
Bird droppings are highly corrosive and
• If you live in a high-corrosion area -
may damage painted surfaces in just a
where road salts are used, near the
few hours. Always remove bird droppings
ocean, areas with industrial pollution,
as soon as possible.
acid rain, and the like, take extra care to
prevent corrosion. In winter, hose off
the underside of your vehicle at least
Interior care
once a month and be sure to clean the
underside thoroughly when winter is
over.
Interior general precautions
• When cleaning underneath the vehicle,
Prevent caustic solutions such as
pay particular attention to the
perfume and cosmetic oil, from
components under the fenders and
contacting the interior parts because they
other areas that are hidden from view.
may cause damage or discoloration. If
Do a thorough job. Just dampening the
they do contact the interior parts, wipe
accumulated mud rather than washing
them off immediately. Refer to the
it away may accelerate corrosion rather
instructions for the proper way to clean
than prevent it. Water under high
vehicle interior surfaces.
pressure and steam are particularly
effective in removing accumulated
NOTICE
mud and corrosive materials.
• Never allow water or other liquids to
• When cleaning lower door panels,
come in contact with
rocker panels, and frame members,
electrical/electronic components
make sure that drain holes are kept
inside the vehicle because this may
open so that moisture can escape and
damage them.
not be trapped inside to accelerate
• When cleaning leather products
corrosion.
(steering wheel, seats, etc.), use neutral
Keep your garage dry
detergents or low alcohol content
Do not park your vehicle in a damp, poorly
solutions. If you use high alcohol
ventilated garage. This creates a
content solutions or acid/ alkaline
favorable environment for corrosion.
detergents, the color of the leather may
fade or the surface may get stripped
This is particularly true if you wash your
off.
vehicle in the garage or drive it into the
garage when it is still wet or covered with
snow, ice, or mud. Even a heated garage
may contribute to corrosion unless it is
well ventilated so moisture is dispersed.
9-66
CarManuals2.com
9
Cleaning the upholstery and interior
Leather
trim
if equipped
• Features of seat leather
Vehicle interior surfaces
- Leather is made from the outer skin
if equipped
of an animal, which goes through a
Remove dust and loose dirt from interior
special process to be available for
surfaces with a whisk broom or a vacuum
use. Because it is a natural product,
cleaner.
each part differs in thickness or
If necessary, clean interior surfaces with a
density.
mixture of warm water and mild
Wrinkles may appear as a natural
non-detergent cleaner (test all cleaners
result of stretching and shrinking
on a concealed area before use).
depending on the temperature and
humidity.
Fabric
- The seat is made of stretchable fabric
if equipped
to improve comfort.
Remove dust and loose dirt from fabric
- The parts contacting the body are
with a whisk broom or vacuum cleaner.
curved and the side supporting area
Clean with a mild soap solution
is high which provides driving
recommended for upholstery or carpets.
comfort and stability.
Remove fresh spots immediately with a
- Wrinkles may appear naturally from
fabric spot cleaner. If you do not pay
usage. It is not a fault of the products.
attention to fresh spots immediately, the
fabric may be stained and its color may be
NOTICE
affected. Also, its fire-resistant properties
may be reduced if the material is not
• Wrinkles or abrasions that appear
properly maintained.
naturally from usage are not covered by
warranty.
NOTICE
• Belts with metallic accessories, zippers,
Using anything but recommended
or keys inside the back pocket may
cleaners and procedures may affect the
damage the seat fabric.
fabric’s appearance and fire-resistant
• Be sure not to wet the seat. It may
properties.
change the nature of natural leather.
• Jeans or clothes that could bleach may
contaminate the surface of the seat
covering fabric.
• Caring for the leather seats
- Vacuum the seat periodically to
remove dust and sand on the seat. It
prevents abrasion or damage of the
leather and maintain its quality.
- Wipe the natural leather seat cover
often with a dry or soft cloth.
9-67
CarManuals2.com
Maintenance
- Use of proper leather protector may
Cleaning the seat belt webbing
prevent abrasion of the cover and
Clean the belt webbing with any mild
helps maintain the color. Be sure to
soap solution recommended for cleaning
read the instructions and consult a
upholstery or carpet. Follow the
specialist when using leather coating
instructions provided with the soap.
or protective agent.
- Light colored (beige, cream beige)
WARNING
leather may be easily contaminated
Do not bleach or re-dye the webbing
and the stains may be noticeable.
because this may weaken the seat belt.
- Avoid wiping with a wet cloth. It may
cause the surface to crack.
• Cleaning the leather seats
Cleaning the interior window glass
- Remove all spills instantly.
If the interior glass surfaces need to be
cleaned, use a glass cleaner. Follow the
- For Cosmetic products (sunscreen,
directions on the glass cleaner container.
foundation, etc.)
Apply cleansing cream on a cloth and
NOTICE
wipe the contaminated spot. Wipe
Do not scrape or scratch the inside of the
off the cream with a damp loth and
rear window. This may result in damage
then wipe with a dry cloth.
to the rear window defroster grid.
- For Beverages (coffee, soft drink,
etc.)
Apply a small amount of neutral
detergent and wipe until it does not
smear.
- For oil
Remove oil instantly with an
absorbable cloth and wipe with stain
remover used only for natural leather.
- For chewing gum
Harden the gum with ice and remove
it gradually.
9-68
CarManuals2.com
9
Emission control system
1. Crankcase emission control
system
The emission control system of your
The positive crankcase ventilation system
vehicle is covered by a written limited
is employed to prevent air pollution
warranty. Please see the warranty
caused by blow-by gases being emitted
information contained in the Owner’s
from the crankcase. This system supplies
Handbook & Warranty Information
fresh filtered air to the crankcase through
booklet in your vehicle.
the air intake hose. Inside the crankcase,
Your vehicle is equipped with an emission
the fresh air mixes with blow-by gases,
control system to meet all applicable
which then pass through the PCV valve
emission regulations. There are three
into the induction system.
emission control systems, as follows:
(1) Crankcase emission control system
(2) Evaporative emission control system
2. Evaporative emission
(3) Exhaust emission control system
control system including
In order to ensure the proper function of
onboard refueling vapor
the emission control systems, it is
recovery (ORVR)
recommended that you have your vehicle
The Evaporative Emission Control System
inspected and maintained by an
is designed to prevent fuel vapors from
authorized HYUNDAI dealer in
escaping into the atmosphere. The ORVR
accordance with the maintenance
system is designed to allow the vapors
schedule in this manual.
from the fuel tank to be loaded into a
canister while refueling at the gas station,
NOTICE
preventing the escape of fuel vapors into
For the Inspection and Maintenance Test
the atmosphere.
(with Electronic Stability Control (ESC)
system)
Canister
• To prevent the vehicle from misfiring
Fuel vapors generated inside the fuel tank
during dynamometer testing, turn the
are absorbed and stored in the onboard
Electronic Stability Control (ESC)
canister. When the engine is running, the
system off by pressing the ESC button
fuel vapors absorbed in the canister are
(ESC OFF light illuminated).
drawn into the surge tank through the
• After dynamometer testing is
purge control solenoid valve.
completed, turn the ESC system back
on by pressing the ESC button again.
Purge Control Solenoid Valve (PCSV)
The purge control solenoid valve is
controlled by the Engine Control Module
(ECM). When the engine coolant
temperature is low during idling, the
PCSV closes so that evaporated fuel is not
taken into the engine. After the engine
warms up during ordinary driving, the
PCSV opens to introduce evaporated fuel
to the engine.
9-69
CarManuals2.com
Maintenance
3. Exhaust emission control
Operating precautions for catalytic
converters
system
if equipped
The Exhaust Emission Control System
controls exhaust emissions while
WARNING
maintaining good vehicle performance.
The exhaust system and catalytic system
When the engine starts or fails to start,
are very hot while the engine is running or
excessive attempts to restart the engine
immediately after the engine is turned off.
may cause damage to the emission
To avoid serious injury or death:
system.
• Do not park, idle, or drive the vehicle
over or near flammable objects, such as
Engine exhaust (carbon monoxide)
grass, vegetation, paper, leaves, etc. A
precautions
hot exhaust system may ignite
• Carbon monoxide is present with other
flammable items under your vehicle.
exhaust fumes. If you smell exhaust
• Keep away from the exhaust system
fumes in your vehicle, drive with all the
and catalytic converter or you may get
windows fully open. Have your vehicle
burned.
inspected and repaired immediately.
Also, do not remove the heat sink
• Do not operate the engine in confined
around the exhaust system, do not seal
or closed areas (such as garages) any
the bottom of the vehicle, and do not
more than what is necessary to move
coat the vehicle for corrosion control. It
the vehicle in or out of the area.
may present a fire risk under certain
• When the vehicle is stopped in an open
conditions.
area for more than a short time with the
engine running, adjust the ventilation
system (as needed) to draw outside air
Your vehicle is equipped with a catalytic
into the vehicle.
converter emission control device.
• Never sit in a parked or stopped vehicle
NOTICE
for an extended time with the engine
running.
To prevent damage to the catalytic
• When the engine stalls or fails to start,
converter and to your vehicle, take the
excessive attempts to restart the
following precautions:
engine may cause damage to the
• Use only UNLEADED FUEL for gasoline
emission control system.
engines.
For more information, refer to "Driving
• Do not operate the vehicle when there
your vehicle" at the beginning of
are signs of engine malfunction, such
chapter 6.
as misfire or a noticeable loss of
performance.
WARNING
• Do not misuse or abuse the engine.
Engine exhaust gases contain carbon
Examples of misuse are coasting with
monoxide (CO). Though colorless and
the engine off and descending steep
odorless, it is dangerous and could be
grades in gear with the engine off.
lethal if inhaled. Follow the instructions
• Do not operate the engine at high idle
on this page to avoid CO poisoning.
speed for extended an extended period
of time (5 minutes or more).
9-70
CarManuals2.com
9
• Do not modify or tamper with any part
Fuel requirements
of the engine or emission control
system. Have all inspections and
adjustments made by an authorized
Gasoline engine
HYUNDAI dealer.
• Avoid driving with an extremely low
Unleaded
fuel level.
Your new vehicle is designed to perform
Running out of fuel may cause the
optimally with unleaded fuel having an
engine to misfire, damaging the
octane number ((R+M)/2) of 87 (Research
catalytic converter.
Octane Number 91) or higher.
Failure to follow these precautions may
Your new vehicle is designed to obtain
void your vehicle warranty.
maximum performance with UNLEADED
FUEL, as well as minimize exhaust
emissions and spark plug fouling.
Gasoline containing ethanol and
methanol
Gasohol, a mixture of gasoline and
ethanol (also known as grain alcohol) are
being marketed along with or instead of
leaded or unleaded gasoline. For
example, "E15" is a gasohol comprised of
15 % ethanol and 85 % gasoline.
Do not use gasohol containing more than
15 % ethanol, and do not use gasoline or
gasohol containing any methanol. Do not
use gasohol containing more than 15 %
ethanol, and do not use gasoline or
gasohol containing any methanol. Never
use leaded fuel or leaded gasohol. Use of
these fuels may damage the fuel system,
engine control system, and emission
control system.
Discontinue using gasohol of any kind if
problems occur. "E85" fuel is an
alternative fuel comprised of 85 %
ethanol and 15 % gasoline, and is
manufactured exclusively for use in
Flexible Fuel Vehicles. "E85" is not
compatible with your vehicle. Use of
"E85" may result in poor engine
performance and damage to your
vehicle’s engine and fuel system.
9-71
CarManuals2.com















Content      ..     3      4      5      6     ..
