Convenience features
Air conditioning
WARNING
To prevent serious injury or death:
• Continued climate control system
operation in the recirculated air
position may allow humidity to increase
inside the vehicle that could fog the
windshield and the side windows and
obscure visibility.
• Do not sleep in a vehicle with the air
conditioning or heating system on.
• Continued climate use of recirculated
OCN7050119
air may cause drowsiness or sleepiness,
and loss of vehicle control. Set the air
Press the A/C button to turn on the air
intake control to the outside (fresh) air
conditioning system (indicator light ON).
position while driving.
Press the button again to turn off the air
conditioning system.
Fan speed control
OFF mode
OCN7050118
OCN7050121
The fan speed can be adjusted as desired
Press the OFF button to turn off the
by pressing the fan speed control button.
climate control system.
NOTICE
You can still operate the mode buttons
and air intake buttons as long as the
Operating the fan speed when the
ignition switch is in the ON position.
ignition switch is in the ON position may
cause the battery to discharge.
5-84
CarManuals2.com
5
• To help keep dust or unpleasant fumes
System operation
from entering the vehicle through the
ventilation system, temporarily set the
Ventilation
air intake control to the recirculation
1. Select the Face Level
mode.
mode. Be sure to return the control to
fresh mode position when the irritation
2. Set the air intake control to the outside
has passed to keep fresh air in the
(fresh) air position.
vehicle. This can help keep the driver
3. Set the temperature control to the
alert and comfortable.
desired position.
• To help prevent interior fog on the
4. Set the fan speed control to the desired
windshield, set the air intake control to
speed.
the fresh air position and the fan speed
to the desired position, turn on the air
conditioning system, and adjust the
Heating
temperature control to desired
1. Select the Floor Level
mode.
temperature.
2. Set the air intake control to the outside
(fresh) air position.
Air conditioning
3. Set the temperature control to the
HYUNDAI Air Conditioning Systems are
desired position.
filled with R-1234yf refrigerant.
4. Set the fan speed control to the desired
1. Start the engine. Press the air
speed.
conditioning button.
5. If desired, turn the air conditioning ON
2. Select the Face Level
mode.
with the temperature control knob set
to heat in order to dehumidify the air
3. Set the air intake control to the outside
before it enters into the cabin.
air or recirculated air position.
If the windshield fogs up, select the Front
4. Adjust the fan speed control and
& Defrost
mode or press the Front
temperature control as desired.
Defrost
mode.
NOTICE
Operation Tips
When using the air conditioning system,
• When starting the vehicle in cold
monitor the temperature gauge closely
weather a more efficient way to heat
while driving up hills or in heavy traffic
the passenger compartment is to do
when outside temperatures are high. Air
the following:
conditioning system operation may cause
engine overheating. Continue to use the
- Turn off or lower the blower right
blower fan but turn the air conditioning
after starting the engine.
system off if the temperature gauge
- If the engine temperature is still low
indicates engine overheating.
and the air flow from the heater is still
cold, after a few minutes of engine
warm up, turn on or set the fan speed
to a higher level and adjust the
temperature setting to hot.
5-85
CarManuals2.com
Convenience features
Air conditioning system operation tips
System maintenance
If the vehicle has been parked in direct
sunlight during hot weather, open the
Cabin air filter
windows for a short time to let the hot
air inside the vehicle escape.
Information
After sufficient cooling has been
• Replace the filter according to the
achieved, switch back from
Maintenance Schedule.
recirculated air position to the fresh
outside air position.
• If the car is being driven in severe
conditions such as dusty, rough roads,
To help reduce moisture inside of the
more frequent cabin air filter
windows on rainy or humid days,
inspections and changes are required.
decrease the humidity inside the
vehicle by operating the air
• When the air flow rate suddenly
conditioning system with the windows
decreases, have the system inspected
and sunroof closed.
by an authorized HYUNDAI dealer.
During air conditioning system
operation, you may occasionally notice
Checking the amount of air
a slight change in engine speed as the
conditioner refrigerant and
air conditioning compressor cycles.
compressor lubricant
This is a normal system operation
characteristic.
If the amount of refrigerant is too low or
too high, the performance of the air
Use the air conditioning system every
conditioning is reduced.
month only for a few minutes to ensure
maximum system performance.
Have the system inspected by an
authorized HYUNDAI dealer.
When using the air conditioning
system, you may notice clear water
NOTICE
dripping (or even puddling) on the
ground under the passenger side of the
It is important that the correct type and
vehicle. This is a normal system
amount of oil and refrigerant are used.
operation characteristic.
Otherwise, damage to the compressor
If you operate the air conditioner
and abnormal system operation may
excessively, the difference between the
occur. To prevent damage, the air
temperature of the outside air and that
conditioning system in your vehicle
of the windshield may cause the outer
should only be serviced by trained and
surface of the windshield to fog up,
certified technicians.
causing loss of visibility. In this case, set
the mode selection button to the
position and set the fan speed control
knob to the lowest speed setting.
5-86
CarManuals2.com
5
Air conditioning refrigerant label
NOTICE
• The refrigerant system should only be
serviced by trained and certified
technicians in a well-ventilated area to
ensure proper and safe operation.
• Never repair the air conditioning
evaporator (cooling coil) or replace
with the one removed from a used or
salvaged vehicle. A new replacement
evaporator must be certified (and
labeled) as meeting SAE Standard
J2842.
OCN7053060
You can find out which air conditioning
refrigerant is applied to your vehicle on
the label located inside of the hood.
WARNING
Example
To prevent serious injury, have the air
conditioning system be serviced by only
trained and certified technicians.
R-1234yf is flammable and operated at
high pressure.
Reclaim all refrigerants with proper
equipment. Venting refrigerants directly
Each symbols and specification on the air
to the atmosphere is harmful to
conditioning refrigerant label is
individuals and environment.
represented as the following:
1. Classification of refrigerant
2. Amount of refrigerant
3. Classification of Compressor lubricant
4. Caution
5. Flammable refrigerant
6. To require registered technician to
service air conditioning system
5-87
CarManuals2.com
Convenience features
Windshield defrosting
Manual climate control
system
and defogging
To defog inside windshield
WARNING
Do not use the defrost-level
position
during the cooling operation in extremely
humid weather. The outer surface of the
windshield may fog and reduce visibility,
causing a collision that results in serious
injury or death.
Set the mode selection button to the
face-level
position and lower the fan
speed.
• For maximum defrost performance, set
OCN7050122N
the temperature control to the highest
temperature setting and the fan speed
1. Select any fan speed.
control to the highest setting.
2. Select the desired temperature.
• If warm air to the floor is desired while
3. Select the
or
position.
defrosting or defogging, select the
The outside (fresh) air is selected
floor-defrost position.
automatically. The air conditioning
• Before driving, clear all snow and ice
automatically operates if the mode is
from the windshield, rear window, side
selected to the defrost-level
position.
view mirrors, and all side windows.
If the air conditioning and outside (fresh)
• Clear all snow and ice from the hood
air position are not selected
and air inlet to improve heater and
automatically, press the corresponding
defroster efficiency and to reduce the
button.
probability of fogging up the inside of
the windshield.
5-88
CarManuals2.com
5
To defrost outside windshield
Automatic climate control
system
To defog inside windshield
OCN7052123C
1. Set the fan speed to the highest
(extreme right) position.
2. Set the temperature to the hottest
OCN7050124L
position.
1. Select the desired fan speed.
3. Select the
position.
2. Select the desired temperature.
The outside (fresh) air and air
3. Press the defroster button (
).
conditioning is selected automatically.
The air conditioning turns on according to
the detected ambient temperature, the
outside (fresh) air position and higher fan
speed are selected automatically.
If the air conditioning, outside (fresh) air
position and higher fan speed are not
selected automatically, adjust the
corresponding button or knob.
If the defrost-level
position is
selected, the fan speed increases.
5-89
CarManuals2.com
Convenience features
To defrost outside windshield
Manual climate control system
1. Turn the ignition switch to the ON
position.
2. Select defroster mode (
).
3. Press the air intake control button at
least 5 times within 3 seconds. The
process should be completed within 10
seconds after the defroster mode (
)
is selected.
The LED indicator on the air intake button
will blink 3 times to indicate that the
OCN7050125L
defogging logic has been disabled.
1. Set fan speed to the highest position.
Repeat the steps again to re-enable the
defogging logic.
2. Set temperature to the extreme hot (HI)
position.
If the battery has been discharged or
disconnected, it resets to the defog logic
3. Press the defroster button (
).
status.
The air conditioning turns on according to
the detected ambient temperature and
Automatic climate control system
the outside (fresh) air position is selected
automatically.
1. Turn the ignition switch to the ON
position.
If the defrost-level
position is
selected, lower fan speed is adjusted to
2. Press the defroster button (
).
higher fan speed.
3. While pressing the air conditioning
button (A/C), press the air intake
control button at least 5 times within 3
Defogging logic
seconds.
if equipped
The automatic climate control
To help reduce the probability of fogging
information screen will blink 3 times to
up the inside of the windshield, the air
indicate that the defogging logic has
intake or air conditioning are controlled
been disabled.
automatically according to certain
Repeat the steps again to re-enable the
conditions such as
or
position. To
defogging logic.
cancel or return the defogging logic, do
If the battery has been discharged or
the following
disconnected, it resets to the defog logic
status.
5-90
CarManuals2.com
5
Rear window defroster
Side view mirror defroster
if equipped
NOTICE
The side view mirror defrosters operate
Never use sharp instruments or window
when you turn on the rear window
cleaners containing abrasives to clean the
defroster.
window to prevent damage to the rear
window defroster.
Auto defogging system (only
for automatic climate control
The defroster heats the window to
system)
remove frost, fog, and thin ice from the
if equipped
interior and exterior of the rear window,
while the engine is running.
OCN7050061
Auto defogging helps reduce the
OCN7050136L
possibility of fogging up the inside of the
• To activate it, press the rear window
windshield by automatically sensing the
defroster button located in the center
moisture on inside the windshield.
control panel. The indicator on the rear
The auto defogging system operates
window defroster button illuminates
when the heater or air conditioning is on.
when the defroster is ON.
• To turn it off, press the rear window
Information
defroster button again.
The Auto Defogging system may not
operate normally, when the outside
Information
temperature is below 14 °F (-10 °C).
• If there is heavy accumulation of snow
on the rear window, brush it off before
operating the rear defroster.
• The rear window defroster
automatically turns off after about 20
minutes or when the ignition switch is
When the Auto Defogging System
in the LOCK/OFF position.
operates, the indicator illuminates.
If a high amount of humidity is detected in
the vehicle, the Auto Defogging System is
enabled.
The following steps are performed
automatically:
5-91
CarManuals2.com
Convenience features
Step 1) A/C button turns on.
Climate control
Step 2) Air intake control changes to
additional features
outside (fresh) air position under low
outside temperature.
Step 3) Defrost-level is selected.
Sunroof inside air
Step 4) Fan speed increases.
recirculation
if equipped
To cancel or reset the Auto Defogging
System
When the sunroof is opened, the outside
(fresh) air position is automatically
Press the front windshield defroster
selected. If you press the air intake
button for 3 seconds when the ignition
control button, the recirculated air
switch is in the ON position.
position is selected but changes back to
When the Auto Defogging System is
the outside (fresh) air position after 3
canceled, the defroster button indicator
minutes. When the sunroof is closed, the
blinks 3 times.
air intake position returns to the previous
When the Auto Defogging System is
position.
reset, the defroster button indicator
blinks 6 times without a signal.
Automatic ventilation
Information
if equipped
• When the air conditioning is turned on
The system automatically selects the
by Auto defogging system, if you try to
outside (fresh) air position when the
turn off the air conditioning, the
climate control system operates over a
indicator blinks 3 times and the air
certain period of time (about 30 minutes)
conditioning does not turned off.
in low temperature with the recirculated
air position selected.
• Do not select recirculated air while the
Auto defogging system is operating.
• When the Auto Defogging System is
To cancel or reactivate the
operating, fan speed adjustment,
automatic ventilation
temperature adjustment, and air intake
When the air conditioning system is on,
control selection are all disabled.
select Face Level mode and press the
recirculation mode button at least 5 times
within 3 seconds while pressing the A/C
NOTICE
button.
When the automatic ventilation is
Do not remove the sensor cover located
canceled, the indicator blinks 3 times.
on the top of the windshield glass.
When the automatic ventilation is
Damage may not be covered by your
activated, the indicator blinks 6 times.
vehicle warranty.
5-92
CarManuals2.com
5
Automatic controls for the
Storage compartment
driver based on climate
control system settings
WARNING
if equipped
Never store cigarette lighters, propane
The temperature of the driver’s seat
cylinders, or other flammable/explosive
warmer is automatically controlled
materials in the vehicle. These items may
depending on the inside and outside
catch fire and/or explode if the vehicle is
temperature of the vehicle when the
exposed to hot temperatures for an
engine is running.
extended period of time.
These features must be enabled from the
Settings menu in the infotainment
system.
WARNING
Select: Setup > Vehicle > Seat (or
Always keep the storage compartment
Climate) > Warmer/Ventilation Features
covers closed securely while driving.
For more information on Auto Comfort
Items inside your vehicle are moving as
Control, refer to the "Seat warmers"
fast as the vehicle. If you have to stop or
sections in chapter 3.
turn quickly, or if there is a collision, the
items may fly out of the compartment and
may cause an injury if they strike the
driver or passengers.
NOTICE
To avoid possible theft, do not leave
valuables in the storage compartments.
5-93
CarManuals2.com
Convenience features
Center console storage
Interior features
Cup holder
Front
OCN7050062
To open:
Grab and hold the latch on the armrest
then lift the lid.
Rear
Glove box
Cups or small beverages cups may be
OCN7050064
placed in the cup holders.
To open:
Pull the lever (1).
WARNING
• Avoid abrupt starting and braking when
WARNING
the cup holder is used to prevent
Always close the glove box door after use.
spilling your drink. If hot liquid spills,
you may be burned.
An open glove box door may cause
serious injury to a passenger in a collision,
Such a burn to the driver may cause
even if the passenger is wearing a seat
loss of vehicle control resulting in a
belt.
collision.
• Only use soft cups in the cup holders.
5-94
CarManuals2.com
5
Power outlet
NOTICE
• Keep your drinks sealed while driving to
prevent spilling.
• When cleaning spilled liquids, do not
use hot air to blow out or dry the cup
holder.
• Keep cans or bottles out of direct sun
light and do not put them in a hot
vehicle. Otherwise, they may explode.
OCN7053068
Sunvisor
The power outlet is designed to provide
power for mobile phones or other devices
designed to operate with vehicle
electrical systems.
The devices should draw less than 180
watts with the engine running.
WARNING
Avoid electrical shocks. Do not place your
fingers or foreign objects (pin, etc.) into a
power outlet or touch the power outlet
with a wet hand.
OIG046437
To use the sunvisor, pull it downward.
To use the sunvisor to block the sun from
the side window, pull it downward,
release it from the bracket (1) and swing it
to the side (2) toward the window.
To use the vanity mirror, pull down the
sunvisor and slide the mirror cover (3).
Adjust the sunvisor forward or backward
(4) as needed (if equipped). Use the ticket
holder (5) to hold tickets.
Close the vanity mirror cover securely and
return the sunvisor to its original position
after use.
WARNING
Do not block your view or the roadway
when using the sunvisor.
5-95
CarManuals2.com
Convenience features
USB charger
NOTICE
Front seat
To prevent damage to the power outlets:
Use the power outlet only when the
engine is running and remove the
accessory plug after use. Using the
accessory plug for an extended period
of time with the engine off may cause
the battery to discharge.
Only use 12 volts electric accessories
that are less than 180 watts in the
electric capacity.
Adjust the air conditioner or heater to
OCN7053069
the lowest operating level when using
Rear seat
the power outlet.
Close the cover when not used.
Some electronic devices may cause
electronic interference when plugged
into a vehicle’s power outlet.
Push the plug in as far as it goes. The
plug may overheat and the fuse may
open.
Only connect devices with reverse
current protection or the current from
the device battery may cause the
vehicle’s electrical/electronic system
The USB charger is designed to recharge
to malfunction.
batteries of small size electronic devices
using a USB cable.
The electrical devices can be charged
when the ignition switch is in the ON or
START position.
5-96
CarManuals2.com
5
Wireless smartphone
Information
charging system
Disconnect the USB cable from the USB
if equipped
port after use.
The battery charging state may be
monitored on the electrical device.
A smartphone or a tablet PC may get
warmer during the charging process. It
does not indicate any malfunction with
the charging system.
A smartphone or a tablet PC that does
not use a USB cable to charge should be
charged using its own charger.
Charging may not be possible when
OCN7053070
using a Type-C to A converter sold by a
[A] Charging pad
mobile phone manufacturer or
commercially available.
Charging smartphone
Do not attempt to use the charging
terminal to turn ON an audio or to play
The wireless smartphone charging
media with the infotainment system.
system charges only the Qi-enabled
smartphones (
).
Use the USB charger when the engine is
running. Using the USB charger for
Visit your smartphone manufacturer’s
prolonged periods of time with the
website to check whether your
ignition switch in the ON position
smartphone supports the Qi technology.
(engine off) may cause the battery to
The wireless charging process starts
discharge.
when you put a Qi-enabled smartphone
To prevent damage to the USB charger:
on the wireless charging unit with the
screen facing up.
- Do not insert foreign objects or spill
liquid into the outlet. The USB
1. The wireless smartphone charger is
charging terminal may be damaged.
available when all doors are closed, and
when the ignition switch is in the ON or
- Do not use devices with working
START position.
current exceeding 3,000 mA (3.0 A).
2. Turn on the wireless charging function
from the Settings menu in the
instrument cluster or infotainment
system. Select:
User Settings > Convenience >
Wireless Charging System (for
instrument cluster type)
Settings > Vehicle > Convenience >
Wireless Charging System (for
infotainment system type)
5-97
CarManuals2.com
Convenience features
3. Place the smartphone on the center of
Information
the wireless charging pad. The
indicator light is orange when the
The wireless smart phone charging
smartphone is charging and turns
system may not support smartphones
green when phone charging is
that do not meet the (
) specification.
complete.
When placing your smartphone on the
charging pad, position the phone in the
Information
middle of the mat for optimal charging
• Remove other items, including the
performance. If your smartphone is off
smart key from the wireless charging
to the side, the charging rate may be
pad.
less and in some cases the smartphone
• For flip type smartphones, when using
may experience higher heat
wireless charging, place the
conduction.
smartphone folded with the device’s
Wireless charging may stop temporarily
back placed on the center of the
when the smart key is used, or when
wireless charging unit.
starting the vehicle or
locking/unlocking the doors.
When charging certain smartphones,
If your smartphone is not charging:
the charging indicator may not change
• Make sure all doors are closed.
to green when the smartphone is fully
• Move the smartphone on the charging
charged.
pad.
The wireless charging process may
• Make sure the indicator light is orange.
temporarily stop, when the
temperature abnormally increases
The indicator light blinks orange for 10
inside the wireless smartphone
seconds if there is a malfunction in the
charging system. The wireless charging
wireless charging system.
process does not restart, until the
The system warns you with a message on
temperature falls.
the cluster display if the smartphone is
The wireless charging process may stop
still on the wireless charging pad after the
when there is any metallic item, such as
vehicle is turned OFF and the front door is
coin, between the wireless smartphone
opened.
charging pad and smartphone.
For some manufacturer’s smartphones,
the system may not warn you even
though the smartphone is left on the
wireless charging unit. This is due to the
particular characteristic of the
smartphone and not a malfunction of
the wireless charging.
When charging some smartphones
with a self-protection feature, the
wireless charging speed may decrease
and the wireless charging may stop.
If the smartphone has a thick case, it
may not charge.
5-98
CarManuals2.com
5
If the smartphone is not completely
Coat hook
contacting the charging pad, wireless
charging may not operate properly.
Some magnetic items such as credit
cards, phone cards, or transit cards may
be damaged if left with the smartphone
during the charging process.
When any smartphone without a
wireless charging function or a metallic
object is placed on the charging pad, a
small noise may because the vehicle
discerns compatibility of the object
placed on the charging pad. It does not
affect your vehicle or the smartphone.
OTM048095
Some smartphones may not be able to
These hooks are not designed to hold
charge depending on the internal
large or heavy items.
structure of the smartphone. If this
occurs, try charging the smartphone by
WARNING
moving it to the left or right side of the
wireless charging pad. However, for
some foldable smartphones that have
magnets inside the smartphone, try
charging the smartphone while holding
it close to the left side of the wireless
charging pad.
If the gear is shifted to P (Park) when
the digital key is not registered,
wireless charging may stop
temporarily.
If the ignition switch is in the LOCK/OFF
OCN7050071
position, the charging stops.
Only hang soft clothing without heavy,
Clock
sharp or breakable objects in the clothes
The clock can be set from the
pockets. In a collision or when the curtain
infotainment system.
airbag is inflated, the objects could move
For more information, refer to the
and cause serious injury.
infotainment system manual.
WARNING
Do not attempt to adjust the clock while
driving.
5-99
CarManuals2.com
Convenience features
Infotainment system
Antenna
NOTICE
• Do not install an aftermarket HID
headlight. Your vehicle’s audio and
electronic devices may not function
properly.
• Prevent chemicals such as perfume,
cosmetic oil, sun cream, hand cleaner,
and air freshener from contacting the
interior parts because they may cause
damage or discoloration.
OCN7050072
Shark fin antenna (1)
USB port
The shark fin antenna receives data
transmitted from base stations and
satelliltes (e.g. GPS, Sirus XM, LTE) and
also transmits to base stations (e.g. LTE).
Glass antenna (2)
Your vehicle uses a glass antenna to
receive both AM and FM signals.
NOTICE
• Do not clean the inside of the rear
OCN7053074
window glass with a cleaner or scraper
The USB port can be used while the
to remove foreign deposits as this may
engine is running.
cause damage to the antenna
elements.
• Small electronic devices can be
charged.
• To prevent damage to the rear glass
antenna, never use sharp instruments
• After connecting a media storage
or window cleaner containing abrasives
device such as a MP3 or USB to the USB
to clean the window. Clean the inside
port, you can listen to music through
the vehicle's speakers or play it on the
surface of the rear glass window with a
infotainment system.
piece of soft cloth.
• When putting a sticker on the inside
Information
surface of the rear window, be careful
not to damage the rear glass antenna.
• Some devices may not be charged
through USB port.
• Do not put sharp instruments nearby
the rear glass antenna.
• When using a portable audio device
connected to the power outlet, noise
may occur during playback. If this
happens, disconnect the USB cable and
use the portable audio device's power
source.
5-100
CarManuals2.com
5
SEEK/PRESET (
/
) (2)
Information
If the SEEK/PRESET switch is pressed up
• Avoid adding metallic coatings such as
or down and held for 0.8 seconds or
Nickel, Cadmium, etc. These can
more, it functions in the following modes:
degrade the receiving AM and FM
broadcast signals.
RADIO mode
• Tinted rear window may affect the
It functions as the AUTO SEEK select
proper functioning of the antenna.
button. It seeks until you release the
button.
Steering wheel audio controls
MEDIA mode
It functions as the FF/RW button.
If the SEEK/PRESET switch is pressed up
or down, it functions in the following
modes.
RADIO mode
It functions as the PRESET STATION
UP/DOWN button.
MEDIA mode
OCN7053073
It functions as the TRACK UP/ DOWN
button.
NOTICE
Do not operate multiple audio remote
MODE (3)
control buttons simultaneously.
Press the MODE button to toggle through
Radio mode.
VOLUME (VOL + / VOL -) (1)
MUTE (
) (4)
• Rotate the VOLUME scroll up to
Press the MUTE button to mute or
increase volume.
activate the sound.
• Rotate the VOLUME scroll down to
decrease volume.
Custom button (
) (5)
• Custom function
• Press and hold to move to the function
setting screen.
Information
For more information, refer to the
separately supplied infotainment system
manual.
5-101
CarManuals2.com
Convenience features
Infotainment system
Bluetooth® wireless
if equipped
technology
For more information, refer to the
infotainment system manual.
Voice recognition
OCN7053075
OCN7050081
For more information, refer to the
separately supplied infotainment system
manual.
OCN7050076
(1) Call/Answer/Call end button
(2) Left Microphone
(3) Right Microphone (if equipped)
For more information, refer to the
infotainment system manual.
WARNING
To prevent driver distraction, minimize
your use of these features while driving.
Distraction may cause a collision,
resulting in serious injury or death.
5-102
CarManuals2.com
5
How vehicle radio works
AM (MW, LW) reception
FM reception
OJF045309L
AM broadcasts can be received at greater
distances than FM broadcasts. This is
OJF045308L
because AM radio waves are transmitted
AM and FM radio signals are broadcast
at low frequencies. These long, low
from transmitter towers located around
frequency radio waves can follow the
your city. They are intercepted by the
curvature of the earth rather than
radio antenna on your vehicle. This signal
travelling straight out into the
is then received by the radio and sent to
atmosphere. In addition, they curve
your vehicle speakers.
around obstructions so that they can
When a strong radio signal has reached
provide better signal coverage.
your vehicle, the precise engineering of
your audio system ensures the best
FM radio station
possible quality reproduction. However,
in some cases the signal coming to your
vehicle may not be strong and clear.
This can be due to factors, such as the
distance from the radio station, closeness
of other strong radio stations or the
presence of buildings, bridges or other
large obstructions in the area.
OJF045310L
FM broadcasts are transmitted at high
frequencies and do not bend to follow the
earth’s surface. Because of this, FM
broadcasts generally begin to fade at
short distances from the station. Also, FM
signals are easily affected by buildings,
mountains, or other obstructions.
5-103
CarManuals2.com
Convenience features
These can result in certain listening
signal. If this occurs, select another
conditions which might lead you to
station with a stronger signal.
believe a problem exists with your radio.
• Multi-Path Cancellation Radio signals
The following conditions are normal and
being received from several directions
do not indicate radio trouble :
can cause distortion or fluttering. This
can be caused by a direct and reflected
signal from the same station, or by
signals from two stations with close
frequencies. If this occurs, select
another station until the condition has
passed.
Using a cellular phone or a two-way
radio
When a cellular phone is used inside the
vehicle, its signal may interfere with the
JBM004
audio system.
• Fading As your vehicle moves away
NOTICE
from the radio station, the signal will
weaken and sound will begin to fade.
When using a communication system
When this occurs, we suggest that you
such as a cellular phone or a radio set
select another stronger station.
inside the vehicle, a separate external
• Flutter/Static Weak FM signals or large
antenna must be fitted. When a cellular
obstructions between the transmitter
phone or a radio set is used with an
and your radio can disturb the signal
internal antenna alone, it may interfere
causing static or fluttering noises to
with the vehicle’s electrical system and
occur. Reducing the treble level may
adversely affect safe operation of the
lessen this effect until the disturbance
vehicle.
clears.
WARNING
Do not use a cellular phone while driving.
Otherwise, it may cause a collision,
resulting in serious injury or death. Stop at
a safe place to use a cellular phone.
OJF045311L
• Station Swapping As a FM signal
weakens, another more powerful signal
near the same frequency may begin to
play. This is because your radio is
designed to lock onto the clearest
5-104
CarManuals2.com
6. Driving your vehicle
Before driving
6-4
Before entering the vehicle
6-4
Before starting
6-4
Vehicle break-in process
6-5
Key ignition switch
6-5
Key ignition switch positions
6-7
Starting the engine
6-8
Turning off the engine
6-8
Push button start ignition switch
6-9
Push button start ignition switch positions
6-10
Starting the engine
6-11
Turning off the engine
6-12
Remotely starting the engine
6-12
Vehicle Auto-Shut Off
6-13
Operating conditions
6-13
System operation
6-13
Deactivating conditions
6-13
6
Intelligent Variable Transmission
6-14
Intelligent Variable Transmission operation
6-15
Parking
6-18
Good driving practices
6-18
Dual Clutch Transmission
6-20
Dual Clutch Transmission operation
6-21
DCT warning messages
6-25
Parking
6-26
Paddle shifter (Manual shift mode)
6-27
Good driving practices
6-27
Braking system
6-28
Power-assist brakes
6-28
Disc brakes wear indicator
6-29
Parking brake
6-29
Electronic Parking Brake (EPB)
6-31
Auto Hold
6-34
Anti-lock Brake System (ABS)
6-36
Electronic Stability Control (ESC)
6-38
Vehicle Stability Management (VSM)
6-40
CarManuals2.com
Hill-start Assist Control (HAC)
6-41
Good braking practices
6-42
Idle Stop and Go (ISG) system
6-42
Auto stop
6-42
Auto start
6-43
Operating conditions
6-44
Deactivating the ISG
6-44
ISG malfunction
6-45
Smart ISG features
6-45
Drive mode integrated control system
6-49
Selecting drive mode
6-49
NORMAL, SPORT, SMART mode features
6-50
Smart shift on trip computer
6-51
Special driving conditions
6-51
Hazardous driving conditions
6-51
Rocking the vehicle
6-51
Smooth cornering
6-52
6
Driving at night
6-52
Driving in the rain
6-52
Driving in flooded areas
6-53
Highway driving
6-53
Winter driving
6-54
Snow or icy conditions
6-54
Winter precautions
6-55
Trailer towing
6-57
Vehicle load limit
6-57
The loading information label
6-58
CarManuals2.com
6
WARNING
Carbon monoxide (CO) gas is toxic. Breathing CO may cause unconsciousness and
death.
Engine exhaust contains carbon monoxide that cannot be seen or smelled.
Do not inhale engine exhaust.
If at any time you smell engine exhaust inside the vehicle, open the windows
immediately. Exposure to CO may cause unconsciousness and death by asphyxiation.
Make sure the exhaust system does not leak.
The exhaust system should be checked whenever the vehicle is raised to change the oil
or for any other purposes. If you hear a change in the sound of the exhaust or drive over
something that strikes the underneath side of the vehicle, have the exhaust system
checked as soon as possible by an authorized HYUNDAI dealer.
Do not run the engine in an enclosed area.
Letting the engine idle in your garage, even with the garage door open, is a hazardous
practice. Run the engine only long enough to start the engine and to move the vehicle
out of the garage.oon as possible by an authorized HYUNDAI dealer.
Avoid idling the engine for an extended period of time with people inside the vehicle.
If it is necessary to idle the engine for a long time with people inside the vehicle, be sure
to do so only in an open area with the air intake set at "Fresh" and fan control set to high
so fresh air is drawn into the interior.
Keep the air intakes clear.
To ensure proper operation of the ventilation system, keep the ventilation air intakes
located in front of the windshield clear of snow, ice, leaves, or other obstructions.
If you must drive with the trunk open:
Close all windows.
Open instrument panel air vents.
Set the air intake control at "Fresh", the air flow control at "Floor" or "Face", and the fan
control set to high.
6-3
CarManuals2.com
Driving your vehicle
Before driving
WARNING
To reduce the risk of serious injury or
death:
Before entering the vehicle
• Always wear your seat belt. All
• Make sure all windows, outer side view
passengers must be properly belted
mirror(s), and outside lights are clean
whenever the vehicle is moving. For
and unobstructed.
more information, refer to the "Seat
• Remove frost, snow, or ice from both
belts" section in chapter 3.
the front and rear windshield as well as
• Always drive defensively. Do not
the front side windows.
assume that the other drivers are
• Visually check the tires for uneven wear
seeing your vehicle. They may not act
and damage.
as you expect. Be prepared to react to
• Check under the vehicle for any sign of
avoid a possible collision. Plan your
leaks.
movements anticipating the
"worst-case" scenario.
• Make sure there are no obstacles
behind you if you intend to back up.
• Stay focused on driving. Driver
distraction may cause a collision.
• Leave plenty of space between you and
Before starting
the vehicle in front of you.
Make sure the hood, the trunk, and the
doors are securely closed and locked.
Adjust the position of the seat and
WARNING
steering wheel.
Adjust the inside and side view mirrors.
Never drink or take drugs while driving.
Verify all the lights work.
Drinking or taking drugs while driving is
dangerous and may result in a collision,
Fasten your seat belt. Check that all
causing serious injury or death.
passengers have fastened their seat
belts.
Drunk driving is the number one
contributor to the highway death toll each
Check the gauges and indicators in the
year. Even a small amount of alcohol can
instrument panel and the messages on
affect your reflexes, perceptions, and
the instrument display when the
judgment. Just one drink may reduce
ignition switch is in the ON position.
your ability to respond to changing
Check that any items you are carrying
conditions and emergencies and your
are stored properly or fastened down
reaction time gets worse with each
securely.
additional drink.
Driving while under the influence of drugs
is as dangerous or more dangerous than
driving under the influence of alcohol.
You are much more likely to have a
serious accident if you drink or take drugs
while driving. If you are drinking or taking
drugs, never drive. Do not ride with a
driver who has been drinking or taking
drugs. Choose a designated driver or call
a taxi.
6-4
CarManuals2.com
6
Vehicle break-in process
Key ignition switch
By following a few simple precautions for
if equipped
the first 600 mi. (1,000 km), you can add
to the performance, economy, and life of
WARNING
your vehicle.
To reduce the risk of serious injury or
• While driving, avoid sudden
death:
acceleration.
• Never allow children or any person who
• Do not maintain a single speed for a
is unfamiliar with the vehicle to touch
long time, either fast or slow. Varying
the ignition switch or related parts.
the engine speed is needed to properly
Unexpected and sudden vehicle
break-in the engine.
movement may occur.
• Avoid hard stops, except in
• Never reach through the steering wheel
emergencies, to allow the brakes to
for the ignition switch, or any other
seat properly.
control, while the vehicle is moving.
• Fuel economy, engine performance,
The presence of your hand or arm in
and engine oil consumption may differ
this area may cause a loss of vehicle
depending on the vehicle break-in
control resulting in a collision.
process and be stabilized after 4,000
mi. (6,000 km). New engines may
consume more oil during the vehicle
break-in period.
• Do not tow a trailer during the first
1,200 mi. (2,000 km) of operation.
B0246EU02
[A] Lock
[B] ACC
[C] ON
[D] START
Whenever the front door is opened, the
ignition switch illuminates if the ignition
switch is not in the ON position. The light
goes off immediately when the ignition
switch is turned ON or goes off after
about 30 seconds when the door is
closed. (for vehicles equipped with
ignition switch illumination)
6-5
CarManuals2.com
Driving your vehicle
WARNING
• Never turn the ignition switch to the
LOCK or ACC position while the vehicle
is moving except in an emergency. This
may result in the engine turning off and
loss of power assist for the steering and
brake systems. This may cause loss of
directional control and braking
function, which could cause a collision.
• Before leaving the driver's seat, always
make sure the shift lever is in the P
(Park) position, apply the parking brake,
turn the ignition switch to the LOCK
position, and take the keys with you to
prevent unintended vehicle movement.
NOTICE
Never use aftermarket keyhole covers.
These covers may prevent the vehicle
from recognizing the key and not allow
the vehicle to start.
6-6
CarManuals2.com
6
Key ignition switch positions
Switch
Action
Notes
Position
To turn the ignition switch to the LOCK
Always stop the vehicle before turning
position, push the key in at the ACC
the ignition switch to the LOCK
position and turn the key towards the
position.
LOCK
LOCK position.
The ignition key can be removed in
the LOCK position.
Some electrical accessories are
ACC
usable. The steering wheel unlocks.
This is the normal key position when
Do not leave the ignition switch in the
the engine has started. All features
ON position when the engine is not
and accessories are usable.
running to prevent the battery from
ON
The warning lights can be checked
discharging.
when you turn the ignition switch
from ACC to ON.
To start the engine, turn the ignition
The engine attempts to start until you
switch to the START position. The
release the key.
START
switch returns to the ON position
when you let go of the key.
6-7
CarManuals2.com
Driving your vehicle
Starting the engine
NOTICE
WARNING
To prevent damage to the vehicle:
• Always wear appropriate shoes when
• Do not hold the ignition key in the
operating your vehicle. Unsuitable
START position for more than 10
shoes such as high heels, ski boots,
seconds. Wait 5 to 10 seconds before
sandals, and flip-flops may interfere
trying again.
with your ability to use the brake,
• Do not turn the ignition switch to the
accelerator, and clutch pedals. Do not
START position with the engine
drive barefoot.
running. It may damage the starter.
• Do not start your vehicle with the
• If the engine stalls while the vehicle is
accelerator pedal depressed. Place
moving, shift to N (Neutral) and use the
your foot firmly on the brake pedal
ignition switch to attempt to restart the
while starting your vehicle.
engine.
• Wait until the engine is at normal idle
• Do not push or tow your vehicle to start
before shifting gears and releasing the
the engine.
brake. Your vehicle may move suddenly
if your vehicle is shifted while the
engine RPM is high. It may cause
Turning off the engine
damage to the transmission system.
1. Stop the vehicle and depress the brake
pedal fully.
1. Make sure the parking brake is applied.
2. Make sure the gear is in P (Park).
2. Make sure the shift lever is in P (Park).
3. Turn the ignition switch to the LOCK
position and apply the parking brake.
3. Depress the brake pedal.
4. Take the key with you when you leave
4. Turn the ignition switch to the START
the vehicle.
position. Hold the key (maximum of 10
seconds) until the engine starts and
release it.
Information
• Do not wait for the engine to warm up
or race the engine while the vehicle
remains stationary.
• Start driving at moderate engine
speeds. Do not rapidly accelerate and
decelerate while driving.
6-8
CarManuals2.com
6
Push button start ignition
WARNING
switch
To turn off the vehicle in an emergency:
if equipped
Press and hold the Push Button Start
ignition switch for more than two
WARNING
seconds. Or rapidly press and release the
Push Button Start ignition switch three
To reduce the risk of serious injury or
times (within three seconds).
death:
If the vehicle is still moving, you can
• Never allow children or any person who
restart the vehicle without depressing the
is unfamiliar with the vehicle to touch
brake pedal by pressing the Push Button
the Push Button Start ignition switch or
Start ignition switch with the gear in the N
related parts. Unexpected and sudden
(Neutral) position.
vehicle movement may occur.
• Never reach through the steering wheel
for the ignition switch, or any other
control, while the vehicle is moving.
WARNING
The presence of your hand or arm in
• Never press the Push Button Start
this area may cause a loss of vehicle
ignition switch while the vehicle is
control resulting in a collision.
moving except in an emergency. This
may result in the vehicle turning off and
loss of power assist for the steering and
brake systems. This may cause loss of
directional control and braking
function, which could cause an
accident.
• Before leaving the driver’s seat, always
make sure the gear is in the P (Park)
position, apply the parking brake, press
the Push Button Start ignition switch to
the OFF position, and take the Smart
Key with you to prevent unintended
vehicle movement.
OCN7060003
Whenever the front door is opened, the
Push Button Start ignition switch
illuminates and goes off 30 seconds after
the door is closed. (if equipped)
6-9
CarManuals2.com
Driving your vehicle
Push button start ignition switch positions
Button
Action
Notes
Position
To turn off the engine, press the Push
Always stop the vehicle before
Button Start ignition switch with the
pressing the Push Button Start
vehicle shifted to P (Park).
ignition switch to the OFF position.
If the Push Button Start ignition switch
OFF
is pressed with the gear shifted to D
(Drive), R (Reverse), or N (Neutral), the
Push Button Start ignition switch
changes to the ACC position.
Press the Push Button Start ignition
If you leave the Push Button Start
switch when the button is in the OFF
ignition switch in the ACC position for
position without depressing the brake
a period of time, the engine turns off
ACC
pedal.
automatically to prevent battery
Some of the electrical accessories are
discharge.
usable.
Press the Push Button Start ignition
Do not leave the Push Button Start
switch while it is in the ACC position
ignition switch in the ON position
ON
without depressing the brake pedal.
when the engine is not running to
The warning lights can be checked
prevent the battery from discharging.
before the engine is started.
To start the engine, depress the brake
If you press the Push Button Start
pedal and press the Push Button Start
ignition switch without depressing the
ignition switch with the gear shifted to
brake pedal, the engine does not start
the P (Park) or the N (Neutral)
and the Push Button Start ignition
START
position.
switch changes as follows: OFFACC
For your safety, start the engine with
ONOFF or ACC
the gear shifted to the P (Park)
position.
6-10
CarManuals2.com
6
Starting the engine
1. Always carry the smart key with you.
2. Make sure the parking brake is applied.
WARNING
3. Make sure the shift lever is in P (Park).
Always wear appropriate shoes when
4. Depress the brake pedal.
operating your vehicle. Unsuitable
5. Press the Push Button Start ignition
shoes such as high heels, ski boots,
switch.
sandals, and flip-flops may interfere
with your ability to use the brake,
Information
accelerator, and clutch pedals. Do not
drive barefoot.
• Do not wait for the engine to warm up
or race the engine while the vehicle
Do not start your vehicle with the
remains stationary.
accelerator pedal depressed. Place
your foot firmly on the brake pedal
• Start driving at moderate engine
while starting your vehicle.
speeds. Do not rapidly accelerate and
decelerate while driving.
Wait until the engine is at normal idle
before shifting gears and releasing the
brake. Your vehicle may move suddenly
if your vehicle is shifted while the
NOTICE
engine RPM is high. It may cause
damage to the transmission system.
To prevent damage to the vehicle:
• Do not press the Push Button Start
ignition switch for more than 10
seconds except when the stop light
Information
fuse is blown.
The vehicle starts by pressing the Push
When the stop light fuse is blown,
Button Start ignition switch, only when
replace the fuse. If you cannot replace
the smart key is in the vehicle.
the fuse, start the engine by pressing
The vehicle may not start even if the
and holding the Push Button Start
smart key is in the vehicle but it is not
ignition switch for 10 seconds with the
near you (e.g. in the cargo area).
Push Button Start ignition switch in the
ACC position.
When the Push Button Start ignition
switch is in the ACC or ON position, if
• If the engine stalls while the vehicle is
any door is open, the system checks for
moving, shift to N (Neutral) and use the
the smart key. When the smart key is
Push Button Start ignition switch to
not in the vehicle, the
indicator
attempt to restart the engine.
blinks and the warning, "Key not in
• Do not push or tow your vehicle to start
vehicle" appears. When all doors are
the engine.
closed, the chime also sounds for about
5 seconds.
6-11
CarManuals2.com
Driving your vehicle
Remotely starting the engine
Information
if equipped
OCN7063004L
OCN7063005
If the smart key battery is weak or the
You can start the vehicle using the
smart key does not work correctly, press
Remote Start button of on the smart key.
the Push Button Start ignition switch with
To start the vehicle remotely:
the smart key.
1. Press the door lock button within 32 ft.
(10 m) from the vehicle.
Turning off the engine
2. Press and hold the remote start (
)
1. Stop the vehicle and depress the brake
button for more than 2 seconds within 4
pedal fully.
seconds.
2. Make sure the gear is in P (Park).
To turn off the engine:
3. Press the Push Button Start ignition
Press the remote start (
) button once.
switch to the OFF position and apply
the parking brake.
Information
4. Take the key with you when you leave
the vehicle.
• The vehicle does not remotely start if
the hood or trunk is open.
• The vehicle must be in P (Park).
• The engine turns off if you get in the
vehicle without a registered smart key
or you do not get in the vehicle within
10 minutes.
6-12
CarManuals2.com
6
Vehicle Auto-Shut Off
System operation
if equipped
If your vehicle is parked and the engine is
left on for a long period of time, the
engine turns off automatically to help
reduce fuel consumption and prevent
carbon dioxide poisoning.
Operating conditions
Vehicle Auto-Shut Off timer operates
when all the following conditions are
OJK041087N
satisfied:
When all the conditions are satisfied, the
• The driver does not fasten their seat
Vehicle Auto-Shut Off operates and turns
belt.
the engine off automatically after 60
• No occupant is detected in the
minutes.
passenger's seat.
A timer appears on the instrument cluster
• The vehicle is stopped and the gear
30 minutes before vehicle shuts off.
shift is in P (Park).
• If the brake or accelerator pedals have
Resetting cluster timer
not been depressed.
A timer appears on the instrument cluster
• The infotainment system is not being
after 30 minutes and is reset by:
updated.
• Releasing the accelerator pedal or
brake pedals.
• Pressing the OK button on the steering
wheel while the timer appears on the
instrument cluster.
Deactivating conditions
The system does not automatically shut
off the engine if:
• The driver’s seat belt is fastened.
• An occupant is detected in the
passenger's seat.
• Driving over 2 mph (3 km/h).
• The brake pedal or accelerator pedal is
depressed.
• The gear is shifted to R (Reverse), D
(Drive), or N (Neutral).
6-13
CarManuals2.com
Driving your vehicle
Intelligent Variable Transmission
if equipped
OCN7063202N
[A] Shift release button
[B] Shift lever
[C] DS mode, manual shift mode
Depress the brake pedal and press the shift release button while moving the shift
lever.
Press the shift release button while moving the shift lever.
The shift lever can freely operate.
6-14
CarManuals2.com
6
Intelligent Variable
P (Park)
Transmission operation
Always come to a complete stop before
shifting into P (Park).
The Intelligent Variable Transmission
(IVT) has no actual fixed gears. The
To shift from P (Park), depress the brake
varying gear ratios are selected
pedal firmly and make sure your foot is
automatically, depending on the position
not depressing the accelerator pedal.
of the shift lever, vehicle's speed and
If you cannot shift the lever out of P
position of the accelerator pedal.
(Park), refer to the "Shift lock release"
The indicator on the instrument cluster
section in this chapter if equipped with a
the shift lever position when the ignition
shift lever.
switch is in the ON position.
WARNING
WARNING
• Shifting into P (Park) while the vehicle is
To reduce the risk of serious injury or
moving may cause you to lose control
death:
of the vehicle.
• Always check the surrounding areas
• After the vehicle has stopped, always
near your vehicle for people, especially
make sure the shift lever is in P (Park),
children, before shifting into D (Drive)
apply the parking brake, and turn the
or R (Reverse).
engine off.
• Before leaving the driver's seat, always
• When parking on an incline, shift the
make sure the shift lever is in the P
gear to P (Park), apply the parking
(Park) position, then apply the parking
brake, and turn the wheels toward the
brake, and place the ignition switch in
curb to prevent the vehicle from rolling
the LOCK/OFF position. Unexpected
downhill.
and sudden vehicle movement may
• Do not use the P (Park) position instead
occur if these precautions are not
of the parking brake.
followed.
• Do not use engine braking (using the
manual shift mode to shift from a
Information
higher gear to a lower gear) on slippery
roads. The vehicle may lose traction
The RPM (revolution per minute) may
with the roadway, resulting in a
increase or decrease when performing
collision.
the Intelligent Variable Transmission (IVT)
self-diagnosis.
6-15
CarManuals2.com
Driving your vehicle
R (Reverse)
The DRIVE MODE switch, located on the
shift lever console or on the left side of
Use this position to drive the vehicle
the dashboard, allows the driver to switch
backward.
from NORMAL mode to SPORT or SMART
NOTICE
mode (if equipped).
For more information, refer to the "Drive
Always come to a complete stop before
mode integrated control system" section
shifting into or out of R (Reverse) to
in this chapter.
prevent damaging the transmission.
DS (Drive Sporty) mode
N (Neutral)
The wheels and transmission are not
engaged.
Use N (Neutral) if you need to restart a
stalled engine, or if it is necessary to stop
with the engine ON. Shift into P (Park) if
you need to leave your vehicle for any
reason.
Always depress the brake pedal when you
are shifting from N (Neutral) to another
gear.
OCN7060007
WARNING
• To shift into DS mode, move the shift
lever from D (Drive) to the center of the
• Do not shift into gear unless your foot is
manual shift mode. The engine and
firmly on the brake pedal.
transmission control logic is
• Do not shift gears with the accelerator
automatically optimized for sporty
pedal depressed. Wait until the engine
driving.
RPM is normal. The vehicle may
• In DS mode, if you move the shift lever
suddenly move if you shift gears and
to + (Up) or - (Down), the gear changes
release the brake pedal when the RPM
to the manual shift mode. If the shift
is high.
lever is moved back into D (Drive), it
changes to D (Drive) and shifts
automatically. The vehicle performs
D (Drive)
according to the mode selected from
The transmission automatically shifts to
the drive mode (NORMAL, SPORT,
the optimal gear ratio, providing the best
SMART).
fuel economy and power.
Shift to D (Drive) while depressing the
brake pedal with the engine ON. Then
release the brake pedal and depress the
accelerator pedal.
For extra power when passing another
vehicle or driving uphill, depress the
accelerator pedal fully. The transmission
automatically downshifts to the next
lower gear.
6-16
CarManuals2.com
6
Manual shift mode
Shift lock system
For your safety, the Intelligent variable
transmission has a shift lock system that
prevents the transmission from shifting P
(Park) into R (Reverse) unless the brake
pedal is depressed.
To shift the transmission from P (Park)
into R (Reverse):
1. Depress and hold the brake pedal.
2. Start the engine or place the ignition
switch in the ON position.
ONX4E060040
3. Depress the brake pedal. press the shift
[A] + (Up)
release button, and put the gear in R
[B] - (Down)
(Reverse).
Whether the vehicle is stationary or
moving, the manual shift mode is
Shift lock release
selected by pushing the shift lever from
the D (Drive) position into the manual
If the shift lever cannot be moved from
gate. To return to D (Drive) range
the P (Park) into R (Reverse) with the
operation, push the shift lever back into
brake pedal depressed then:
the main gate.
In manual shift mode, moving the shift
lever backward and forward allows you to
select the desired range of gears for the
current driving conditions.
+ (Up) : Push the lever forward once to
shift up one gear.
- (Down) : Pull the lever backwards once
to shift down one gear.
Information
OCN7H063004
• Downshifts are made automatically
1. Place the ignition switch in the
when the vehicle slows down.
LOCK/OFF position.
• When the engine rpm approaches the
2. Apply the parking brake.
red zone, the transmission upshifts
3. Carefully remove the shift lever boots.
automatically.
4. Move the shift lever while holding the
• If the driver pushes the lever to + (Up) or
release button (1) with a tool (e.g.
- (Down), the transmission may not
flathead screw-driver).
shift if the next gear is outside of the
If you need to use the shift lock release,
allowable engine RPM range.
have the vehicle inspected by an
authorized HYUNDAI dealer immediately.
6-17
CarManuals2.com
Driving your vehicle
Good driving practices
NOTICE
Never shift the gear from P (Park) or N
Be careful not to damage the trim around
(Neutral) to any other gear when the
the shift lever while removing the shift
accelerator pedal is depressed.
lever boots.
Never shift the gear into P (Park) when
the vehicle is moving.
Ignition key interlock system
Do not shift to N (Neutral) when driving
to prevent a loss of engine braking and
if equipped
transmission damage that may cause a
The ignition key cannot be removed
collision.
unless the shift lever is in the P (Park)
position.
Never attempt to select a gear that is
opposite the direction of the vehicle
motion. Check the gear position before
Parking
driving. Stop the vehicle before shifting
to the desired gear. The engine may
Always come to a complete stop and
stop, causing a collision.
continue to depress the brake pedal. Shift
the gear to the P (Park) position, apply the
Do not drive with your foot resting on
parking brake, and place the ignition
the brake pedal. Even light, but
switch in the LOCK/OFF position. Take
consistent pedal pressure may result in
the key with you when exiting the vehicle.
the brakes overheating, brake wear,
and possibly even brake failure.
WARNING
Do not hold the vehicle on an incline
• When you stay in the vehicle with the
with the accelerator pedal. This can
engine running, be careful not to
cause the transmission to overheat.
depress the accelerator pedal for a long
Always use the brake pedal or parking
time. The engine or exhaust system
brake.
may overheat and start a fire.
Always apply the parking brake when
leaving the vehicle. Do not depend on
• The exhaust gas and the exhaust
placing the transmission in P (Park) to
system are very hot and may cause
keep the vehicle from moving.
burns. Keep away from the exhaust
system components.
Exercise extreme caution when driving
on a slippery surface. Be especially
• Do not stop or park over flammable
careful when braking, accelerating, or
materials, such as dry grass, paper, or
shifting gears. On a slippery surface, an
leaves. They may ignite and cause a
abrupt change in vehicle speed may
fire.
cause the drive wheels to lose traction
and may cause loss of vehicle control
resulting in a collision.
Optimum vehicle performance and
economy is obtained by smoothly
depressing and releasing the
accelerator pedal.
6-18
CarManuals2.com
6
WARNING
To reduce the risk of serious injury or
death:
• Always wear your seat belt. In a
collision, an unbelted occupant is
significantly more likely to be seriously
injured or killed than a properly belted
occupant.
• Avoid high speeds when cornering or
turning.
• Do not make quick steering wheel
movements, such as sharp lane
changes or fast, sharp turns.
• The risk of rollover greatly increases if
you lose control of your vehicle at
highway speeds.
• Loss of control often occurs if two or
more wheels drop off the roadway and
the driver over steers to reenter the
roadway.
• In the event your vehicle leaves the
roadway, do not steer sharply. Instead,
slow down before pulling back into the
travel lanes.
• HYUNDAI recommends you follow all
posted speed limits.
6-19
CarManuals2.com
Driving your vehicle
Dual Clutch Transmission
if equipped
OCN7N063008N
[A] Shift release button
[B] Shift lever
[C] DS mode, manual shift mode
Depress the brake pedal and press the shift release button while moving the shift
lever.
Press the shift release button while moving the shift lever.
The shift lever can freely operate.
6-20
CarManuals2.com
6
Dual Clutch Transmission
When D (Drive) is selected, the
transmission will automatically shift
operation
through the gears similar to a
The dual clutch transmission has 7
conventional automatic transmission.
forward speeds and one reverse speed.
Unlike a traditional automatic
The individual speeds are selected
transmission, the gear shifting can
automatically in the D (Drive) position.
sometimes be felt and heard as the
actuators engage the clutches and the
The indicator on the instrument cluster
gears are selected.
the shift lever position when the ignition
switch is in the ON position.
The dual clutch transmission adopts a
dry-type dual clutch, which is different
WARNING
from the torque converter of the
automatic transmission. It shows better
To reduce the risk of serious injury or
acceleration performance and
death:
increased fuel efficiency while driving
• Always check the surrounding areas
but initial launch might be little bit
near your vehicle for people, especially
slower than the automatic
children, before shifting into D (Drive)
transmission.
or R (Reverse).
As a result, gear shifts are sometimes
• Before leaving the driver’s seat, always
more noticeable than a conventional
make sure the shift lever is in the P
automatic transmission and a light
(Park) position, then apply the parking
vibration during launching can be felt
brake, and place the ignition switch in
as the transmission speed. This is a
the LOCK/OFF position. Unexpected
normal condition of the dual clutch
and sudden vehicle movement may
transmission.
occur if these precautions are not
The dry-type clutch transfers torque
followed.
more directly and provides a direct
• Do not use engine braking (using the
drive feeling which may feel different
manual shift mode or paddle shifters to
from a conventional automatic
shift from a higher gear to a lower gear)
transmission. This may be more
on slippery roads. The vehicle may lose
noticeable when launching the vehicle
traction with the roadway, resulting in a
from a stop or when traveling at low,
collision.
stop-and-go vehicle speeds.
When rapidly accelerating at a low
vehicle speed, the engine rpm may
• The dual clutch transmission can be
increase highly depending on the
thought of as an automatically shifting
vehicle’s driving condition.
manual transmission. It gives the
driving feel of a manual transmission,
For smooth launch uphill, press down
yet provides the ease of a fully
the accelerator pedal smoothly
automatic transmission.
depending on the current conditions.
If you release your foot from the
accelerator pedal at low vehicle speed,
you may feel strong engine braking,
which is similar to manual transmission.
6-21
CarManuals2.com
Driving your vehicle
• When driving downhill, you may use
P (Park)
Sports Mode or press the paddle
Always come to a complete stop before
shifters (if equipped) to downshift to a
shifting into P (Park).
lower gear in order to control your
To shift from P (Park), depress the brake
speed without using the brake pedal
pedal firmly and make sure your foot is
excessively.
not depressing the accelerator pedal.
• When you turn the engine on and off,
If you cannot shift the lever out of P
you may hear clicking sounds as the
(Park), refer to the "Shift lock release"
system goes through a self-test. This is
section in this chapter if equipped with a
a normal sound for the dual clutch
shift lever.
transmission.
• During the first 1000 mi. (1,500 km), you
WARNING
may feel that the vehicle may not be
• Shifting into P (Park) while the vehicle is
smooth when accelerating at low
moving may cause you to lose control
speed. During this break-in period, the
of the vehicle.
shift quality and performance of your
new vehicle is continuously optimized.
• After the vehicle has stopped, always
make sure the shift lever is in P (Park),
WARNING
apply the parking brake, and turn the
engine off.
In case of transmission failure, you may
not continue to drive and the position
• When parking on an incline, shift the
indicator (D, R) on the cluster will blink.
gear to P (Park), apply the parking
Contact an authorized HYUNDAI dealer
brake, and turn the wheels toward the
and have the system checked.
curb to prevent the vehicle from rolling
downhill.
• Do not use the P (Park) position instead
of the parking brake.
R (Reverse)
Use this position to drive the vehicle
backward.
NOTICE
Always come to a complete stop before
shifting into or out of (Reverse) to prevent
damaging the transmission.
6-22
CarManuals2.com
6
N (Neutral)
DS (Drive Sporty) mode
Use N (Neutral) if you need to restart a
To shift into DS mode, move the shift
stalled engine, or if it is necessary to stop
lever from D (Drive) to the center of the
with the engine ON. Shift into P (Park) if
manual shift mode. The engine and
you need to leave your vehicle for any
transmission control logic is
reason.
automatically optimized for sporty
driving.
The wheels and transaxle are not
engaged.
In DS mode, if you move the shift lever to
+ (Up) or - (Down), the gear changes to
Always depress the brake pedal when you
the manual shift mode. If the shift lever is
are shifting from N (Neutral) to another
moved back into D (Drive),it changes to D
gear.
(Drive) and shifts automatically. The
vehicle performs according to the mode
D (Drive)
selected from the drive mode (NORMAL,
The transmission automatically shifts
SPORT, SMART).
through a 7-gear sequence, providing the
best fuel economy and power.
Manual shift mode
Shift to D (Drive) while depressing the
brake pedal with the engine ON. Then
release the brake pedal and depress the
accelerator pedal.
For extra power when passing another
vehicle or driving uphill, depress the
accelerator fully. The transmission
automatically downshifts to the next
lower gear.
The DRIVE MODE switch, located on the
shift lever console or on the left side of
the dashboard, allows the driver to switch
OCN7N063009N
from NORMAL mode to SPORT or SMART
[A] + (Up)
[B] - (Down)
mode (if equipped)
Whether the vehicle is stationary or
For more information, refer to the "Drive
moving, the manual shift mode is
mode integrated control system" section
selected by pushing the shift lever from
in this chapter.
the D (Drive) position into the manual
gate. To return to D (Drive) range
WARNING
operation, push the shift lever back into
• Do not shift into gear unless your foot is
the main gate.
firmly on the brake pedal.
In manual shift mode, moving the shift
• Do not shift gears with the accelerator
lever backward and forward allows you to
pedal depressed. Wait until the engine
select the desired range of gears for the
RPM is normal. The vehicle may
current driving conditions.
suddenly move if you shift gears and
Up (+) : Push the lever forward once to
release the brake pedal when the RPM
shift up one gear.
is high.
Down (-) : Pull the lever backwards once
to shift down one gear.
6-23
CarManuals2.com
Driving your vehicle
Shift lock release
Information
If the shift lever cannot be moved from
• Downshifts are made automatically
the P (Park) into R (Reverse) with the
when the vehicle slows down. When
brake pedal depressed then:
the vehicle stops, the first gear is
automatically selected.
• When the engine rpm approaches the
red zone, the transmission upshifts
automatically.
• If the driver pushes the lever to + (Up) or
- (Down), the transmission may not
shift if the next gear is outside of the
allowable engine RPM range.
Shift lock system
OCN7N060011L
For your safety, the dual clutch
1. Place the ignition switch in the
transmission has a shift lock system that
LOCK/OFF position
prevents the transmission from shifting P
2. Apply the parking brake.
(Park) into R (Reverse) unless the brake
3. Carefully remove the shift lever boots.
pedal is depressed.
4. Move the shift lever while holding the
To shift the transmission from P (Park)
release button (1) with a tool (e.g.
into R (Reverse):
flathead screw-driver).
1. Depress and hold the brake pedal.
If you need to use the shift lock release,
2. Start the engine or place the ignition
have the vehicle inspected by an
switch in the ON position.
authorized HYUNDAI dealer immediately.
3. Depress the brake pedal. press the shift
release button, and put the gear in R
NOTICE
(Reverse).
Be careful not to damage the trim around
the shift lever while removing the shift
lever boots.
Ignition key interlock system
if equipped
The ignition key cannot be removed
unless the shift lever is in the P (Park)
position.
6-24
CarManuals2.com
6
DCT warning messages
If the clutch and the transmission
temperature is high, the self-protection
mode warns you with a warning chime
Transmission overheated warning
and message while the shift indicator on
If the warning messages on the cluster
the cluster display blinks.
continues to blink, contact an authorized
• Move the vehicle to a safe location and
HYUNDAI dealer.
shift the gear to P (Park) with the engine
running. Wait until the transmission is
Steep grade! Press brake pedal
sufficiently cooled down.
• If you ignore this warning, you may
experience abrupt shifts, frequent
shifts, or jerkiness.
Transmission hot! Park with engine On
2C_DCTWarningMessageInCluster
This message appears when the vehicle is
driving up hills or on steep grades.
If the vehicle is held or creeping forward
on an incline by applying the accelerator
pedal, the clutch and transmission may
2C_ShiftOverheatStopVehicleInfo
result in damage.
If you continue to drive with an
Press the brake pedal, if the messages
overheated transmission, the above
appears on the cluster display.
warning message appears, and the
self-protection mode disables the clutch.
Transmission temperature is high! Stop
• Move the vehicle to a safe location and
safely
shift the gear to P (Park) with the engine
running. Wait until the transmission is
sufficiently cooled down.
• If the above warning message is
displayed continuously, contact an
authorized HYUNDAI dealer.
2C_DCTWarningMessageInCluster_2
Repeated stop-and-go launches on steep
grades, sudden take off or acceleration,
or other harsh driving conditions may
increase the clutch and transmission
temperature.
6-25
CarManuals2.com
Driving your vehicle
Cooling... Remain parked for 00 min.
Parking
Always come to a complete stop and
continue to depress the brake pedal. Shift
the gear to the P (Park) position, apply the
parking brake, and place the ignition
switch in the LOCK/OFF position. Take
the key with you when exiting the vehicle.
WARNING
When you stay in the vehicle with the
engine running, be careful not to depress
2C_DCTWarningMessageInCluster_3
the accelerator pedal for a long time. The
If you move the vehicle to a safe location
engine or exhaust system may overheat
and shift the gear to P (Park) with the
and start a fire.
engine running, the above warning
The exhaust gas and the exhaust system
message appears.
are very hot and may cause burns. Keep
• Wait until the clutch is sufficiently
away from the exhaust system
cooled down.
components.
Do not stop or park over flammable
Transmission cooled down. Resume
materials, such as dry grass, paper, or
driving
leaves. They may ignite and cause a fire.
2C_ShiftOverheatCanDriveInfo
This message appears when your vehicle
can be driven.
Drive the vehicle smoothy as possible.
6-26
CarManuals2.com
6
Paddle shifter (Manual shift
Good driving practices
mode)
Never shift the gear from P (Park) or N
if equipped
(Neutral) to any gear when the
accelerator pedal is depressed.
Never shift the gear into P (Park) when
the vehicle is moving.
Do not shift to N (Neutral) when driving
to prevent a loss of engine braking and
transmission damage that may cause a
collision.
Never attempt to select a gear that is
opposite the direction of the vehicle
motion. Check the gear position before
driving. Stop the vehicle before shifting
OCN7N060010
to the desired gear. The engine may
The paddle shifter is available when the
stop, causing a collision.
gears is in the D (Drive) position.
Do not drive with your foot resting on
Pull the + or - paddle shifter once to shift
the brake pedal. Even light, but
up or down one gear and the system
consistent pedal pressure may result in
changes from automatic shift mode to
the brakes overheating, brake wear,
manual shift mode.
and possibly even brake failure.
To change back to the automatic shift
When driving in sports mode, slow
mode from manual shift mode, do one of
down before shifting to a lower gear.
the following:
Otherwise, the lower gear may not be
• Gently depress the accelerator pedal
engaged if the engine rpms are outside
for more than 5 seconds (Except Sport
of the allowable range.
Mode).
Always apply the parking brake when
leaving the vehicle. Do not depend on
• Drive the vehicle under 6 mph (10
placing the transmission in P (Park) to
km/h).
keep the vehicle from moving.
• Pull and hold the right side paddle
Exercise extreme caution when driving
shifter.
on a slippery surface. Be especially
careful when braking, accelerating or
Information
shifting gears. On a slippery surface, an
If the + and - paddle shifters are pulled at
abrupt change in vehicle speed may
the same time, gear shift may not occur.
cause the drive wheels to lose traction
and may cause loss of vehicle control
resulting in a collision.
Optimum vehicle performance and
economy is obtained by smoothly
depressing and releasing the
accelerator pedal.
6-27
CarManuals2.com
Driving your vehicle
Braking system
WARNING
To reduce the risk of SERIOUS INJURY or
DEATH:
Power-assist brakes
ALWAYS wear your seat belt. In a
Your vehicle has power-assisted brakes
collision, an unbelted occupant is
that adjust automatically through normal
significantly more likely to be seriously
usage.
injured or killed than a properly belted
If the engine is not running or is turned off
occupant.
while driving, the power assist for the
Avoid high speeds when cornering or
brakes does not work. You can still stop
turning.
your vehicle by applying greater force to
Do not make quick steering wheel
the brake pedal than typical. The stopping
movements, such as sharp lane
distance, however, may be longer than
changes or fast, sharp turns.
with power brakes.
The risk of rollover is greatly increased
When the engine is not running, the
if you lose control of your vehicle at
reserve brake power is partially depleted
highway speeds.
each time the brake pedal is depressed.
Loss of control often occurs if two or
Do not pump the brake pedal when the
more wheels drop off the roadway and
power assist has been interrupted.
the driver over steers to reenter the
roadway.
Information
In the event your vehicle leaves the
• When the brake pedal is depressed
roadway, do not steer sharply. Instead,
under certain driving conditions or
slow down before pulling back into the
weather conditions, you may
travel lanes.
temporarily hear a noise. This is normal
and does not indicate a problem with
HYUNDAI recommends you follow all
your brakes.
posted speed limits.
• While driving on a road with deicing
chemicals, brake noise or abnormal tire
wear may occur due to deicing
chemicals. In a safe traffic condition,
additionally apply the brakes to remove
deicing chemicals on the brake discs
and pads.
6-28
CarManuals2.com
6
Disc brakes wear indicator
WARNING
When your brake pads are worn and new
Take the following precautions:
pads are required, you may hear a high
• Do not drive with your foot resting on
pitched warning sound from your front or
the brake pedal. This creates abnormal
rear brakes. You may hear this sound
high brake temperatures, excessive
come and go or it may occur whenever
brake lining and pad wear, and
you depress the brake pedal.
increased stopping distances.
• When descending down a long or steep
Information
hill, use the paddle shifter or shift lever
Always replace both the left and right
and manually downshift to a lower gear
brake pads on the front and rear axles at
in order to control your speed without
the same time.
using the brake pedal excessively.
Applying the brakes continuously will
cause the brakes to overheat and may
Parking brake
result in a temporary loss of braking
if equipped
performance.
• Wet brakes may impair the vehicle's
ability to safely slow down and the
Applying the parking brake
vehicle may also pull to one side when
the brakes are applied. Applying the
brakes lightly indicates whether they
have been affected in this way. Always
test your brakes in this fashion after
driving through deep water. To dry the
brakes, lightly tap the brake pedal to
heat up the brakes while maintaining a
safe forward speed until the brake
performance returns to normal. Avoid
driving at high speeds until the brakes
function correctly.
OCN7080008
Always set the parking brake before
leaving the vehicle, to apply:
Firmly depress the brake pedal.
Pull up the parking brake lever as far as
possible.
WARNING
To reduce the risk of serious injury or
death, do not operate the parking brake
while the vehicle is moving except in an
emergency situation. It may damage the
brake system and cause a collision.
6-29
CarManuals2.com
Driving your vehicle
Releasing the parking brake
NOTICE
• Do not apply the accelerator pedal
while the parking brake is engaged. If
you depress the accelerator pedal with
the parking brake engaged, a warning
will sound. Damage to the parking
brake may occur.
• Driving with the parking brake on may
overheat the braking system and cause
premature wear or damage to brake
parts.
OCN7060010
To release:
Firmly depress the brake pedal.
While pressing the release button (1),
slightly pull up on the parking brake lever
then lower the parking brake lever (2).
WARNING
• Whenever leaving the vehicle or
This light illuminates when the Parking
parking, always come to a complete
Brake is applied with the ignition switch in
stop and continue to depress the brake
the ON position or when the engine is
pedal. Shift the vehicle into the P (Park)
running.
position, then apply the parking brake,
Before driving, make sure the parking
and move the ignition switch to the
brake is released and the parking brake
LOCK/OFF position.
warning light is OFF.
• Vehicles with the parking brake not
If the Parking Brake warning light remains
fully engaged are at risk of moving
on after the Parking Brake is released
inadvertently and causing serious injury
while the engine is running, there may be
to yourself or others.
a malfunction in the brake system.
• Never allow anyone who is unfamiliar
If at possible, stop driving the vehicle
with the vehicle to touch the parking
immediately. If that is not possible, use
brake.
extreme caution while operating the
• Only release the parking brake when
vehicle and only continue to drive the
you are seated inside the vehicle with
vehicle until you can reach a safe
your foot firmly on the brake pedal.
location.
6-30
CarManuals2.com
6
Electronic Parking Brake (EPB)
WARNING
if equipped
To reduce the risk of serious injury or
death, do not operate the EPB while the
Applying the parking brake
vehicle is moving except in an emergency
situation. It may damage the brake
system and cause a collision.
Information
During emergency braking, the Parking
Brake warning light illuminates and you
may hear a clicking noise.
OCN7H063005
NOTICE
To apply EPB (Electronic Parking Brake):
If you notice a noise or burning smell
1. Depress and hold the brake pedal.
when the EPB is used for emergency
braking, have the system inspected by an
2. Pull up the EPB switch.
authorized HYUNDAI dealer.
Make sure the Parking Brake warning light
comes on.
Releasing the parking brake
EPB (Electronic Parking Brake) may be
automatically applied when:
• Requested by other systems.
• The driver turns the vehicle off while
Auto Hold is operating.
Emergency braking
If there is a problem with the brake pedal
while driving, emergency braking is
possible by pulling up and holding the
EPB switch. Braking is possible only while
you are holding the EPB switch. However,
OCN7H063006
braking distance may be longer than
normal.
To release EPB (Electronic Parking
Brake):
1. Move the ignition switch to ON or
START.
2. Press the EPB switch while depressing
the brake pedal.
Make sure the Parking Brake warning light
goes off.
6-31
CarManuals2.com
Driving your vehicle
To release EPB (Electronic Parking Brake)
Warning messages
automatically:
To release EPB, fasten seatbelt and close
• Gear in P (Park) or in N (Neutral)
door, hood and trunk
With the engine running, depress the
brake pedal and shift out of P (Park) or
N (Neutral) to R (Reverse) or D (Drive).
Make sure the doors, hood, and trunk
are closed and the seat belt is fastened.
Information
• You can engage EPB even though the
ignition switch is in the LOCK/OFF
position (only if battery power is
available), but you cannot release it.
• Depress the brake pedal and release
OCN7060151L
the parking brake manually with the
If the driver's seat belt is unfastened, or
EPB switch before you drive downhill or
the hood, trunk, doors are open, and you
when backing up.
try to drive with EPB applied, a warning
sounds and a message appears.
NOTICE
WARNING
To prevent serious injury or death from
• If the Parking Brake warning light is still
unintended vehicle movement:
on even though the EPB has been
released, have the system inspected by
• Always come to a complete stop and
an authorized HYUNDAI dealer.
continue to depress the brake pedal
before parking, shift the gear into P
• Do not drive your vehicle with EPB
(Park), pull up the EPB switch, and
applied. It may cause excessive brake
move the ignition switch to the
pad and brake rotor wear.
LOCK/OFF position. Take the key with
you when leaving the vehicle.
• Never allow anyone who is unfamiliar
with the vehicle to touch the EPB
switch.
• Only release EPB when you are seated
inside the vehicle with your foot firmly
on the brake pedal.
NOTICE
Driving with the parking brake on may
overheat the braking system and cause
premature wear or damage to brake
parts.
6-32
CarManuals2.com
6
Parking brake automatically engaged
Information
• In winter, the EPB related device may
freeze and cannot be released. Do not
use the EPB but park on a flat surface
with the gear in P (Park). Use wheel
chocks under the wheels if necessary. If
the EPB applies automatically when the
gear is shifted to P (Park), turn off the
Auto Hold, and press the EPB switch to
release the parking brake.
• A clicking sound may be heard while
operating or releasing the EPB. These
OCN7060153L
conditions are normal and indicate that
When EPB is applied while Auto Hold is
EPB is functioning properly.
activated, a warning sounds and a
• When leaving your keys with a parking
message appears.
attendant or assistant, be sure to
inform him/her how to operate the EPB.
EPB malfunction
Electronic Parking Brake (EPB) warning
AUTO HOLD turning Off! Press brake
light illuminates if the ignition switch is in
pedal
the ON position and goes off in about 3
seconds if the system is operating
normally.
If the EPB warning light remains on,
comes on while driving, or does not come
on when the ignition switch is ON, the
EPB may have malfunctioned.
If this occurs, have the system inspected
by an authorized HYUNDAI dealer.
The EPB warning light may illuminate
when the ESC indicator light comes on to
indicate that ESC is not working properly,
OCN7060152L
but it does not indicate a malfunction of
When the conversion from Auto Hold to
EPB.
EPB is not working properly, a warning
sounds and a message appears.
6-33
CarManuals2.com
Driving your vehicle
Auto Hold
NOTICE
if equipped
• If the Parking Brake warning light does
Auto Hold maintains the vehicle in a
not illuminate or blinks after the EPB
standstill even though the brake pedal is
switch has been pulled, the EPB may
not depressed after the driver brings the
not be applied.
vehicle to a complete stop by depressing
• If the EPB warning light is still on or the
the brake pedal.
Parking Brake warning light blinks
when the EPB warning light is on, press
the switch, and then pull it up. Repeat
To apply:
this one more time. If the EPB warning
does not go off, have your vehicle
towed on a flatbed tow truck to an
authorized HYUNDAI dealer.
Parking brake warning light
OCN7H063007
1. Press the AUTO HOLD switch. The
white AUTO HOLD indicator comes on
and the system is in standby.
This light illuminates when the Parking
Brake is applied with the ignition switch in
the ON position or when the engine is
running.
Before driving, make sure the parking
brake is released and the parking brake
warning light is OFF.
If the Parking Brake warning light remains
on after the Parking Brake is released
while the engine is running, there may be
a malfunction in the brake system.
If possible, stop driving the vehicle
OCN7060017
immediately. If that is not possible, use
2. When you stop the vehicle completely
extreme caution while operating the
by depressing the brake pedal, Auto
vehicle and only continue to drive the
Hold maintains the brake pressure to
vehicle until you can reach a safe
hold the vehicle stationary. The
location.
indicator changes from white to green.
The vehicle remains stationary even if
you release the brake pedal.
6-34
CarManuals2.com
6
To release:
Information
If you depress the accelerator pedal with
the gear in D (Drive) or manual shift mode
• The Auto Hold does not operate when:
or R (Reverse), the Auto Hold is released
- The gear is in P (Park).
automatically and the vehicle starts to
- The gear is in R (Reverse).
move. The AUTO HOLD indicator changes
- EPB is applied.
from green to white.
• The Auto Hold automatically switches
WARNING
to EPB when:
Always look around your vehicle before
- The driver's door or hood is opened.
depressing the accelerator pedal to
- The vehicle is in a standstill for more
release Auto Hold.
than 10 minutes.
- The vehicle is on a steep slope.
- The vehicle moves several times.
To cancel:
- The trunk is opened.
The Parking Brake warning light comes
on, the AUTO HOLD indicator changes
from green to white, and a warning
sounds and a message appears to
inform you that EPB has been
automatically engaged. Before driving,
depress the brake pedal, check the
surrounding area, and release the
parking brake manually with the EPB
switch.
OCN7H063008
1. Depress and hold the brake pedal.
2. Press the AUTO HOLD switch.
NOTICE
The AUTO HOLD indicator turns off.
If the AUTO HOLD indicator changes to
yellow, Auto Hold does not work properly.
WARNING
Contact an authorized HYUNDAI dealer.
To prevent unintended vehicle
movement, always depress your foot on
the brake pedal to cancel the Auto Hold
before you:
• Drive downhill.
• Drive the vehicle in R (Reverse).
• Park the vehicle.
6-35
CarManuals2.com
Driving your vehicle
Warning messages
AUTO HOLD turning Off! Press brake
pedal
Parking brake automatically engaged
OCN7060152L
OCN7060153L
When the conversion from Auto Hold to
When EPB is applied while Auto Hold is
EPB is not working properly, a warning
activated, a warning sounds and a
sounds and a message appears.
message appears.
Press brake pedal to deactivate AUTO
Anti-lock Brake System (ABS)
HOLD
WARNING
Anti-Lock Braking System (ABS) or
Electronic Stability Control (ESC) system
will not prevent accidents due to
improper or dangerous driving
maneuvers. Even though vehicle control
is improved during emergency braking,
always maintain a safe distance between
you and objects ahead of you. Always
reduce the vehicle speed in extreme road
conditions.
OCN7060154L
The braking distance for vehicles
If you did not apply the brake pedal when
equipped with ABS or ESC may be longer
you release Auto Hold by pressing the
than for those without these systems in
AUTO HOLD switch, a warning sounds
the following road conditions:
and a message appears.
• Rough, gravel, or snow-covered roads.
• On roads where the road surface is
pitted or has different surface height.
• Tire chains are installed on your vehicle.
Never test the safety features of an ABS or
ESC equipped vehicle by high speed
driving or cornering. It may cause a
collision and endanger the safety of
yourself or others.
6-36
CarManuals2.com
6
ABS is an electronic braking system that
WARNING
helps prevent a braking skid. ABS allows
the driver to steer and brake at the same
If the ABS (
) warning light is on and
time.
stays on, you may have a problem with
the ABS. Your power brakes work
Using ABS
normally. To reduce the risk of serious
injury or death, contact your authorized
To obtain the maximum benefit from your
HYUNDAI dealer as soon as possible.
ABS in an emergency situation, do not
attempt to modulate your brake pressure
and do not try to pump your brakes.
Depress your brake pedal as hard as
Information
possible.
When you drive on a road having poor
When you apply your brakes under
traction, such as an icy road, and apply
conditions that may lock the wheels, you
your brakes continuously, ABS is active
may hear sounds from the brakes, or feel
continuously and the ABS (
) warning
a corresponding sensation in the brake
light may illuminate. Pull your vehicle
pedal. This is normal and it means your
over to a safe place and turn off the
ABS is active.
vehicle.
ABS does not reduce the time or distance
Restart the vehicle. If the ABS warning
to stop the vehicle.
light is off, your ABS system is normal.
Always maintain a safe distance from the
If not, contact an authorized HYUNDAI
vehicle in front of you.
dealer as soon as possible.
ABS does not prevent a skid that results
from sudden changes in direction, such
as trying to take a corner too fast or
making a sudden lane change. Always
Information
drive at a safe speed for the road and
When you jump start your vehicle
weather conditions.
because of a drained battery, the ABS
ABS cannot prevent a loss of stability.
(
) warning light may turn on at the
Always steer moderately when braking
same time. It does not mean your ABS is
hard. Severe or sharp steering wheel
malfunctioning. Have the battery
movement can still cause your vehicle to
recharged before driving the vehicle.
veer into oncoming traffic or off the road.
On loose or uneven road surfaces,
operation of the anti-lock brake system
may result in a longer stopping distance
than for vehicles equipped with a
conventional brake system.
The ABS (
) warning light stays on for
several seconds after the ignition switch
is in the ON position.
During that time, ABS goes through
self-diagnosis and the light goes off if
everything is normal. If the light stays on,
contact an authorized HYUNDAI dealer as
soon as possible.
6-37
CarManuals2.com
Driving your vehicle
Electronic Stability Control
ESC operation
(ESC)
ESC ON condition
When the ignition switch is in the ON
position, ESC and the ESC OFF indicator
lights illuminate for about three seconds.
After both lights go off, ESC is enabled.
When operating
When ESC is operating, the ESC indicator
light blinks:
OCN7060021
• When you apply your brakes under
Electronic Stability Control helps stabilize
conditions that may lock the wheels,
the vehicle during cornering maneuvers.
you may hear sounds from the brakes,
ESC checks where you are steering and
or feel a corresponding sensation in the
where the vehicle is actually going. ESC
brake pedal.
applies braking pressure to any one of the
• If Cruise Control has been used when
vehicle's brakes and intervenes in the
ESC activates, Cruise Control
engine management system to assist the
automatically disengages. Refer to the
driver with keeping the vehicle on the
"Cruise Control (CC)" section in chapter
intended path. It is not a substitute for
7 (if equipped).
safe driving practices. Always adjust your
speed and driving to the road conditions.
• When moving out of the mud or driving
on a slippery road, the engine RPM
WARNING
(revolutions per minute) may not
increase even if you depress the
Never drive too fast for the road
accelerator pedal all the way. This is to
conditions when cornering. ESC does not
maintain the stability and traction of
prevent a collision.
the vehicle and does not indicate a
Excessive speed in turns, abrupt
problem.
maneuvers, and hydroplaning on wet
surfaces may result in severe collisions.
6-38
CarManuals2.com
6
ESC OFF condition
Indicator lights
■ ESC indicator light (blinks)
To cancel ESC operation:
State 1
Press the ESC OFF button briefly. The
■ ESC OFF indicator light (comes on)
ESC OFF indicator light and the
message, "Traction Control disabled"
illuminate.
The traction control function of ESC
(engine management) is disabled, but
the brake control function of ESC
When the ignition switch is in the ON
(braking management) still operates.
position, the ESC indicator light
State 2
illuminates, then goes off if the ESC
system is operating normally.
Press and hold the ESC OFF button
continuously for more than 3 seconds.
The ESC indicator light blinks whenever
The ESC OFF indicator light and the
ESC is operating.
message, "Traction & Stability Control
If the ESC indicator light stays on, have
disabled" illuminate and a warning
your vehicle inspected by an authorized
chime sounds. Both the traction control
HYUNDAI dealer as soon as possible.
function of ESC (engine management)
The ESC OFF indicator light comes on
and the brake control function of ESC
when ESC is turned off.
(braking management) are disabled.
If the ignition switch is moved to the
WARNING
LOCK/OFF position when ESC is off,
When ESC is blinking, this indicates ESC is
ESC remains off. Upon restarting the
active:
vehicle, ESC automatically turns on
again.
• Drive slowly and Never attempt to
accelerate.
• Never turn off ESC while the ESC
indicator light is blinking. You may lose
control of the vehicle and collide.
Information
Driving with wheels and tires with
different sizes may cause the ESC system
to malfunction. Before replacing tires,
make sure all four tires and wheels are the
appropriate size for your vehicle. Never
drive the vehicle with different sized
wheels and tires installed.
6-39
CarManuals2.com
Driving your vehicle
ESC OFF usage
Vehicle Stability Management
(VSM)
When Driving
Vehicle Stability Management is a
The ESC OFF mode should only be used
function of the Electronic Stability
briefly to help free the vehicle if stuck in
Control (ESC) system. It helps the vehicle
snow or mud, by temporarily stopping
stay stable when accelerating or braking
operation of ESC, to maintain wheel
suddenly on wet, slippery, and rough
torque.
roads where traction over the four tires
To turn off ESC while driving, press the
can suddenly become uneven.
ESC OFF button while driving on a flat
road surface.
WARNING
VSM is not a substitute for safe driving
NOTICE
practices. To prevent serious injury or
To prevent damage to the transmission:
death:
• Do not allow wheel(s) of one axle to
• Always monitor the speed and the
spin excessively while the ESC, ABS,
distance to the vehicle ahead of you.
and Parking Brake warning lights
• Never drive too fast for the road
appear. The repairs would not be
conditions. Excessive speed in bad
covered by the vehicle warranty.
weather or on slippery and uneven
Reduce engine power and do not spin
roads may result in severe collisions.
the wheel(s) excessively while these
lights appear.
• When operating the vehicle on a
VSM operation
dynamometer, make sure ESC is turned
The VSM operates when:
off (ESC OFF light illuminated).
• Vehicle speed is approximately above 9
mph (15 km/h) on curve roads.
• Vehicle speed is approximately above
Information
12 mph (20 km/h) when the vehicle is
Turning ESC off does not affect ABS or
braking on rough roads
standard brake system operation.
• The Electronic Stability Control (ESC) is
on.
6-40
CarManuals2.com
6
When operating
Hill-start Assist Control (HAC)
When you apply your brakes under
Hill-Start Assist Control helps prevent the
conditions that can activate ESC, you may
vehicle from rolling backwards when
hear sounds from the brakes, or feel a
starting from a stop on a hill.
corresponding sensation in the brake
pedal. This is normal and it means your
WARNING
VSM is active.
Always be ready to depress the
accelerator pedal when starting from a
Information
stop on an uphill slope. Hill-Start Assist
VSM does not operate when:
Control activates only for about 2
• Driving on a banked road such as
seconds.
gradient or incline.
• Driving in reverse.
• The ESC OFF indicator light is on.
Information
• The MDPS (Motor Driven Power
• Hill-Start Assist Control does not
Steering) warning light (
) is on or
operate when the gear is shifted to P
blinks.
(Park) or N (Neutral).
• Hill-Start Assist Control activates even
when the ESC (Electronic Stability
VSM OFF condition
Control) is off. It does not activate, if the
To cancel VSM operation, press the ESC
ESC is not operating normally.
OFF button. ESC OFF (
) indicator light
illuminates.
To turn on VSM again, press the ESC OFF
button again. The ESC OFF indicator light
goes out.
WARNING
If the ESC (
) indicator light or MDPS
(
) warning light stays illuminated or
blinks, your vehicle may have a
malfunction with the VSM system. Have
the vehicle inspected by an authorized
HYUNDAI dealer as soon as possible.
6-41
CarManuals2.com
Driving your vehicle
Good braking practices
Idle Stop and Go (ISG)
WARNING
system
if equipped
Whenever leaving the vehicle or parking,
always come to a complete stop and
The Idle Stop and Go (ISG) system
continue to depress the brake pedal. Shift
reduces fuel consumption by
the gear to the P (Park) position, apply the
automatically shutting down the engine
parking brake, and move the ignition
when the vehicle is at a standstill. (e.g. red
switch to the LOCK/OFF position.
light and traffic jam)
Vehicles parked with the parking brake
The engine starts automatically as soon
not applied or not in P (Park) may roll
as the starting conditions are met.
inadvertently and may cause injury to the
The ISG is ON whenever the engine is
driver and others. ALWAYS apply the
running.
parking brake before exiting the vehicle.
Wet brakes can be dangerous! The brakes
Information
may get wet if the vehicle is driven
When the engine automatically starts by
through standing water or if it is washed.
the ISG system, some warning lights
Your vehicle may not stop quickly if the
(ABS, ESC, ESC OFF, EPS or Parking brake
brakes are wet. Wet brakes may cause the
warning light) may turn on for a few
vehicle to pull to one side.
seconds.
To dry the brakes, apply the brakes lightly
This happens because of low battery
until the braking action returns to normal.
voltage. It does not mean the system has
If the braking action does not return to
malfunctioned.
normal, stop as soon as it is safe to do so
and contact an authorized HYUNDAI
dealer for assistance.
Auto stop
DO NOT drive with your foot resting on
the brake pedal. Even light, but constant
If you depress the brake pedal and the
pedal pressure may result in the brakes
vehicle comes to a stop with the ISG ON,
overheating, brake wear, and possibly
the engine will stop automatically.
even brake failure.
Stop the vehicle completely by pressing
If a tire goes flat while you are driving,
the brake pedal when the gear is in the D
apply the brakes gently and keep the
(Drive) or N (Neutral) position.
vehicle pointed straight ahead while you
are slowing down. When you are moving
slowly enough for it to be safe to do so,
pull off the road and stop in a safe
location.
Keep your foot firmly on the brake pedal
when the vehicle is stopped to prevent
the vehicle from rolling forward.
OCN7063192N
6-42
CarManuals2.com
6
The engine will stop and the green Auto
Auto start
Stop (
) indicator on the instrument
When the engine stops automatically by
cluster will appear.
ISG, the engine will restart if the driver
takes one of the following actions:
NOTICE
• Releases the brake pedal.
If you open the engine hood in auto stop
• Moves the shift gear to the R(Reverse)
mode, the following will happen:
position or the Manual mode while
• Auto Stop is Off. Shift to P or N and start
depressing the brake pedal.
engine manually
OCN7063193N
OCN7060157N
The engine will start and the green Auto
- The ISG system will deactivate.
Stop indicator (
) on the instrument
- The ISG system will deactivate
cluster will change to white.
• Press brake pedal for Auto Start
OIK057086N
If you shift the gear from N to D (Manual
mode) or R without depressing the
brake pedal after stopping engine
automatically, the engine does not
restart automatically and a warning
chime alarms. When this happens,
press the brake pedal for auto start.
6-43
CarManuals2.com
Driving your vehicle
The engine will also restart
NOTICE
automatically without any driver
actions if the following occurs:
• If the ISG system does not meet the
• The brake vacuum pressure is low.
operation condition, the ISG system is
deactivated. If the ISG does not
• The engine has stopped for about
operate, the reason for the
5minutes.
non-operation will appear on the
• The air conditioning is ON with the fan
cluster display.
speed set to the highest position.
• If the light or warning message comes
• The front defroster is ON.
on continuously, please check the
• The battery is weak.
operation condition.
• The cooling and heating performance
• ISG system will be activated with the
of the climate control system is
vehicle equipped with Smart Cruise
unsatisfactory.
Control if the operating conditions are
met.
• The vehicle is shifted to P (Park) when
Auto Hold is activated. (if equipped
with Auto Hold)
Deactivating the ISG
• The door is opened or the seatbelt is
unfastened when Auto Hold is
activated. (if equipped with Auto Hold)
• The EPB switch is pressed when Auto
Hold is activated. (if equipped with
Auto Hold)
Operating conditions
The ISG will operate under the following
condition:
• The driver's seatbelt is fastened.
OCN7060021N
• The driver's door and hood are closed.
• If you wish to deactivate the ISG, press
• The brake vacuum pressure is
the ISG OFF button. The light on the ISG
adequate.
OFF button will illuminate.
• The battery sensor is activated and the
• If you press the ISG OFF button again,
battery is sufficiently charged.
the ISG will be activated and the light
on the ISG OFF button will turn off.
• Outside temperature is not too low or
too high.
• The vehicle is driven over a constant
speed and stops.
• The climate control system satisfies the
conditions.
• The vehicle is sufficiently warmed up.
• The incline is gradual.
• The steering wheel is turned less
than180 degrees and then the vehicle
stops.
6-44
CarManuals2.com
6
ISG malfunction
Smart ISG features
Early Engine Restart
If the engine was stopped automatically
by ISG, Early Engine Restart can
automatically restart the engine from ISG
without driver action when the vehicle
ahead pulls away and the front view
camera detects the preceding vehicle’s
movement.
OCN7063192N
The ISG may not operate when an ISG
related sensor or system error occurs. The
following will happen:
• The yellow AUTO STOP (
) indicator
on the instrument cluster will appear.
When the engine is in Idle Stop mode, it's
possible to restart the engine without the
driver taking any action.
Before leaving the vehicle or doing
OCN7063194N
anything in the engine compartment,
stop the engine by the Push Button Start
ignition switch to the OFF position.
NOTICE
If the AGM battery is reconnected or
replaced, ISG function will not operate
immediately. If you want to use the ISG
function, the battery sensor needs to be
calibrated for approximately 4 hours with
the ignition off. After calibration, turn the
OCN7063193N
engine on and off 2 or 3 times.
If the engine restarts automatically by the
Early Engine Restart function, a message
will appear on the cluster display when
the "AUTO STOP" page on the instrument
cluster is selected.
6-45
CarManuals2.com
Driving your vehicle
OCN7063195N
OCN7063196N
(1) Timer
If a STOP, YIELD or Roundabout sign is
(2) Auto Start: vehicle ahead is driving
detected and the ISG system is
away
deactivated by ISG inhibition at traffic
signs, a message will appear on the
NOTICE
cluster display (if equipped) when the
"AUTO STOP" page on the instrument
• Even when the preceding vehicle drives
cluster is selected.
away, the Early Engine Restart function
may not restart the engine in case of
limitations of the front view camera
which can detect the preceding
vehicle's movement.
• Regarding the limitations of the front
view camera, please refer to
Limitations of Smart ISG features.
• If the engine was turned off by ISG, it
can be restarted anytime by releasing
the brake pedal, regardless of Early
Engine Restart.
OCN7063197N
ISG inhibition at traffic signs
(STOP/YIELD/Roundabout)
ISG inhibition at traffic signs can
deactivate the ISG system and keep the
engine on when stopped at certain traffic
signs (STOP/YIELD/Roundabout).
OCN7063198N
(1) Timer
(2) Auto Stop paused. STOP sign
detected
6-46
CarManuals2.com
6
ISG inhibition from turn signal
ISG inhibition from turn signal can
deactivate the ISG system and keep the
engine on when the turn signal is on and
the front view camera does not detect a
preceding vehicle.
If the ISG system is deactivated by ISG
inhibition from turn signal, a message will
appear on the cluster display when the
"AUTO STOP" page on the instrument
cluster is selected.
OCN7063199N
(1) Timer
(2) Auto Stop paused. YIELD sign
detected
OCN7063201N
(1) Timer
(2) AUTO STOP conditions not met.
Waiting to turn.
OCN7063200N
If the ISG system has been deactivated by
(1) Timer
ISG inhibition from turn signal and the
(2) Auto Stop paused. Roundabout sign
vehicle has not moved for 12 seconds,
detected
then the engine will shutdown
automatically to reduce fuel consumption
NOTICE
if all Operation Conditions are met.
• Even when stopped at a STOP, YIELD,or
NOTICE
Roundabout sign, this feature may not
deactivate the ISG system in case of
• Even when stopped with the turn signal
limitations of the front view camera
on, this feature may not deactivate the
which is able to detect traffic signs
ISG system in case of limitations of the
ahead.
front view camera.
• Regarding the limitations of the front
• Regarding the limitations of the front
view camera, please refer to
view camera, please refer to
Limitations of Smart ISG features.
Limitations of Smart ISG features.
6-47
CarManuals2.com
Driving your vehicle
overturned, or the side of the vehicle
WARNING
is visible, etc.
Limitations of Smart ISG features
-
The front vehicle's ground clearance
• Smart ISG features may not operate
is low or high
normally, or may operate
-
A vehicle, pedestrian or cyclist
unexpectedly, under the following
suddenly cuts in front
circumstances:
-
The vehicle in front is detected late
-
The detecting sensor or the
-
The vehicle in front is suddenly
surroundings are contaminated or
blocked by an obstacle
damaged
-
The vehicle in front suddenly
-
The temperature around the front
changes lane or suddenly reduces
view camera is high or low due to
speed
surrounding environment
-
The vehicle in front is bent out of
-
The camera lens is contaminated due
shape
to tinted, filmed or coated
-
The vehicle in front steers in the
windshield, damaged glass, or sticky
opposite direction of your vehicle to
foreign material (sticker, bug, etc.) on
avoid a collision
the glass
-
With a vehicle in front, your vehicle
-
Moisture is not removed or frozen on
changes lane at low speed
the windshield
-
The vehicle in front is covered with
-
Driving in heavy rain or snow, or thick
snow
fog
-
You are departing or returning to the
-
The field of view of the front view
lane
camera is obstructed by sun glare
-
Unstable driving
-
Street light or light from an oncoming
vehicle is reflected on the wet road
-
You are on a roundabout and the
surface, such as a puddle on the road
vehicle in front is not detected
-
Your vehicle is being towed
-
You are continuously driving in a
circle
-
The surroundings are very bright
-
The vehicle in front has an unusual
-
The surroundings are very dark.
shape
-
The brightness changes suddenly
• Some traffic signs may not be detected
(e.g. when entering or exiting a
by the front view camera under the
tunnel)
following circumstances:
-
The brightness outside is low, and the
- If located uphill or downhill away
headlamps are not on or are not
from the vehicle
bright
- If located multiple lanes away from
-
Only part of the vehicle is detected
the vehicle
-
The vehicle in front is a bus, heavy
- If partially or entirely blocked or
truck, truck with a unusually shaped
covered by another vehicle, tree, or
luggage, trailer, etc.
any obstacles
-
The vehicle in front has no tail lights,
- If damaged or alternated by stickers,
tail lights are located unusually, etc.
graffiti, etc.
-
The rear of the front vehicle is small
- If turned away from the vehicle
or the vehicle does not look normal,
such as when the vehicle is tilted,
6-48
CarManuals2.com
6
The mode changes whenever the DRIVE
Drive mode integrated
MODE button is pressed.
control system
• NORMALSPORTSMART
if equipped
When the NORMAL mode is selected, it
does not appear on the instrument
cluster.
Selecting drive mode
The drive mode will change to NORMAL
Type A
mode when the engine is restarted.
However, except when it is in SMART
mode. SMART mode will be maintained,
as selected when the engine is restarted.
If you change the setting of the drive
mode integrated control mode, SCC
reaction of Smart Cruise Control is also
changed. (if equipped)
Drive mode
integrated control
SCC reaction
mode
Type B (N Line)
NORMAL
Normal
SPORT
Fast
SMART
Normal
The drive mode can be selected
according to the driver’s preference or
road condition.
Information
If there is a problem with the instrument
cluster, the drive mode will be in NORMAL
mode and may not change to SPORT
mode.
6-49
CarManuals2.com
Driving your vehicle
NORMAL, SPORT, SMART
Information
mode features
• When using the SMART mode, if your
acceleration pedal input is gradual, the
NORMAL mode
drive mode maximizes the fuel
NORMAL mode provides smooth driving
efficiency.
and comfortable riding.
• When your vehicle is in SMART mode
and your driving style is more
aggressive so that your acceleration
SPORT mode
pedal input is more abrupt, the drive
mode changes to reflect a more SPORT
driving characteristic.
SPORT mode provides sporty response. In
SPORT mode, the fuel efficiency may
Various driving situations, which you may
decrease.
encounter in SMART mode
• When the SPORT mode is selected, the
• The driving mode automatically
SPORT indicator illuminates on the
changes to SMART SPORT, when you
instrument cluster.
abruptly accelerate the vehicle or
• When the SPORT mode is activated:
repetitively operate the steering wheel
- The engine RPM tends to remain
In this mode, your vehicle drives in a
raised over a certain time even after
lower gear for abrupt
releasing the accelerator pedal.
accelerating/decelerating and
increases the engine brake
- Upshifts are delayed when
performance.
accelerating.
• You may still sense the engine brake
performance, even when you release
SMART mode
the accelerator pedal in SMART SPORT
mode. It is because your vehicle
remains to be in a lower gear over a
certain period of time for next
SMART mode selects the proper driving
acceleration.
mode between NORMAL, and SPORT by
• The driving mode automatically
judging the driver's driving habits (mild or
changes to SMART SPORT mode only in
dynamic) from the brake pedal
harsh driving conditions. In most
depression or the steering wheel
driving situations, the driving mode is
operation.
set to SMART NORMAL mode.
• When the SMART mode is selected, the
• The driving mode automatically
SMART indicator illuminates on the
changes to SMART NORMAL mode with
instrument cluster.
the same driving patterns, when the
• The vehicle starts in SMART mode,
vehicle starts to drive on an upward
when the engine has been turned OFF
slope of a certain angle.
in SMART mode.
6-50
CarManuals2.com
6
SMART mode deactivates automatically
Special driving conditions
SMART mode may deactivate if:
• The driver manually shifts gears.
Hazardous driving conditions
• Cruise Control may deactivate the
SMART mode. When a higher speed is
When hazardous driving conditions are
set by Cruise Control, it starts to control
encountered such as water, snow, ice,
the vehicle speed and deactivates the
mud, and sand:
SMART mode.
• Drive cautiously and allow for longer
• Extremely high/low transmission oil
braking distances.
temperatures may temporarily
• Avoid abrupt braking or steering.
deactivate the SMART mode, because
• If your vehicle is stuck in snow, mud, or
the transmission is outside its normal
sand, use the second gear. Accelerate
operating condition.
slowly to avoid unnecessary wheel spin.
• Put sand, rock salt, tire chains, or other
Smart shift on trip computer
non-slip materials under the wheels to
if equipped
provide additional traction if stuck in
ice, snow, or mud.
Select the Trip Computer mode (
) on
the instrument cluster and move to the
WARNING
smart shift screen. Then, the driver can
see the drive mode selected and the drive
Downshifting with an automatic
mode which is automatically switched by
transmission while driving on slippery
the SMART mode.
surfaces may cause an accident. The
sudden change in tire speed may cause
the tires to skid. Be careful when
downshifting on slippery surfaces.
Rocking the vehicle
If it is necessary to rock the vehicle to free
it from snow, sand, or mud, first turn the
steering wheel right and left to clear the
area around your front wheels. Then, shift
back and forth between R (Reverse) and a
OIG069021L
forward gear.
The drive mode selected by the driver (1)
Try to avoid spinning the wheels, and do
and the driving style gauge (2) showing
not race the engine.
the driver’s driving style are displayed on
To prevent transmission wear, wait until
the screen.
the wheels stop spinning before shifting
gears. Release the accelerator pedal
while shifting, and press lightly on the
accelerator pedal while the transmission
is in gear. Slowly spinning the wheels in
forward and reverse directions causes a
rocking motion that may free the vehicle.
6-51
CarManuals2.com
Driving your vehicle
• Keep your headlights clean and
WARNING
properly aimed. Dirty or improperly
Always turn off the ESC system before
aimed headlights can make it much
rocking the vehicle. If the vehicle is stuck
more difficult to see at night.
and excessive wheel spin occurs, the
• Avoid staring directly at the headlights
temperature in the tires may increase
of oncoming vehicles. You may be
very quickly. If the tires become
temporarily blinded, and it takes
damaged, a tire blow out or tire explosion
several seconds for your eyes to
may occur - you and others may be
readjust to the darkness.
injured. Do not attempt this procedure if
people or objects are near the vehicle.
Driving in the rain
If you attempt to free the vehicle, the
vehicle may overheat quickly, possibly
Rain and wet roads can make driving
causing an engine compartment fire or
dangerous. When driving in the rain or on
other damage. Try to avoid spinning the
slick pavement:
wheels as much as possible to prevent
Slow down and allow extra following
overheating of the tires or the engine. DO
distance. A heavy rainfall makes it
NOT allow the vehicle to spin the wheels
harder to see and increases the
above 35 mph (56 km/h).
distance needed to stop your vehicle.
If you are still stuck after rocking the
Turn OFF your Cruise Control. (if
vehicle a few times, have the vehicle
equipped)
pulled out by a tow vehicle to avoid
Replace your windshield wiper blades
engine overheating, possible damage to
when they show signs of streaking or
the transmission, and tire damage. Refer
missing areas on the windshield.
to the "Towing" section in chapter 8.
Make sure your tires have enough
tread. If your tires do not have enough
tread, making a quick stop on wet
Smooth cornering
pavement may cause a skid and
Avoid braking or gear changing in
possibly lead to a collision. Refer to the
corners, especially when roads are wet.
"Tires and wheels" section in chapter 9.
Ideally, cornering should be taken under
Turn on your headlights to make it
gentle acceleration.
easier for others to see you. Using your
headlights when using your windshield
Driving at night
wipers is required in some jurisdictions.
Night driving presents more hazards than
Driving too fast through large puddles
driving in the daylight. Here are some
may affect your brakes. If you must go
important tips to remember:
through puddles, try to drive through
them slowly.
• Slow down and keep more distance
between you and other vehicles,
If you believe your brakes are wet,
because it may be more difficult to see
apply them several times while the
at night, especially in areas where there
vehicle is moving slowly.
are no street lights.
• Adjust your mirrors to reduce the glare
from other drivers’ headlights.
6-52
CarManuals2.com
6
Hydroplaning
Highway driving
If the road is wet enough and you are
driving fast enough, your vehicle may
Tires
have little or no contact with the road
Adjust the tire inflation pressure, as
surface and actually ride on the water.
specified. Under-inflation may overheat
The best advice is SLOW DOWN when the
or damage the tires.
road is wet.
Do not install worn-out or damaged tires,
The risk of hydroplaning increases as the
which may reduce traction or fail.
depth of tire tread decreases, refer to the
"Tires and wheels" section in chapter 9.
Information
Never over-inflate your tires above the
Driving in flooded areas
maximum inflation pressure, as specified
Avoid driving through flooded areas
on your tires.
unless you are sure the water is not
deeper than the bottom of the wheel hub.
If you are not sure, turn around and find a
Fuel, engine coolant and engine oil
different route.
Driving at higher speeds on the highway
Drive through any water slowly. Allow
consumes more fuel and is less efficient
adequate stopping distance because the
than driving at a slower, more moderate
brake performance can be reduced.
speed. Maintain a moderate speed to
conserve fuel when driving on the
After driving through water, dry the
highway.
brakes by gently applying them several
times while the vehicle is moving slowly.
Check both the engine coolant level and
the engine oil before driving.
Drive belt
A loose or damaged drive belt may
overheat the engine.
6-53
CarManuals2.com
Driving your vehicle
Tire chains
Winter driving
Since the sidewalls of radial tires are
thinner than other types of tires, they may
Snow or icy conditions
be damaged by mounting some types of
tire chains on them. Therefore, the use of
You need to keep sufficient distance
snow tires is recommended
between your vehicle and the vehicle in
front.
instead of tire chains. If tire chains must
be used, use genuine HYUNDAI Parts and
Apply the brakes gently. Speeding, rapid
install the tire chains after reviewing the
acceleration, sudden brake applications,
instructions provided with the tire chains.
and sharp turns are very hazardous
Damage to your vehicle caused by
practices. When decelerating, use engine
improper tire chain use is not covered by
braking to the fullest extent. Sudden
your vehicle manufacturer’s warranty.
brake applications on snowy or icy roads
may cause the vehicle to skid.
When using tire chains, attach them to
the front wheels.
To drive your vehicle in deep snow, it may
be necessary to use snow tires or to install
WARNING
tire chains on your tires.
The use of tire chains may adversely
Always carry emergency equipment. You
affect vehicle handling:
may want to carry tire chains, tow straps
or chains, a flashlight, emergency flares,
• Drive less than 20 mph (30 km/h) or the
sand, a shovel, jumper cables, a window
chain manufacturer’s recommended
scraper, gloves, ground cloth, coveralls, a
speed limit, whichever is lower.
blanket, etc.
• Drive carefully and avoid bumps, holes,
sharp turns, and other road hazards,
which may cause the vehicle to
Snow tires
bounce.
WARNING
• Avoid sharp turns or locked wheel
braking.
Snow tires should be equivalent in size
and type to the vehicle’s standard tires.
• Install tire chains only in pairs and on
Otherwise, the safety and handling of
the front tires. Installing tire chains on
your vehicle may be adversely affected.
the tires provides a greater driving
force, but does not prevent side skids.
Use snow tires when the road
temperature is below 45 °F (7 °C). If you
CAUTION
mount snow tires on your vehicle, be sure
to use the same inflation pressure as the
If your vehicle has 235/40R18 size tires,
original tires. Mount snow tires on all four
do not use tire chain; they can damage
wheels to balance your vehicle’s handling
your vehicle (wheel, suspension and
in all weather conditions. The traction
body).
provided by snow tires on dry roads may
not be as high as your vehicle’s original
equipment tires. Check with the tire
dealer for maximum speed
Information
recommendations.
Do not install studded tires without first
checking local and municipal regulations
for possible restrictions against their use.
6-54
CarManuals2.com
6
Chain installation
Winter precautions
When installing tire chains, follow the
manufacturer’s instructions and mount
Use high quality ethylene glycol
them as tightly possible. Drive slowly (less
coolant
than 20 mph (30 km/h) or the chain
Your vehicle is delivered with high quality
manufacturer’s recommended speed
ethylene glycol coolant in the cooling
limit) with chains installed. If you hear the
system. It is the only type of coolant that
chains contacting the body or chassis,
should be used because it helps prevent
stop and tighten them. If they still make
corrosion in the cooling system,
contact, slow down until the noise stops.
lubricates the water pump, and prevents
Remove the tire chains as soon as you
freezing. Be sure to replace or replenish
begin driving on cleared roads.
your coolant in accordance with the
When mounting snow chains, park the
"Maintenance services" in chapter 9.
vehicle on level ground away from traffic.
Before winter, have your coolant tested to
Turn on the vehicle's Hazard Warning
make sure that its freezing point is
Flasher and place a triangular emergency
sufficient for the temperatures
warning device behind the vehicle (if
anticipated during the winter.
available). Always place the vehicle in P
(Park), apply the parking brake, and turn
off the engine before installing snow
Check battery and cables
chains.
Winter temperatures may affect the
battery performance. Inspect the battery
NOTICE
and cables, as specified in chapter 9. The
When using tire chains:
battery charging level can be checked by
an authorized HYUNDAI dealer or in a
• Wrong size chains or improperly
service station.
installed chains may damage your
vehicle’s brake lines, suspension, body,
and wheels.
Change to "winter weight" oil if
necessary
• Use SAE "S" class or wire chains.
In some regions in winter, it is
• If you hear noise caused by chains
recommended to use the "winter weight"
contacting the body, retighten the
oil with lower viscosity. In addition,
chains to prevent contact with the
replace the engine oil and filter if it is
vehicle body.
close to the next maintenance interval.
• To prevent body damage, retighten the
Fresh engine oil ensures optimum engine
chains after driving 0.3-0.6 mi. (0.5-1.0
operation during the winter months. For
km).
more information, refer to chapter 10.
• Do not use tire chains on vehicles
When you are not sure about a type of
equipped with aluminum wheels. If
winter weight oil, contact an authorized
unavoidable, use a wire type chain.
HYUNDAI dealer.
• Use wire chains less than 0.47 in. (12
mm) thick to prevent damage to the
Check spark plugs and ignition
chain’s connection.
system
Inspect the spark plugs, as specified in
chapter 9. If necessary, replace them.
Also check all ignition wirings and
components for any cracks, wear, and
damage.
6-55
CarManuals2.com
Driving your vehicle
To prevent locks from freezing
Carry emergency equipment
Spray approved de-icing fluid or glycerin
In accordance with weather conditions,
into key holes. When a lock opening is
carry appropriate emergency equipment,
already covered with ice, spray approved
while driving. Some of the items you may
de-icing fluid over the ice to remove it.
want to carry include tire chains, tow
When an internal part of a lock freezes, try
straps or chains, flashlight, emergency
to thaw it with a heated key. Carefully use
flares, sand, shovel, jumper cables,
the heated key to avoid an injury.
window scraper, gloves, ground cloth,
coveralls, blanket, etc.
Use approved window washer
anti-freeze solution
Do not place objects or materials in
the engine compartment
Add window washer anti-freeze solution,
as specified on the window washer
Putting objects or materials in the engine
container. Window washer anti-freeze
compartment may cause an engine
solution is available from an authorized
failure or a fire, because they may block
HYUNDAI dealer, and most vehicle
the engine cooling. Such damage is not
accessory outlets.
covered by the manufacturer’s warranty.
NOTICE
To keep locks from freezing
Do not use engine coolant or other types
To keep the locks from freezing, squirt an
of anti-freeze solution, to prevent any
approved de-icer fluid or glycerine into
damage to the vehicle paint.
the key opening. If a lock is covered with
ice, squirt it with an approved deicing
fluid to remove the ice. If the lock is frozen
Do not let your parking brake freeze
internally, you may be able to thaw it out
Under some conditions, your parking
by using a heated key. Handle the heated
brake may freeze in the engaged position.
key with care to avoid injury.
This is most likely to happen when there is
an accumulation of snow or ice around or
Drive your vehicle when water vapor
near the rear brakes or the brakes are wet.
condenses and accumulates inside
When there is the risk that your parking
the exhaust pipes
brake may freeze: temporarily apply the
parking brake with the gear in P (Park),
When the vehicle is stopped for a long
then block the rear wheels, and then
time in winter while the engine is running,
release the parking brake.
water vapor may condense and
accumulate inside the exhaust pipes.
Water in the exhaust pipes may cause
Do not let ice and snow accumulate
noise, etc., but it is drained driving at
underneath
medium to high speed.
Under some conditions, snow and ice
may build up under the fenders and
interfere with the steering. When driving
in such conditions during the severe
winter, check underneath the vehicle on a
regular basis, to make sure that the front
wheels and the steering components are
not blocked.
6-56
CarManuals2.com
6
Trailer towing
Vehicle load limit
Do not use this vehicle for trailer towing.
Two labels on your driver’s door sill
show how much weight your vehicle
was designed to carry: the Tire and
Loading Information Label and the
Certification Label.
Before loading your vehicle,
familiarize yourself with the following
terms for determining your vehicle’s
weight ratings, from the vehicle’s
specifications and the Certification
Label:
Base Curb Weight
This is the weight of the vehicle
including a full tank of fuel and all
standard equipment. It does not
include passengers, cargo, or
optional equipment.
Vehicle Curb Weight
This is the weight of your new vehicle
when you picked it up from your
dealer plus any aftermarket
equipment.
Cargo Weight
This figure includes all weight added
to the Base Curb Weight, including
cargo and optional equipment.
GAW (Gross Axle Weight)
This is the total weight placed on
each axle (front and rear) - including
vehicle curb weight and all payload.
GAWR (Gross Axle Weight Rating)
This is the maximum allowable
weight that can be carried by a single
axle (front or rear). These numbers
are shown on the Certification Label.
The total load on each axle must
never exceed its GAWR.
6-57
CarManuals2.com
Driving your vehicle
GVW (Gross Vehicle Weight)
Type C
This is the Base Curb Weight plus
actual Cargo Weight plus passengers.
GVWR (Gross Vehicle Weight
Rating)
This is the maximum allowable
weight of the fully loaded vehicle
(including all options, equipment,
passengers and cargo). The GVWR is
shown on the Certification Label
located on the driver’s door sill.
Type D
The loading information label
Type A
The label located on the driver’s door
jamb shows the original tire size, cold
tire pressures recommended for your
Type B
vehicle, the number of people that
can be in your vehicle and vehicle
capacity weight.
Occupants and cargo - Maximum
Load
5 persons: 849 lbs (385 kg)
The combined weight of occupants
and cargo should never exceed the
maximum load limit shown on the
Loading Information Label. Note that
when towing a trailer, the combined
weight must include the tongue load.
6-58
CarManuals2.com
6
Seating capacity
4.The resulting figure equals the
Total: 5 persons (Front seat: 2
available amount of cargo and
persons, Rear seat: 3 persons)
luggage load capacity. For
example, if the "XXX" amount
Seating capacity is the maximum
equals 1400 lbs. and there will be
number of occupants including a
five 150 lb passengers in your
driver that your vehicle may carry.
vehicle, the amount of available
However, the seating capacity may
cargo and luggage load capacity is
be reduced based upon the weight of
650 lbs. (1400 - 750 (5 x 150) = 650
all of the occupants, and the weight
lbs.)
of the cargo being carried or towed.
Do not overload the vehicle because
5.Determine the combined weight of
there is a limit to the total weight, or
luggage and cargo being loaded on
load limit including occupants and
the vehicle. That weight may not
cargo that the vehicle can carry.
safely exceed the available cargo
and luggage load capacity
calculated in Step 4.
Towing capacity
6.If your vehicle will be towing a
Do not use this vehicle for trailer
trailer, load from your trailer will be
towing.
transferred to your vehicle. Consult
this manual to determine how this
Cargo capacity
reduces the available cargo and
The cargo capacity of your vehicle
luggage load capacity of your
increases or decreases depending on
vehicle.
the weight, the number of occupants,
and the tongue load, if your vehicle is
WARNING
equipped with a trailer.
Do not overload the vehicle because
there is a limit to the total weight, or
Steps for determining correct load
load limit, including occupants and
limit
cargo that the vehicle can carry.
1. Locate the statement "The
Overloading may shorten the life of
combined weight of occupants and
the vehicle. If the GVWR or the GAWR
cargo should never exceed XXX kg
is exceeded, parts on the vehicle may
or XXX lbs." on your vehicle's
break, and it may change the
placard.
handling of your vehicle. These may
cause you to lose control and result in
2.Determine the combined weight of
an accident.
the driver and passengers that will
be riding in your vehicle.
3.Subtract the combined weight of
the driver and passengers from XXX
kg or XXX lbs.
6-59
CarManuals2.com
Driving your vehicle
+
Example 1
Passenger Weight
Maximum
Cargo Weight
(150 lbs. × 2= 300
Load (1400
(1100 lbs.)
lbs.) (68 kg × 2= 136
lbs.) (635 kg)
(499 kg)
kg)
+
Example 2
Passenger Weight
Maximum
Cargo Weight
(150 lbs. × 5 = 750
Load (1400
(650 lbs.)
lbs.) (68 kg × 5 = 340
lbs.) (635 kg)
(295 kg)
kg)
+
Example 3
Passenger Weight
Maximum
Cargo Weight
(172 lbs. × 5 = 860
Load (1400
(540 lbs.)
lbs.) (78 kg × 5 = 390
lbs.) (635 kg)
(245 kg)
kg)
6-60
CarManuals2.com
6
Certification label
WARNING
• Never exceed the GVWR for your
vehicle, the GAWR for the front or
rear axle and the vehicle capacity
weight. Exceeding these ratings
may affect your vehicle's handling
and braking ability, and cause a
collision.
• Do not overload your vehicle.
Overloading your vehicle may
cause heat buildup in your vehicle's
tires, possible tire failure, increased
OBH059070
stopping distances, and poor
The certification label is located on
vehicle handling. All of which may
the driver's door sill at the center
result in a collision.
pillar and shows the maximum
allowable weight of the fully loaded
vehicle. This is called the GVWR
WARNING
(Gross Vehicle Weight Rating). The
GVWR includes the weight of the
If you carry items inside your vehicle
vehicle, all occupants, fuel, and
(e.g., suitcases, tools, packages, or
cargo.
anything else), they are moving as
This label also tells you the maximum
fast as the vehicle. If you have to stop
weight that can be supported by the
or turn quickly, or if there is a
front and rear axles, called Gross Axle
collision, the items may cause an
Weight Rating (GAWR).
injury if they strike the driver or a
passenger.
The total weight of the vehicle,
including all occupants, accessories,
• Put items in the cargo area of your
cargo, and trailer tongue load must
vehicle. Try to spread the weight
not exceed the Gross Vehicle Weight
evenly.
Rating (GVWR) or the Gross Axle
• Do not stack items like suitcases
Weight Rating (GAWR). To find out
inside the vehicle above the top of
the actual loads on your front and
the seats.
rear axles, you need to go to a weigh
• Do not leave an unsecured child
station and weigh your vehicle. Be
restraint in your vehicle.
sure to spread out your load equally
• When you carry cargo inside the
on both sides of the centerline.
vehicle, secure it.
6-61
CarManuals2.com
CarManuals2.com
7. Driver assistance system
Before using driver assistance system
7-4
Driver assistance system settings
7-5
Forward Collision Avoidance Assist (FCA) (Front view camera only)
7-6
Forward Collision-Avoidance Assist settings
7-6
Forward Collision-Avoidance Assist operation
7-7
Forward Collision-Avoidance Assist malfunction and limitations
7-9
Forward Collision Avoidance Assist (FCA) (Sensor fusion)
7-17
Forward Collision-Avoidance Assist settings
7-18
Forward Collision-Avoidance Assist operation
7-19
Forward Collision-Avoidance Assist malfunction and limitations
7-24
Lane Keeping Assist (LKA)
7-32
Lane Keeping Assist settings
7-32
Lane Keeping Assist operation
7-33
Lane Keeping Assist malfunction and limitations
7-35
Blind-spot Collision-Avoidance Assist (BCA)
7-37
Blind-spot Collision-Avoidance Assist settings
7-38
Blind-spot Collision-Avoidance Assist operation
7-39
Blind-spot Collision-Avoidance Assist malfunction and limitations
7-41
Safe Exit Warning (SEW)
7-45
Safe Exit Warning settings
7-45
7
Safe Exit Warning operation
7-46
Safe Exit Warning malfunction and limitations
7-47
Manual Speed Limit Assist (MSLA)
7-49
Manual Speed Limit Assist operation
7-49
Intelligent Speed Limit Assist (ISLA)
7-51
Intelligent Speed Limit Assist settings
7-52
Intelligent Speed Limit Assist operation
7-52
Intelligent Speed Limit Assist malfunction and limitations
7-54
Driver Attention Warning (DAW)
7-56
Driver Attention Warning settings
7-56
Driver Attention Warning operation
7-57
Driver Attention Warning malfunction and limitations
7-59
Blind-spot View Monitor (BVM)
7-62
Blind-spot View Monitor settings
7-62
Blind-spot View Monitor operation
7-62
CarManuals2.com
Blind-spot View Monitor malfunction
7-63
Cruise Control (CC)
7-63
Cruise Control operation
7-63
Smart Cruise Control (SCC)
7-67
Smart Cruise Control settings
7-67
Smart Cruise Control operation
7-68
Smart Cruise Control malfunction and limitations
7-76
Navigation-based Smart Cruise Control (NSCC)
7-82
Navigation-based Smart Cruise Control settings
7-82
Navigation-based Smart Cruise Control operation
7-83
Limitations of Navigation-based Smart Cruise Control
7-84
Lane Following Assist (LFA)
7-87
Lane Following Assist operation
7-87
Lane Following Assist malfunction and limitations
7-89
Highway Driving Assist (HDA)
7-90
Highway Driving Assist settings
7-90
Highway Driving Assist operation
7-91
Highway Driving Assist malfunction and limitations
7-93
Rear View Monitor (RVM)
7-94
7
Rear View Monitor settings
7-95
Rear View Monitor operation
7-95
Rear View Monitor malfunction and limitations
7-97
Surround View Monitor (SVM)
7-97
Surround View Monitor settings
7-98
Surround View Monitor operation
7-99
Surround View Monitor malfunction and limitations
7-101
Rear Cross-traffic Collision-Avoidance Assist (RCCA)
7-101
Rear Cross-traffic Collision-Avoidance Assist settings
7-102
Rear Cross-traffic Collision-Avoidance Assist operation
7-102
Rear Cross-traffic Collision-Avoidance Assist malfunction and limitations
7-106
Forward/Reverse Parking Distance Warning (PDW)
7-110
Forward/Reverse Parking Distance Warning operation
7-110
Forward/Reverse Parking Distance Warning malfunction and precautions
7-112
Reverse Parking Collision-Avoidance Assist (PCA)
7-114
Reverse Parking Collision-Avoidance Assist settings
7-114
CarManuals2.com
7. Driver assistance system
Reverse Parking Collision-Avoidance Assist operation
7-115
Reverse Parking Collision-Avoidance Assist malfunction and limitations
7-116
Driver assistance system sensors
7-120
Cameras
7-120
Radars
7-121
Ultrasonic sensors
7-122
Declaration of conformity
7-123
Front radar
7-123
Rear corner radar
7-124
7
CarManuals2.com
Driver assistance system
Limitations of driver assistance
Before using driver
system
assistance system
Nearby vehicles, road conditions, or other
factors may delay the response from
WARNING
Driver Assistance system or cause these
systems not to function, including:
Always maintain a safe distance from the
vehicles ahead and adjust your vehicle
• Lane-restricted driving situations
speed to the road conditions. Driver
(tollbooths, construction zones, etc.)
Assistance system may not operate in all
• Curves, hills, or other road features that
situations and cannot avoid all collisions.
may detect vehicles in adjacent lanes or
To prevent serious injury or death:
not detect vehicles ahead in the
roadway
• Control your vehicle at all times. In
some cases, the Driver Assistance
• If other vehicles, pedestrians, or
system may provide unanticipated
cyclists are not detected
braking or steering.
• Driving in inclement weather, such as
• Never attempt to activate any Driver
heavy rain, snow or icy conditions
Assistance system by intentionally
• Interference from strong
driving toward people, animals,
electromagnetic waves
objects, or other vehicles.
• Streets with railroad tracks or other
• The steering, braking, and acceleration
embedded metal objects
inputs from you may override the
• If anything is blocking or covering a
responses from driver assistance
sensor
system.
• If any camera, radar, or sensor is
• Do not use Driver Assistance system
damaged
when towing a trailer or using a hitch
mounted carrier.
• Do not use Driver Assistance system if
you believe the sensors or the systems
may not be functioning properly.
Information
Due to the infotainment software version,
the description of each function of the
driver assistance system may differ from
the owner's manual.
7-4
CarManuals2.com
7
Driver assistance system
Driving Safety Priority: Lowers all other
audio volumes when the Driving Safety
settings
system sounds a warning.
Parking Safety Priority: Lowers all
Warning Methods
other audio volumes when the Parking
Type A
Assist view is active.
CAUTION
For safety, the warning method is
different depending on each function of
the driver assistance system.
Please check how each function warns
you.
Information
ONX4OB073097N
Type B
If you change the Warning Methods, it
can be applied to each function of the
driver assistance system. Please check
and change it in each function.
If the vehicle is restarted, Warning
Methods will maintain the last setting.
The setting menu may not exist based
on vehicle specification.
If you turn off the Warning Volume, for
your safety, the function may warn you
with a low volume, except Blind-Spot
OCN7073260N
Collision-Avoidance Assist and Rear
The Warning Methods can be set with the
Cross-Traffic Collision-Avoidance
vehicle on. Select User Settings > Driver
Assist.
Assistance > Warning Methods from the
The Warning Volume and Haptic
settings menu in the instrument cluster or
Warning cannot be turned off at the
Press Settings and select Vehicle > Driver
same time. When one of the warning is
Assistance > Warning Methods from the
turned off the other is activated.
infotainment system to change the
The Lane Safety Audible Warning Off
following settings:
can be set when both the Warning
Warning Volume: Adjusts the volume
Volume and the Haptic Warning are on.
of the warning sound.
Haptic Warning: Activate the steering
wheel vibration warning. (if equipped)
Lane Safety Audible Warning Off:
Turns off the Lane Safety Audible
Warning, even when both warning
volume and haptic warning are on.
7-5
CarManuals2.com
Driver assistance system
Forward Collision
Forward Collision-Avoidance
Assist settings
Avoidance Assist (FCA)
(Front view camera only)
Forward Safety
if equipped
OCN7073262N
OCN7061112L
With the ignition switch ON, go to User
Settings > Driver Assistance > Driving
Forward Collision-Avoidance Assist uses
Safety from the settings menu in the
the front view camera to help detect a
instrument cluster or Settings > Vehicle >
vehicle, a pedestrian ahead on the road.
Driver Assistance > Driving Safety from
The function may warn you with a
the settings menu in the infotainment
warning message on the instrument
system to select the following:
cluster and an audible warning if a
collision is imminent. If necessary, it may
• If Forward Safety is selected, Forward
assist with braking your vehicle to help
Collision-Avoidance Assist will warn the
reduce collision speed and avoid a
driver with a warning message, an
collision.
audible warning depending on the
collision risk levels. Braking assist will
Information
be applied depending on the collision
risk levels. If Forward Safety is
Forward Collision-Avoidance Assist
deselected, Forward Safety will turn
(Front view camera only) uses the
off. The warning light (
) will
following sensor:
illuminate on the cluster.
• Front view camera
Refer to the "Driver assistance system
WARNING
sensors" section in this chapter for the
Each time the engine is restarted,
location.
Forward Collision-Avoidance Assist turns
on.
If Forward Safety is selected after the
engine is restarted, the function does
NOT brake your vehicle to help avoid a
collision.
7-6
CarManuals2.com
7
Forward Safety Warning Timing
Information
You can set the following Warning
Methods:
• Warning Volume/Haptic
Warning/Driving Safety Priority
For more information, refer to the "Driver
assistance system settings" section in this
chapter.
Forward Collision-Avoidance
OCN7073261N
Assist operation
With the ignition switch ON, go to User
Forward Collision-Avoidance Assist may
Settings > Driver Assistance > Driving
warn and brake your vehicle depending
Safety > Forward Safety Warning
on the collision risk level.
Timingfrom the settings menu in the
instrument cluster or Settings > Vehicle >
Driver Assistance > Driving Safety >
Basic function
Forward Safety Warning Timing settings
menu in the infotainment system to
Collision Warning
change the initial warning activation time.
Warning Timing is set to Standard at the
factory.
WARNING
• Even though Standard is selected for
Forward Safety Warning Timing if the
vehicle ahead of you suddenly stops,
the initial warning activation time may
not seem late.
• Select Late for Forward Safety Warning
OCN7073154L
Timing when traffic is light and your
vehicle speed is slow.
If Forward Collision-Avoidance Assist
judges that a collision may occur, the
message may appear on the instrument
cluster and an audible warning is heard
Information
when:
When the engine is restarted, the
• A vehicle or powered two-wheeler is
Warning Timing maintains its last setting.
detected, and your vehicle speed is
about 6-112 mph (10-180 km/h).
• A pedestrian or cyclist is detected, and
your vehicle speed is about 6-50 mph
(10-80 km/h).
7-7
CarManuals2.com
Driver assistance system
Emergency Braking
Depress the brake pedal immediately and
check the surroundings.
• Braking control ends about 2 seconds
after your vehicle is stopped following
an Emergency Braking event.
WARNING
Forward Collision-Avoidance Assist may
not operate in all situations and cannot
avoid all collisions.
To prevent serious injury or death:
OCN7073155L
Only change the settings after parking
your vehicle at a safe location.
If Forward Collision-Avoidance Assist
judges avoiding a collision may be
Control your vehicle at all times. Do not
difficult, it applies higher brake force that
depend on Forward
may help avoid a collision with the
Collision-Avoidance Assist to avoid a
vehicle, pedestrian or cyclist detected
collision. Always maintain a safe
ahead.
distance from the vehicles ahead and
reduce your vehicle speed as needed.
The warning message may appear on the
instrument cluster and an audible
Forward Collision-Avoidance Assist
warning is heard when:
may stop operating, or may not
operate, or operate unnecessarily
• A vehicle or powered two-wheeler is
depending on the road conditions and
detected, and your vehicle speed is
surroundings.
about 6-37 mph (10-60 km/h).
When Active Assist or Warning Only is
• A pedestrian or cyclist is detected, and
selected and ESC is turned off by
your vehicle speed is about 6-37 mph
pressing and holding the ESC OFF
(10-60 km/h).
button, Forward Collision-Avoidance
Assist turns off automatically. Then the
Stopping vehicle and ending brake control
Forward Collision-Avoidance Assist
settings cannot be changed using the
settings menu and the warning light
illuminates on the instrument cluster. If
ESC is turned on again by pressing the
ESC OFF button, Forward
Collision-Avoidance Assist maintains its
last setting.
Never attempt to activate Forward
Collision-Avoidance Assist by
intentionally driving toward people,
OCN7073156L
animals, objects, or other vehicles.
Forward Collision-Avoidance Assist
After your vehicle has stopped following
may not assist braking your vehicle if
an Emergency Braking event, the "Drive
you depress the brake pedal sufficiently
carefully" warning message may appear
in response to the potential hazard
on the instrument cluster.
detected by the function to avoid all
collisions.
7-8
CarManuals2.com
7
During Forward Collision-Avoidance
Information
Assist operation, your vehicle may stop
suddenly. Always wear your seat belt,
• When a collision is imminent, braking
check your passengers have their seat
may be assisted if you depress the
belts fastened and secure loose objects
brake pedal insufficiently.
that may become projectiles.
• The images and colors in the
When other system’s warning message
instrument cluster may differ
appears or audible warning is heard,
depending on the cluster type or theme
Forward Collision-Avoidance Assist
selected from the settings menu.
may not warn you.
You may not hear the audible warning
of Forward Collision-Avoidance Assist if
Forward Collision-Avoidance
the surrounding environment is too
Assist malfunction and
noisy.
limitations
Forward Collision-Avoidance Assist
WARNING
malfunction
Even if there is an issue with Forward
Collision-Avoidance Assist, the
vehicle’s braking system operates
normally.
During emergency braking, braking by
the Forward Collision-Avoidance Assist
automatically cancels if you depress
the accelerator pedal or sharply steer
your vehicle.
Depending on the characteristics of the
vehicle, pedestrian detected, and the
B0314EU01
surroundings, the speed or detection
When Forward Collision-Avoidance Assist
ranges for Forward Collision-Avoidance
is not working properly, the "Check
Assist may be reduced. The function
Forward Safety system" warning
may not operate or be limited.
message may appear, and the and
Forward Collision-Avoidance Assist
warning lights may illuminate on the
operates only under certain conditions
instrument cluster. Have the vehicle
that determines the risk level:
inspected by an authorized HYUNDAI
- Condition of other vehicles
dealer.
- The direction vehicles are driven
- Vehicle speed
- Surroundings
If your vehicle speed is too high or the
speed difference from the other vehicle
is too large, the function may be limited
or not operate.
7-9
CarManuals2.com
Driver assistance system
Forward Collision-Avoidance Assist
WARNING
disabled
• Forward Collision-Avoidance Assist
may not operate properly even if there
is no warning message or warning light
on the instrument cluster.
• Forward Collision-Avoidance Assist
may not operate properly in open areas
where no objects are detected (e.g.
empty parking lot) or when the
detecting sensors are blocked right
after turning on the engine.
• Forward Collision-Avoidance Assist
OCN7070032L
may not operate properly even after the
When the front view camera is covered or
engine has been restarted when the
blocked, Forward Collision-Avoidance
detecting sensors are blocked or there
Assist may be temporarily limited or
is a problem with the function.
disabled.
The "Forward Safety system disabled.
Limitations of Forward
Camera obscured" warning message
Collision-Avoidance Assist
may appear, and the and warning
Forward Collision-Avoidance Assist may
lights may illuminate on the instrument
not operate normally or may operate
cluster.
unexpectedly if:
The function operates normally when
• The detecting sensor or the
such foreign material is removed, and the
surroundings are contaminated or
engine is restarted.
damaged.
If Forward Collision-Avoidance Assist
• The temperature around the front view
does not operate normally after the
camera is high or low due to
sensor has been uncovered or unblocked,
surrounding environment.
have the vehicle inspected by an
authorized HYUNDAI dealer.
• The camera lens is contaminated due to
tinted, filmed or coated windshield,
damaged glass, or sticky foreign
material (sticker, bug, etc.) on the glass.
• Moisture is not removed or frozen on
the windshield.
• Washer fluid is continuously sprayed, or
the wiper is on.
• Driving in heavy rain or snow, or thick
fog.
• The field of view of the front view
camera is obstructed by sun glare.
• Street light or light from an oncoming
traffic is reflected on the wet road
surface, such as a puddle on the road.
• An object is placed on the dashboard.
7-10
CarManuals2.com
7
Your vehicle is being towed.
The vehicle or powered two-wheeler in
front steers in the opposite direction of
The surrounding is very bright.
your vehicle to avoid a collision.
The surrounding is very dark, such as in
With a vehicle in front, your vehicle
a tunnel, etc.
changes lane at low speed.
The brightness changes suddenly, for
The vehicle in front is covered with
example when entering or exiting a
snow.
tunnel.
You are departing or returning to the
The brightness outside is low, and the
lane.
headlights are not on or are not bright.
Unstable driving.
Driving through steam, smoke or
shadow.
You are on a roundabout and the
vehicle in front is not detected.
Only part of the vehicle, powered
two-wheeler, pedestrian or cyclist is
You are continuously driving in a circle.
detected.
The vehicle or powered two-wheeler in
The vehicle in front is a bus, heavy
front has an unusual shape.
truck, truck with an unusually shaped
The vehicle or powered two-wheeler in
cargo, trailer, etc.
front is driving uphill or downhill.
The vehicle or powered two-wheeler in
The pedestrian or cyclist is not fully
front has no tail lights, tail lights are
detected, for example, if the pedestrian
located unusually, etc.
is leaning over or is not fully walking
The brightness outside is low, and the
upright.
tail lights are not on or are not bright.
The pedestrian or cyclist is wearing
The rear of the front vehicle is small or
clothing or equipment that makes it
the vehicle does not look normal, such
difficult to detect as a pedestrian or
as when the vehicle is tilted,
cyclist.
overturned, or the side of the vehicle is
visible, etc.
The front vehicle’s ground clearance is
low or high.
A vehicle, powered two-wheeler,
pedestrian or cyclist suddenly cuts in
front.
The vehicle or powered two-wheeler in
front is detected late.
The vehicle or powered two-wheeler in
front is suddenly blocked by an
ORS071178
obstacle.
The illustration above shows the image
The vehicle or powered two-wheeler in
the front view camera is capable of
front suddenly changes lane or
detecting as a vehicle, powered
suddenly reduces speed.
two-wheeler, pedestrian and cyclist.
The vehicle or powered two-wheeler in
• The pedestrian or cyclist in front is
front is bent out of shape.
moving very quickly.
The front vehicle’s speed is fast or slow.
• The pedestrian or cyclist in front is short
or is posing a low posture.
7-11
CarManuals2.com
Driver assistance system
The pedestrian or cyclist in front has
WARNING
impaired mobility.
The pedestrian or cyclist in front is
Driving on a curved road
moving intersected with the driving
direction.
There is a group of pedestrians, cyclists
or a large crowd in front.
The pedestrian or cyclist is wearing
clothing that easily blends into the
background, making it difficult to
detect.
The pedestrian or cyclist is difficult to
distinguish from the similarly shaped
structure in the surroundings.
OADAS003SD
You are driving by a pedestrian, cyclist,
traffic signs, structures, etc., near the
intersection.
Driving in a parking lot.
Driving through a tollgate, construction
area, unpaved road, partial paved road,
uneven road, speed bumps, etc.
Driving on an incline road, curved road,
etc.
Driving through a roadside with trees or
streetlights.
OCN7073241L
The adverse road conditions cause
excessive vehicle vibrations while
driving.
Your vehicle height is low or high due to
heavy loads, abnormal tire pressure,
etc.
Driving through a narrow road where
trees or grass or overgrown.
There is interference by
electromagnetic waves, such as driving
in an area with strong radio waves or
electrical noise.
OADAS002SD
7-12
CarManuals2.com
7
OCN7073244L
OADAS005SD
Forward Collision-Avoidance Assist
may not detect other vehicles, powered
two-wheeler, pedestrians or cyclists in
front of you when driving on a curve
and may not activate a warning or
brake your vehicle when needed.
When driving on a curved road, always
maintain a safe distance from others on
the road. Reduce your vehicle speed or
steer your vehicle as needed.
OCN7073245L
If a vehicle, powered two-wheeler,
pedestrian or cyclist is detected in the
next lane or outside the lane when
driving on a curved road, Forward
Collision-Avoidance Assist may warn
you and may brake your vehicle even
when not needed.
Always check road conditions, and if
necessary, take appropriate actions to
OADAS006SD
drive safely.
OCN7073242L
7-13
CarManuals2.com
Driver assistance system
Driving on an inclined road
OCN7073246L
OADAS063SD
Forward Collision-Avoidance Assist
may not detect other vehicles, powered
two-wheeler, pedestrians or cyclists in
front of you while driving uphill or
downhill.
This may result in unnecessary warning
or braking assist, or no warning or
braking assist when needed.
Also, vehicle speed may rapidly
decrease when a vehicle, powered
two-wheeler, pedestrian or cyclist
ahead is suddenly detected. Always
OCN7073243L
maintain a safe distance from the
others on the road. Adjust your vehicle
speed or steer your vehicle depending
on the road conditions.
OADAS007SD
7-14
CarManuals2.com
7
Changing lanes
OADAS033SD
OADAS032SD
[A] Your vehicle
[B] Lane changing vehicle
[A] Your vehicle
[C] Same lane vehicle
[B] Lane changing vehicle
When a vehicle or powered
When a vehicle moves into your lane
two-wheeler in front of you merges out
from an adjacent lane, it cannot be
of the lane, Forward
detected by the sensor until it is in the
Collision-Avoidance Assist may not
sensor's detection range. Forward
immediately detect the vehicle that is
Collision-Avoidance Assist may not
now in front of you.
immediately detect the vehicle or
powered two-wheeler when the vehicle
In this case, you must maintain a safe
changes lanes abruptly.
braking distance, and if necessary,
steer your vehicle and depress the
In this case, you must maintain a safe
brake pedal to reduce your driving
braking distance, and if necessary,
speed in order to maintain a safe
steer your vehicle and depress the
distance.
brake pedal to reduce your driving
speed in order to maintain a safe
distance.
7-15
CarManuals2.com
Driver assistance system
Detecting a vehicle
WARNING
• When you are towing a trailer or
another vehicle, turn off Forward
Collision-Avoidance Assist.
• Forward Collision-Avoidance Assist
may operate if objects that are similar
in shape or characteristics to vehicles,
powered two-wheelers, pedestrians
are detected.
• Forward Collision-Avoidance Assist
may not detect bicycles, motorcycles,
OCN7073218L
or smaller wheeled objects such as
Forward Collision-Avoidance Assist
luggage bags, shopping carts, or
may not be able to detect all potential
strollers.
hazards, like if the vehicle in front of
• Forward Collision-Avoidance Assist
you has cargo that extends rearward
may not operate normally if there is
past the end of the vehicle or if the
interference from strong
vehicle in front of you has higher
electromagnetic waves.
ground clearance. Always maintain a
• Forward Collision-Avoidance Assist
safe distance from the vehicles ahead.
may not operate for 15 seconds right
Adjust your vehicle speed or steer your
after your vehicle is started or when the
vehicle depending on the road
front view camera is initialized.
conditions.
7-16
CarManuals2.com
7
Junction Turning function
Forward Collision
Avoidance Assist (FCA)
(Sensor fusion)
if equipped
Basic function
OCN7061111L
Junction Turning function can help avoid
a collision with an oncoming vehicle in an
adjacent lane when turning left at a
crossroad with the turn signal on by
applying emergency braking.
OCN7061164L
Direct Oncoming function
Forward Collision-Avoidance Assist
detects a vehicle, a powered two-wheeler
a pedestrian, or a cyclist ahead on the
road and may warn you of a possible
collision with a warning message on the
instrument cluster and a warning sound.
Also, Forward Collision-Avoidance Assist
may assist with braking your vehicle to
help reduce collision speed or avoid a
collision.
OCN7073201
[A] Oncoming vehicle
Direct Oncoming function helps reduce
the speed at the collision when a vehicle
approaching from the opposite side is
detected.
7-17
CarManuals2.com

















Content      ..     1      2      3      4      ..
