05
Using a cellular phone or a twoway
radio
When a cellular phone is used inside
the vehicle, noise may be produced
from the audio system. This does not
mean that something is wrong with the
audio equipment. In such a case, use
the cellular phone at a place as far as
possible from the audio equipment.
OJF045311L
NOTICE
Station Swapping As a FM signal
When using a communication system
weakens, another more powerful
such as a cellular phone or a radio set
signal near the same frequency may
inside the vehicle, a separate external
begin to play. This is because your
antenna must be fitted. When a cellular
radio is designed to lock onto the
phone or a radio set is used with an
clearest signal. If this occurs, select
internal antenna alone, it may interfere
another station with a stronger signal.
with the vehicle’s electrical system and
adversely affect safe operation of the
Multi-Path Cancellation Radio
vehicle.
signals being received from several
directions can cause distortion or
fluttering. This can be caused by a
WARNING
direct and reflected signal from the
Do not use a cellular phone while
same station, or by signals from two
stations with close frequencies. If this
driving. Stop at a safe location to use a
cellular phone.
occurs, select another station until the
condition has passed.
5-119

-------------------------------------------------------------------------------------------------------------------------------------------------------------

6.Driving Your Vehicle
Before Driving
6-4
Before Entering the Vehicle
6-4
Before Starting
6-4
Engine Start/Stop Button
6-5
Vehicle Auto-Shut Off
6-11
Operating Conditions
6-11
Deactivating Conditions
6-11
System Operation
6-11
Manual Transmission
6-12
Manual Transmission Operation
6-12
Good Driving Practices
6-14
Rev Matching
6-15
Dual Clutch Transmission
6-18
Dual Clutch Transmission Operation
6-18
LCD Display for Transmission Temperature and Warning Message
6-20
Parking
6-26
Paddle Shifter (Manual Shift Mode)
6-26
Good Driving Practices
6-27
Brake System
6-28
Power Brakes
6-28
Disc Brakes Wear Indicator
6-28
High Performance Brake
6-29
6
Parking Brake
6-29
Anti-lock Brake System (ABS)
6-31
Electronic Stability Control (ESC)
6-32
Vehicle Stability Management (VSM)
6-37
Hill-Start Assist Control (HAC)
6-38
Good Braking Practices
6-39
Electronic Control Suspension (ECS)
6-40
Electronic Limited Slip Differential
6-41
Warning messages
6-42
N Button
6-43
N1/N2 Button Settings
6-43

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Drive Mode Integrated Control System
6-44
Drive Mode
6-44
N Mode
6-46
NGS (N Grin Shift)
6-48
Vehicle Characteristic
6-49
Performance Option
6-51
Performance Option Settings
6-51
Launch Control
6-52
Shift Light
6-55
N Track Sense Shift (for DCT)
6-57
N Power Shift (for DCT)
6-59
N Sound Equalizer
6-59
Maximum Performance Driving
(How to drive with Octane Number Learning)
6-61
Special Driving Conditions
6-62
Hazardous Driving Conditions
6-62
Rocking the Vehicle
6-62
Smooth Cornering
6-63
Driving at Night
6-63
Driving in the Rain
6-63
Driving in Flooded Areas
6-64
Highway Driving
6-64
6
Winter Driving
6-65
Snow or Icy Conditions
6-65
Winter Precautions
6-67
Vehicle Load Limit
6-69
Tire Loading Information Label
6-70
Trailer Towing
6-73

-------------------------------------------------------------------------------------------------------------------------------------------------------------

06
WARNING
Carbon monoxide (CO) gas is toxic. Breathing CO can cause unconsciousness and
death.
Engine exhaust contains carbon monoxide which cannot be seen or smelled.
Do not inhale engine exhaust.
If at any time you smell engine exhaust inside the vehicle, open the windows
immediately. Exposure to CO can cause unconsciousness and death by asphyxiation.
Be sure the exhaust system does not leak.
The exhaust system should be checked whenever the vehicle is raised to change the
oil or for any other purpose. If you hear a change in the sound of the exhaust or if you
drive over something that strikes the underneath side of the vehicle, have the exhaust
system checked as soon as possible by an authorized HYUNDAI dealer.
Do not run the engine in an enclosed area.
Letting the engine idle in your garage, even with the garage door open, is a hazardous
practice. Run the engine only long enough to start the engine and to move the vehicle
out of the garage.
Avoid idling the engine for prolonged periods with people inside the vehicle.
If it is necessary to idle the engine for a prolonged period with people inside the
vehicle, be sure to do so only in an open area with the air intake set at "Fresh" and fan
control set to high so fresh air is drawn into the interior.
Keep the air intakes clear.
To assure proper operation of the ventilation system, keep the ventilation air intakes
located in front of the windshield clear of snow, ice, leaves, or other obstructions.
If you must drive with the trunk open:
Close all windows.
Open instrument panel air vents.
Set the air intake control at "Fresh", the air flow control at "Floor" or "Face", and the fan
control set to high.
WARNING
CALIFORNIA PROPOSITION 65 WARNING
Engine exhaust and a wide variety of automobile components including
components found in the interior furnishings in a vehicle, contain or emit harmful
chemicals known to the State of California to cause cancer and birth defects and
reproductive harm. In addition, certain fluids contained in vehicles and certain
products of components contain or emit chemicals known to the State of California
to cause cancer and birth defects or other reproductive harm.
6-3

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving Your Vehicle
BEFORE DRIVING
Before Entering the Vehicle
WARNING
• Be sure all windows, outside mirror(s),
To reduce the risk of SERIOUS INJURY or
and outside lights are clean and
DEATH, take the following precautions:
unobstructed.
ALWAYS wear your seat belt. All
• Remove frost, snow, or ice.
passengers must be properly belted
• Visually check the tires for uneven
whenever the vehicle is moving.
wear and damage.
For more information, refer to "Seat
• Check under the vehicle for any sign
Belts" in chapter 3.
of leaks.
Always drive defensively. Assume
• Be sure there are no obstacles behind
other drivers or pedestrians may be
careless and make mistakes.
you if you intend to back up.
Stay focused on the task of driving.
Before Starting
Driver distraction can cause
accidents.
Make sure the hood, the trunk, and
the doors are securely closed and
Leave plenty of space between you
locked.
and the vehicle in front of you.
Adjust the position of the seat and
steering wheel.
WARNING
Adjust the inside and side view
NEVER drink alcohol or take drugs and
mirrors.
drive.
Verify all the lights work.
Drinking alcohol or taking drugs and
Fasten your seatbelt. Check that
driving is dangerous and may result in
all passengers have fastened their
an accident and SERIOUS INJURY or
seatbelts.
DEATH.
Check the gauges and indicators
Drunk driving is the number one
in the instrument panel and the
contributor to the highway death
messages on the instrument display
toll each year. Even a small amount
when the Engine Start/Stop button is
of alcohol will affect your reflexes,
in the ON position.
perceptions and judgment. Just
Check that any items you are carrying
one drink can reduce your ability to
are stored properly or fastened down
respond to changing conditions and
securely.
emergencies and your reaction time
gets worse with each additional drink.
Driving while under the influence
of drugs is as dangerous or more
dangerous than driving under the
influence of alcohol.
You are much more likely to have a
serious accident if you drink or take
drugs and drive. If you are drinking or
taking drugs, don't drive. Do not ride
with a driver who has been drinking
or taking drugs. Choose a designated
driver or call a taxi.
6-4

-------------------------------------------------------------------------------------------------------------------------------------------------------------

06
ENGINE START/STOP BUTTON
WARNING
NEVER press the Engine Start/Stop
button while the vehicle is in motion
except in an emergency. This will
result in the engine turning off and
loss of power assist for the steering
and brake systems.
This may lead to loss of directional
control and braking function, which
could cause an accident.
OCN7060003
Before leaving the driver's seat,
Whenever the front door is opened, the
always make sure the shift lever is in
Engine Start/Stop button will illuminate
the P (Park) position, set the parking
and will go off 30 seconds after the door
brake, press the Engine Start/Stop
is closed. (if equipped)
button to the OFF position, and take
the Smart Key with you. Unexpected
vehicle movement may occur if these
WARNING
precautions are not followed.
To reduce risk of serious injury or death,
NEVER reach through the steering
NEVER allow children or any person
wheel for the Engine Start/Stop
who is unfamiliar with the vehicle to
button or any other control while the
touch the Engine Start/Stop button or
vehicle is in motion. The presence
related parts. Unexpected and sudden
of your hand or arm in this area
vehicle movement can occur.
may cause a loss of vehicle control
resulting in an accident.
WARNING
To turn the engine off in an emergency:
Press and hold the Engine Start/Stop
button for more than two seconds OR
rapidly press and release the Engine
Start/Stop button three times (within
three seconds).
If the vehicle is still moving, you can
restart the engine without depressing
the brake pedal by pressing the Engine
Start/Stop button with the shift lever in
the N (Neutral) position.
6-5

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving Your Vehicle
Engine Stop/Start button positions
- Vehicle with manual transmission
Button
Action
Notes
Position
To turn off the engine, stop the vehicle
If the steering wheel is not locked
and then press the Engine Start/Stop
properly when you open the driver's
OFF
button.
door, the warning chime will sound.
The steering wheel locks to protect
the vehicle from theft.
Press the Engine Start/Stop button
If you leave the Engine Start/Stop
when the button is in the OFF position
button in the ACC position for more
without depressing the clutch pedal.
than one hour, the battery power will
Some of the electrical accessories are
turn off automatically to prevent the
usable.
battery from discharging.
ACC
The steering wheel unlocks.
If the steering wheel doesn't unlock
properly, the Engine Start/Stop button
will not work.
Press the Engine Start/Stop button
while turning the steering wheel right
and left to release.
Press the Engine Start/Stop button
Do not leave the Engine Start/Stop
while it is in the ACC position without
button in the ON position when the
ON
depressing the clutch pedal.
engine is not running to prevent the
The warning lights can be checked
battery from discharging.
before the engine is started.
To start the engine, depress the clutch
If you press the Engine Start/Stop
and brake pedals and press the Engine
button without depressing the clutch
Start/ Stop button with the shift lever
pedal, the engine does not start and
START
in neutral.
the Engine Start/Stop button changes
as follows:
OFF → ACC → ON → OFF or ACC
6-6

-------------------------------------------------------------------------------------------------------------------------------------------------------------

06
Engine Stop/Start button positions
- Vehicle with dual clutch transmission
Button
Action
Notes
Position
To turn off the engine, press the
If the steering wheel is not locked
Engine Start/Stop with shift lever is in
properly when you open the driver’s
OFF
P (Park). The steering wheel locks to
door, the warning chime will sound.
protect the vehicle from theft.
Press the Engine Start/Stop button
If you leave the Engine Start/Stop
when the button is in the OFF position
button in the ACC position for more
without depressing the brake pedal.
than one hour, the battery power will
Some electrical accessories are
turn off automatically to prevent the
usable.
battery from discharging.
ACC
The steering wheel unlocks.
If the steering wheel doesn’t unlock
properly, the Engine Start/Stop button
will not work. Press the Engine Start/
Stop button while turning the steering
wheel right and left to release tension.
Press the Engine Start/Stop button
Do not leave the Engine Start/Stop
while it is in the ACC position without
button in the ON position when the
ON
depressing the brake pedal.
engine is not running to prevent the
The warning lights can be checked
battery from discharging.
before the engine is started.
To start the engine, depress the brake
If you press the Engine Start/Stop
pedal and press the Engine Start/Stop
button without depressing the brake
button with the shift lever in the P
pedal, the engine does not start and
START
(Park) or in the N (Neutral) position.
the Engine Start/Stop button changes
For your safety, start the engine with
as follows:
the shift lever in the P (Park) position.
OFF → ACC → ON → OFF or ACC
6-7

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving Your Vehicle
Starting the engine
Vehicle with manual transmission:
1. Always carry the smart key with you.
2. Make sure the parking brake is
WARNING
applied.
Always wear appropriate shoes when
3. Make sure the shift lever is in neutral.
operating your vehicle.
4. Depress the clutch and brake pedals.
Unsuitable shoes, such as high heels,
ski boots, sandals, flip-flops, etc.,
5. Press the Engine Start/Stop button.
may interfere with your ability to use
the brake and accelerator pedals.
Information
Do not start the vehicle with the
accelerator pedal depressed. The
Depress the brake pedal and clutch pedal
vehicle can move and lead to an
until the engine starts.
accident.
Vehicle with dual clutch transmission:
Wait until the engine rpm is normal.
The vehicle may suddenly move if
1. Always carry the smart key with you.
the brake pedal is released when the
2. Make sure the parking brake is
rpm is high.
applied.
3. Make sure the shift lever is in P (Park).
Information
4. Depress the brake pedal.
The engine will start by pressing the
5. Press the Engine Start/Stop button.
Engine Start/Stop button, only when
the smart key is in the vehicle.
Information
Even if the smart key is in the vehicle,
if it is far away from the driver, the
Do not wait for the engine to warm up
engine may not start.
while the vehicle remains stationary.
Start driving at moderate engine
When the Engine Start/Stop button
speeds. (Aggressive accelerating and
is in the ACC or ON position, if any
decelerating should be avoided.)
door is open, the system checks for the
smart key. If the smart key is not in the
Always start the vehicle with your foot
vehicle, the “
” indicator will blink
on the brake pedal. Do not depress the
and the warning "Key not in vehicle"
accelerator while starting the vehicle.
will come on and if all doors are closed,
Do not rev the engine while warming
the chime will also sound for about
it up.
5 seconds. Keep the smart key in the
vehicle when using the ACC position or
if the vehicle engine is ON.
6-8

-------------------------------------------------------------------------------------------------------------------------------------------------------------

06
NOTICE
To prevent damage to the vehicle:
If the engine stalls while you are in
motion, do not attempt to move the
shift lever to the P (Park) position.
If traffic and road conditions permit,
you may put the shift lever in the N
(Neutral) position while the vehicle
is still moving and press the Engine
Start/Stop button in an attempt to
restart the engine.
OCN7N061250N
Do not push or tow your vehicle to
start the engine.
Information
If the smart key battery is weak or the
NOTICE
smart key does not work correctly, you
To prevent damage to the vehicle:
can start the engine by pressing the Engine
Start/Stop button with the smart key in
When the stop lamp switch fuse is
blown, you can't start the engine
the direction of the picture above.
normally. Replace the fuse with a new
one. If you are not able to replace
the fuse, you can start the engine by
Turning off the engine
pressing and holding the Engine Start/
Vehicle with manual transmission:
Stop button for 10 seconds with the
Engine Start/Stop button in the ACC
1. Stop the vehicle and depress the
clutch and brake pedals at the same
position.
time.
Do not press the Engine Start/Stop
button for more than 10 seconds except
2. With the clutch and brake pedals
when the stop lamp switch fuse is
depressed, put the shift lever in
blown.
neutral.
For your safety always depress the
3. Press the Engine Start/Stop button to
brake pedal before starting the engine.
the off position and apply the parking
brake.
Vehicle with Dual clutch transmission:
1. Stop the vehicle and depress the
brake pedal fully.
2. Make sure the gear is in P(Park).
3. Press the Engine Start/Stop button
to the OFF position and apply the
parking brake.
6-9

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving Your Vehicle
Remote start
To start the vehicle remotely:
1. Press the door lock button within 10 m
(32 feet) from the vehicle.
2. Press the remote start (
) button for
over 2 seconds within 4 seconds after
locking the doors. The hazard warning
lights will blink.
3. To turn off the remote start function,
press the remote start (
) button
once.
• The remote start (
) button may not
operate if the smart key is not within
OCN7060005
10 m (32 feet).
You can start the vehicle using the
• The vehicle will not remotely start if
Remote Start button of the smart key.
the engine hood or trunk is opened.
• The vehicle must be in P (Park) for the
remote start function to start.
• The engine turns off if you get in the
vehicle without a registered smart key.
• The engine turns off if you do not get
in the vehicle within 10 minutes after
remotely starting the vehicle.
• Do not idle the engine for a long
period.
6-10

-------------------------------------------------------------------------------------------------------------------------------------------------------------

06
VEHICLE AUTO-SHUT OFF
If your vehicle is parked and the engine
System Operation
is left on for a long period of time, the
engine will turn off automatically to help
reduce fuel consumption and prevent
accidents caused by carbon dioxide
poisoning.
Operating Conditions
Vehicle Auto-Shut Off timer operates
when all the following conditions are
satisfied:
• Vehicle speed is below 1.8 mph (3
km/h), and the gear is shifted to P
OJK041087N
(Park)
When all the conditions are satisfied, the
• The brake pedal and accelerator pedal
Vehicle Auto-Shut Off operates and turns
are not depressed
the engine off automatically after 60
minutes.
• The driver’s seat belt is unfastened
A timer appears on the instrument
• The passenger seat is empty
cluster 30 minutes before vehicle shut
• The infotainment system is being
off.
updated
Resetting cluster timer
Deactivating Conditions
To reset the cluster timer, do one of
Vehicle Auto-Shut Off timer turns off
following:
when one of the situation occur:
• Release the accelerator pedal or brake
• Vehicle speed is above 1.8 mph (3
pedal after Vehicle Auto-Shut Off is
km/h)
complete.
• The gear is shifted to R (Reverse), D
• Press the OK button on the steering
(Drive) or N (Neutral)
wheel while the timer appears on the
• The brake pedal or accelerator pedal
instrument cluster.
is depressed
• The driver’s seat belt is fastened
CAUTION
• A passenger is in the passenger’s seat
Do not leave a passenger or a pet in
the vehicle in hot weather since the air
conditioning system turns off when the
engine is off.
6-11

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving Your Vehicle
MANUAL TRANSMISSION (IF EQUIPPED)
Manual Transmission Operation
The manual transmission has 6
forward gears. The transmission is fully
synchronized in all forward gears so
shifting to either a higher or a lower gear
is easily accomplished.
WARNING
Before leaving the driver’s seat,
always make sure the shift lever is in
OCN7N060001
1st gear when the vehicle is parked
The shift lever can be moved without
on a uphill and in R (Reverse) on a
pressing the button (1).
downhill, set the parking brake, and
The button (1) must be pressed while
place the Engine Start/Stop button
moving the shift lever.
in the OFF position. Unexpected
vehicle movement may occur if these
precautions are not followed.
When parking on an incline, block
the wheels to prevent the vehicle
from rolling down.
To shift to R (Reverse), make sure the
vehicle has completely stopped, and
then move the shift lever to neutral
before moving into R (Reverse).
When you've come to a complete stop
and it's hard to shift into 1st gear or R
(Reverse):
1. Put the shift lever in neutral and
release the clutch pedal.
2. Depress the clutch pedal, and then
shift into first or R (Reverse) gear.
Information
During cold weather, shifting may be
difficult until the transmission lubricant
has warmed up.
6-12

-------------------------------------------------------------------------------------------------------------------------------------------------------------

06
Using the clutch
Downshifting
The clutch pedal should be depressed all
Down shift to a lower gear when slowing
the way before:
down in heavy traffic or driving up a
steep hill to prevent high engine loads.
- Starting the engine
Also, downshifting reduces the chance
The engine will not start without
of stalling and helps to reaccelerate the
depressing the clutch pedal.
vehicle when you need to increase your
- Shifting into gear, up shifting to the
speed.
next higher gear, or down shifting to
When the vehicle is going downhill,
the next low gear.
downshifting helps maintain safe speed
by providing a load from the engine and
When releasing the clutch pedal, release
results in less wear on the brakes.
it slowly. The clutch pedal should always
be fully released while driving.
NOTICE
NOTICE
To prevent damage to the engine,
clutch and transmission:
To prevent unnecessary wear or
damage to the clutch:
When downshifting from 5th
gear to 4th gear, be careful not to
Do not rest your foot on the clutch
inadvertently push the shift lever
pedal while driving.
sideways engaging the 2nd gear.
Do not hold the vehicle with the
A drastic downshift may cause the
clutch on an incline, while waiting for
engine speed to increase to the point
the traffic light, etc.
the tachometer will enter the red-
Always depress the clutch pedal
zone and may cause engine damage.
down fully to prevent noise or
Do not downshift more than two
damage.
gears at a time or downshift the
Do not start with the 2nd (second)
gear when the engine is running at
gear engaged except when you start
high speed (5,000 RPM or higher).
on a slippery road.
Such downshifting may damage the
engine, clutch and the transmission.
Do not drive with cargo loaded more
than the recommended loading
capacity.
Make sure to depress the clutch
pedal until the engine starts
completely. If you release the clutch
pedal before the engine starts
completely, the engine may stop.
6-13

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving Your Vehicle
Good Driving Practices
WARNING
Never take the vehicle out of gear and
Do not use the engine brake (shifting
coast down a hill. This is extremely
from a higher gear to lower gear)
dangerous.
rapidly on slippery roads. The vehicle
Don't "ride" the brakes. This can
may slip causing an accident.
cause the brakes and related parts to
overheat and malfunction.
WARNING
When you are driving down a long hill,
slow down and shift to a lower gear.
To reduce the risk of SERIOUS INJURY
Engine braking will help slow down
or DEATH:
the vehicle.
ALWAYS wear your seat belt. In a
Slow down before shifting to a lower
collision, an unbelted occupant
gear. This will help avoid over-revving
is significantly more likely to be
the engine, which can cause damage.
seriously injured or killed than a
properly belted occupant.
Slow down when you encounter cross
winds. This gives you much better
Avoid high speeds when cornering or
control of your vehicle.
turning.
Be sure the vehicle is completely
Do not make quick steering wheel
stopped before you shift into R
movements, such as sharp lane
(Reverse) to prevent damage to the
changes or fast, sharp turns.
transmission.
The risk of rollover is greatly
Exercise extreme caution when
increased if you lose control of your
driving on a slippery surface. Be
vehicle at highway speeds.
especially careful when braking,
Loss of control often occurs if two or
accelerating or shifting gears. On a
more wheels drop off the roadway
slippery surface, an abrupt change
and the driver over steers to reenter
in vehicle speed can cause the drive
the roadway.
wheels to lose traction and may cause
In the event your vehicle leaves
loss of vehicle control resulting in an
the roadway, do not steer sharply.
accident.
Instead, slow down before pulling
back into the travel lanes.
HYUNDAI recommends you follow all
posted speed limits.
6-14

-------------------------------------------------------------------------------------------------------------------------------------------------------------

06
Rev Matching
2. Select Drive Mode.
The Rev Matching system automatically
REV indicator
helps synchronize engine rpm with the
optimal speed of the gearabout to be
engaged which reduces the impact of
clutch connection and improves gear
shift response.
Information
Fully depress the clutch pedal. Without
the clutch pedal fully depressed, the
system may not respond correctly.
OCN7N061257N
The system does not operate when
DRIVE MODE button
backing up.
Rev Matching controls the engine speed
up to the rev limit, but the function
cannot prevent over-revving caused by
shifting mistake.
Rev Matching activation
OCN7N061218
OCN7N071148L
1. Press REV button (ON/OFF)
• Press the REV button to turn on the
system. A message appears "Rev
Matching On" with a REV indicator on
the cluster LCD display.
• Press the REV button again to turn off
the system. A message appears "Rev
Matching Off" and the REV indicator
disappears.
6-15

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving Your Vehicle
DRIVE MODE button
N1 button
Use Rev Matching in normal driving
conditions in below modes.
• When ECO mode is selected:
- Rev Matching cannot be activated
even if the driver presses the REV
button.
- REV indicator is off.
• When NORMAL mode is selected:
- Rev Matching activates if Rev
OCN7N061208
Matching is turned on by the REV
N2 button
button.
- White REV indicator illuminates.
- Engine rpm response during gear
shift is smooth.
• When SPORT mode is selected:
- Rev Matching activates if Rev
Matching is turned on by the REV
button.
- Yellow REV indicator illuminates.
OCN7N071130L
- Engine rpm response is faster than
NORMAL mode.
REV indicator
The system must be turned on by
pressing the REV button whenever the
engine is turned on.
Information
If N1 or N2 button is set to ‘Drive mode’
from the infotainment system, the drive
mode can be selected by pressing N1 or N2
button.
OCN7N061257N
For more details, please refer to the
infotainment system manual separately
Information
supplied.
Set N1 or N2 button from the infotainment
system, then N mode can be selected
by pressing N1 or N2 button. For more
details, please refer to the infotainment
system manual separately supplied.
6-16

-------------------------------------------------------------------------------------------------------------------------------------------------------------

06
N button (N1/N2 button)
Rev Matching operation
Use Rev Matching when driving on race
Engine speed is automatically
tracks, etc. in N mode.
synchronized with the next selected
• When N mode (SPORT+) is selected:
gear. The accelerator pedal does not
have to be depressed to speed up the
- REV Matching is turned on
engine RPM.
automatically. To turn off Rev
Matching, press the REV button.
• Clutch depressed with the gear
engaged
- Red REV indicator illuminates.
At once, engine speed automatically
- Engine speed is automatically
decreases right after the clutch is
adjusted to the shifted gear without
disengaged, but the selected gear is
the accelerator pedal depressed.
fixed and then the engine RPM reverts
- Engine RPM response is faster than
to the selected gear’s target speed.
SPORT mode when downshifting
This operation method gives more
with heavy braking such as when
comfortable feeling in public road
driving on a race track.
driving.
• When CUSTOM mode (CUSTOM 1/
• Up shifting
CUSTOM 2) is selected:
Engine speed will automatically
- You may select the drive mode you
decrease and stay at the target engine
prefer from the infotainment system
speed before the clutch is engaged.
screen Custom setting page. (OFF/
• Down shifting
NORMAL/SPORT/ SPORT+).
Engine speed will automatically
For more details on “Custom Mode”
increase and stay at the target engine
refer to the infotainment system
speed.
manual separately supplied.
Warning message
OCN7N061224L
Downshift Alert. Downshifting at high
RPMs may result in engine damage.
If transmission input rpm is too high
(over rev limit) due to shifting, a warning
message will appear and a warning
chime will sound.
6-17

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving Your Vehicle
DUAL CLUTCH TRANSMISSION (IF EQUIPPED)
OCN7N061252L
Depress the brake pedal and press the shift lever while moving the shift lever.
Press the shift lever while moving the shift lever.
The shift lever can freely operate.
Dual Clutch Transmission Operation
The dual clutch transmission has 8 forward speeds and one reverse speed.
The individual speeds are selected automatically in the D (Drive) position.
6-18

-------------------------------------------------------------------------------------------------------------------------------------------------------------

06
The dual clutch transmission gives the
WARNING
driving feel of a manual transmission,
To reduce the risk of serious injury or
yet provides the ease of a fully
death:
automatic transmission. Unlike a
ALWAYS check the surrounding
traditional automatic transmission,
areas near your vehicle for people,
the gear shifting can be felt (and
especially children, before shifting a
heard) on the dual clutch transmission
vehicle into D (Drive) or R (Reverse).
- Think of it as an automatically
Before leaving the driver’s seat,
shifting manual transmission.
always make sure the shift lever
- Shift into Drive range and get
is in the P (Park) position, then set
fully automatic shifting, similar
the parking brake, and place the
to a conventional automatic
Engine Start/Stop button in the OFF
transmission
position. Unexpected and sudden
Dual clutch transmission adopts wet-
vehicle movement can occur if these
type dual clutch, which is different
precautions are not followed.
from torque converter of automatic
When using Manual Shift Mode, do
transmission, and shows better
not use engine braking (shifting from
acceleration performance during
a high gear to lower gear) rapidly on
driving. But, initial launch might
slippery roads. The vehicle may slip
be little bit slower than automatic
causing an accident.
transmission.
To avoid damage to your transaxle,
Gear shifts are sometimes more
do not try to accelerate in R (Reverse)
noticeable than a conventional
or any forward gear position with the
automatic transmission and a light
brakes on.
vibration during launching can be felt
When stopped on slope, do not hold
as the transmission speed is matched
the vehicle with accelerator pedal.
with the engine speed. This is a
Use the service brake or the parking
normal condition of the dual clutch
brake.
transmission.
The wet-type clutch transfers torque
and provides a direct driving feeling
which may feel different from a
conventional automatic transmission
with a torque converter. This may be
more noticeable when starting from a
stop or low vehicle speed.
When rapidly accelerating at low
vehicle speed, engine could rev at
high RPM depending on vehicle drive
condition.
6-19

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving Your Vehicle
• For smooth launch uphill, press
LCD Display for Transmission
down the accelerator pedal smoothly
Temperature and Warning
depending on the current conditions.
Message
• If you release your foot from the
Transmission temperature gauge
accelerator pedal at low vehicle
speed, you may feel strong engine
brake, which is similar to manual
transmission.
• When driving downhill, you may
use Manual Mode to downshift to a
lower gear in order to control your
speed without using the brake pedal
excessively.
• When you turn the engine on and off,
you may hear clicking sounds as the
system goes through a self test. This
OCN7N061225L
is a normal sound for the Dual clutch
Select trip computer mode on
transmission.
the LCD display and move to the
transmission temperature screen to
WARNING
see the temperature of the dual clutch
transmission.
Due to transmission failure, you may
not continue to drive and the position
Try to drive so that the temperature
indicator (D, R) on the cluster will blink.
gauge do not show high/overheat.
We recommend you to contact an
When the transmission is overheated,
authorized HYUNDAI dealer and have
the warning message will display
the system checked.
on the LCD. Follow the displayed
message.
The transmission temperature is
displayed in three colors (white,
orange and red) as it increases. (if
equipped with the cluster type B)
Orange temperature gauge is
displayed right before the warning
message appears on the LCD display.
(if equipped)
CAUTION
Increase (high temperature) of the
transmission temperature gauge
usually appears on an incline when
the vehicle is stopped for a long time
using accelerator pedal, without
depressing the brake pedal.
To maintain the optimal transmission
performance, drive so that the white
gauge is not exceeded. (if equipped)
6-20

-------------------------------------------------------------------------------------------------------------------------------------------------------------

06
DCT warning messages
OCN7N061227N
OCN7N061226L
Transmission high temperature
This warning message is displayed when
Under certain conditions, such as
vehicle is driven slowly on a grade and
repeated stop-and-go launches
the vehicle detects that the brake pedal
on steep grades, sudden take off
is not applied.
or acceleration, or other harsh
driving conditions, the transmission
clutch temperatures will increase
Steep grade
excessively. Finally the clutch in
Driving up hills or on steep grades:
transmission could be overheated.
• To hold the vehicle on an incline use
When the clutch is overheated, the
the foot brake or the parking brake.
safe protection mode engages and
• When in stop-and-go traffic on an
the gear position indicator on the
incline, keep some distance ahead
cluster blinks with a chime. At this
before moving the vehicle forward.
time, “Transmission temperature is
Then hold the vehicle on the incline
high! Stop safely” warning message
with the foot brake.
will appear on the LCD display and
• If the vehicle is held on a hill by
driving may not be smooth.
applying the accelerator pedal
or by creeping with brake pedal
disengaged, the clutch and
transmission may overheat which
can result in damage. At this time, a
warning message will appear on the
LCD display.
• If the LCD warning is active, the foot
brake must be applied.
• Ignoring the warnings can lead to
damage to the transmission.
6-21

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving Your Vehicle
If this occurs, pull over to a safe
Transmission overheated
location, stop the vehicle with the
• If the vehicle continues to be driven
engine running, apply the brakes and
and the clutch temperatures reach
shift the vehicle to P (Park), and allow
the maximum temperature limit, the
the transmission to cool.
"Transmission hot! Park with engine
If you ignore this warning, the driving
On" warning will be displayed. When
condition may become worse.
this occurs the clutch is disabled
You may experience abrupt shifts,
until the clutch cools to normal
frequent shifts, or jerkiness. To return
temperatures.
to the normal driving condition, stop
• The warning will display a time to wait
the vehicle and apply the foot brake
for the transmission to cool.
or shift into P (Park). Then allow the
• If this occurs, pull over to a safe
transmission to cool for a few minutes
location, stop the vehicle with the
with engine on, before driving off.
engine running, apply the brakes and
When possible, drive the vehicle
shift the vehicle to P (Park), and allow
smoothly.
the transmission to cool.
• When the message "Transmission
cooled down. Resume driving"
appears you can continue to drive
your vehicle.
• When possible, drive the vehicle
smoothly.
If any of the warning messages in the
LCD display continue to blink, for your
safety, contact an authorized HYUNDAI
dealer and have the system checked.
OCN7N061225L
OCN7N061228L
OCN7N061229L
6-22

-------------------------------------------------------------------------------------------------------------------------------------------------------------

06
Transmission ranges
R (Reverse)
The indicator in the instrument cluster
Use this position to drive the vehicle
displays the shift lever position when the
backward.
Engine Start/Stop button is in the ON
position.
NOTICE
Always come to a complete stop before
P (Park)
shifting into or out of R (Reverse); you
Always come to a complete stop before
may damage the transaxle if you shift
shifting into P (Park).
into R (Reverse) while the vehicle is in
To shift from P (Park), you must depress
motion.
firmly on the brake pedal and make sure
your foot is off the accelerator pedal.
N (Neutral)
If you have done all of the above and
The wheels and transaxle are not
still cannot shift the lever out of P
engaged.
(Park), see "Shift-Lock Release" in this
Use N (Neutral) if you need to restart a
chapter.
stalled engine, or if it is necessary to stop
The shift lever must be in P (Park) before
with the engine ON. Shift into P (Park)
turning the engine off.
if you need to leave your vehicle for any
reason.
Always depress the brake pedal when
WARNING
you are shifting from N (Neutral) to
Shifting into P (Park) while the
another gear.
vehicle is in motion may cause you to
lose control of the vehicle.
After the vehicle has stopped, always
make sure the shift lever is in P
(Park), apply the parking brake, and
turn the engine off.
Do not use the P (Park) position in
place of the parking brake.
6-23

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving Your Vehicle
D (Drive)
This is the normal driving position. The
transmission will automatically shift
through a 8-gear sequence, providing
the best fuel economy and power.
For extra power when passing another
vehicle or driving uphill, depress the
accelerator fully. The transmission will
automatically downshift to the next
lower gear (or gears, as appropriate).
The DRIVE MODE switch, located on the
OCN7N061252L
shift lever console, allows the driver to
Manual shift mode
switch from NORMAL mode to ECO or
Whether the vehicle is stationary or
SPORT mode (if equipped)
in motion, sports mode is selected by
For more information, refer to "Drive
pushing the shift lever from the D (Drive)
Mode Integrated Control System" later
position into the manual gate. To return
in this chapter.
to D (Drive) range operation, push the
shift lever back into the main gate.
WARNING
In manual shift mode, moving the shift
lever backwards and forwards will allow
Do not shift into gear unless your
you to select the desired range of gears
foot is firmly on the brake pedal.
for the current driving conditions.
Shifting into gear when the engine
Up (+) : Pull the lever backwards once
is running at high speed can cause
to shift up one gear.
the vehicle to move very rapidly. You
Down (-) : Push the lever forward once
may lose control of the vehicle and
to shift down one gear.
cause accidents.
Do not drive with the shift lever in N
(Neutral). The engine brake will not
work and may lead to an accident.
NOTICE
Always make sure the vehicle is
stationary, at a complete stop, before
selecting D (Drive).
6-24

-------------------------------------------------------------------------------------------------------------------------------------------------------------

06
Shift-lock release
Information
If the shift lever cannot be moved from
Only the eight forward gears can be
the P (Park) position into R (Reverse)
selected. To reverse or park the vehicle,
position with the brake pedal depressed,
move the shift lever to the R (Reverse)
continue depressing the brake, and then
or P (Park) position as required.
do the following:
Downshifts are made automatically
when the vehicle slows down. When the
vehicle stops, 1st gear is automatically
selected.
When the engine RPM approaches the
red zone the transmission will upshift
automatically.
If the driver presses the lever to + (Up)
or - (Down) position, the transmission
may not make the requested gear
change if the next gear is outside of
the allowable engine RPM range.
OCN7N061253L
The driver must execute upshifts in
1. Set the Engine Start/Stop button in
accordance with road conditions,
the OFF position
taking care to keep the engine RPM
below the red zone.
2. Apply the parking brake.
3. Carefully remove the shift lever boots.
Shift-lock system
4. Move the shift lever while holding
For your safety, the dual clutch
the release button (1) with a tool (for
transmission has a shift-lock system
example, flathead screw-driver).
which prevents shifting the transmission
If you need to use the shift-lock release,
from P (Park) into R (Reverse) unless the
we recommend that the system be
brake pedal is depressed.
inspected by an authorized HYUNDAI
To shift the transmission from P (Park)
dealer immediately.
into R (Reverse):
1. Depress and hold the brake pedal.
CAUTION
2. Start the engine or place the Engine
Be careful not to damage the trim
Start/Stop button in the ON position.
beside of the shift lever while removing
3. Move the shift lever.
the shift lever boots.
6-25

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving Your Vehicle
Parking
Paddle Shifter (Manual Shift
Always come to a complete stop and
Mode) (if equipped)
continue to depress the brake pedal.
Move the shift lever into the P (Park)
position, apply the parking brake, and set
the Engine Start/Stop button to the OFF
position. Take the Key with you when
exiting the vehicle.
WARNING
When you stay in the vehicle with
the engine running, be careful not to
depress the accelerator pedal for a long
OCN7N071061
period of time. The engine or exhaust
The paddle shifter is available when the
system may overheat and start a fire.
gear is in the D (Drive) position.
The exhaust gas and the exhaust system
are very hot. Keep away from the
With the shift lever in the D position
exhaust system components.
The paddle shifter will operate when
Do not stop or park over flammable
the vehicle speed is more than 6 mph
materials, such as dry grass, paper or
(10km/h). Pull the [+] or [-] paddle shifter
leaves. They may ignite and cause a fire.
once to shift up or down one gear and
the system changes from automatic
mode to manual mode.
When the vehicle speed is lower than
6 mph (10km/h), if you depress the
accelerator pedal for more than 5
seconds or if you move the shift lever
from D (Drive) to manual shift mode and
move it from manual shift mode to D
(Drive) again, the system changes from
manual mode to automatic mode.
When the engine reaches maximum rpm
in manual shift mode by paddle shifting
at shift lever D (driving) position, the shift
is automatically performed.
With the shift lever in the manual shift
mode
Pull the [+] or [-] paddle shifter once to
shift up or down one gear. In the manual
shift mode (+, -) position, even when the
engine reaches full speed, it does not
shift automatically.
Information
If the [+] and [-] paddle shifters are pulled
at the same time, gear shift may not occur.
6-26

-------------------------------------------------------------------------------------------------------------------------------------------------------------

06
Good Driving Practices
• Optimum vehicle performance and
economy is obtained by smoothly
Never move the shift lever from P
depressing and releasing the
(Park) or N (Neutral) to any other
accelerator.
position with the accelerator pedal
depressed.
Never move the shift lever into P
WARNING
(Park) when the vehicle is in motion.
To reduce the risk of SERIOUS INJURY
Be sure the vehicle is completely
or DEATH:
stopped before you attempt to shift
ALWAYS wear your seatbelt. In a
into R (Reverse) or D (Drive).
collision, an unbelted occupant
Do not move the shift lever to N
is significantly more likely to be
(Neutral) when driving. Doing so
seriously injured or killed than a
may result in an accident because
properly belted occupant.
of a loss of engine braking and the
Avoid high speeds when cornering or
transmission could be damaged.
turning.
When driving uphill or downhill,
Do not make quick steering wheel
always shift to D (Drive) for driving
movements, such as sharp lane
forward or shift to R (Reverse) for
changes or fast, sharp turns.
driving backwards, and check the
The risk of rollover is greatly
gear position indicated on the cluster
increased if you lose control of your
before driving. Driving in the opposite
vehicle at highway speeds.
direction of the selected gear, can
lead to a dangerous situation by
Loss of control often occurs if two or
shutting off the engine and affecting
more wheels drop off the roadway
the braking performance.
and the driver over steers to reenter
the roadway.
Do not drive with your foot resting
on the brake pedal. Even light, but
In the event your vehicle leaves
consistent pedal pressure can result
the roadway, do not steer sharply.
in the brakes overheating, brake wear
Instead, slow down before pulling
and possibly even brake failure.
back into the travel lanes.
When driving in sports mode, slow
HYUNDAI recommends you follow all
down before shifting to a lower gear.
posted speed limits.
Otherwise, the lower gear may not be
engaged if the engine RPM is outside
of the allowable range.
WARNING
Always apply the parking brake when
If your vehicle is stuck in snow, mud,
leaving the vehicle. Do not depend on
sand, etc., you may attempt to free the
placing the transmission in P (Park) to
vehicle by rocking it back and forth. Do
keep the vehicle from moving.
not attempt this procedure if people or
objects are anywhere near. Vehicle may
Exercise extreme caution when
suddenly move forward or backward as
driving on a slippery surface. Be
it becomes unstuck, causing injury or
especially careful when braking,
damage to nearby people or objects.
accelerating or shifting gears. On a
slippery surface, an abrupt change
in vehicle speed can cause the drive
wheels to lose traction and may cause
loss of vehicle control resulting in an
accident.
6-27

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving Your Vehicle
BRAKE SYSTEM
Power Brakes
Wet brakes may impair the vehicle's
ability to safely slow down; the
Your vehicle has power-assisted brakes
vehicle may also pull to one side
that adjust automatically through normal
when the brakes are applied.
usage.
Applying the brakes lightly will
If the engine is not running or is turned
indicate whether they have been
off while driving, the power assist for
affected in this way. Always test your
the brakes will not work. You can still
brakes in this fashion after driving
stop your vehicle by applying greater
through deep water. To dry the
force to the brake pedal than typical.
brakes, lightly tap the brake pedal to
The stopping distance, however, will be
heat up the brakes while maintaining
longer than with power brakes.
a safe forward speed until brake
When the engine is not running, the
performance returns to normal.
reserve brake power is partially depleted
Avoid driving at high speeds until the
each time the brake pedal is applied.
brakes function correctly.
Do not pump the brake pedal when the
power assist has been interrupted.
Disc Brakes Wear Indicator
Only pump the brakes on slippery
When your brake pads are worn and new
surfaces if the power assist has been
pads are required, you will hear a high
interrupted to maintain steering control.
pitched warning sound from your front
Do not pump the brakes on slippery
or rear brakes. You may hear this sound
surfaces if the brakes are operating
come and go or it may occur whenever
normally.
you depress the brake pedal.
Note that some driving conditions or
climates may cause a brake squeal
WARNING
when you first apply (or lightly apply)
Take the following precautions:
the brakes. This is normal and does not
Do not drive with your foot resting
indicate a problem with your brakes.
on the brake pedal. This will create
abnormal high brake temperatures,
NOTICE
excessive brake lining and pad wear,
and increased stopping distances.
To avoid costly brake repairs, do not
continue to drive with worn brake pads.
When descending down a long or
steep hill, move the gear shift lever
to Manual Shift Mode and manually
Information
downshift to a lower gear in order
Always replace brake pads as complete
to control your speed without using
front or rear axle sets.
the brake pedal excessively. Applying
the brakes continuously will cause
the brakes to overheat and could
result in a temporary loss of braking
performance.
6-28

-------------------------------------------------------------------------------------------------------------------------------------------------------------

06
High Performance Brake
Parking Brake
As this vehicles equipped with the
Applying the parking brake
High Performance Brake (applied with
material having high coefficient of
friction), noise such as a squeal, squeak
or groan is generated while braking. This
is normal and the friction may create
circle patterns on the disc surface. This
is also a normal situation which does not
affect braking performance.
NOTICE
Occasional brake noise is normal. If
OCN7080008
a continuous grinding or continuous
squeal sound is present, the
Always set the parking brake before
brake lining may be worn-out. We
leaving the vehicle, to apply:
recommend that the vehicle be
Firmly depress the brake pedal.
checked by an authorized HYUNDAI
Pull up the parking brake lever as far as
dealer.
possible.
If the vehicle has continuous
vibration or shudder in the steering
wheel while braking, we recommend
WARNING
that the vehicle be checked by an
To reduce the risk of SERIOUS INJURY
authorized HYUNDAI dealer.
or DEATH, do not operate the parking
brake while the vehicle is moving
except in an emergency situation. It
WARNING
could damage the brake system and
Frequent speeding and braking may
lead to an accident.
deform components and worn the disc
brake causing vibration when braking.
Prevent brake damage by avoiding
excessive braking. Brake wear, noise,
vibration from excessive braking or
deformation of the brakes caused
by repeatedly braking in high speed,
racing on tracks, etc., can be excluded
from warranty coverage.
6-29















Content      ..     7      8      9      10     ..
