With the central door lock switch
WARNING
Driver’s door
Do not leave children or animals
unattended in your vehicle. An enclosed
vehicle can become extremely hot,
causing death or serious injury to
unattended children or animals who
cannot escape the vehicle.
Children might operate features of the
vehicle that could injure them, or they
could encounter other harm, possibly
from someone gaining entry to the
vehicle.
OCN7N051083N
When pressing the (
) portion (1) of
the switch, all vehicle doors will lock.
WARNING
- If the smart key is in the vehicle
Always secure your vehicle.
and any door is opened, the doors
Leaving your vehicle unlocked increases
will not lock even though the lock
the potential risk to you or others from
button (1) of the central door lock
someone hiding in your vehicle.
switch is pressed.
To secure your vehicle, while
When pressing the (
) portion (2)
depressing the brake, move the shift
of the switch, all vehicle doors will
lever to the P (Park) position, engage
unlock.
the parking brake, and set the Engine
Doors indicating light (3)
Start/Stop button in the OFF position,
When all vehicle doors are locked, the
close all windows, lock all doors, and
indicating lights on the driver’s door
always take the key with you.
and passenger’s door will turn on. If
any door is unlocked, it would go off.
WARNING
If you stay in the vehicle for a long time
WARNING
while the weather is very hot or cold,
The doors should always be fully
there are risks of injuries or danger to
closed and locked while the
life. Do not lock the vehicle from the
vehicle is in motion. If the doors
outside when someone is in the vehicle.
are unlocked, the risk of being
thrown from the vehicle in a crash is
WARNING
increased.
Opening a door when something is
Do not pull the inner door handle of
approaching may cause damage or
the driver’s or passenger’s door while
injury. Be careful when opening doors
the vehicle is moving.
and watch for vehicles, motorcycles,
bicycles or pedestrians approaching the
vehicle in the path of the door.
5-29

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
Automatic Door Lock and Unlock
Child-Protector Rear Door Locks
Features
Impact sensing door unlock system
(if equipped)
All doors will be automatically unlocked
when an impact causes the air bags to
deploy.
Speed sensing door lock system (if
equipped)
All doors will be automatically locked
OCN7N051129N
when vehicle speed exceeds 9 mph (15
km/h).
The child safety lock is provided to help
prevent children seated in the rear from
You can activate or deactivate the Auto
accidentally opening the rear doors.
Door Lock/Unlock features from the User
Settings Mode on the LCD display.
The rear door safety locks should be used
whenever children are in the vehicle.
For more details, refer to “LCD Display”
in chapter 4. If your vehicle is equipped
The child safety lock is located on the
with additional navigation, please refer
edge of each rear door. When the child
to the infotainment system manual
safety lock is in the lock position, the
separately supplied.
rear door will not open if the inner door
handle is pulled.
To lock the child safety lock, insert a key
(or screwdriver) (1) into the hole and turn
it to the lock position.
To allow a rear door to be opened from
inside the vehicle, unlock the child safety
lock.
WARNING
If children accidently open the rear
doors while the vehicle is in motion,
they could fall out of the vehicle. The
rear door safety locks should always
be used whenever children are in the
vehicle.
5-30

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
REAR OCCUPANT ALERT (ROA)
Rear Occupant Alert helps prevent the
WARNING
driver from leaving a passenger in the
rear seats.
Rear Occupant Alert provides
information to the driver to check
the rear seats but it does not detect
Rear Occupant Alert Operation
whether there is an object or passenger.
Always check the rear seats when
leaving the vehicle.
Information
The open and close history of the rear
door is initialized if the driver turns off the
engine and lock vehicle doors.
However, the alarm may sound again
whenever the driver’s door is opened if the
previous history of the rear door is not
OCN7050135L
initialized.
When the driver turns off the engine and
opens the driver’s door after opening and
closing a rear door, a warning message
“Check rear seats” appears on the
cluster.
5-31

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
THEFT-ALARM SYSTEM
This system helps to protect your vehicle
Information
and valuables. The horn will sound and
the hazard warning lights will blink
Do not lock the doors until all
continuously if any of the following
passengers have left the vehicle. If the
occur:
remaining passenger leaves the vehicle
when the system is armed, the alarm
- A door is opened without using the
will be activated.
smart key.
If the vehicle is not disarmed with the
- The trunk is opened without using the
smart key, open the doors by using the
smart key.
mechanical key and start the engine by
- The engine hood is opened.
directly pressing the Engine Start/Stop
The alarm continues for 30 seconds, then
button with the smart key.
the system resets. To turn off the alarm,
If the system is disarmed by unlocking
unlock the doors with the smart key.
the vehicle, but neither a door or the
The Theft Alarm System automatically
trunk is opened within 30 seconds, the
sets 30 seconds after you lock the doors
doors will relock and the system will
and the trunk. For the system to activate,
rearm automatically.
you must lock the doors and the trunk
from outside the vehicle with the smart
key or by pressing the button on the
outside of the door handle with the
smart key in your possession.
The hazard warning lights will blink and
the chime will sound once to indicate the
system is armed.
Once the security system is set, opening
any door, the trunk, or the hood without
using the smart key will cause the alarm
to activate.
The Theft Alarm System will not set if the
hood, the trunk, or any door is not fully
closed. If the system will not set, check
the hood, the trunk, or the doors are fully
closed.
Do not attempt to alter this system or
add other devices to it.
5-32

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
STEERING WHEEL
Electric Power Steering (EPS)
Information
The system assists you with steering the
The following symptoms may occur during
vehicle. If the vehicle is turned off or
normal vehicle operation:
if the power steering system becomes
The steering effort may be high
inoperative, you may still steer the
immediately after setting the Engine
vehicle, but it will require increased
Start/Stop button to the ON position.
steering effort.
This happens as the system performs
Also, the steering effort becomes heavier
the EPS system diagnostics. When the
as the vehicle’s speed increases and
diagnostics are completed, the steering
becomes lighter as the vehicle’s speed
wheel effort will return to its normal
decreases for better control of the
condition.
steering wheel.
When the battery voltage is low, you
Should you notice any change in the
may have to put more steering effort.
effort required to steer during normal
However, it is a temporary condition so
vehicle operation, have the system
that it will return to normal condition
checked by an authorized HYUNDAI
after charging the battery.
dealer.
A click noise may be heard from the
EPS relay after the Engine Start/Stop
CAUTION
button is in the ON or OFF position.
If the Electric Power Steering System
Motor noise may be heard when the
does not operate normally, the
vehicle is at a stop or at a low driving
warning light (
) will illuminate
speed.
on the instrument cluster. You may
When you operate the steering wheel
steer the vehicle, but it will require
in low temperatures, abnormal noise
increased steering efforts. Take your
may occur. If the temperature rises, the
vehicle to an authorized HYUNDAI
noise will disappear. This is a normal
dealer and have the system checked
condition.
as soon as possible.
When an error is detected from the
When an abnormality is detected
EPS, the steering effort assist function
in the electric power steering
may become inoperative in order to
system, to prevent an accident, the
prevent fatal accidents. Instrument
steering assist function may become
cluster warning lights may be on or the
inoperative. At this time, the warning
steering effort may be high. If these
light turns on or blinks on the cluster.
symptoms occur, drive the vehicle to
The steering wheel may become
a safe area as soon as it is safe to do
difficult to control or operate. Have
so. Have the system checked by an
your vehicle checked immediately,
authorized HYUNDAI dealer as soon
after moving the vehicle to a safe
as possible.
area.
5-33

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
Tilt Steering / Telescope Steering
Information
When adjusting the steering wheel to a
Sometimes the lock release lever may not
comfortable position, adjust the steering
engage completely. This may occur when
wheel so that it points toward your chest,
the gears of the locking mechanism do not
not toward your face. Make sure you can
completely mesh. If this occurs, pull down
see the instrument cluster warning lights
on the lock release lever, readjust the
and gauges. After locking the lever, push
steering wheel again, and then pull back
the steering wheel both up and down to
up on the release lever to lock the steering
be certain it is locked in position. Always
wheel in place.
adjust the position of the steering wheel
before driving.
CAUTION
While adjusting the steering wheel
WARNING
height, please do not push or pull it
NEVER adjust the steering wheel while
hard since the fixture can be damaged.
driving. This may cause loss of vehicle
control resulting in an accident.
Horn
OCN7N051013
OCN7N051016
To adjust the steering wheel angle and
To sound the horn, press the area
height:
indicated by the horn symbol on your
steering wheel (see illustration). The
1. Pull down the lock-release lever (1).
horn will operate only when this area is
2. Adjust the steering wheel to the
pressed.
desired angle (2) and height (3, if
equipped). Move the steering wheel,
so it points toward your chest, not
NOTICE
toward your face. Make sure you can
Do not strike the horn severely to
see the instrument panel warning
operate it, or hit it with your fist. Do not
lights and gauges.
press on the horn with a sharp-pointed
3. Pull up the lock-release lever to lock
object.
the steering wheel in place.
5-34

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
MIRRORS
Inside Rearview Mirror
Day/night rearview mirror
(if equipped)
Before driving your vehicle, check to
see that your inside rearview mirror is
properly positioned. Adjust the rearview
mirror so that the view through the rear
window is properly centered.
WARNING
Make sure your line of sight is not
obstructed. Do not place objects in the
rear seat, cargo area, or behind the rear
head restraints which could interfere
with your vision through the rear
OCN7050017L
window.
[A] : Lever, [B] : Day, [C] : Night
Make this adjustment before you start
WARNING
driving and while the day/night lever is in
the day position.
To prevent serious injury during an
accident or deployment of the air bag,
Pull the day/night lever towards you to
do not modify the rearview mirror and
reduce glare from the headlamps of the
do not install a wide mirror.
vehicles behind you during night driving.
Remember that you lose some rearview
clarity in the night position.
WARNING
NEVER adjust the mirror while driving.
This may cause loss of vehicle control
resulting in an accident.
NOTICE
When cleaning the mirror, use a paper
towel or similar material dampened
with glass cleaner. Do not spray glass
cleaner directly on the mirror as this
may cause the liquid cleaner to enter
the mirror housing.
5-35

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
Electrochromic mirror (ECM) with
Automatic-Dimming Night Vision Safety™
HomeLink® system (if equipped)
(NVS®) Mirror (if equipped)
Your vehicle may be equipped with
The NVS® Mirror automatically reduces
a Gentex Automatic-Dimming Mirror
glare by monitoring light levels in the
with an Integrated HomeLink® Wireless
front and the rear of the vehicle. Any
Control System.
object that obstructs either light sensor
will degrade the automatic dimming
During nighttime driving, this feature
control feature.
will automatically detect and reduce
rearview mirror glare. The HomeLink®
For more information regarding NVS®
Universal Transceiver allows you to
mirrors and other applications, please
activate your garage door(s), electric
refer to the Gentex website:
gate, home lighting, etc.
Your mirror will automatically dim
upon detecting glare from the vehicles
traveling behind you.
The mirror defaults to the ON position
each time the vehicle is started.
Integrated HomeLink® Wireless Control
System
The HomeLink® Wireless Control System
provides a convenient way to replace
OCN7050084N
up to three hand held radio-frequency
(1) HomeLink Channel 1
transmitters used to activate compatible
(2) HomeLink Channel 2
devices such as gate operators, garage
door openers, entry door locks, security
(3) HomeLink Channel 3
systems, and home lighting.
(4) Garage Door Opener Status Indicator:
Closing or Closed
NOTICE
(5) HomeLink Operation Indicator
HomeLink® operates while the Engine
(6) Garage Door Opener Status Indicator:
Start/Stop button is in the ACC or
Opening or Opened
ON position for safety reasons. It is
(7) HomeLink User Interface Indicator
to prevent unintentional security
problems from happening when the
vehicle is parked outside the garage.
5-36

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
1. Programming HomeLink®
WARNING
The following steps show how to
Before programming HomeLink® to a
program HomeLink. If you have any
garage door opener or gate operator,
questions or are having difficulty
make sure people and objects are out
programming your HomeLink buttons,
of the way of the device to prevent
refer to the HomeLink website or call the
potential harm or damage. Do not
HomeLink customer support toll-free
use the HomeLink® with any garage
number. Do this, before going back to
door opener that lacks the safety
the dealer who sold you the car.
stop and reverse features required
by U.S. federal safety standards (this
• Visit the HomeLink website at: www.
homelink.com. Then at the top of the
includes any garage door opener model
manufactured before April 1, 1982).
page, choose your vehicle make. Then
watch the You Tube video, and/or
A garage door that cannot detect an
object - signaling the door to stop and
access additional website information.
reverse - does not meet current U.S.
• If you choose to access the website
federal safety standards. Using a garage
via your cell phone, scan the QR code.
door opener without these features
increases the risk of serious injury or
death.
For more information, contact
HomeLink® at www.homelink.com, or
call Home-Link customer support at
• Or, call HomeLink customer support
1-800-355-3515.
at 1-800-355-3515 (Please have the
It is also recommended that a new
vehicle make/model AND the opener
battery be replaced in the handheld
device make/model readily available.)
transmitter of the device being trained
to HomeLink® for quicker training and
accurate transmission of the radio
frequency.
5-37

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
1) Programming Preparation
2) Programming a New HomeLink®
OCN7050084N
OCN7N051214N
1. When programming a garage door
1. Press and release the HomeLink
opener, it is advised to park the
button (1), (2) or (3), you would like
vehicle outside of the garage.
to program. The HomeLink indicator
light (7) will flash orange slowly (if
2. It is recommended that a new battery
be placed in the handheld transmitter
not, perform the steps of “Erasing
HomeLink Buttons” section, and start
of the device being programmed to
HomeLink for quicker training and
over).
accurate transmission of the radio-
frequency signal.
3. Set the Engine Start/Stop button
to the ACC (Accessory) position for
programming of HomeLink.
OCN7N051215N
2. Position the garage door opener
remote 1 - 3 inches (2 - 8cm) away
from the HoleLink buttons.
5-38

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
3. While the HomeLink indicator light (7)
is flashing orange, press and hold the
hand-held remote button. Continue
pressing the handheld remote button
until the HomeLink indicator light (7)
light changes from orange to green.
You may now release the handheld
remote button.
4. Wait until your garage door comes
to a complete stop, regardless of
position, before proceeding to the
next steps.
5. Press and release the HomeLink
ODL3A040504
button you are programming and
 A ladder and/or second person may
observe the indicator light.
simplify the following steps.
• If the indicator light remains solid
7. Firmly press and release the “Learn”,
green, your device should operate
“Smart”, “Set” or “Program” button.
when the HomeLink button is
You now have up to 30 seconds in
pressed. At this point, if your device
which to complete the next step.
operates, programming is complete.
8. Return to the vehicle and firmly press,
• If the indicator light rapidly
hold for two seconds and release,
flashes green, firmly press, hold
the HomeLink button up to three
for two seconds and release the
times in a row slowly. Do not press
HomeLink button up to three times
the HomeLink button rapidly. As soon
in a row slowly to complete the
as you see the garage door start to
programming process. Do not press
move, stop pressing any buttons
the HomeLink button rapidly. At
until a few seconds after the garage
this point if your device operates,
door has come to a complete stop,
programming is complete. If the
regardless of position. At this point,
device does not operate, continue
programming is complete and your
with step 6.
device should operate when the
6. At the garage door opener motor,
HomeLink button is pressed and
(security gate motor, etc.) locate the
released.
“Learn”, “Smart”, “Set” or “Program”
button. This can usually be found
where the hanging antenna wire is
attached to the motor-head unit (see
the device’s manual to identify this
button). The name and color of the
button may vary by manufacturer.
5-39

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
3) Two-Way Communication
2. On your garage door opener in your
Programming (For select garage door
garage, locate the “Learn” button
openers)
(usually near where the hanging
If your garage door opener has the
antenna wire is attached to the garage
‘myQ’ logo on its side, your opener
door opener). If there is difficulty
likely has Two-Way Communication
locating this button, reference the
capability. HomeLink has the capability
device’s owner’s manual.
to establish Two-Way Communication
3. Press and release the “Learn” button.
with your garage door opener. HomeLink
4. A light on your garage door opener
can receive and display “closing”
may flash, and your Two-Way
or “opening” status messages from
Communication indicators (4), (6) in
compatible garage door openers. At
your vehicle may flash, confirming
any time, Home-Link can also recall
completion of the process.
and display the last recorded status
5. Return to the vehicle and firmly
communicated by the garage door
press and release the programmed
opener to indicate your garage door
HomeLink button to activate
being “closed” or “opened”.
your garage door. The Two-Way
To check if your garage door opener is
Communication indicators (4), (6)
compatible with this feature, refer to
flash in orange when the door is
moving. Do not make any additional
way-Communication. If your garage
button presses until AFTER the garage
door opener has this functionality, AND
door has come to a complete stop.
the Two-Way Communication indicators
6. Your Two-Way Communication
(4), (6) in the mirror appear while the
programming is now complete.
garage door is opening/closing, then
no further steps are needed. Two-Way
Communication Programming is already
Information
complete. However, if your garage door
opener has this functionality, AND the
If your garage door opener has Two-
Two-Way Communication indicators (4),
Way Communication functionality,
(6) in the mirror DO NOT appear while
it is possible for HomeLink to stop
the garage door is opening/closing, use
functioning the garage door shortly
the following instructions to enable this
after initial programming, IF the Two-
functionality.
Way Communication Programming
wasn’t properly completed. This
1. In your vehicle, press and hold the
usually happens after the first 10 times
programmed HomeLink button for 2
a programmed HomeLink button is
seconds, then release. Confirm that
pressed. If you experience this, completing
the garage door is moving. AFTER it
the “Programming a New HomeLink
stops, you will have one minute to
Button” and “Two-Way Communication
complete the following steps:
Programming” will restore door
 A ladder and/or second person may
operation.
simplify the following steps.
5-40

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
4) Canadian Programming
2. Operating HomeLink®
Canadian radio-frequency laws require
1) Operating HomeLink®
transmitter remote signals to “time-
out” (or quit) after a couple seconds of
transmission, which may not be long
enough for HomeLink to pick up the
signal during programming.
If you live in Canada or you are having
difficulties programming a gate operator
or garage door opener by using the
programming procedures, replace
“Programming a New HomeLink Button”
step 3 with the following:
While the HomeLink indicator light (7)
OJX1050294N
is flashing orange, press and release
1. Press and release the desired
(“cycle”) your device’s handheld remote
programmed HomeLink button (1, 2
every two seconds until the HomeLink
or 3).
indicator light (7) changes from orange
to green. You may now release the hand-
held remote button. Then proceed with
Information
“Programming a New HomeLink Button”
The HomeLink indicator (7) should
step 4.
light green, solid or flashing, and your
programmed device should operate.
If your device does not operate, the
HomeLink programming was not
successful, and you’ll need to reprogram
the button.
5-41

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
2)
Two-Way Communication Display
• If the indicator (4) flashes in Orange,
Behavior
it indicates that the garage door is
“Closing”.
• The indicator (4) turns solid green
once the garage door has closed.
• If the indicator (6) flashes in Orange,
it indicates that the garage door is
“Opening”.
• The indicator (6) turns solid green
once the garage door has fully
opened.
• If the indicator (4) or (6) does not
turn to green, it indicates that the
OCN7050088N
last status of garage door was not
1.
Press and release one of the
received properly. The HomeLink
programmed HomeLink buttons (1, 2
mirror tries to receive the last known
or 3).
status of the garage door for a few
seconds.
3) Recalling Garage Door Status
HomeLink mirror with Two-Way
Communication provides a way to view
the last stored message from the garage
door opener. In order to recall the last
known status of the last activated device,
press the buttons “1 and 2” OR “2 and 3”
simultaneously.
• If the indicator (4) appears solid
OCN7N051216N
Green, it indicates that the last
2.
The indicator (4) and (6) operates as
activated device was “closed”
properly.
below, if your garage door opener
has Two-Way Communication
• If the indicator (6) appears solid
functionality.
Green, it indicates that the last
activated device was “open” properly.
5-42

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
3. Erasing HomeLink® Buttons
2) The following instructions will erase
ALL HomeLink® programming from
1) Erasing and Reprogramming a Single
ALL buttons:
HomeLink® Button:
1. Press and hold the desired HomeLink
button you want to re-program. DO
NOT release the button.
2. The HomeLink indicator light (7) will
illuminate solid green. Release the
button as soon as the HomeLink
indicator light (7) begins to flash
orange, usually about 20 seconds.
3. Proceed with the steps in the
“Programming a New HomeLink
Button” section.
OCN7N051217N
1. Press and hold the buttons (1) and (3)
Information
simultaneously.
2. The HomeLink indicator light (7) will
If you do not complete the re-
illuminate solid Orange for about 10
programming of a new device to the
seconds.
button, it will revert to the previously
stored programming.
3. Release the buttons once the
HomeLink indicator light (7) changes
to Green and flashes rapidly.
4. Now all three HomeLink buttons
(1), (2) and (3) are cleared of any
programming.
Information
HomeLink® and the HomeLink® House
logo are registered trademarks of Gentex
Corporation.
The myQ logo is a registered trademark of
The Chamberlain Group, Inc.
5-43

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
FCC (USA) and ISED (Canada)
FCC (Htats-Unis) et ISED (Canada)
This device complies with FCC rules
Cet appareil est conforme aux
part 15 and Innovation, Science, and
règlements de la FCC, section 15, et
Economic Development Canada RSS-
au CNR-210 d’Innovation, Sciences et
210. Operation is subject to the following
Dhveloppement économique Canada. Le
two conditions: (1) This device may not
fonctionnement est assujetti aux deux
cause harmful interference, and (2) This
conditions suivantes : (1) cet appareil ne
device must accept any interference that
doit pas causer d’interférences nuisibles
may be received including interference
et (2) cet appareil doit accepter toute
that may cause undesired operation.
interférence reçue, y compris celle qui
WARNING: The transmitter has been
pourrait entraîner un dysfonctionnement.
tested and complies with FCC and
MISE EN GARDE : L’émetteur a subi des
ISED rules. Changes or modifications
tests et est conforme aux règlements
not expressly approved by the party
de la FCC et d’ISDE. Les changements
responsible for compliance could void
ou modifications non approuvés
the user’s authority to operate the
explicitement par la partie responsable
device.
de la conformité pourraient rendre
caduque l’autorisation de l’utilisateur de
This equipment complies with FCC
se servir du dispositif.
and ISED radiation exposure limits set
forth for an uncontrolled environment.
Cet appareil est conforme aux limites
End Users must follow the specific
d’exposition aux radiations de la FCC et
operating instructions for satisfying RF
d’ISDE établies pour un environnement
exposure compliance. This transmitter
non contrôlé. Les utilisateurs finaux
must be at least 20cm from the user and
doivent respecter les instructions
must not be co-located or operating in
d’utilisation spécifiques pour satisfaire
conjunction with any other antenna or
aux exigences de conformité aux
transmitter.
expositions de RF. L’émetteur doit
se trouver à 20 cm au minimum de
l’utilisateur et ne doit pas être situé au
même endroit que tout autre émetteur
ou antenne ni fonctionner avec un autre
émetteur ou antenne.
Méjico
La operación de este equipo está sujeta
a las siguientes dos condiciones: (1) es
posible que este equipo o dispositivo
pueda no causar interferencia dañina, y
(2) este dispositivo o dispositivos deben
aceptar cualquier interferencia, que
incluye la interferencia que puede causar
su operación no deseada.
5-44

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
HomeLink 5 Programing Flow Chart
ODL3A040518
5-45

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
Side View Mirrors
WARNING
Do not adjust or fold the side view
mirrors while driving. This may cause
loss of vehicle control resulting in an
accident.
NOTICE
Do not scrape ice off the mirror face;
this may damage the surface of the
glass.
If the mirror is jammed with ice, do
OCN7N051019N
not adjust the mirror by force. Use an
Make sure to adjust the side view mirrors
approved spray de-icer (not radiator
to your desired position before you begin
antifreeze) spray, or a sponge or soft
driving.
cloth with very warm water, or move
the vehicle to a warm place and
Your vehicle is equipped with both
allow the ice to melt.
left-hand and right-hand side view
mirrors. The mirrors can be adjusted
remotely with the remote switch. The
side view mirrors can be folded to help
prevent damage when going through
an automatic car wash or when passing
through a narrow street.
The right side view mirror is convex.
Objects seen in the mirror are closer than
they appear.
Use the inside rear view mirror or look
back directly to determine the actual
distance of other vehicles prior to
changing lanes.
5-46

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
Side View Mirror Adjustment
Folding the side view mirrors
OCN7N050001N
OCN7N051022L
1. Press either the L (left side) or R (right
To fold the side view mirrors, grasp the
side) button (1) to select the side view
housing of the mirror and then fold it
mirror you would like to adjust.
inwards.
2. Use the mirror adjustment control (2)
to position the selected mirror up,
down, left or right.
3. After adjustment, put the button into
neutral (center) position to prevent
inadvertent adjustment.
NOTICE
The mirrors stop moving when
they reach the maximum adjusting
angles, but the motor continues to
operate while the switch is pressed.
Do not press the switch longer than
necessary, because this can damage
the motor.
Do not attempt to adjust the side
view mirrors by hand, because this
can damage the motor.
5-47

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
WINDOWS
OCN7N050002N
(1) Driver’s door power window switch
(5) Window opening and closing
(2) Front passenger’s door power
(6) Automatic power window
window switch
(7) Power window lock switch
(3) Rear door (left) power window switch
(4) Rear door (right) power window
switch
5-48

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
Power Windows
Window opening and closing
The Engine Start/Stop button must be
in the ON position to be able to raise
or lower the windows. Each door has a
Power Window switch to control that
door’s window. The driver has a Power
Window Lock switch which can block
the operation of passenger windows.
The power windows will operate for
approximately 3 minutes after the Engine
Start/Stop button is in the ACC or OFF
position. However, if the front doors
are opened, the Power Windows will
OCN7050082
not operate even within the 3 minutes
To open:
period.
Press the window switch down to the
first detent position (5). Release the
WARNING
switch when you want the window to
stop.
To avoid serious injury or death, do not
extend your head, arms or body outside
the windows while driving.
To close:
Pull the window switch up to the first
detent position (5). Release the window
Information
switch when you want the window to
In cold and wet climates, power
stop.
windows may not work properly due to
freezing conditions.
Auto down window (if equipped)
While driving with the rear windows
Pressing the power window switch
down or with the sunroof (if equipped)
down momentarily to the second
opened (or partially opened), your
detent position (6) completely lowers
vehicle may demonstrate a wind
the window even when the switch is
buffeting or pulsation noise. This
released. To stop the window at the
noise is normal and can be reduced
desired position while the window is in
or eliminated by taking the following
operation, pull up or press down and
actions. If the noise occurs with one
release the switch.
or both of the rear windows down,
partially lower both front windows
Auto up/down window (if equipped)
approximately one inch. If you
Pressing or pulling up the power window
experience the noise with the sunroof
switch momentarily to the second
open, slightly close the sunroof.
detent position (6) completely lowers or
lifts the window even when the switch
is released. To stop the window at the
desired position while the window is in
operation, pull up or press down and
release the switch.
5-49

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
To reset the power windows
Automatic reverse (if equipped)
If the power windows do not operate
normally, the automatic power window
system must be reset as follows:
1. Set the Engine Start/Stop button to
the ON position.
2. Close the window and continue
pulling up on the power window
switch for at least one second.
If the power windows do not operate
properly after resetting, have the system
checked by an authorized HYUNDAI
OCN7050026
dealer.
If a window senses any obstacle while it
is closing automatically, it will stop and
WARNING
lower approximately 12 inches (30 cm) to
allow the object to be cleared.
The automatic reverse feature doesn’t
activate while resetting the power
If the window detects the resistance
window system. Make sure body parts
while the power window switch is
or other objects are safely out of the
pulled up continuously, the window
way before closing the windows to
will stop upward movement then lower
avoid injuries or vehicle damage.
approximately 1 inch (2.5 cm).
If the power window switch is pulled
up continuously again within 5 seconds
after the window is lowered by the
automatic window reverse feature,
the automatic window reverse will not
operate.
Information
The automatic reverse feature is only
active when the “Auto Up” feature is used
by fully pulling up the switch to the second
detent.
WARNING
Make sure body parts or other objects
are safely out of the way before closing
the windows to avoid injuries or vehicle
damage.
Objects less than 0.16 inch (4 mm) in
diameter caught between the window
glass and the upper window channel
may not be detected by the automatic
reverse window and the window will
not stop and reverse direction.
5-50

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
NOTICE
WARNING
Do not install any accessories on the
NEVER leave the keys in your vehicle
windows. The automatic reverse
with unsupervised children, when
feature may not operate.
the engine is running.
NEVER leave any child unattended in
Power window lock switch
the vehicle. Even very young children
may inadvertently cause the vehicle
to move, entangle themselve s in
the windows, or otherwise injure
themselves or others.
Always double check to make
sure arms, hands, head and other
obstructions are safely out of the
way before closing a window.
Do not allow children to play with the
power windows. Keep the driver’s
door power window lock switch in
OCN7050027
the LOCK position (pressed). Serious
The driver can disable the power window
injury can result from unintentional
switches on the rear passenger doors by
window operation by the child.
pressing the power window lock switch.
Do not extend your head, arms or
When the power window lock switch is
body outside the windows while
pressed:
driving.
• The rear passenger control will not
be able to operate the rear passenger
power window
• Note that the front passenger control
is still able to operate the front
passenger window, and that the driver
master control can still operate all the
power windows.
NOTICE
To prevent possible damage to the
power window system, do not open
or close two windows or more at the
same time. This will also ensure the
longevity of the fuse.
Never try to operate the main
switch on the driver’s door and the
individual door window switch in
opposite directions at the same time.
If this is done, the window will stop
and cannot be opened or closed.
5-51

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
SUNROOF (IF EQUIPPED)
If your vehicle is equipped with a
Sunshade
sunroof, you can slide or tilt your sunroof
with the sunroof switch located on the
overhead console.
OCN7050029
Use the sunshade to block direct sunlight
coming through the sunroof glass.
OCN7050028
Open or close the sunshade by hand.
The sunroof can only be operated when
the Engine Start/Stop button is in the ON
position.
Information
The sunroof can be operated for
The sunshade opens automatically when
approximately 3 minutes after the the
the sunroof glass is opened, but the
Engine Start/Stop button is in the ACC or
sunshade does not close automatically
OFF position. However, if the front door
when the sunroof glass is closed. Also, only
is open, the sunroof cannot be operated
the sunshade cannot be closed when the
even within the 3 minute period.
sunroof glass is opened.
WARNING
NOTICE
Never adjust the sunroof or sunshade
Do not pull the sunshade up or down,
while driving. This could result in loss
or apply excessive force as such action
of control and an accident that may
may damage the sunshade or cause it
cause injury, or property damage.
to malfunction.
Do not leave the engine running
and the key in your vehicle with
unsupervised children. Unattended
children could operate the sunroof,
which could result in serious injury.
Do not sit on the top of the vehicle. It
may cause injury or vehicle damage.
NOTICE
Do not operate the sunroof when roof
bars are installed on the vehicle or
when there is luggage on the roof.
5-52

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
Tilt Open/Close
Slide Open/Close
OCN7N051030L
OCN7N051031
• Push the sunroof switch upward, the
• Push the sunroof switch rearward,
sunroof glass tilts open.
the sunshade and sunroof glass slide
open.
• Push the sunroof switch forward when
the sunroof glass is tilt opened, the
Push the sunroof switch forward, only
sunroof glass closes.
the sunroof glass closes.
The sunroof glass tilts open or closes
• Push the sunroof switch forward or
while the switch is pushed.
rearward to the first detent position,
the sunroof glass moves until the
switch is released.
Information
• Push the sunroof switch forward
The sunroof glass cannot slide open and
or rearward to the second detent
tilt open at the same time. You cannot tilt
position, the sunroof glass operates
the sunroof glass open while the sunroof
automatically (auto slide feature). To
glass is slide open. Also, you cannot slide
stop the sunroof movement at any
the sunroof glass open while the sunroof
point, push the sunroof switch in any
is tilt open. Slide open or tilt open the
direction.
sunroof glass when the sunroof glass is
• The sunroof glass stops halfway
completely closed.
(first detent position) before it is fully
opened. To fully open the sunroof
glass, push the sunroof switch
rearward once more. At this time, the
sunroof glass opens only while the
switch is pushed.
To stop the sunroof movement at any
point, push the sunroof switch in any
direction.
Information
To reduce wind noise while driving,
we recommend that you drive at the
recommended position (first detent
position) before the maximum slide open
position.
5-53

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
Automatic Reversal
NOTICE
Do not continue to push the sunroof
switch after the sunroof is fully
opened, closed, or tilted. Damage to
the sunroof motor could occur.
Continuous operations such as slide
open/close, tilt open/close, etc. may
cause the motor or sunroof system to
malfunction.
Regularly remove any accumulated
dust on the sunroof rail.
Dust accumulated between the
ODH043039
sunroof and roof panel can make
If the sunroof glass senses any obstacle
noise Open the sunroof and remove
while it is closing automatically, it will
dust regularly using a clean cloth.
reverse direction then stop at a certain
Do not try to open the sunroof when
position.
the temperature is below freezing
The auto reverse function may not
or when the sunroof is covered
work if an object thin or soft is caught
with snow or ice. The sunroof may
between the sliding sunroof glass and
not work properly and may break if
sunroof sash.
opened by force.
Do not open or drive with the sunroof
WARNING
glass open immediately after rain or
washing the vehicle. Water may wet
Make sure heads, hands, arms or
the interior of the vehicle.
any other body parts or objects are
out of the way before operating the
Do not extend any luggage outside
sunroof. Body parts or objects may
the sunroof while driving. Vehicle
get caught causing injuries or vehicle
damage may occur if the vehicle
damage.
suddenly stops.
Never deliberately use your body
parts to test the automatic reversal
WARNING
function. The sunroof glass may
Do not extend your head, arms, body
reverse direction, but there is a risk
parts or objects outside the sunroof
of injury.
while driving. Injuries may occur if the
vehicle suddenly stops.
5-54

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
Resetting the Sunroof
5. Once again push and hold the sunroof
switch forward until the sunroof glass
slides open and close. Do not release
the switch until the operation is
completed.
If you release the switch during
operation, start the procedure again
from step 2.
Information
If the sunroof is not reset when the vehicle
battery is disconnected or discharged, or
OCN7N051032
the sunroof fuse is blown, the sunroof may
In some circumstances resetting the
not operate normally.
sunroof operation may need to be
performed. Some instances where
Sunroof Open Warning
resetting the sunroof may be required
include:
• When the 12-volt battery is either
disconnected or discharged
• When the sunroof fuse is replaced
• If the sunroof one-touch AUTO OPEN/
CLOSE operation is not functioning
properly
Sunroof resetting procedure:
1. It is recommended to perform the
reset procedure with the vehicle
OCN7N041018L
engine running. Start the vehicle in P
If the driver turns off the engine when
(Park).
the sunroof is not fully closed, the
warning chime will sound for several
2. Make sure the sunroof glass is in the
fully closed position. If the sunroof
seconds and the sunroof open warning
will appear on the cluster LCD display.
glass is open, push the switch forward
until the sunroof glass is fully closed.
Close the sunroof securely when leaving
3. Release the switch when the sunroof
your vehicle.
glass is fully closed.
4. Push the switch forward until the
CAUTION
sunroof glass moves slightly. Then
Make sure the sunroof is closed fully
release the switch.
when leaving your vehicle.
If the sunroof is left open, rain or snow
may wet the interior of the vehicle.
Also, leaving the sunroof open when the
vehicle is unattended may invite theft.
5-55

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
HOOD
Opening the hood
OCN7050035
OCN7N051218N
5. Hold the hood open with the support
rod (3).
1. Park the vehicle and set the parking
brake.
2. Pull the release lever to unlatch the
WARNING
hood. The hood should pop open
Support rod
slightly.
After driving, the engine
compartment and support rod will
be hot. Grasp the support rod in the
area wrapped in rubber to prevent
burns.
The support rod must be inserted
completely into the hole provided
whenever you inspect the engine
compartment. This will prevent
the hood from falling and possibly
injuring you.
OCN7N051034N
3. Go to the front of the vehicle, raise
the hood slightly, push the secondary
latch up (1) inside of the hood center
and lift the hood (2).
4. Pull out the support rod.
5-56

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
Closing the hood
WARNING
1. Before closing the hood, check the
Before closing the hood, ensure
following:
all obstructions are removed from
• All filler caps in engine
around the hood opening.
compartment must be correctly
Always double check to be sure that
installed.
the hood is firmly latched before
• Gloves, rags or any other
driving away. Check there is no
combustible material must
hood open warning light or message
be removed from the engine
displayed on the instrument cluster.
compartment.
Driving with the hood opened may
2. Return the support rod to its clip to
cause a total loss of visibility, which
prevent it from rattling.
might result in an accident.
3. Lower the hood halfway (lifted
Do not move the vehicle with the
approximately 30 cm from the closed
hood in the raised position, as vision
position) and push down to securely
is obstructed, which might result in
lock in place. Then double check to be
an accident, and the hood could fall
sure the hood is secure.
or be damaged.
*G UIF IPPE DBO CF SBJTFE TMJHIUMZ
JU JT OPU TFDVSFMZ MPDLFE
0QFO JU
BHBJO BOE DMPTF JU XJUI NPSF GPSDF
5-57

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
TRUNK
Opening the trunk
Inside
1. Make sure the shift lever is in P (Park,
for Dual clutch transmission) or
first gear or R (Reverse, for manual
transmission) and set the parking
brake.
Outside
OCN7050037
- Use the trunk release lever.
3. Lift the trunk lid up.
Closing the trunk
Lower the trunk lid and press down
OCN7N051036N
until it locks. To be sure the trunk lid is
2.
Then do one of the following:
securely fastened, always check by trying
to pull it up again.
Hold down the trunk unlock button
located on your smart key for more
than 1 second.
WARNING
Additionally, for vehicles equipped
Always keep the trunk lid completely
with smart key :
closed while the vehicle is in motion. If
- While all doors are unlocked, press
it is left open or ajar, poisonous exhaust
the switch in the trunk to open the
gases containing carbon monoxide
trunk with or without the smart key
(CO) may enter the vehicle and serious
in your possession.
illness or death may result.
- If any door is locked or all doors are
locked, the switch can still be used
Information
to open the trunk, as long as the
smart key is in your possession.
To prevent damage to the trunk lift
cylinders and the attached hardware,
always close the trunk before driving.
NOTICE
In cold and wet climates, trunk lock
and trunk mechanisms may not work
properly due to freezing conditions.
5-58















Content      ..     4      5      6      7     ..
