Hyundai ix20 (2017 year). Instruction - part 7
Features of your vehicle
MIRRORS
Inside rearview mirror
Electrochromic mirror (ECM)
(if equipped)
Adjust the rearview mirror so that the
center view through the rear window is
The electric rearview mirror automatical-
seen. Make this adjustment before you
ly controls the glare from the headlights
start driving.
Night
of the car behind you in nighttime or low
light driving conditions. The sensor
mounted in the mirror senses the light
WARNING - Rear visibility
level around the vehicle, and automati-
Do not place objects in the rear
cally controls the headlight glare from
seat or cargo area which would
vehicles behind you.
interfere with your vision out of the
When the engine is running, the glare is
Day
rear window.
automatically controlled by the sensor
OAM049023
mounted in the rearview mirror.
Day/night rearview mirror
Whenever the shift lever is shifted into
WARNING
(if equipped)
reverse, the mirror will automatically go
Do not adjust the rearview mirror
Make this adjustment before you start
to the brightest setting in order to
while the vehicle is moving. This
driving and while the day/night lever is in
improve the drivers view behind the vehi-
could result in loss of control, and
the day position.
cle.
an accident which could cause
Pull the day/night lever toward you to
death, serious injury or property
reduce glare from the headlights of the
CAUTION
damage.
vehicles behind you during night driving.
When cleaning the mirror, use a
Remember that you lose some rearview
paper towel or similar material
clarity in the night position.
dampened with glass cleaner. Do
WARNING
not spray glass cleaner directly on
Do not modify the inside mirror and
the mirror as that may cause the liq-
do not install a wide mirror. It could
uid cleaner to enter the mirror hous-
result in injury, during an accident
ing.
or deployment of the air bag.
4 36
Features of your vehicle
■ Type A
Outside rearview mirror
CAUTION
Be sure to adjust the mirror angles
Do not scrape ice off the mirror
before driving.
face; this may damage the surface
Your vehicle is equipped with both left-
of the glass. If ice should restrict
hand and right-hand outside rearview
movement of the mirror, do not
mirrors. The mirrors can be adjusted
force the mirror for adjustment. To
remotely with the remote switch
(if
remove ice, use a deicer spray.
equipped). The mirror heads can be fold-
Indicator
Sensor
ed back to prevent damage during an
automatic car wash or when passing
through a narrow street.
CAUTION
OYN049030
If the mirror is jammed with ice, do
■ Type B
not adjust the mirror by force. Use
WARNING - Rearview mir-
an approved spray de-icer (not radi-
rors
ator antifreeze) to release the
Rearview display
Sensor
•
The right outside rearview mirror
frozen mechanism or move the
is convex. In some countries, the
vehicle to a warm place and allow
left outside rearview mirror is also
the ice to melt.
convex. Objects seen in the mir-
ror are closer than they appear.
•
Use your interior rearview mirror
WARNING
Indicator
or direct observation to determine
Do not adjust or fold the outside
OYN049031
the actual distance of following
rearview mirrors while the vehicle
To operate the electric rearview mirror:
vehicles when changing lanes.
is moving. This could result in loss
• The mirror defaults to the ON position
of control, and an accident which
whenever the ignition switch is turned on.
could cause death, serious injury
• Press the ON/OFF button (1) to turn
or property damage.
the automatic dimming function off.
The mirror indicator light will turn off.
Press the ON/OFF button (1) to turn
the automatic dimming function on.
The mirror indicator light will illuminate.
4
37
Features of your vehicle
CAUTION
•
The mirrors stop moving when
they reach the maximum adjust-
ing angles, but the motor contin-
ues to operate while the switch is
pressed. Do not press the switch
longer than necessary, the motor
may be damaged.
•
Do not attempt to adjust the out-
side rearview mirror by hand.
Doing so may damage the parts.
B510A01E
OJC040032
Remote control
Electric type (if equipped)
Manual type (if equipped)
The electric remote control mirror switch
To adjust an outside mirror, move the
allows you to adjust the position of the
control lever.
left and right outside rearview mirrors. To
adjust the position of either mirror, move
the lever (1) to R (Right) or L (Left) to
select the right side mirror or the left side
mirror, then press a corresponding point
on the mirror adjustment control to posi-
tion the selected mirror up, down, left or
right.
After adjustment, put the lever into neu-
tral (center) position to prevent inadver-
tent adjustment.
4 38
Features of your vehicle
Outside rearview mirror heater
(if equipped)
The outside rearview mirror heater is
actuated in connection with the rear win-
dow defroster. To heat the outside
rearview mirror glass, push the button
(
) for rear window defroster.
The outside rearview mirror glass will be
heated for defrosting or defogging and
will give you improved rear vision in
inclement weather conditions. Push the
button again to turn the heater off. The
1LDA2083A
OJC040033
outside rearview mirror heater automati-
Folding the outside rearview mirror
Electric Type
cally turns off after 20 minutes.
Manual type
To fold the outside rearview mirror, press
To fold the outside rearview mirror, grasp
the button.
the housing of the mirror and then fold it
To unfold it, press the button again.
toward the rear of the vehicle.
CAUTION
The electric type outside rearview
mirror operates even though the
ignition switch is in the LOCK posi-
tion. However, to prevent unneces-
sary battery discharge, do not adjust
the mirrors longer than necessary
while the engine is not running.
CAUTION
In case it is an electric type outside
rearview mirror, don’t fold it by
hand. It could cause motor failure.
4 39
Features of your vehicle
INSTRUMENT CLUSTER
■ Type A
1. Tachometer
2. Turn signal indicators
3. Speedometer
4. Warning and indicator lights
5. Engine temperature gauge
■ Type B
6. Fuel gauge
7. Odometer/Tripmeter*
* if equipped
The actual cluster in the vehicle may differ from the illustration.
OJC043040/OJC043041
4 40
Features of your vehicle
■ Left-hand drive type
■ Kilometer per hour
WARNING
- Type A
- Type B
Never adjust the instrument cluster
while driving. This could result in
loss of control and lead to an acci-
dent that may cause death, serious
injury, or property damage.
OYN049044
OJC040048
■ Right-hand drive type
■ Mile per hour
- Type B
- Type A
OYN049044R
OJC043049
Instrument panel illumination
Gauges
(if equipped)
Speedometer
Rotate the illumination control switch to
The speedometer indicates the forward
adjust the instrument panel illumination
speed of the vehicle.
intensity. For instrument cluster type A,
The speedometer is calibrated in kilome-
the vehicle’s parking lights or headlights
ters per hour and/or miles per hour.
should be on to adjust the instrument
panel illumination.
4 41
Features of your vehicle
■ Gasoline
The tachometer pointer may move slight-
■ Type A
■ Type B
- Type A
- Type B
ly when the ignition switch is in ON posi-
tion with the engine OFF. This movement
is normal and will not affect the accuracy
of the tachometer once the engine is run-
ning.
CAUTION
Do not operate the engine within
the tachometer's RED ZONE.
OJC040046
This may cause severe engine dam-
■ Diesel
age.
OJC040050
- Type A
- Type B
Engine temperature gauge
This gauge shows the temperature of the
engine coolant when the ignition switch
is ON. The gauge is supplemented by a
Engine coolant temperature warning
light, which illuminates when the engine
is overheating.
Do not continue driving with an overheat-
ed engine. If your vehicle overheats, refer
OJC040047
to “If the engine overheats” in section 6.
Tachometer
The tachometer indicates the approxi-
mate number of engine revolutions per
minute (rpm).
Use the tachometer to select the correct
shift points and to prevent lugging and/or
over-revving the engine.
4 42
Features of your vehicle
■ Type A
■ Type B
CAUTION
WARNING - Fuel gauge
If the gauge shows beyond the nor-
Running out of fuel can expose
mal range area toward the “130”
vehicle occupants to danger.
position, it indicates overheating
You must stop and obtain addition-
that may damage the engine.
al fuel as soon as possible after the
warning light comes on or when the
gauge indicator comes close to the
“0” level.
WARNING
Never remove the radiator cap
when the engine is hot. The engine
CAUTION
OJC040051
coolant is under pressure and
Avoid driving with a very low fuel
could cause severe burns. Wait
Fuel gauge
level. Running out of fuel could
until the engine is cool before
The fuel gauge indicates the approxi-
cause the engine to misfire, damag-
adding coolant to the reservoir.
mate amount of fuel remaining in the fuel
ing the catalytic converter.
tank. The fuel tank capacity is given in
section 8. The fuel gauge is supplement-
ed by a low fuel warning light, which will
illuminate when the fuel tank is nearly
empty.
On inclines or curves, the fuel gauge
may fluctuate or the low fuel warning light
may come on earlier than usual due to
the movement of fuel in the tank.
: The arrow indicates the fuel filler lid
is in the left side of the vehicle.
4 43
Features of your vehicle
■ Type A
■ Type B
■ Type A
■ Type B
■ Type A
■ Type B
OJC040100
OJC045187/OJC045188
OJC045190/OJC045189
Odometer (km or mi.)
Transaxle Shift Indicator
In the Sports Mode, this indicator informs
The odometer indicates the total dis-
which gear is desired while driving to
Automatic Transaxle Shift Indicator
tance the vehicle has been driven.
save fuel.
(if equipped)
You will also find the odometer useful to
This indicator displays which automatic
• Shifting up : ▲2, ▲3, ▲4, ▲5, ▲6
determine when periodic maintenance
transaxle shift lever is selected.
• Shifting down :
▼1, ▼2, ▼3, ▼4, ▼5
should be performed.
For example
• Park : P
✽ NOTICE
: Indicates that shifting up to the 3rd
• Reverse : R
gear is desired (currently the shift
It is forbidden to alter the odometer of
• Neutral : N
lever is in the 2nd or 1st gear).
all vehicles with the intent to change the
• Drive : D
mileage registered on the odometer. The
: Indicates that shifting down to the
• Sports Mode : 1, 2, 3, 4, 5, 6
3rd gear is desired
(currently the
alteration may void your warranty cov-
erage.
shift lever is in the 4th gear).
When the system is not working properly,
the indicator is not displayed.
4 44
Features of your vehicle
■ Type A
■ Type B
Press the TRIP button for less than 1
second to select any mode as follows:
Tripmeter A
Tripmeter B
Distance to empty*
Average fuel consumption*
OJC045190/OJC045189
OJC040045
Manual Transaxle Shift Indicator
Tripmeter/Trip computer (if equipped)
Average refuel consumption*
(if equipped)
The trip computer is a microcomputer-
This indicator informs which gear is
controlled driver information system that
Instant fuel consumption*
desired while driving to save fuel.
displays information related to driving,
when the ignition switch is in the ON
• Shifting up : ▲2, ▲3, ▲4, ▲5, ▲6
position. All stored driving information
Average speed*
• Shifting down :
(except TRIP A/B) resets if the battery is
▼1, ▼2, ▼3, ▼4, ▼5
disconnected.
For example
Elapsed time*
: Indicates that shifting up to the 3rd
gear is desired (currently the shift
lever is in the 2nd or 1st gear).
* if equipped
: Indicates that shifting down to the
3rd gear is desired
(currently the
shift lever is in the 4th, 5th, or 6th
gear).
When the system is not working properly,
the indicator is not displayed.
4 45
Features of your vehicle
■ Type A
■ Type B
■ Type A
■ Type B
■ Type A
■ Type B
OJC040101
OJC040102
OJC040103
Tripmeter (km or mi.)
Distance to empty (if equipped)
Average fuel consumption (if equipped)
TRIP A : Tripmeter A
(km or mi.)
(l/100 km or MPG)
TRIP B : Tripmeter B
This mode indicates the estimated dis-
This mode calculates the average fuel
This mode indicates the distance of indi-
tance to empty based on the current fuel
consumption from the total fuel used and
in the fuel tank and the amount of fuel
the distance since the last average con-
vidual trips selected since the last trip-
delivered to the engine. When the
sumption reset. The total fuel used is cal-
meter reset.
remaining distance is below 50 km (30
culated from the fuel consumption input.
The meter's working range is from 0.0 to
miles), “---” will be displayed.
For an accurate calculation, drive more
999.9 km (0.0 to 999.9 miles).
The meter’s working range is from 50 to
than 50 m (0.03 miles).
Pressing the RESET button for more
999 km (30 to 999 miles).
Pressing the RESET button for more
than 1 second, when the tripmeter (TRIP
than 1 second, when the average fuel
A or TRIP B) is displayed, clears the trip-
consumption is being displayed, clears
meter to zero (0.0).
the average fuel consumption to zero (--
.-).
4 46
Features of your vehicle
■ Type A
■ Type B
■ Type A
■ Type B
✽ NOTICE
•
If the vehicle is not on level ground or
the battery power has been interrupt-
ed, the “Distance to empty” function
may not operate correctly.
The trip computer may not register
additional fuel if less than 6 liters (1.6
gallons) of fuel are added to the vehi-
cle.
•
The fuel consumption and distance to
empty may vary significantly based
on driving conditions, driving habits,
OJC040107L
OJC040105
and condition of the vehicle.
Average refuel consumption
Instant fuel consumption (if equipped)
•
The distance to empty value is an esti-
(l/100 km or MPG)
(l/100 km or MPG)
mate of the available driving distance.
This may differ from the actual driv-
This mode calculates the average fuel
This mode calculates the instant fuel
ing distance available.
consumption from the total fuel used and
consumption of the last few seconds.
the distance since the last tank refuel.
The total fuel used is calculated from the
fuel consumption input. For an accurate
calculation, drive more than 50 m (0.03
miles).
The average refuel consumption resets
to zero (--.-) when the vehicle is refueled.
4 47
Features of your vehicle
■ Type A
■ Type B
■ Type A
■ Type B
Warnings and indicators
All warning lights are checked by turning
the ignition switch ON (do not start the
engine). If any light does not illuminate,
we recommend that the system be
checked by an authorized HYUNDAI
dealer.
After starting the engine, check to make
sure that all warning lights are off. If any
are still on, this indicates a situation that
needs attention.
OJC040104
OJC040106
Average speed (km/h or MPH)
Elapsed time (if equipped)
This mode calculates the average speed
This mode indicates the total time trav-
of the vehicle since the last average
eled since the last driving time reset.
speed reset.
Even if the vehicle is not in motion, the
Even if the vehicle is not in motion, the
driving time keeps going while the engine
average speed keeps going while the
is running.
engine is running.
The meter’s working range is from
Pressing the RESET button for more
00:00~99:59.
than 1 second, when the average speed
Pressing the RESET button for more
is being displayed, clears the average
than 1 second, when the driving time is
speed to zero (---).
being displayed, clears the driving time to
zero (00:00).
4 48
Features of your vehicle
Air bag warning light
Seat belt warning
Engine oil pressure
warning
This warning light will illuminate for
As a reminder to the driver and passen-
This warning light indicates the engine oil
approximately 6 seconds each time you
ger, the seat belt warning light will illumi-
pressure is low.
turn the ignition switch to the ON posi-
nate for approximately 6 seconds each
If the warning light illuminates while driv-
tion.
time you turn the ignition switch ON
ing:
This light also comes on when the
regardless of belt fastening.
1. Drive safely to the side of the road and
Supplemental Restraint System (SRS) is
For details, refer to the “Seat belt” in sec-
stop.
not working properly. If the AIR BAG
tion 3.
2. With the engine off, check the engine
warning light does not come on, or con-
oil level. If the level is low, add oil as
tinuously remains on after operating for
required.
about 6 seconds when you turned the
If the warning light remains on after
ignition switch to the ON position or start-
adding oil or if oil is not available, we rec-
ed the engine, or if it comes on while
ommend that you call an authorized
driving, we recommend that the system
HYUNDAI dealer.
be inspected by an authorized HYUNDAI
dealer.
For information about the passenger’s
CAUTION
front air bag ON/OFF indicator, refer to
If the engine is not stopped imme-
"Air bag - supplemental restraint system"
diately after the engine oil pressure
in section 3.
warning light is illuminated, severe
damage could result.
4 49
Features of your vehicle
Engine oil level warning
CAUTION
light
CAUTION
If the oil pressure warning light
If the light comes on continuously
stays on while the engine is run-
after adding the engine oil and trav-
ning, serious engine damage may
elling approximately 50 ~ 100 km
The engine oil level warning light illumi-
result. The oil pressure warning
after the engine warms up, we rec-
nates when the engine oil level should be
light comes on whenever there is
ommend that the system be
checked.
insufficient oil pressure. In normal
checked by an authorized HYUNDAI
If the warning light comes on, check the
operation, it should come on when
dealer.
engine oil level as soon as possible and
the ignition switch is turned on,
Even if this light doesn't come on
add engine oil as required.
then go out when the engine is
after the engine has started, the
Slowly pour the recommended oil little by
started. If the oil pressure warning
engine oil should be checked and
little into a funnel.
(Oil refill capacity
:
light stays on while the engine is
supplied periodically.
approximately 0.6 ~ 1.0 l)
running, there is a serious malfunc-
Use only the specified engine oil. (Refer
tion.
to "Recommended lubricants and capac-
If this happens, stop the car as
Turn signal indicator
ities" in section 8.)
soon as it is safe to do so, turn off
Do not overfill the engine oil. Make sure
the engine and check the oil level. If
the oil level is not above F (Full) mark on
the oil level is low, fill the engine oil
the dipstick.
to the proper level and start the
The blinking green arrows on the instru-
engine again. If the light stays on
✽ NOTICE
ment panel show the direction indicated
with the engine running, turn the
by the turn signals. If the arrow comes on
• If you travel approximately
50 km
engine off immediately. In any
but does not blink, blinks more rapidly
~100 km after the engine warms up,
instance where the oil light stays on
than normal, or does not illuminate at all,
after adding the engine oil, the warn-
when the engine is running, we rec-
it indicates a malfunction in the turn sig-
ing light will go off.
ommend that the system be
nal system. You should consult your deal-
• Cycle the ignition from OFF to ON 3
checked by an authorized HYUNDAI
er for repairs.
times within 10 seconds, the warning
dealer.
This indicator also blinks when the haz-
light will go off immediately. However,
when you turn off the warning light
ard warning switch is turned on.
without adding the engine oil, the light
will come on again after traveling
approximately 50 ~ 100 km after the
engine warms up.
4
50
Features of your vehicle
High beam indicator
Light on indicator
Engine coolant tempera-
ture warning light
This indicator illuminates when the head-
The indicator illuminates when the tail
The warning light shows the temperature
lights are on and in the high beam posi-
lights or headlights are ON.
of the engine coolant when the ignition
switch is ON.
tion or when the turn signal lever is pulled
into the Flash-to-Pass position.
The warning light illuminates if the tem-
Automatic transaxle shift
perature of the engine coolant is above
position indicator
120±3°C (248±5.5°F).
Low Beam Indicator
(if equipped)
Do not continue driving with an overheat-
ed engine. If your vehicle overheats, refer
The indicator displays which automatic
to “Overheating” in the section 6.
This indicator illuminates when the head-
transaxle shift lever is selected.
lights are on and in the low beam posi-
✽ NOTICE
tion.
Manual transaxle shift
If the engine coolant temperature warn-
indicator (if equipped)
ing light illuminates, it indicates over-
Front fog light indicator
heating that may damage the engine.
(if equipped)
This indicator informs you which gear is
desired while driving to save fuel.
This indicator illuminates when the front
For example
fog lights are ON.
: Indicates that shifting up to the 3rd
gear is desired (currently the shift
lever is in the 2nd or 1st gear).
Rear fog light indicator
: Indicates that shifting down to the
3rd gear is desired (currently the
shift lever is in the 4th or 5th gear).
This indicator illuminates when the rear
When the system is not working proper-
fog lights are ON.
ly, the indicator (Up & Down Arrow and
gear) is not displayed.
4 51
Features of your vehicle
Charging system warning
EPS (Electric power steer-
Door ajar warning light
light
ing) system warning light
(if equipped)
(if equipped)
This warning light indicates a malfunction
This warning light illuminates after the
This warning light illuminates when a
of either the generator or electrical
ignition key is turned to the ON position
door is not closed securely.
charging system.
and then it will go off when the engine
If the warning light illuminates while the
starts.
Tailgate open warning light
vehicle is in motion:
This light also comes on when the EPS
(if equipped)
1. Drive to the nearest safe location.
has malfunctioned. If it comes on while
driving, we recommend that the system
2. With the engine off, check the genera-
be inspected by an authorized HYUNDAI
tor drive belt for looseness or break-
This warning light illuminates when the
dealer.
age.
tailgate is not closed securely.
3. If the belt is adjusted properly, a prob-
lem exists somewhere in the electrical
Door and tailgate open
charging system. We recommend that
indicator (if equipped)
the system be checked by an author-
ized HYUNDAI dealer.
This indicator illuminates when a door
or/and tailgate is not closed securely.
4 52
