Driving your vehicle
WARNING - Driving under
WARNING
the influence of alcohol or
When you intend to park or stop the
drugs
vehicle with the engine on, be care-
Drinking and driving is dangerous.
ful not to depress the accelerator
Drunk driving is the number one
pedal for a long period of time. It
contributor to the highway death
may overheat the engine or exhaust
toll each year. Even a small amount
system and cause fire.
of alcohol will affect your reflexes,
perceptions and judgement.
Driving whilst under the influence
of drugs is as dangerous or more
dangerous than driving drunk.
You are much more likely to have a
serious accident if you drink or
take drugs and drive.
If you are drinking or taking drugs,
don’t drive. Do not ride with a driv-
er who has been drinking or taking
drugs. Choose a designated driver
or call a cab.
5 4
Driving your vehicle
KEY POSITIONS
ACC (Accessory)
The steering wheel is unlocked and elec-
trical accessories are operative.
✽ NOTICE
If difficulty is experienced in turning the
ignition switch to the ACC position, turn
the key whilst turning steering wheel
right and left to release the tension.
ON
The warning lights can be checked
OTQ057001
OTQ057002
before the engine is started. This is the
Illuminated ignition switch
Ignition switch position
normal running position after the engine
(if equipped)
LOCK
is started.
Whenever a front door is opened, the
The steering wheel locks to protect
Do not leave the ignition switch ON if the
ignition switch will be illuminated for your
against theft. The ignition key can be
engine is not running to prevent battery
convenience, provided the ignition switch
removed only in the LOCK position.
discharge.
is not in the ON position. The light will go
When turning the ignition switch to the
off immediately when the ignition switch
LOCK position, push the key inward at
START
is turned on or go off after about 30 sec-
the ACC position and turn the key toward
Turn the ignition switch to the START
onds when the door is closed.
the LOCK position.
position to start the engine. The engine
will crank until you release the key; then
it returns to the ON position. The brake
warning lamp can be checked in this
position.
5 5
Driving your vehicle
(Continued)
WARNING - Ignition switch
•
Do not place any movable objects
•
Never turn the ignition switch to
around the driver’s seat as they
LOCK or ACC whilst the vehicle
may move whilst driving, inter-
is moving. This would result in
fere with the driver and lead to an
loss of directional control and
accident.
braking function, which could
cause an accident.
•
The anti-theft steering column
lock is not a substitute for the
parking brake. Before leaving the
driver’s seat, always make sure
the shift lever is engaged in P
(Park) for the automatic transmis-
sion and set the parking brake
fully and shut the engine off.
Unexpected and sudden vehicle
movement may occur if these
precautions are not taken.
•
Never reach for the ignition
switch, or any other controls
through the steering wheel whilst
the vehicle is in motion. The pres-
ence of your hand or arm in this
area could cause a loss of vehicle
control, an accident and serious
bodily injury or death.
(Continued)
5 6
Driving your vehicle
STARTING THE ENGINE
Starting the petrol engine
WARNING
CAUTION
1. Make sure the parking brake is
If the engine stalls whilst you are in
•
Always wear appropriate shoes
applied.
motion, do not attempt to move the
when operating your vehicle.
2. Manual Transmission - Depress the
shift lever to the P (Park) position. If
Unsuitable shoes (high heels, ski
clutch pedal fully and shift the trans-
traffic and road conditions permit,
boots,etc.) may interfere with
mission into Neutral. Keep the clutch
you may put the shift lever in the N
your ability to use the brake and
pedal and brake pedal depressed
(Neutral) position whilst the vehicle
accelerator pedal, and the clutch
whilst turning the ignition switch to the
(if equipped).
start position.
is still moving and turn the ignition
switch to the START position in an
•
Do not start the vehicle with the
Automatic Transmission - Place the
attempt to restart the engine.
accelerator pedal depressed. The
transmission shift lever in P
(Park).
Depress the brake pedal fully.
vehicle can move and lead to an
accident.
You can also start the engine when
the shift lever is in the N
(Neutral)
CAUTION
•
Wait until the engine rpm is nor-
position.
•
Do not engage the starter for
mal. The vehicle may suddenly
3. Turn the ignition switch to START and
more than 10 seconds. If the
move if the brake padel is
hold it there until the engine starts (a
engine stalls or fails to start, wait
released when the rpm is high.
maximum of
10 seconds), then
5 to 10 seconds before re-engag-
release the key.
ing the starter. Improper use of
It should be started without depressing
the starter may damage it.
the accelerator.
•
Do not turn the ignition switch to
4. Do not wait for the engine to warm up
the START position with the
whilst the vehicle remains stationary.
engine running. It may damage
Start driving at moderate engine
the starter.
speeds. (Steep accelerating and decel-
erating should be avoided.)
5 7
Driving your vehicle
Starting the diesel engine
✽ NOTICE - Diesel Engine
Glow indicator light
If the accelerator is pressed for a long
To start the diesel engine when the
time whilst standing still, the engine
engine is cold, it has to be pre-heated
power will be limited to prevent the
before starting the engine and then have
exhaust parts from overheating.
to be warmed up before starting to drive.
1. Make sure the parking brake is
applied.
2. Manual Transmission - Depress the
clutch pedal fully and shift the trans-
mission into Neutral. Keep the clutch
pedal and brake pedal depressed
whilst turning the ignition switch to the
W-60
start position.
3. Turn the ignition switch to the ON posi-
Automatic Transmission - Place the
tion to pre-heat the engine. Then the
transmission shift lever in P(park).
glow indicator light will illuminate.
Depress the brake pedal fully.
4. If the glow indicator light goes out, turn
You can also start the engine when the
the ignition switch to the START posi-
shift lever is in the N(neutral) position.
tion and hold it there until the engine
starts (a maximum of 10 seconds),
then release the key.
✽ NOTICE
If the engine were not started within 10
seconds after the preheating is complet-
ed, turn the ignition switch once more to
the LOCK position during 10 seconds,
and then to the ON position, in order to
preheat again.
5 8
Driving your vehicle
Starting and stopping the engine for tur-
bocharger intercooler
1. Do not race or accelerate the engine
immediately after starting.
If the engine is cold, idle for several
seconds before sufficient lubrication is
ensured in the turbocharger unit.
2. After high speed or extended driving,
requiring a heavy engine load, run the
engine on idle condition about
1
minute before turning it off.
This idle time will allow the tur-
bocharger to cool prior to shutting the
engine off.
CAUTION
Do not turn the engine off immedi-
ately after it has been subjected to
a heavy load. Doing so may cause
severe damage to the engine or tur-
bocharger unit.
5 9
Driving your vehicle
MANUAL TRANSMISSION (IF EQUIPPED)
■ Type A
Manual transmission operation
CAUTION
The manual transmission has 5 (or 6, if
•
When downshifting from fifth
equipped) forward gears.
gear to fourth gear, caution
This shift pattern is imprinted on the shift
should be taken not to inadver-
knob. The transmission is fully synchro-
tently press the gear shift lever
nised in all forward gears so shifting to
sideways in such a manner that
either a higher or a lower gear is easily
second gear is engaged. Such a
accomplished.
drastic downshift may cause the
Press the clutch pedal down fully whilst
engine speed to increase to the
N
shifting, then release it slowly.
point that the tachometer will
If your vehicle is equipped with an igni-
enter the red-zone. Such over-
tion lock switch, the engine will not start
revving of the engine may possi-
when starting the engine without
■ Type B
bly cause engine damage.
depressing the clutch pedal. (if equipped)
•
Do not downshift more than 2
The gearshift lever must be returned to
gears or downshift the gear when
the neutral position before shifting into R
the engine is running at high
(Reverse).
speed
(5,000 RPM or higher).
Make sure the vehicle is completely
Such a downshifting may damage
stopped before shifting into R (Reverse).
the engine, clutch and the trans-
Never operate the engine with the
mission.
tachometer (rpm) in the red zone.
N
The shift lever can be moved without
pulling the ring (1).
The ring (1) must be pulled up whilst
moving the shift lever.
OTQ057004/OCM050003
5 10
Driving your vehicle
• During cold weather, shifting may be
Using the clutch
difficult until the transmission lubricant
WARNING
The clutch should be pressed all the way
is warmed up. This is normal and not
•
Before leaving the driver’s seat,
to the floor before shifting, then released
harmful to the transmission.
always set the parking brake fully
slowly. The clutch pedal should always be
• If you've come to a complete stop and
and shut the engine off. Then
fully released whilst driving. Do not rest
it's hard to shift into 1st or R(Reverse),
make sure the transmission is
your foot on the clutch pedal whilst driv-
leave the shift lever at N(Neutral) posi-
shifted into
1st gear when the
ing. This can cause unnecessary wear.
tion and release the clutch. Press the
vehicle is parked on a level or
Do not partially engage the clutch to hold
clutch pedal back down, and then shift
uphill grade, and shifted into R
the car on an incline. This causes unnec-
into 1st or R(Reverse) gear position.
(Reverse) on a downhill grade.
essary wear. Use the foot brake or park-
Unexpected and sudden vehicle
ing brake to hold the car on an incline. Do
movement can occur if these pre-
not operate the clutch pedal rapidly and
CAUTION
cautions are not followed in the
repeatedly.
•
To avoid premature clutch wear
order identified.
and damage, do not drive with
•
If your vehicle has a manual
Downshifting
your foot resting on the clutch
transmission not equipped with a
When you must slow down in heavy traf-
pedal. Also, don’t use the clutch
ignition lock switch, it may move
fic or whilst driving up steep hills, down-
to hold the vehicle stopped on an
and cause a serious accident
shift before the engine starts to labour.
uphill grade, whilst waiting for a
when starting the engine without
Downshifting reduces the chance of
traffic light, etc.
depressing the clutch pedal
stalling and gives better acceleration
•
Do not use the shift lever as a
whilst the parking brake is
when you again need to increase your
handrest during driving, as this
released and the shift lever not in
speed. When the vehicle is travelling
can result in premature wear of
the N(Neutral) position.
down steep hills, downshifting helps
the transmission shift forks.
•
Do not use the engine brake
maintain safe speed and prolongs brake
•
To prevent possible damage to
(shifting from a high gear to
life.
the clutch system, do not start
lower gear) rapidly on slippery
with the
2nd
(second) gear
roads. The vehicle may slip caus-
engaged except when you start
ing an accident.
on a slippery road.
5 11
Driving your vehicle
Good driving practices
WARNING
•
Never take the car out of gear and
coast down a hill. This is extremely
•
Always buckle-up! In a collision,
hazardous. Always leave the car in
an unbelted occupant is signifi-
gear.
cantly more likely to be seriously
•
Don't "ride" the brakes. This can cause
injured or killed than a properly
them to overheat and malfunction.
belted occupant.
Instead, when you are driving down a
•
Avoid high speeds when corner-
long hill, shift to a lower gear. When
ing or turning.
you do this, engine braking will help
•
Do not make quick steering
slow the car.
wheel movements, such as sharp
•
Slow down before shifting to a lower
lane changes or fast, sharp turns.
gear. This will help avoid over-revving
•
The risk of rollover is greatly
the engine, which can cause damage.
increased if you lose control of
•
Slow down when you encounter cross
your vehicle at highway speeds.
winds. This gives you much better con-
•
Loss of control often occurs if
trol of your car.
two or more wheels drop off the
•
Be sure the car is completely stopped
roadway and the driver over-
before you attempt to shift into reverse.
steers to reenter the roadway.
The transmission can be damaged if
•
In the event your vehicle leaves
you do not. To shift into reverse,
the roadway, do not steer sharply.
depress the clutch, move the shift lever
Instead, slow down before pulling
to neutral, wait 3 seconds, then shift to
back into the travel lanes.
the reverse position.
•
Never exceed posted speed lim-
•
Exercise extreme caution when driving
its.
on a slippery surface. Be especially
careful when braking, accelerating or
shifting gears. On a slippery surface,
an abrupt change in vehicle speed can
cause the drive wheels to lose traction
and the vehicle to go out of control.
5 12
Driving your vehicle
AUTOMATIC TRANSMISSION
Type A
Type B
Lock release button prevents shift lever
Lock release button prevents shift lever
movement without first depressing the
movement without first depressing the
button.
button.
O/D button
Automatic mode
Sports mode
Depress the brake pedal and lock release button when shifting, if your vehicle is
equipped with shift lock system
The lock release button must be depressed whilst moving the shift lever.
The shift lever can be moved without depressing the lock release button.
OTQ057006R/OTQ057006R-1
5 13
Driving your vehicle
Automatic transmission operation
For smooth operation, depress the brake
pedal when shifting from N (Neutral) to a
CAUTION
The automatic transmission has 5 (or 4)
forward or reverse gear.
•
To avoid damage to your trans-
forward speeds and one reverse speed.
The individual speeds are selected auto-
mission, do not accelerate the
engine in R (Reverse) or any for-
matically, depending on the position of
WARNING - Automatic
ward gear position with the
the shift lever.
transmission
brakes on.
•
Always check the surrounding
•
When stopped on an incline, do
✽ NOTICE
areas near your vehicle for peo-
not hold the vehicle stationary
The first few shifts on a new vehicle, if
ple, especially children, before
with engine power. Use the serv-
the battery has been disconnected, may
shifting a car into D (Drive) or R
ice brake or the parking brake.
be somewhat abrupt. This is a normal
(Reverse).
•
Do not shift from N (Neutral) or P
condition, and the shifting sequence will
•
Before leaving the driver’s seat,
(Park) into D
(Drive), or R
adjust after shifts are cycled a few times
always make sure the shift lever
(Reverse) when the engine is
by the TCM (Transmission Control
is in the P (Park) position; then
above idle speed.
Module) or PCM (Powertrain Control
set the parking brake fully and
Module).
shut the engine off. Unexpected
and sudden vehicle movement
can occur if these precautions
are not followed in the order iden-
tified.
•
Do not use the engine brake
(shifting from a high gear to
lower gear) rapidly on slippery
roads.
The vehicle may slip causing an
accident.
5 14
Driving your vehicle
Transmission ranges
R (Reverse)
The indicator in the instrument cluster
CAUTION
Use this position to drive the vehicle
displays the shift lever position when the
The transmission may be damaged
backward.
ignition switch is in the ON position.
if you shift into P (Park) whilst the
vehicle is in motion.
CAUTION
P (Park)
Always come to a complete stop
Always come to a complete stop before
before shifting into or out of R
shifting into P (Park). This position locks
(Reverse); you may damage the
the transmission and prevents the drive
transmission if you shift into R
wheels from rotating.
whilst the vehicle is in motion,
except as explained in “Rocking the
vehicle” in this section.
WARNING
•
Shifting into P (Park) whilst the
vehicle is in motion will cause the
N (Neutral)
drive wheels to lock which will
The wheels and transmission are not
cause you to lose control of the
engaged. The vehicle will roll freely even
vehicle.
on the slightest incline unless the parking
•
Do not use the P (Park) position
brake or service brakes are applied.
in place of the parking brake.
Always make sure the shift lever
is latched in the P (Park) position
WARNING
and set the parking brake fully.
Do not drive with the shift lever in N
•
Never leave a child unattended in
(Neutral).
a vehicle.
The engine brake will not work and
lead to an accident.
5 15
Driving your vehicle
D (Drive)
2 (Second Gear, if equipped)
This is the normal forward driving posi-
Use 2 (Second Gear) for more power
tion. The transmission will automatically
when climbing hills and for increased
shift through a 5 (or 4)-gear sequence,
braking when going down hills. This posi-
providing the best fuel economy and
tion also helps reduce wheel spin on slip-
power.
pery surfaces. When the shift lever is
placed in 2 (Second Gear), the transmis-
For extra power when passing another
sion will automatically shift from first to
vehicle or climbing grades, depress the
second gear.
accelerator fully, at which time the trans-
mission will automatically downshift to
L (Low, if equipped)
the next lower gear.
Move the shift lever to this position in
OTQ057007R
hard pulling situations and for climbing
✽ NOTICE
steep grades.
O/D (Over Drive) system
Always come to a complete stop before
(if equipped)
shifting into D (Drive).
CAUTION
Pressing the O/D system button cancels
Do not exceed the recommended
and engages the overdrive system.
When the O/D system is cancelled, the
maximum speeds in
2
(Second
O/D OFF indicator illuminates and the
Gear) or L
(Low). Operating the
vehicle at speeds above the maxi-
transmission gear range is limited to 1st
mum recommended, for 2 (Second
through 3rd.
Gear) or L (Low) may cause exces-
sive heat to develop which could
result in damage to or failure of the
automatic transmission.
5 16
Driving your vehicle
The transmission will not shift to 4th gear
✽ NOTICE
until the O/D system button is pressed
•
In sports mode, the driver must exe-
again to release the switch.
cute upshifts in accordance with road
When driving down a sloping road with
conditions, taking care to keep the
the transmission in O/D (4th), you can
engine speed below the red zone.
decrease the vehicle speed without using
+ (UP)
•
In sports mode, only the 5 forward
the brakes by pressing the O/D button.
gears can be selected. To reverse or
Sports mode
When the ignition is switched OFF, O/D
park the vehicle, move the shift lever
OFF mode is automatically cancelled.
to the R (Reverse) or P (Park) position
as required.
•
In sports mode, downshifts are made
O/D OFF Indicator
- (DOWN)
automatically when the vehicle slows
This indicator light illuminates in the
OTQ057007R-1
down. When the vehicle stops, 1st gear
instrument panel when the O/D mode is
Sports mode (if equipped)
is automatically selected.
cancelled.
•
In sports mode, when the engine rpm
Whether the vehicle is stationary or in
approaches the red zone shift points
motion, sports mode is selected by push-
are varied to upshift automatically.
ing the shift lever from the D (Drive) posi-
•
To maintain the required levels of
tion into the manual gate. To return to D
vehicle performance and safety, the
(Drive) range operation, push the shift
system may not execute certain
lever back into the main gate.
gearshifts when the shift lever is oper-
ated.
In sports mode, moving the shift lever
•
When driving on a slippery road,
backwards and forwards will allow you to
push the shift lever forward into the
make gearshifts rapidly. In contrast to a
+(up) position. This causes the trans-
manual transmission, the sports mode
mission to shift into the
2nd gear
allows gearshifts with the accelerator
which is better for smooth driving on
pedal depressed.
a slippery road. Push the shift lever to
Up (+)
: Push the lever forward once to
the -(down) side to shift back to the 1st
shift up one gear.
gear.
Down (-) : Pull the lever backwards once
to shift down one gear.
5 17
Driving your vehicle
Good driving practices
• Exercise extreme caution when driving
(Continued)
on a slippery surface. Be especially
•
Never move the gear shift lever from P
• Loss of control often occurs if
careful when braking, accelerating or
(Park) or N (Neutral) to any other posi-
two or more wheels drop off the
shifting gears. On a slippery surface,
tion with the accelerator pedal
roadway and the driver over-
an abrupt change in vehicle speed can
depressed.
cause the drive wheels to lose traction
steers to reenter the roadway.
•
Never move the gear shift lever into P
and the vehicle to go out of control.
• In the event your vehicle leaves
(Park) when the vehicle is in motion.
• Optimum vehicle performance and
the roadway, do not steer sharply.
•
Be sure the car is completely stopped
Instead, slow down before pulling
economy is obtained by smoothly
before you attempt to shift into R
back into the travel lanes.
depressing and releasing the accelera-
(Reverse).
tor pedal.
• Never exceed posted speed lim-
•
Never take the car out of gear and
its.
coast down a hill. This may be
extremely hazardous. Always leave the
WARNING
car in gear when moving.
• Always buckle-up! In a collision,
•
Do not "ride" the brakes. This can
WARNING
an unbelted occupant is signifi-
cause them to overheat and malfunc-
cantly more likely to be seriously
If your vehicle becomes stuck in
tion. Instead, when you are driving
injured or killed than a properly
snow, mud, sand, etc., then you
down a long hill, shift to a lower gear.
may attempt to rock the vehicle free
belted occupant.
When you do this, engine braking will
by moving it forward and backward.
• Avoid high speeds when corner-
help slow the car.
Do not attempt this procedure if
ing or turning.
•
Slow down before shifting to a lower
people or objects are anywhere
• Do not make quick steering
gear. Otherwise, the lower gear may
near the vehicle. During the rocking
wheel movements, such as sharp
operation the vehicle may suddenly
not be engaged.
lane changes or fast, sharp turns.
move forward of backward as it
•
Always use the parking brake. Do not
• The risk of rollover is greatly
becomes unstuck, causing injury
depend on placing the transmission in
increased if you lose control of
or damage to nearby people or
P (Park) to keep the car from moving.
your vehicle at highway speeds.
objects.
(Continued)
5 18
Driving your vehicle
Moving up a steep grade from a stand-
Shift lock system (if equipped)
Ignition key interlock system
ing start
(if equipped)
For your safety, the Automatic
To move up a steep grade from a stand-
Transmission has a shift lock system
The ignition key cannot be removed
ing start, depress the brake pedal, shift
which prevents shifting the transmission
unless the shift lever is in the P (Park)
the shift lever to D
(Drive). Select the
out of P (Park) unless the brake pedal is
position. If the ignition switch is in any
appropriate gear depending on load
depressed.
other position, the key cannot be
weight and steepness of the grade, and
removed.
release the parking brake. Depress the
To shift the transmission out of P (Park):
accelerator gradually whilst releasing the
Type A
service brakes.
1. Depress and hold the brake pedal.
When accelerating from a stop on a
steep hill, the vehicle may have a ten-
2. Depress the lock release button and
dency to roll backwards. Shifting the
move the shift lever.
shift lever into 2 (Second Gear) will
Type B (If the ignition key interlock sys-
help prevent the vehicle from rolling
tem is equipped)
backwards.
1. Depress and hold the brake pedal.
2. Start the engine or turn the ignition to
the ON position.
3. Depress the lock release button and
move the shift lever.
If
the brake pedal is repeatedly
depressed and released with the shift
lever in the P (Park) position, a chattering
sound near the shift lever may be heard.
This is a normal condition.
5 19
Driving your vehicle
BRAKE SYSTEM
Power brakes
(Continued)
WARNING - Brakes
Your vehicle has power-assisted brakes
•
Always, confirm the position of
that adjust automatically through normal
•
Do not drive with your foot rest-
the brake and accelerator pedal
usage.
ing on the brake pedal. This will
before driving. If you do not
In the event that the power-assisted
create abnormal high brake tem-
check the position of the acceler-
brakes lose power because of a stalled
peratures, excessive brake lining
ator and brake pedal before driv-
engine or some other reason, you can
and pad wear, and increased
ing, you may depress the acceler-
still stop your vehicle by applying greater
stopping distances.
ator instead of the brake pedal. It
force to the brake pedal than you nor-
•
When descending a long or steep
may cause a serious accident.
mally would. The stopping distance, how-
hill, shift to a lower gear and
ever, will be longer.
avoid continuous application of
When the engine is not running, the
the brakes. Continuous brake
reserve brake power is partially depleted
application will cause the brakes
each time the brake pedal is applied. Do
to overheat and could result in a
not pump the brake pedal when the
temporary loss of braking per-
power assist has been interrupted.
formance.
Pump the brake pedal only when neces-
•
Wet brakes may impair the vehi-
sary to maintain steering control on slip-
cle’s ability to sefely slow down;
pery surfaces.
the vehicle may also pull to one
side when the brakes are applied.
Applying the brakes lightly will
indicate whether they have been
affected in this way. Always test
your brakes in this fashion after
driving through deep water. To
dry the brakes, apply them lightly
whilst maintaining a safe forward
speed until brake performance
returns to normal.
(Continued)
5 20
