Hyundai i800 (2016 year). Instruction - part 10

Features of your vehicle

Face-Level

Floor-Level

Air flow is directed toward the upper body

Most of the air flow is directed to the

and face. Additionally, each outlet can be

floor, with a small amount of the air being

controlled to direct the air discharged

directed to the windscreen and side win-

from the outlet.

dow defrosters.

Bi-Level

Floor/Defrost-Level

Air flow is directed towards the face and

Most of the air flow is directed to the floor

OTQ047071R

the floor.

and the windscreen with a small amount

Instrument panel vents

directed to the side window defrosters.

The outlet vents can be opened or closed

separately using the thumbwheel.

Also, you can adjust the direction of air

delivery from these vents using the vent

control lever as shown.

4 91

Features of your vehicle

■ Type A

■ Type B

Recirculated air position

With the recirculated air

position selected, air from

the passenger compart-

ment will be drawn through

the heating system and

heated or cooled according

to the function selected.

❈ According to the outside temperature if

the recirculation air position is on for a

long time, the air intake position will auto-

matically change to the outside(fresh) air

OTQ045230

OTQ045264

position to ventilate the inside air.

Temperature control

Air intake control

The temperature control button (knob)

The air intake control is used to select

Outside (fresh) air position

allows you to control the temperature of

the outside (fresh) air position or recircu-

With the outside (fresh) air

the airflow in the vehicle.

lated air position.

position selected, air enters

To change the air intake control position,

the vehicle from outside

To change the temperature :

press the control button.

and is heated or cooled

• Press the

(red) switch to increase

according to the function

temperature.

selected.

• Press the

(blue) switch to decrease

temperature.

The temperature status will be displayed

at the above switch panel as a indicator.

4 92

Features of your vehicle

✽ NOTICE

Prolonged operation of the heater in the

WARNING

recirculated air position

(without air

•

Continue using the climate con-

conditioning selected) may cause fog-

trol system in the recirculated air

ging of the windscreen and side windows

position may allow humidity to

and the air within the passenger com-

increase inside the vehicle which

partment may become stale.

may fog the glass and obscure

In addition, prolonged use of the air con-

visibility.

ditioning with the recirculated air posi-

•

Do not sleep in a vehicle with the

tion selected will result in excessively dry

air conditioning or heating sys-

air in the passenger compartment.

tem on. It may cause serious

harm or death due to a drop in the

oxygen level and/or body temper-

OTQ045235

ature.

Fan speed control

•

Continue using the climate control

The fan speed control knob allows you to

system in the recirculated air

control the fan speed of the airflow in the

position can cause drowsiness or

vehicle.

sleepiness, and loss of vehicle

To change the fan speed:

control. Set the air intake control

• Turn the knob to the right

(+) to

to the outside (fresh) air position

increase fan speed.

as much as possible whilst driv-

• Turn the knob to the left (-) to decrease

fan speed.

To turn off the fan speed, press the OFF

button.

4 93

Features of your vehicle

OTQ045238

OTQ045240

OTQ047076

Air conditioning

OFF mode (for 1st)

Rear heating and air conditioning

Press the A/C button to turn the air con-

Press the front blower OFF button to turn

(if equipped)

ditioning system on (indicator light will

off the front air climate control system.

The temperature, fan speed and mode of

illuminate).

However, you can still operate the mode

the rear climate control system can be

Press the button again to turn the air

and air intake buttons as long as the igni-

controlled independently regardless of the

conditioning system off.

tion switch is in the ON position.

front climate control system operation.

Turn the rear climate control selection

knob to the “R” and set the rear tempera-

ture, fan speed and mode to the desired

position.

However, the front climate control system

should be operated together for rear air

conditioning;

1. Set the front fan speed to the desired

position.

2. Push the air conditioning button.

3. Set the rear temperature, fan speed

and mode to the desired position.

4 94

Features of your vehicle

In the front seat

The rear mode is selected automatically

by selecting the rear temperature control.

•

: Rear air blows from the upper

vents on the rear side ceiling.

•

: Rear air blows from the upper

vents on the rear side ceiling and

the lower vents on the floor.

•

: Rear air blows from the lower

vents on the floor.

OTQ045231

In the rear seat

OTQ047077

Rear vents

The vent can be adjusted by rotating the

thumb wheel.

✽ NOTICE

If all the vents are closed, it may cause

some noise. Always open

2 vents or

more.

OTQ047079

Rear temperature control

To change the air temperature in the rear

passenger compartment, turn the knob

to the right for warm and hot air or left for

cooler air.

4 95

Features of your vehicle

In the front seat

System operation

Operation Tips

•

To keep dust or unpleasant fumes from

Ventilation

entering the car through the ventilation

1. Set the mode to the

position.

system, temporarily set the air intake

2. Set the air intake control to the outside

control to the recirculated air position.

(fresh) air position.

Be sure to return the control to the

3. Set the temperature control to the

fresh air position when the irritation

desired position.

has passed to keep fresh air in the

4. Set the fan speed control to the

vehicle. This will help keep the driver

desired speed.

alert and comfortable.

OTQ047095

•

Air for the heating/cooling system is

In the rear seat

Heating

drawn in through the grilles just ahead

1. Set the mode to the

position.

of the windscreen. Care should be

taken that these are not blocked by

2. Set the air intake control to the outside

leaves, snow, ice or other obstructions.

(fresh) air position.

•

To prevent interior fog on the wind-

3. Set the temperature control to the

screen, set the air intake control to the

desired position.

fresh air position and fan speed to the

4. Set the fan speed control to the

desired position, turn on the air condi-

desired speed.

tioning system, and adjust the temper-

5. If dehumidified heating is desired, turn

ature control to desired temperature.

OTQ047080

the air conditioning system

(if

Rear fan speed control

equipped) on.

To change the fan speed, turn the knob

• If the windscreen fogs up, set the mode

to the right for higher speed or left for

to the

or

position.

lower speed.

To turn off the fan, turn the knob to the 0

position.

4 96

Features of your vehicle

Air conditioning (if equipped)

Air conditioning system operation tips

✽ NOTICE

HYUNDAI Air Conditioning Systems are

•

If the vehicle has been parked in direct

•

When using the air conditioning sys-

filled with environmentally friendly

sunlight during hot weather, open the

tem, monitor the temperature gauge

R-134a refrigerant.

closely whilst driving up hills or in

windows for a short time to let the hot

1. Start the engine. Push the air condi-

heavy traffic when outside tempera-

air inside the vehicle escape.

tioning button.

tures are high. Air conditioning sys-

•

To help reduce moisture inside of the

2. Set the mode to the

position.

tem operation may cause engine over-

windows on rainy or humid days,

heating. Continue to use the blower

decrease the humidity inside the vehi-

3. Set the air intake control to the outside

fan but turn the air conditioning sys-

cle by operating the air conditioning

air or recirculated air position.

tem off if the temperature gauge indi-

system.

4. Adjust the fan speed control and tem-

cates engine overheating.

•

During air conditioning system opera-

perature control to maintain maximum

•

When opening the windows in humid

tion, you may occasionally notice a

comfort.

weather air conditioning may create

slight change in engine speed as the

• When maximum cooling is desired, set

water droplets inside the vehicle.

air conditioning compressor cycles.

the temperature control to the extreme

Since excessive water droplets may

This is a normal system operation

left position, then set the fan speed

cause damage to electrical equipment,

characteristic.

control to the highest speed.

air conditioning should only be run

•

Use the air conditioning system every

with the windows closed.

month only for a few minutes to ensure

maximum system performance.

•

When using the air conditioning sys-

tem, you may notice clear water drip-

ping (or even puddling) on the ground

under the passenger side of the vehi-

cle. This is a normal system operation

characteristic.

4 97

Features of your vehicle

✽ NOTICE

Checking the amount of air con-

Outside air

•

Replace the filter according to the

ditioner refrigerant and compres-

Maintenance Schedule.

sor lubricant

Recirculated

If the car is being driven in severe

When the amount of refrigerant is low,

air

conditions such as dusty or rough

the performance of the air conditioning is

roads, more frequent air conditioner

reduced. Overfilling also has a negative

filter inspections and changes are

impact on the air conditioning system.

required.

Therefore, we recommend that the sys-

•

When the air flow rate suddenly

tem be inspected by a HYUNDAI autho-

Blower

decreases, we recommend that the

rised repairer.

Heater core

system be checked by a HYUNDAI

Climate control

Evaporator

air filter

authorised repairer.

core

1LDA5047

✽ NOTICE

Climate control air filter

It is important when servicing the air

conditioning system that the correct

(if equipped)

type and amount of oil and refrigerant is

The climate control air filter installed

used. Otherwise, damage to the com-

behind the glove box filters the dust or

pressor and abnormal system operation

other pollutants that come into the vehi-

may occur.

cle from the outside through the heating

and air conditioning system. If dust or

other pollutants accumulate in the filter

WARNING

over a period of time, the air flow from the

Improper service may cause seri-

air vents may decrease, resulting in

ous injury to the person performing

moisture accumulation on the inside of

the service. For more detailed infor-

the windscreen even when the outside

mation, we recommend that you

(fresh) air position is selected. If this hap-

contact a HYUNDAI authorised

pens, we recommend that the climate

repairer.

control air filter be replaced by a

HYUNDAI authorised repairer.

4 99

Features of your vehicle

WINDSCREEN DEFROSTING AND DEFOGGING

•

For maximum defrosting, set the tem-

WARNING - Windscreen

perature control to the extreme

heating

right/hot position and the fan speed

control to the highest speed.

Do not use the

or

position

during cooling operation in

•

If warm air to the floor is desired whilst

extremely humid weather. The dif-

defrosting or defogging, set the mode

ference between the temperature of

to the floor-defrost position.

the outside air and that of the wind-

•

Before driving, clear all snow and ice

screen could cause the outer sur-

from the windscreen, rear window, out-

face of the windscreen to fog up,

side rear view mirrors, and all side win-

causing loss of visibility. In this

dows.

case, set the mode selection knob

•

Clear all snow and ice from the bonnet

or button to the

position and

and air inlet in the cowl grill to improve

OTQ045268

fan speed control knob or button to

heater and defroster efficiency and to

Manual climate control system

the lower speed.

reduce the probability of fogging up the

To defog inside windscreen

inside of the windscreen.

1. Select any fan speed except “0” posi-

tion.

2. Select desired temperature.

3. Select the

or

position.

4. If the

position is selected, the out-

side (fresh) air and air conditioning will

be selected automatically.

If the air conditioning and outside (fresh)

air position are not selected automatical-

ly, press the corresponding button manu-

ally.

4 100

Features of your vehicle

If the air-conditioning, outside (fresh) air

position and higher fan speed are not

selected automatically, adjust the corre-

sponding button or knob manually.

If the

position is selected, lower fan

speed is controlled to higher fan speed.

OTQ045269

OTQ045270

To defrost outside windscreen

Automatic climate control system

1. Set the fan speed to the highest

To defog inside windscreen

(extreme right) position.

1. Select desired fan speed.

2. Set the temperature to the extreme hot

2. Select desired temperature.

position.

3. Press the defroster button (

).

3. Select the

position.

4. The air-conditioning will turn on

4. The outside (fresh) air and air condi-

according to the detected ambient

tioning will be selected automatically.

temperature, outside (fresh) air posi-

tion and higher fan speed will be

selected automatically.

4 101

Features of your vehicle

Defogging logic (if equipped)

To reduce the possibility of fogging up

the inside of the windscreen, the air

intake or air conditioning are controlled

automatically according to certain condi-

tions such as

position. To cancel or

return the defogging logic, do the follow-

ing.

OTQ045271

OTQ045277

To defrost outside windscreen

Manual climate control system

1. Set fan speed to the highest position.

1. Turn the ignition switch to the ON posi-

2. Set temperature to the extreme hot

tion.

(HI) position.

2. Turn the mode selection knob to the

3. Press the defroster button (

).

defrost position (

).

4. The air-conditioning will turn on

3. Push the air intake control button at

according to the detected ambient

least 5 times within 3 seconds.

temperature and outside

(fresh) air

The indicator light in the air intake control

position will be selected automatically.

button will blink 3 times with 0.5 second

If the

position is selected, lower fan

of interval. It indicates that the defogging

speed is controlled to higher fan speed.

logic is canceled or returned to the pro-

grammed status.

If the battery has been discharged or dis-

connected, it resets to the defog logic

status.

4 102

Features of your vehicle

OTQ045272

Automatic climate control system

1. Turn the ignition switch to the ON posi-

tion.

2. Press the defroster button (

).

3. Whilst pressing the air conditioning

button (A/C), press the air intake con-

trol button at least 5 times within 3 sec-

onds.

The indicator on the air intake button

blinks 3 times with 0.5 seconds of inter-

val. It indicates that the defogging logic is

canceled or returned to the programmed

status.

4 103

Features of your vehicle

STORAGE COMPARTMENT

These compartments can be used to

store small items required by the driver

or passengers.

CAUTION

• To avoid possible theft, do not

leave valuables in the storage

compartment.

• Always keep the storage com-

partment covers closed whilst

driving. Do not attempt to place

so many items in the storage

OTQ047107/H

OTQ047108

compartment that the storage

compartment cover can not close

Glove box

Sunglass holder (if equipped)

securely.

To open the glove box, pull the handle

To open the sunglass holder, press the

and the glove box will automatically

cover and the holder will slowly open.

open. Close the glove box after use.

Place your sunglasses in the compart-

WARNING - Flammable

ment door with the lenses facing out.

materials

Push to close.

WARNING

Do not store cigarette lighters,

To reduce the risk of injury in an

propane cylinders, or other flamma-

accident or sudden stop, always

ble/explosive materials in the vehi-

keep the glove box door closed

cle. These items may catch fire

whilst driving.

and/or explode if the vehicle is

exposed to hot temperatures for

extended periods.

CAUTION

Do not keep food in the glove box

for a long time.

4 104

Features of your vehicle

WARNING

•

Do not keep objects except sun-

glass inside the sunglass holder.

Such objects can be thrown from

the holder in the event of a sud-

den stop or an accident, possibly

injuring the passengers in the

vehicle.

•

Do not open the sunglass holder

whilst the vehicle is moving. The

rear view mirror of the vehicle

can be blocked by an open sun-

OTQ047109/H

OTQ045081R

glass holder.

Multi box (if equipped)

Cool box (if equipped)

•

Do not put the glasses forcibly

To open the cover, pull the handle down.

You can keep beverage cans or other

into a sunglass holder to prevent

Close the cover after use.

items cool using the open/close lever of

breakage or deformation of

the vent installed in the multi box.

glasses. It may cause personal

1. Turn on the fan and set the tempera-

injury if you try to open it forcibly

ture control to the desired position.

when the glasses are jammed in

holder.

4 105

Features of your vehicle

2. Set the mode control to the face (

) or bi-level (

) position.

WARNING

3. Turn the open/close lever of the vent

Do not put the perishable food in

installed in the multi box to the open

the cool box because it may not be

position.

able to maintain the necessary con-

sistent temperature to keep the

4. When the cool box is not used, turn

food fresh.

the lever to its closed position.

For improving the effectiveness of the

cool box, do as follows;

1. Set the temperature to the cold

(extreme left) position for cool air.

Turn on the air conditioning system for

cooler air.

2. Set the fan speed to the highest

(extreme right) position.

3. Set the mode to the face (

) posi-

tion.

✽ NOTICE

If some items in the cool box block the

vent, the cooling effectiveness of the cool

box is reduced.

4 106

Features of your vehicle

INTERIOR FEATURES

Front

WARNING

• Do not hold the lighter in after it

is already heated because it will

overheat.

• If the lighter does not pop out

within 30 seconds, remove it to

prevent overheating.

• Do not insert foreign objects into

the socket of the cigarette lighter.

It may damage the cigarette

OTQ047111R

lighter.

Rear (if equipped)

OTQ047110R

Cigarette lighter

CAUTION

For the cigarette lighter to work, the igni-

tion switch must be in the ACC position

We recommend that you use parts

or the ON position.

for replacement from a HYUNDAI

authorised repairer.

To open the cover, press the cover and it

will slowly open.

The use of plug-in accessories

(shavers, hand-held vacuums, and

To use the cigarette lighter, push it all the

coffee pots, etc.) may damage the

way into its socket. When the element

socket or cause electrical failure.

has heated, the lighter will pop out to the

1VQA2187

“ready” position.

Ashtray

WARNING - Ashtray use

• Do not use the vehicle’s ashtrays

as waste receptacles.

• Putting lit cigarettes or matches in

an ashtray with other combustible

materials may cause a fire.

4 107

Content   ..  8  9  10  11   ..
