Features of your vehicle

Cruise Indicator Light

Cruise SET Indicator Light

Glow indicator

(if equipped)

(if equipped)

(Diesel engine)

SET

The indicator light illuminates when the

This indicator light illuminates:

CRUISE

ignition switch is placed at the ON posi-

• When the cruise control speed is set.

tion. The engine can be started after the

preheat indicator light goes off. The illu-

This indicator light illuminates:

For more details, refer to “Cruise Control

minating time varies with the water tem-

• When the cruise control system is

System” in chapter 5.

perature, air temperature and battery

enabled.

condition.

For more details, refer to “Cruise Control

✽ NOTICE

System” in chapter 5.

If the engine was not started within 10

seconds after the preheating is complet-

ed, turn the ignition switch once more to

the LOCK position during 10 seconds,

and then to the ON position, in order to

preheat again.

CAUTION

If the preheat indicator light contin-

ues to illuminate or flash on and off

after the engine has warmed up or

whilst driving, we recommend that

the system be checked by a

HYUNDAI authorised repairer.

4 57

Features of your vehicle

Fuel filter warning light

Overspeed warning

Key reminder warning chime

(Diesel engine)

(if equipped)

120

(if equipped)

km/h

If the driver’s door is opened whilst the

ignition key is left in the ignition switch

This warning light illuminates for 3 sec-

(ACC or LOCK position), the key

Overspeed warning light

onds after the ignition switch is set to the

reminder warning chime will sound. This

If you drive with the speed of 120 km/h or

ON position and then it will go out. If it

is to prevent you from locking your keys

more, the overspeed warning light will

lights up whilst the engine is running, it

in the vehicle. The chime sounds until the

blink. This is to prevent you from driving

indicates that water has accumulated

key is removed from the ignition switch or

your vehicle with overspeed.

inside the fuel filter. If this happens,

the driver’s door is closed.

remove the water from the fuel filter. For

more information, refer to “Fuel filter” in

Overspeed warning chime

section 7.

If you drive with the speed of 120 km/h or

more, the overspeed warning chime will

sound for about 5 seconds. This is to pre-

CAUTION

vent you from driving your vehicle with

When the fuel filter warning light is

overspeed.

illuminated, engine power (vehicle

speed & idle speed) may decrease.

If you keep driving with the warning

light on, you can damage your vehi-

cle's engine parts and injection sys-

tem of the Common Rail. If this

occurs, we recommend that the

system be checked by a HYUNDAI

authorised repairer.

4 58

Features of your vehicle

Low Tyre Pressure Warning

This warning light remains on after

Light (if equipped)

blinking for approximately 60 seconds or

repeats blinking and off at the intervals

of approximately 3 seconds:

• When there is a malfunction with the

This warning light illuminates:

TPMS.

•

Once you set the ignition switch or

In this case, we recommend that you

Engine Start/Stop Button to the ON

have the vehicle inspected by a

position.

HYUNDAI authorised repairer as soon

- It illuminates for approximately 3 sec-

as possible.

onds and then goes off.

For more details, refer to

“Tyre

•

When one or more of your tyres are

Pressure Monitoring System (TPMS)”

significantly underinflated.

in chapter 6.

For more details, refer to

“Tyre

Pressure Monitoring System (TPMS)”

WARNING - Safe Stopping

in chapter 6.

• The TPMS cannot alert you to

severe and sudden tyre damage

caused by external factors.

• If you notice any vehicle instabili-

ty, immediately take your foot off

the accelerator pedal, apply the

brakes gradually with light force,

and slowly move to a safe posi-

tion off the road.

4 59

Features of your vehicle

REAR PARKING ASSIST SYSTEM (IF EQUIPPED)

Operation of the rear parking

WARNING

assist system

The rear parking assist system is a

Operating condition

supplementary function only. The

• This system will activate when revers-

operation of the rear parking assist

ing with the ignition switch ON.

system can be affected by several

If the vehicle is moving at a speed over

factors

(including environmental

3 mph (5 km/h), the system may not be

conditions). It is the responsibility

activated correctly.

of the driver to always check the

• The sensing distance whilst the rear

area behind the vehicle before and

parking assist system is in operation is

whilst reversing.

approximately 47 in. (120 cm).

Sensors

OTQ047055

• When more than two objects are

sensed at the same time, the closest

The rear parking assist system assists

one will be recognized first.

the driver during backward movement of

the vehicle by chiming if any object is

sensed within a distance of 47 in. (120

Types of warning sound

cm) behind the vehicle. This system is a

• When an object is 47 in. to 32 in. (120

supplemental system and it is not intend-

cm to 81 cm) from the rear bumper:

ed to nor does it replace the need for

Buzzer beeps intermittently.

extreme care and attention of the driver.

• When an object is 31 in. to 16 in. (80

The sensing range and objects

cm to 41 cm) from the rear bumper:

detectable by the rear parking assist sen-

Buzzer beeps more frequently.

sors are limited. Whenever reversing, pay

• When an object is within 15 in. (40 cm)

as much attention to what is behind you

of the rear bumper:

as you would in a vehicle without a rear

Buzzer sounds continuously.

parking assist system.

4 60

Features of your vehicle

REARVIEW CAMERA (IF EQUIPPED)

HAZARD WARNING FLASHER

1. Vehicle width

2.100 cm from the rear bumper

3.50 cm from the rear bumper

4.300 cm from the rear bumper

✽ NOTICE

The warning "Warning ! Check sur-

roundings for safety " will appear on the

rearview display when the rearview

camera is activated.

OTQ045415

OTQ045267R

WARNING

The hazard warning flasher should be

•

This system is a supplementary

used whenever you find it necessary to

function only. It is the responsi-

stop the car in a hazardous location.

bility of the driver to always

When you must make such an emer-

check the inside/outside rearview

gency stop, always pull off the road as far

mirror and the area behind the

as possible.

vehicle before and whilst backing

The hazard warning lights are turned on

up because there is a dead zone

by pushing in the hazard switch. This

that cannot be seen through the

causes all turn signal lights to blink. The

camera.

OTQ055210R

hazard warning lights will operate even

•

Always keep the camera lens

The rearview camera will activate when

though the key is not in the ignition

clean. If the lens is covered with

the back-up light is ON with the ignition

switch.

foreign matter, the camera may

switch ON and the shift lever in the R

To turn the hazard warning lights off,

not operate normally.

(Reverse) position.

push the switch a second time.

4 63

Features of your vehicle

LIGHTING

Battery saver function

•

The purpose of this feature is to pre-

vent the battery from being dis-

charged. The system automatically

turns off the parking lights when the

driver removes the ignition key and

opens the driver-side door.

•

With this feature, the parking lights will

be turned off automatically if the driver

parks on the side of road at night.

If necessary, to keep the lights on

when the ignition key is removed, per-

form the following:

OTQ045245R

OTQ045246R

1) Open the driver-side door.

Lighting control

Parking light position (

)

2) Turn the parking lights OFF and ON

The light switch has a Headlight and a

When the light switch is in the parking

again using the light switch on the

Parking light position.

light position

(1st position), the tail,

steering column.

To operate the lights, turn the knob at the

license and instrument panel lights are

end of the control lever to one of the fol-

ON.

CAUTION

lowing positions:

If the driver gets out of the vehicle

(1) OFF position

through other doors

(except dri-

(2) Parking light position

ver’s door), the battery saver func-

(3) Headlight position

tion does not operate. Therefore, it

(4) Auto light position (if equipped)

causes the battery to be dis-

charged. In this case, make sure to

turn off the lamp before getting out

of the vehicle.

4 64

Features of your vehicle

CAUTION

•

Do not cover or spill anything on

the sensor

(1) located on the

instrument panel.

•

Do not clean the sensor using a

window cleaner, the cleanser may

leave a light film which could

interfere with sensor operation.

•

If your vehicle has window tint or

other types of metallic coating on

the front windscreen, the AUTO

OTQ045247R

OTQ045244R

light system may not work proper-

Headlight position (

)

AUTO light position (if equipped)

When the light switch is in the AUTO

When the light switch is in the headlight

position

(2nd position) the head, tail,

position, the parking (position) light and

license and instrument panel lights are

headlights will be turned ON or OFF

ON.

automatically depending on the amount

of light outside the vehicle.

✽ NOTICE

Even with the AUTO light feature in oper-

ation, it is recommended to manually turn

The ignition switch must be in the ON

ON the lights when driving at night or in

position to turn on the headlights.

a fog, or when you enter dark areas,

such as tunnels and parking facilities.

4 65

Features of your vehicle

OTQ045248R

OTQ045249R

OTQ045256R

High - beam operation

To flash the headlights, pull the lever

Turn signals and lane change sig-

towards you. It will return to the normal

nals

To turn on the high beam headlights,

(low beam) position when released. The

push the lever away from you. Pull it back

The ignition switch must be on for the

headlight switch does not need to be on

for low beams.

turn signals to function. To turn on the

to use this flashing feature.

The high-beam indicator will light when

turn signals, move the lever up or down

the headlight high beams are switched

(A). Green arrow indicators on the instru-

on. To prevent the battery from being dis-

ment panel indicate which turn signal is

charged, do not leave the lights on for a

operating.

prolonged time whilst the engine is not

They will self-cancel after a turn is com-

running.

pleted. If the indicator continues to flash

after a turn, manually return the lever to

the OFF position.

WARNING

To signal a lane change, move the turn

Do not use high beam when there

signal lever slightly and hold it in position

are other vehicles. Using high

(B). The lever will return to the OFF posi-

beam could obstruct the other dri-

tion when released.

ver's vision.

4 66

Features of your vehicle

If an indicator stays on and does not

flash or if it flashes abnormally, one of the

turn signal bulbs may be burned out and

will require replacement.

✽ NOTICE

If an indicator flash is abnormally quick

or slow, a bulb may be burned out or

have a poor electrical connection in the

circuit.

OTQ047056R

OTQ047132R

Front fog light (if equipped)

Rear fog light (if equipped)

Fog lights are used to provide improved

To turn the rear fog lights on, turn the

visibility when visibility is poor due to fog,

headlight switch to the headlight on posi-

rain or snow, etc. The fog lights will turn

tion and press the rear fog light switch

on when fog light switch is pressed after

(light on switch will illuminate).

the parklight is turned on.

The rear fog lights turn on when the rear

To turn off the fog lights, press the switch

fog switch is pressed after the front fog

again.

switch is turned to ON and the headlight

switch to the parklight position.

(if

equipped)

CAUTION

To turn the rear fog lights off, press the

When in operation, the fog lights

rear fog light switch again or turn the

consume large amounts of vehicle

headlight switch to the OFF position.

electrical power. Only use the fog

lights when visibility is poor.

4 67

Features of your vehicle

Daytime running light

Listed below are the examples of proper

(if equipped)

switch settings. For loading conditions

other than those listed below, adjust the

Daytime Running Lights (DRL) can make

switch position so that the beam level

it easier for others to see the front of your

may be the nearest as the condition

vehicle during the day. DRL can be help-

obtained according to the list.

ful in many different driving conditions,

and it is especially helpful after dawn and

Switch position

before sunset.

Loading condition

The DRL system will make the head-

Wagon

Van

lights turn OFF when:

Driver only

0

0

1. The parklight switch is ON.

Driver + Front passenger

0

0

2. Engine stops.

OTQ047133R

Driver + Front passenger

1

-

Headlight levelling device

+ 4th row passenger

(if equipped)

Full passengers

Manual type

1

-

To adjust the headlight beam level

(including driver)

according to the number of the passen-

Full passengers (including

gers and the loading weight in the lug-

driver) + Maximum per-

2

1

gage area, turn the beam levelling

switch.

missible loading

The higher the number of the switch

Driver + Maximum per-

position, the lower the headlight beam

3

1

level. Always keep the headlight beam at

missible loading

the proper levelling position, or head-

lights may dazzle other road users.

4 68

Features of your vehicle

WIPERS AND WASHERS

Windscreen wiper/washer

Rear window wiper/washer

A : Wiper speed control

(if equipped)

·

- Single wipe

· 0 - Off

Type A

Type A

· --- - Intermittent wipe

(if equipped)

· 1 - Low wiper speed

· 2 - High wiper speed

B : Intermittent wipe time adjustment

C : Wash with brief wipes*

D : Rear wiper/washer control*

Type B

Type B

·

- Spraying washer fluid

·

- Continuous wipe

· 0 - Off

·

- Wash with brief wipes

* : if equipped

OTQ048902/OTQ049902/OTQ048909/OTQ049909

4 69

Features of your vehicle

Windscreen wipers

✽ NOTICE

Windscreen washers

Operates as follows when the ignition

•

When you operate the wipers, if your

In the 0 position, pull the lever gently

switch is turned ON.

vehicle has a problem in any part of

toward you to spray washer fluid on the

: For a single wiping cycle, push the

the wiper operation system, the wiper

windscreen and to run the wipers 1-3

lever upward and release it with the

may operate in the 1 mode regardless

cycles.

lever in the 0 position. The wipers

of the wiper switch position. In this

Use this function when the windscreen is

will operate continuously if the lever

case, we recommend that the system

dirty.

is pushed upward and held.

be checked by a HYUNDAI autho-

The spray and wiper operation will con-

0 : Wiper is not in operation.

rised repairer.

tinue until you release the lever.

•

When the ignition key is removed, the

--- : Wiper operates intermittently at the

If the washer does not work, check the

wiper blade sometimes may move to

same wiping intervals. Use this

washer fluid level. If the fluid level is not

properly position slightly for reducing

mode in a light rain or mist. To vary

sufficient, you will need to add appropri-

the deterioration of the windscreen

the speed setting, turn the speed

ate non-abrasive windscreen washer

wipers.

control knob.

fluid to the washer reservoir.

1 : Normal wiper speed

The reservoir filler neck is located in the

2 : Fast wiper speed

front of the engine compartment on the

driver side.

✽ NOTICE

If there is heavy accumulation of snow

CAUTION

or ice on the windscreen, defrost the

To prevent possible damage to the

windscreen for about

10 minutes, or

washer pump, do not operate the

until the snow and/or ice is removed

washer when the fluid reservoir is

before using the windscreen wipers to

empty.

ensure proper operation.

If you do not remove the snow and/or ice

before using the wiper and washer, it

may damage the wiper and washer sys-

tem.

4 70

Features of your vehicle

Rear Window Wiper and Washer

WARNING

(if equipped)

Do not use the washer in freezing

Turn the switch to desired position to

temperatures without first warming

operate the rear wiper and washer.

the windscreen with the defrosters;

the washer solution could freeze on

- Wash with brief wipes

contact with the windscreen and

obscure your vision.

- Normal wiper operation

0 - Wiper is not in operation

- Spraying washer fluid and wiping

CAUTION

•

To prevent possible damage to

✽ NOTICE

the wipers or windscreen, do not

operate the wipers when the

Do not operate the washer continuously

for more than 15 seconds or when the

windscreen is dry.

fluid reservoir is empty; this could dam-

•

To prevent damage to the wiper

age the system. Do not operate the wiper

blades, do not use petrol,

when the window is dry; this can result

kerosene, paint thinner, or other

in scratching as well as premature wiper

solvents on or near them.

blade wear. For the same reason, do not

•

To prevent damage to the wiper

operate the washer when the washer

arms and other components, do

fluid reservoir is empty.

not attempt to move the wipers

manually.

•

To prevent possible damage to

the wipers and washer system,

use anti-freezing washer fluids in

the winter season or cold weath-

er.

4 71

Features of your vehicle

INTERIOR LIGHT

Type A

CAUTION

• DOOR : In the DOOR position, the light

Do not use the interior lights for

comes on when any door is

extended periods when the engine

opened regardless of the igni-

is not running.

tion switch position. When

It may cause battery discharge.

doors are unlocked by the

transmitter, the light comes on

for approximately 30 seconds

as long as any door is not

WARNING

open. The light goes out grad-

Do not use the interior lights when

ually after approximately

30

driving in the dark. Accidents could

OTQ047060

seconds if the door is closed.

happen because the view may be

Type B

However, if the ignition switch

obscured by interior lights.

is ON or all doors are locked,

the light will turn off immedi-

ately.

If a door is opened with the

ignition switch in the ACC or

LOCK position, the light stays

on for about

20 minutes.

However, if a door is opened

with the ignition switch in the

OTQ047060G

ON position, the light stays on

continuously.

Map lamp (if equipped)

• ROOM : In the ROOM position, the light

•

: Push the switch to turn the

stays on at all times.

map lamp on or off. This light

produces a spot beam for con-

venient use as a map lamp at

night or as a personal lamp for

the driver and the front pas-

senger.

4 72

Features of your vehicle

Type A

➀

: Push the switch to turn the

map lamp on or off. This light

produces a spot beam for

convenient use as a map

lamp at night or as a person-

al lamp for the rear passen-

ger.

➁ DOOR : In the DOOR position, the

/

light comes on when any

OTQ047062

door is opened regardless of

Type B

the ignition switch position.

➂ ROOM : In the ROOM position, the

OTQ047061

/

light stays on at all times.

Room lamp (Rear, if equipped)

•

: Push the switch to turn the

rear room lamp on or off.

CAUTION

Do not leave the switch in this posi-

tion for an extended period of time

when the vehicle is not running.

OTQ047206

Type C

OTQ047201

4 73

Content   ..  6  7  8  9   ..
